2006 CHRYSLER CROSSFIRE check engine light

If your OBD system isnot ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
you may need to do nothing more than drive your
vehicle as you normally would in order for your OBD
system to update. A recheck with the above test routine
may then indicate that the system is now ready.
Regardless of whether your vehicle’s OBD system is
ready or not ready, if the CHECK ENGINE light is
illuminated during normal vehicle operation, you should
have your vehicle serviced before going to the I/M
station. The I/M station can fail your vehicle because the
CHECK ENGINE light is on with the engine running.REPLACEMENT PARTS
Use of genuine Moparparts for normal/scheduled
maintenance and repairs is highly recommended to in-
sure the designed performance. Damage or failures
caused by the use of non-Moparparts for maintenance
and repairs will not be covered by the warranty offered
by DaimlerChrysler Corporation.
DEALER SERVICE
Your dealer has the qualified service personnel, special
tools and equipment to perform all service operations in
an expert manner. Service Manuals are available which
include detailed service information for your Crossfire.
Refer to these manuals before attempting any procedure
yourself.
NOTE:Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
208 MAINTAINING YOUR VEHICLE

Catalytic Converter
The catalytic converter requires the use of unleaded fuel
only. Leaded gasoline will destroy the effectiveness of the
catalyst as an emission control device.
Under normal operating conditions, the catalytic converter
will not require maintenance. However, it is important to
keep the engine properly serviced to assure proper catalyst
operation and prevent possible catalyst damage.
If the CHECK ENGINE light is flashing, immediate
service is required.
CAUTION!
Damage to the catalytic converter can result if your
vehicle is not kept in proper operating condition. In the
event of engine malfunction, particularly involving
engine misfire or other apparent loss of performance,
have your vehicle serviced promptly. Continued opera-
tion of your vehicle with a severe malfunction could
cause the converter to overheat, resulting in possible
damage to the converter and the vehicle.
WARNING!
A hot exhaust system can start a fire if you park over
materials that can burn. Such materials might be
grass or leaves coming into contact with your ex-
haust system. Do not park or operate your vehicle in
areas where your exhaust system can contact any-
thing that can burn.
In unusual situations involving grossly malfunctioning
engine operation, a scorching odor may suggest severe
and abnormal catalyst overheating. If this occurs, stop
the vehicle, turn off the engine and allow it to cool.
Service, including a tune up to DaimlerChrysler Corpo-
ration’s specifications, should be obtained immediately.
To minimize the possibility of catalyst damage:
•Do not shut off the engine or interrupt the ignition
when the transmission is in gear and the vehicle is in
motion.
•Do not try to start the engine by pushing or towing the
vehicle.
214 MAINTAINING YOUR VEHICLE

Windshield Washer Reservoir
The washer fluid reservoir is located in the engine
compartment and should be checked for fluid level at
regular intervals. Fill the reservoir with windshield
washer solvent (not radiator antifreeze) rated not to
freeze at -25°F (-31°C). Operate the system for a few
seconds to flush out the residual water.WARNING!
Do not overfill the washer reservoir. Do not attempt
to fill to the top of the filler neck. Fluid may leak out
onto the floor or driveway causing a potential slip
and fall hazard. When the indicator light first illu-
minates, the maximum fill amount is 1 gallon or 4
liters.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
220 MAINTAINING YOUR VEHICLE

Your Flexible Service System (FSS) — see Understanding
Your Instrument Panel section — should give you an
exact indication of when your vehicle should be sched-
uled for service and which schedule to follow.
Additional Periodic Maintenanceitems should also be
performed beyond the items listed in the following charts
to assure the optimum performance of your Crossfire.
SCOPE OF WORK FOR “A” SCHEDULE
MAINTENANCE SERVICE
Oil Change
•Change oil and replace filter
Maintenance
•Lubricate hood hinges, latch, and secondary latch
•Reset FSS Display
Function Check
•Horn, hazard warning flashers, turn signals, and indi-
cator lamps
•Headlamps and exterior lighting
•Windshield wipers and washer system
Inspection
•Check front and rear brake pads for lining thickness
•Check tires for damage and general condition
•Check tire inflation pressures and correct if necessary
Fluid Levels
Check fluid levels for the following systems and correct if
necessary. Should there be a loss of fluid that cannot be
explained by regular use, trace and eliminate the cause.
•Engine cooling system (check corrosion inhibitor/
antifreeze)
•Hydraulic brake system
•Power steering system
•Windshield washer system
258 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Fluid Levels
Check fluid levels for the following systems and correct if
necessary. Should there be a loss of fluid that cannot be
explained by regular use, trace and eliminate the cause.
•Engine cooling system (check corrosion inhibitor/
antifreeze)
•Hydraulic brake system
•Power steering system
•Windshield washer system
FSS SYSTEM
The Flexible Service System (FSS) permits a flexible service
schedule that is directly related to the operating conditions
of the vehicle. See the Understanding Your Instrument
Panel section for details on how to use the FSS.
The oil change interval for your Crossfire is initially set at
7,000 miles (Canada: 11,000 km). Very light duty driving
cycles (most trips more than 10 miles [16 km] at moderate
speeds in moderate temperature conditions) can extend
the service interval beyond 7,000 miles (Canada: 11,000km). IfANYof the following apply to your driving, the
oil change interval can be reduced significantly:
Day or night temperatures are below 32°F (0°C).
Stop and go driving.
Extensive engine idling.
Driving in dusty conditions.
Short trips of less than 10 miles (16 km).
More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
There are two symbols which will appear in the main
odometer display field prior to the next suggested service.
This symbol represents Service A.
This second symbol represents Service B. Ser-
vice B rotates with Service A and includes
additional service tasks.
260 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

At Each Stop for Fuel
•
Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. See the procedure de-
scribed in Checking Your Engine Oil in the Under-
standing Your Instrument Panel section or under
Engine Oil in the Maintaining Your Vehicle section.
Add oil only when the level is at or below the ADD or
MIN mark.
•Check the windshield washer solvent and add if
required.
•Inspect wiper blade condition.
•Check operation of lighting systems.
•Inspect tires for unusual wear, damage, and pressure
(at least every 14 days).
•Mechanical assemblies (e.g., engine, transmission, etc.)
- check for leaks.
Once a Month
•
Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder and power steering and add as
needed.
•Check all lights and all other electrical items for correct
operation.
Additional Periodic Maintenance
The following maintenance items should be performed
during the scheduled maintenance nearest the time
elapsed and/or distance shown. Follow the interval that
occurs first.
Every 2 years:
•Inspect body for paint damage.
•Check chassis and supporting body parts for damage
and corrosion.
262 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

ABS (Anti-Lock Brake) System............. 111
Adding Engine Coolant (Antifreeze)......... 223
Adding Fuel.......................... 173
Aiming Headlights...................... 246
Air Cleaner, Engine (Engine Air Cleaner Filter) . 213
Air Conditioning....................128,216
Air Conditioning Filter................... 264
Air Conditioning Refrigerant.............. 216
Air Conditioning System................. 216
Air Pressure, Tires...................... 160
Airbag................................ 29
Airbag Deployment...................... 33
Airbag Light........................32,116
Airbag Maintenance...................... 39
Airbag On/Off Switch..................37,41
Alignment and Balance.................. 165
Antenna.............................. 127
Antifreeze (Engine Coolant)............... 251
Anti-Lock Warning Light................. 111
Appearance Care....................... 230
Ashtrays and Lighter..................... 64
Automatic Door Locks.................... 13
Automatic Transmission...............141,228Fluid and Filter Changes................ 228
Fluid Level Check..................... 228
Fluid Type.......................... 228
Special Additives..................... 229
Autostick............................. 145
Ball Joints............................ 218
Battery............................ 112,215
Saving Feature (Protection)............... 75
Belts, Drive........................... 213
Belts, Seat............................. 22
Body Mechanism Lubrication.............. 218
Brake Assist System...................... 89
Brake, Parking......................... 148
Brake System.......................150,225
Anti-Lock........................... 150
Hoses.............................. 226
Master Cylinder...................... 227
Break-In Recommendations, New Vehicle . . . 47,158
Bulbs, Light........................... 243
Capacities, Fluid....................... 249
Capacity, Cargo Weight.................. 175
282 INDEX

Disposal
Engine Oil.......................... 212
Door Locks, Automatic................... 13
Drive Belts............................ 213
Drive Shaft Universal Joints............... 218
Driving
On Slippery Surfaces.................. 189
Electronic Speed Control.................. 94
Electronic Stability Program................ 91
Emergency, In Case of
Hazard Warning Flasher................ 178
Jump Starting........................ 187
Overheating......................... 178
Towing............................. 191
Emergency Trunk Release................. 19
Emission Control System Maintenance....207,257
Engine
Break-In Recommendations............... 47
Checking Oil Level.................... 209
Compartment........................ 205
Oil .............................209,251
Oil Change Interval................... 211Oil Selection......................... 212
Exhaust Gas Caution..................... 47
Exhaust System........................ 221
Exterior Lights......................... 243
Filters
Air Cleaner.......................... 213
Air Conditioning..................... 264
Engine Fuel......................... 213
Engine Oil.......................... 212
Fluid Capacities.....................249,251
Fluid Leaks............................ 48
Fluid Level Checks
Manual Transmission.................. 229
Fluids, Lubricants and Genuine Parts........ 252
Four-Way Hazard Flasher................. 178
Freeing A Stuck Vehicle.................. 190
Fuel................................. 171
Adding............................. 173
Additives........................... 172
Filler Cap........................... 173
Filter.............................. 213
Octane Rating........................ 171
284 INDEX
