DIC Controls and Displays
When the ignition is turned to ON or START, the DIC
will display the following:
BUICK:BUICK will be displayed for three seconds.
DRIVER #:This message will be displayed for another
three seconds after BUICK appears in the display.
This display lets the driver know which driver’s remote
keyless entry transmitter is being used and the
driver’s customization features.
The DIC controls are
located to the left of the
steering column on
the instrument panel.
The DIC will be in the last mode displayed when the
engine was turned off. To select a different mode, press
MODE. The display will cycle through its options at
each press of MODE.MODE:This button lets you cycle through the options
on the display.
SET:This button is used to select and set the options
to your preference.
The DIC will always display the compass reading and
the outside temperature. If the temperature is below
38°F (3°C), the temperature reading will toggle between
displaying the temperature and the word ICE for
two minutes.
AVG ECONOMY (Average Economy):Average fuel
economy is viewed as a long term approximation of your
overall driving conditions. To learn the average fuel
economy from a new starting point, press and hold
the SET button while the average fuel economy
is displayed on the DIC. The average fuel economy will
set to zero.
INST ECONOMY (Instant Economy):Instant fuel
economy re ects the fuel economy that the vehicle
has right now. Instant fuel economy varies with
your driving conditions, such as acceleration, braking
and the grade of the road being traveled. Unlike average
fuel economy, instant fuel economy cannot be reset.
3-62
DIC Vehicle Personalization
The DIC is used to program the choices of two drivers.
The drivers are recognized as DRIVER 1 or DRIVER 2
in the DIC display. You will let the DIC know which driver
you are by using your remote keyless entry transmitter.
Each remote keyless entry transmitter was
pre-programmed to belong to DRIVER 1 or DRIVER 2.
Each transmitter may be programmed differently for
each driver’s preferences (lights, doors, horn or activate
the programmed radio stations for driver 1 or driver 2)
using your remote keyless entry transmitter.
After you press the LOCK button on your transmitter
and the ignition key is in ON, the DIC will display
the identi ed driver number. The vehicle will also recall
the vehicle customization features that were last
programmed to correspond to your transmitter.
If you unlock your vehicle using your key instead of
your transmitter, the DIC will not change drivers
and your vehicle will recall the information from the
last transmitter used.
If your vehicle does not have a DIC, you do not have
available the vehicle customization features using
the remote keyless entry transmitter.
Entering Programming Mode
To program features, your vehicle must be in the
programming mode. Do the following:
1. Turn the ignition key to ON with the vehicle in
PARK (P).
2. Press and release the MODE button,
scrolling through the DIC messages, until
PERSONALIZATION PRESS SET TO BEGIN
is displayed.
3. Press the SET button and TO SELECT DRIVER
PRESS REMOTE LOCK will appear. Press the
LOCK button on the remote keyless entry
transmitter. This identi es which remote keyless
entry transmitter is being programmed by
displaying PERSONALIZATION FOR DRIVER 1
or DRIVER 2.
3-64
Interior Lighting Delay
The interior lighting delay feature can be programmed to
one of the following modes:
OFF:This feature will not illuminate the interior of your
vehicle when all of the doors are closed.
ON:This feature will continue to illuminate the interior
lamps for 25 seconds after all doors have been
closed so that you can nd your ignition and buckle
your safety belt at night.
Interior lighting delay will not occur while the ignition is
in ON. After 25 seconds, the interior lamps will fade
out. The lamps will fade out before the 25 seconds if
one of the following occurs:
The ignition is turned to ON
All doors are locked using the remote keyless entry
transmitter
There is no occupant activity detected for an
illumination period of 25 secondsYour vehicle was originally programmed to ON. The
mode may have been changed since then. To determine
the current mode, or to change the mode, do the
following:
1. Follow the instructions for “Entering Programming
Mode” listed previously.
2. Press the MODE button until INTERIOR LIGHTING
DELAY appears on the DIC.
3. Press the SET button until the arrow is before
ON or OFF.
The mode you selected is now set. You can either
exit programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
3-66
Interior Lighting On
The interior lighting on feature can be programmed to
one of the following modes:
KEY OUT:The interior lamps will come on for about
25 seconds whenever you remove the key from
the ignition.
DOOR:The interior lamps will come on for about
25 seconds when any door is opened.
Interior lighting on will not occur while the ignition is
in ON. After 25 seconds, the interior lamps will fade out.
The lamps will fade out before the 25 seconds if one
of the following occurs:
The ignition is turned to ON
LOCK is pressed on the remote keyless entry
transmitter
There is no occupant activity detected for an
illumination period of 25 secondsYour vehicle was originally programmed to DOOR.
The mode may have been changed since then.
To determine the current mode, or to change the
mode, do the following:
1. Follow the instructions for “Entering Programming
Mode” listed previously.
2. Press the MODE button until INTERIOR LIGHTING
ON appears on the DIC.
3. Press the SET button until the arrow is before
KEY OUT or DOOR.
The mode you selected is now set. You can either
exit programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
3-67
Delayed Locking
The delayed locking feature can be programmed to
one of the following modes:
ON:Lock your vehicle using the power door lock switch
or the remote keyless entry transmitter while any door
is opened, you will hear three chimes and the doors will
not lock. Five seconds after the last door is closed,
all doors will lock.
Once delayed locking is programmed to ON, you can do
the following:
Cancel the delayed locking by pressing unlock
using the power door lock switch or by fully inserting
the key in the ignition
Override the delayed locking feature by pressing lock
immediately using the power door lock switch
Let the delayed locking feature complete the locking
of the vehicleOFF:The doors will always lock immediately when you
lock the doors using the power door lock switch or
press LOCK on the remote keyless entry transmitter.
Your vehicle was originally programmed to ON.
The mode may have been changed since then.
To determine the current mode, or to change the mode,
do the following:
1. Follow the instructions for “Entering Programming
Mode” listed previously.
2. Press the MODE button until DELAYED LOCKING
appears on the DIC.
3. Press the SET button until the arrow is before
ON or OFF.
The mode you selected is now set. You can either
exit programming mode by following the instructions
later in this section or program the next feature available
on your vehicle.
3-69
