Engine electronicsGeneral warning light
lights up yellow.
Engine electronics sym-
bol appears on the dis-
play.
The engine is running
in emergency operating
mode. Engine power might
be reduced and this can
cause hazardous situations,
particularly if you attempt to
overtake other road users.
Engine power level might be
lower than normal: adapt your
style of riding accordingly.
The engine electronics control
unit has diagnosed a fault. In
exceptional cases, the engine
stops and refuses to start.
Otherwise, the engine runs in
emergency operating mode.
You can continue to ride,
but bear in mind that the usual engine power might
not be available.
Have the fault rectified as
quickly as possible by a
specialist workshop, prefer-
ably an authorised BMW
Motorrad dealer.
Insufficient engine oil
pressure General warning light
flashes red.
Engine oil pressure sym-
bol appears on the dis-
play.
The oil pressure in the lube-
oil system is too low. Stop
immediately and switch off
the engine if the warning light
shows.
The insufficient oil
pressure warning does
not fulfil the function of an
oil gauge. The only way of
checking whether the oil level is correct is to check the oil
level indicator.
A low oil level is one reason
why a warning indicating in-
sufficient oil pressure is is-
sued.
Checking engine oil level
( 89)
If the oil level is too low: Top up the engine oil ( 90)
If the warning indicating in-
sufficient engine oil level is
issued and a check indicates
that the engine oil level is cor-
rect: Other engine problems
besides a low oil level
can cause the insufficient en-
gine oil pressure warning to
be issued. Continuing to ride
in these cases can cause en-
gine damage.
If this warning is issued even
though the engine oil level is
325zStatus indicators
ponents are not designed to
withstand. Damage caused in
this way is not covered by the
warranty.
Do not tamper with the
control unit of the electronic
engine-management
system.ChecklistUse the following checklist
to check important functions,
settings and wear limits be-
fore you ride off.Brakes
Brake-fluid levels, front and
rear
Clutch
Clutch fluid level
Shock absorber setting and
spring preload
Tyre-tread depth and tyre
pressures Cases correctly installed
and luggage secured
At regular intervals: Engine oil level (every refuel-
ling stop)
Brake-pad wear (every third
refuelling stop)
StartingSide standYou cannot start the motor-
cycle with the side stand ex-
tended and a gear engaged.
The engine will switch itself off
if you start it with the gearbox
in neutral and then engage a
gear before retracting the side
stand.GearboxYou can start the engine
when the gearbox is in neutral
or if you pull the clutch with
a gear engaged. Do not pull
the clutch until after you have switched on the ignition, as
otherwise the engine will
refuse to start. When the
gearbox is in neutral, the
green neutral telltale light is
on and the gear indicator
in the multifunction display
shows N.
Start the engineKill switch
1in run posi-
tion A.
Switch on the ignition.
Pre-ride check is
performed. ( 67)
ABS self-diagnosis is per-
formed. ( 67)
566zRiding
Press starter button1.
If ambient temperatures
are very low, you might
find it necessary to open the
throttle slightly when starting
the engine. At ambient tem-
peratures below 0 °C, disen-
gage the clutch after switch-
ing on the ignition.
The start attempt is
automatically interrupted
if battery voltage is too low.
Recharge the battery before
you start the engine, or use
jump leads and a donor
battery to start. The engine starts.
Consult the troubleshooting
chart below if the engine
refuses to start. ( 132)
Pre-ride checkThe instrument cluster runs
a test of the 'General' warn-
ing light when the ignition
is switched on. The warn-
ing light shows first red and
then yellow, so that you can
check that it is in working or-
der. This pre-ride check is in-
dicated by the word
CHECK!
appearing in the display. The
test is aborted if you start the
engine before it completes.
Phase 1
General warning light
lights up red.
The
CHECK!
reminder ap-
pears on the display. Phase 2
General warning light
lights up yellow.
The
CHECK!
reminder ap-
pears on the display.
If the 'General' warning light is
not displayed:
Some malfunctions can-
not be indicated if the
'General' warning light cannot
be displayed.
Check that the 'General'
warning light comes on, and
that it lights up yellow and
then red.
Have the fault rectified as
quickly as possible by a
specialist workshop, prefer-
ably an authorised BMW
Motorrad dealer.
ABS self-diagnosisBMW Motorrad Integral ABS
performs self-diagnosis to
ensure its operability. Self-
567zRiding
Tyre pressures
Tyre pressure, front2.5 bar, One-up, tyre cold
2.5 bar, Two-up and/or with luggage, tyre
cold
Tyre pressure, rear 2.9 bar, One-up, tyre cold
2.9 bar, Two-up and/or with luggage, tyre
coldElectricsOn-board socket, rating 5 A
Fuses All circuits are electronically protected, so
plug-in fuses are no longer necessary. If an
electronic fuse trips and de-energises a cir-
cuit, the circuit is active as soon as the igni-
tion is switched on after the fault has been
rectified.
Type
Type, battery AGM (Absorptive Glass Mat) battery
Technical data
Battery rated voltage 12 V
Battery rated capacity 14 Ah
9141zTechnical data
Topping up, 90
Warning, engine oil level, 26
Warning, engine oil pres-
sure, 25
ESA, 59 Adjust spring preload, 60
Adjust suspension damp-
ing, 59
Call up settings, 59
EWS Warning, 24
F
Final drive Technical data, 139
Frame Technical data, 143
Front-wheel stand Installing, 106
Fuel Quantity reading, 20
Refuelling, 71
Technical data, 135
Warning, fuel down to
reserve, 24
Fuses, 141 G
Gear indicator, 20
Grip heating, 16, 48
H
Handlebar fittings
General view, left side, 15
General view, right side, 16
Hazard warning flashers, 15, 16
Switching off, 41
Switching on, 40
Headlight Adjusting headlight beam
throw, 51
High-beam headlight, 18
Low-beam headlight, 18
Side lights, 18
Headlight flasher, 15
High-beam headlight, 15
Horn, 15
I
Ignition Switching off, 38
Switching on, 38 Immobiliser
Warning, 24
Instrument cluster Overview, 17
Sensor for lighting, 17
J
Jump start, 118
L
Laying up, 128
Lights Switch on the high-beam
headlight, 50
Switching off parking
lights, 51
Switching on parking
lights, 51
Switching on the low-beam
headlight, 50
Switching on the side
lights, 50
11157zIndex
