2006 BMW MOTORRAD K 1200 GT suspension

Spring preload.......... 69
Shock absorbers . . . . . . . . 70
Electronic Suspension
Adjustment ESA
OE
....... 71
Tyres . . ................. 73
5 Riding . . . . . . .......... 75
Safety instructions . . . . . . . 76
Checklist . . . . . . .......... 78
Starting ................. 78
Running in . . . . .......... 81
Parking your
motorcycle . . . . .......... 82
Refuelling . . . . . .......... 83
Tyre pressure control
RDC
OE
.................. 85
Brake system, general . . . 85
Brake system with BMW
Motorrad Integral ABS . . . 86
Electronic engine
management with BMW
Motorrad ASC
OE
......... 90
6 Accessories .......... 93
General instructions . . . . . 94
Power socket . .......... 94
Luggage . . . . . . .......... 95 Case . . .
................. 95
Topcase
OA
.............. 98
7 Maintenance . . . ..... 101
General instructions . . . . 102
Toolkit . ................ 102
Engine oil . . . . . ......... 103
Brake system,
general ................ 105
Brake pads . . . . ......... 105
Brake fluid . . . . ......... 107
Clutch . ................ 109
Tyres . . ................ 109
Rims . . . ................ 110
Wheels . ................ 110
Front-wheel stand . ..... 117
Bulbs . . ................ 119
Jump start . . . . ......... 127
Battery . ................ 128
8 Care . ................ 133
Care products . ......... 134
Washing motorcycle . . . . 134
Cleaning easily damaged
components . . . ......... 135
Paint care . . . . . ......... 136 Protective wax
coating
................ 136
Laying up the
motorcycle . . . . ......... 136
Restoring motorcycle to
use .................... 137
9 Technical data . . ..... 139
Troubleshooting
chart . . . ................ 140
Threaded fasteners ..... 141
Engine . ................ 142
Riding specifications . . . . 145
Clutch . ................ 145
Transmission . . ......... 145
Final drive . . . . . ......... 147
Running gear . . ......... 147
Brakes . ................ 148
Wheels and tyres . . ..... 148
Electrics . . . . . . ......... 149
Frame . . ................ 151
Dimensions . . . ......... 151
Weights ................ 152

ESA Electronic SuspensionAdjustment
Electronic Suspension
Adjustment.
DWA Anti-theft alarm (Diebs-
tahlwarnanlage)
ABS Anti-lock brake system
RDC Tyre pressure control
(ReifenDruck-Control)
ASC Automatic Stability Control.EquipmentWhen you ordered your BMW
motorcycle, you chose vari-
ous items of custom equip-
ment. This Rider's Manual
describes optional extras (OE)
offered by BMW and selec-
ted optional accessories (OA).
This explains why the manual
may also contain descriptions of equipment which you have
not ordered. Please note, too,
that your motorcycle might
not be exactly as illustrated
in this manual on account of
country-specific differences.
If your BMW was supplied
with equipment not described
in this Rider's Manual, you will
find these features described
in separate manuals.
Technical dataAll dimensions, weights and
power ratings stated in the
Rider's Manual are quoted
to the standards and comply
with the tolerance require-
ments of the Deutsche Institut
für Normung e.V. (DIN). Ver-
sions for individual countries
may differ.
CurrencyThe high safety and quality
standards of BMW motor-
cycles are maintained by con-
stant development work on
designs, equipment and ac-
cessories. Because of this,
your motorcycle may differ
from the information supplied
in the Rider's Manual. Nor
can errors and omissions be
entirely ruled out. We hope
you will appreciate that no
claims can be entertained on
the basis of the data, illustra-
tions or descriptions in this
manual.
17zGeneral instructions

Operation
Ignition switch and steering
lock . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Electronic immobiliser . . . . . . . . . 44
Hazard warning flashers . . . . . . . 45
Odometer and tripmeters . . . . . . 46
Multifunction display . . . . . . . . . . . 47
Clock . . . . . . . . . . . . . . . . . . . . . . . . . 47
Tyre pressure control RDC
OE
.. 48
Residual range . . . . . . . . . . . . . . . . 49
On-board computer
OE
......... 49
Cruise-control systemOE
....... 53
Emergency off switch (kill
switch) . . . . . . . . . . . . . . . . . . . . . . . . 55
Grip heating
OE
................ 56
Seat heating
OE
................ 57
Clutch . . . . . . . . . . . . . . . . . . . . . . . . 58 Brakes . . . . . . . . . . . . . . . . . . . . . . . . 59
Handlebars . . . . . . . . . . . . . . . . . . . 59
Lights . . . . . . . . . . . . . . . . . . . . . . . . . 60
Headlight . . . . . . . . . . . . . . . . . . . . . 61
Turn indicators . . . . . . . . . . . . . . . . 62
Stowage compartment . . . . . . . . 63
Automatic Stability Control
ASC
OE
........................ 64
Front and rear seats . . . . . . . . . . . 65
Helmet holder . . . . . . . . . . . . . . . . . 68
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . 68
Windscreen . . . . . . . . . . . . . . . . . . . 69
Spring preload . . . . . . . . . . . . . . . . 69
Shock absorbers . . . . . . . . . . . . . . 70
Electronic Suspension
Adjustment ESA
OE
............ 71
441zOperation

ing screw1in the direction
indicated by the H arrow.
If you want a softer damp-
ing characteristic, use a
screwdriver to turn adjust-
ing screw 1in the direction
indicated by the S arrow.
The adjusting screw can
be turned through three
and a half turns.
Rear suspension
damping, basic setting
Turn the adjusting screw
as far as it will go in the
direction indicated by the
H arrow and then turn it
back one and a half turns
in the direction indicated
by the S arrow. (One-up
85 kg)
Electronic Suspension
Adjustment ESA
OE
SettingsElectronic Suspension Ad-
justment ESA provides a con-
venient way of adapting the
motorcycle to different condi-
tions. Three spring preload
settings can be combined
with three damping charac-
teristics to fine-tune the mo-
torcycle's suspension to the
load it carries and the surface
over which you want to ride.
The damping characteristic is
shown in panel 1of the mul- tifunction display, and spring
preload in panel
2.
Call up settingsSwitch on the ignition.
Press button 1.
The current setting is dis-
played.
The reading remains visible
for a few seconds before
disappearing automatically.Adjust suspension
dampingSwitch on the ignition.
471zOperation

When removing the right
brake caliper, take care not
to alter the routing of the
sensor cable of the brake-
pad wear detector.
Raise the front of the mo-
torcycle until the front wheel
can rotate freely. BMW Mo-
torrad recommends the
BMW Motorrad front wheel
stand for lifting the motor-
cycle.
Fit the front-wheel stand
( 118)
Remove right-hand axle
clamping screw5. The left axle clamping
screw locates the
threaded bush in the front
suspension. If the threaded
bush is not correctly aligned
the gap between the ABS
sensor ring and the ABS
sensor will not be correct and
this can cause the ABS to
malfunction or allow the ABS
sensor to be damaged.
In order to ensure that the
threaded bush remains cor-
rectly aligned, do not slacken
or remove the left axle camp-
ing screw.
Remove quick-release
axle 6, while supporting the
wheel.
Lower the front wheel to the
ground between the front
forks.
Take care not to damage
the ABS sensor when
rolling out the front wheel. Note the ABS sensor when
rolling out the front wheel.
Roll the front wheel forward
to remove.
Installing front wheel
ABS malfunctions on ac-
count of incorrect speed
signal.
Segmentation differs between
individual types of sensor
ring; it is very important to en-
sure that the correct sensor
ring is installed. Install only
the sensor ring that matches
the motorcycle's construction
status.
Threaded fasteners not
tightened to the spe-
cified torque can work loose
or their threads can suffer
damage.
Always have the security of
the fasteners checked by a
specialist workshop, prefer-
7112zMaintenance

front wheel with the BMW
Motorrad front-wheel stand.Fit the front-wheel standPlace the motorcycle on
centre stand ( 83)
Slacken adjusting screws1.
Push the two pins 2apart
until the front suspension
fits between them.
Use locating pins 3to set
the front wheel stand to the
desired height.
Centre the front wheel stand
relative to the front wheel and push it against the front
axle.
Push both mounting pins
2
through the triangles of the
brake caliper anchorages
just far enough to allow
the front wheel to be rolled
between them.
There is a risk of dam-
aging the ABS sensor
ring of the BMW Integral ABS.
Push the pin in just far
enough to ensure that it
clears the sensor ring of the
BMW Integral ABS. Tighten adjusting screws
1.
If the motorcycle is
raised too far the centre
stand will lift clear of the
ground and the motorcycle
could topple to one side.
When raising the motorcycle,
make sure that the centre
stand remains on the
ground.
Apply uniform pressure to
push the front wheel stand
down and raise the motor-
cycle.
7118zMaintenance

Final driveFinal drive, typeShaft drive with bevel gears
Final drive gear ratio 2.82Running gearFront suspensionDouble leading link
Front suspension - total suspension travel 115 mm, Static 125 mm, Dynamic
Rear suspension type Central spring strut pivoted to lever system
with coil spring and single-tube gas-filled
shock absorber; spring preload steplessly
hydraulically adjustable, rebound stage
damping steplessly adjustable.
with OE Electronic Suspension Adjust-
ment (ESA): Central spring strut pivoted to lever system
with coil spring and single-tube gas-filled
shock absorber; spring basic setting three-
way adjustable, compression and rebound
stages each three-way adjustable
Rear suspension, total suspension travel 135 mm, at wheel
9147zTechnical data

Cruise-control system, 16Deactivating, 54
Resuming cruising
speed, 55
Set road speed, 53
Step-by-step accelera-
tion, 53
Step-by-step decelera-
tion, 54
Stepless acceleration, 54
Stepless deceleration, 54
Switching off, 55
Switching on, 53
Telltale light, 23
D
Dimensions Technical data, 151
E
Electrics Technical data, 149
Emergency off switch (kill switch), 17, 55 Engine
Starting, 78
Technical data, 142
Temperature gauge, 23
Warning, engine electron-
ics, 28
Engine oil Checking level, 103
Filler neck, 15
Oil dipstick, 15
Technical data, 144
Topping up, 105
Warning, engine oil level, 29
Warning, engine oil pres-
sure, 28
ESA, 16, 71 Adjust spring preload, 72
Adjust suspension damp-
ing, 71
Call up settings, 71
EWS Warning, 27 F
Final drive
Technical data, 147
Frame Technical data, 151
Front seat Adjusting, 15, 66
Heating, 17, 57
Installation, 66
Removal, 65
Front-wheel stand Installing, 118
Fuel Quantity reading, 23
Refuelling, 83
Technical data, 143
Warning, fuel down to
reserve, 27
Fuses, 149
G
Gear indicator, 23
Grip heating, 17, 56
11165zIndex
