2006 Acura TSX display

With your phone on and the
ignition in the ACCESSORY (I) or
ON (II) position, press and release
the Talk button. After the beep,
say ‘‘Phone set up.’’ The HFL
response is ‘‘Phone set up options
are status, pair, edit, delete, and
list.’’
Press and release the Talk button.
Af ter the beep, say ‘‘Pair.’’ The
HFL response is ‘‘The pairing
process requires operation of your
mobile phone. For saf ety, only
perf orm this f unction while the
vehicle is stopped. State a f our-
digit code f or pairing. Note this
code. It will be requested by the
phone.’’
Press and release the Talk button.
Af ter the beep, say the f our-digit
code you want to use. For example,
say‘‘1,2,3,4.’’TheHFLresponse
is,‘‘1,2,3,4.Isthiscorrect?’’Press and release the Talk button.
After the beep, say the name you
want to use. For example, say
‘‘Eric’s phone.’’ The HFL response
is ‘‘Eric’s phone has been
successf ully paired. Returning to
the main menu.’’
If you want to pair another phone,
repeat steps 1 through 7.
Steps 5 and 6 show a
common way to get your phone into
its Discovery mode. If these steps do
not work on your phone, ref er to the
phone’s operating manual.
Follow the prompts on your phone
togetitintoitsDiscoverymode.
The phone will search f or the HFL.
When it comes up, select
HandsFreeLink f rom the list of
options displayed on your phone.
When asked by the phone, enter
the four-digit code from step 3 into
your phone. The HFL response is
‘‘A new phone has been f ound.
What would you like to name this
phone?’’ Press and release the Talk button.
Af ter the beep, say ‘‘Yes.’’ The
HFL response is ‘‘Searching f or a
Bluetooth phone. Make sure the
phone you are trying to pair is in
Discovery mode.’’
1.
4.
5.
6.7.
2.
3. 8.
CONT INUED
HandsFreeL ink
Features
217
NOTE:
TM
——y
y
(yy

Stop f illing the tank af ter the f uel
nozzle automatically clicks of f . Do
not try to ‘‘top off’’ the tank. Leave
some room f or the f uel to expand
with temperature changes.
even though the tank is not f ull,
there may be a problem with your
vehicle’s fuel vapor recovery
system. The system helps keep
f uel vapors f rom going into the
atmosphere. Try f illing at another
pump. If this does not f ix the
problem, consult your dealer.To Open the Hood:
Park the vehicle, and set the
parking brake. Pull the hood
release handle located under the
lower lef t corner of the dashboard.
The hood will pop up slightly.
Screw the fuel fill cap back on
until it clicks at least once. If you
do not properly tighten the cap,
the malf unction indicator lamp
maycomeon(seepage ).You
will also see a ‘‘TIGHTEN FUEL
CAP’’ message in the inf ormation
display.
Push the f uel f ill door closed until
it latches.
1.
6.
4.
5.
324
If the f uel nozzle keeps clicking of f
Service Station Procedure
Opening and Closing the Hood
230
HOOD RELEASE HANDLE
——yy
(yy

Always drive in the highest gear
possible.
Try to maintain a constant speed.
Everytimeyouslowdownand
speed up, your vehicle uses extra
f uel. Use cruise control when
appropriate.
Combine several short trips into
one.
The air conditioning puts an extra
load on the engine which makes it
usemorefuel.Usethefresh-air
ventilation when possible.
Always maintain your vehicle
according to the maintenance
messages given by the multi-
inf ormation display. See
on page
.
an underinf lated tire
causes more ‘‘rolling resistance,’’
which uses more f uel.
The build-up of snow or mud on
your vehicle’s underside adds
weight and rolling resistance.
Frequent cleaning helps your f uel
mileage and reduces the chance of
corrosion.
Drive moderately. Rapid
acceleration, abrupt cornering,
and hard braking use more f uel. 273
For example,
Improving Fuel Economy
Owner’s
Maintenance Checks
Fuel Economy
Bef ore Driving
233
——y
y
(yy

Youshoulddothefollowingchecks
and adjustments bef ore you drive
your vehicle.Make sure all windows, mirrors,
and outside lights are clean and
unobstructed. Remove f rost, snow,
or ice.
Make sure the doors are securely
closed and locked.
Fasten your seat belt. Check that
your passengers have f astened
their seat belts (see page ). Check the steering wheel
adjustment (see page ).
Check that the hood is f ully closed.
Check that the trunk is f ully
closed.
Visually check the tires. If a tire
looks low, use a gauge to check its
pressure.
Check that any items you may be
carrying are stored properly or
f astened down securely. Check the adjustment of the
inside and outside mirrors (see
pages and ).
When you start the engine, check
the gauges and indicators in the
instrument panel and the
messages in the multi-inf ormation
display (see pages and ).
Check the seat adjustment (see
pages and ).
3. 2. 1.
4.
5. 6.
7.
8.
9.
11.
10. 17
145 146
124 61 76
139
138
Preparing to Drive
240
——yy
(yy

The ‘‘D’’ indicator comes on f or a
f ew seconds when you turn the
ignition switch to the ON (II)
position. If it f lashes while driving (in
any shif t position), it indicates a
possible problem in the transmission.If the malf unction indicator lamp
comes on along with the ‘‘D’’
indicator, there is a problem in the
automatic transmission control
system. Avoid rapid acceleration, and
have the transmission checked by
your dealer as soon as possible.
These indicators in the tachometer
show which position the shif t lever is
in. When the ‘‘D’’ indicator warns of a
possible problem with the
transmission, you will see a ‘‘CHECK
TRANSMISSION’’ message in the
multi-inf ormation display (see page
). To shif t f rom any position, move the
shiftlever.Youcannotshiftoutof
Park when the ignition switch is in
the LOCK (0) or the ACCESSORY
(I) position.
82
Automatic Transmission
Shif t L ever Position Indicators
Shif ting
244
SHIFT LEVER
——yy
(yy

µ
µ
When you move the shif t lever f rom
‘‘D’’ to ‘‘M’’ position, the display
shows the selected gear.
In Sequential SportShif t mode, each
time you push f orward on the shif t
lever, the transmission shif ts to a
higher gear. Pull back on the lever to
downshif t. The number of the gear
selected is displayed on the
instrument panel.
With
the shif t lever in ‘‘D’’ position, you
can select the Sequential SportShif t
Mode to shif t gears; much like a
manual transmission, but without a
clutch pedal.
To enter the Sequential SportShif t
mode, move the shif t lever f urther to
the driver’s side. To return to ‘‘D,’’
move the shift lever to the
passenger’s side.
This position is similar
to D, except only the first three
gears are selected instead of all f ive.
Use D when towing a trailer in hilly
terrain, or to provide engine braking
when going down a steep hill. D can
also keep the transmission f rom
cycling between third and f ourth
gears in stop-and-go driving.
3
3
Automatic Transmission
Sequential SportShif t ModeDrive (D )3
246
SELECTED GEAR
——yy
(yy

à
à
൵
ൠµ
ൠµ
CONT INUED
If the vehicle speed slows to below
the redline of the selected lower gear
position while the indicator is
f lashing, the transmission will
downshif t and the display will show
the selected lower gear. If you try to manually downshif t at a
speed that would cause the engine to
exceed the redline in a lower gear,
the transmission will not downshif t.
Thegearindicatorwillflashthe
numberof thelowergearseveral
times, then return to the higher gear. The transmission will also shif t
automatically as the vehicle comes to
a complete stop. It will downshif t to
f irst gear when the vehicle speed is
under 6 mph (10 km/h). Downshif ting gives you more power
when climbing, and provides engine
brakingwhengoingdownasteephill.
The transmission may automatically
downshif t f rom the higher gear to
the lower gear under the f ollowing
conditions:
The vehicle speeds drops below5 4:33mph(52km/h)
4 3:20mph(32km/h)
If you drive uphill between 54:4533mph
(72 52 km/h)
43:3320mph
(52 32 km/h)
32:2010mph
(32 16 km/h)
If you press the brake pedal as you
drive downhill.
When you accelerate away f rom a
stop, the transmission will be in f irst
gear. The transmission will not
automatically upshift. Watch the
tachometer and upshif t manually
bef ore the engine reaches redline.
The transmission remains in the
selectedgear(5,4,3,2,or1).There
is no automatic downshif t when you
push the accelerator pedal to the
f loor.
Automatic Transmission
Driving
247
Up shift
Down shift
——yy
(yy

à
à
à
à
à
à
à
à When you are in Sequential
SportShif t mode, and the vehicle is
stopped, push f orward on the shif t
lever to shif t to second gear. You will
see ‘‘2’’ in the display. Starting out in
second gear will help to reduce
wheelspin in deep snow or on a
slippery surf ace.
If you start out in second gear, the
transmission will be f ixed in that
gear.
The transmission will not
automatically downshif t to f irst gear
even when the vehicle speed is
under 6 mph (10 km/h). You need to
shif t down to f irst gear manually.
To shift from
21
32
43
54 Speed range
under 31 mph (50 km/h)
under 69 mph (110 km/h)
under 88 mph (140 km/h)
under 131 mph (210 km/h)
The table shows the speed ranges
f or upshif ting and downshif ting.
To shift from 12
23
34
45 Speed range
over 0 mph (0 km/h)
over 6 mph (10 km/h)
over 20 mph (32 km/h)
over 33 mph (52 km/h)
Automatic Transmission
St art ing in Second Gear
248
——yy
(y
y
