Page 2030 of 2893

ACURA CSX 2006 Service Repair Manual Wake-up and Sleep Function
Fail-safe Function
Hardware Fail-safe Control
Software Fail-safe Control
Fail-safe function
22-84Multiplex Integrated Control System
System Description (cont’d)
The multip

Wake-up and Sleep Function
Fail-safe Function
Hardware Fail-safe Control
Software Fail-safe Control
Fail-safe function
22-84Multiplex Integrated Control System
System Description (cont’d)
The multiplex integrated control system has wake-up and sleep functions to decrease parasitic draw on the battery
when the ignition switch in LOCK (0).
In the sleep mode, the MICU stops functioning (communication and CPU control) when it is not necessary for the system to operate.
As soon as any operation is requested (for example, a door is unlocked), the related control unit in the sleep mode
immediately wakes up and begins to function.
When the ignition switch is turned to LOCK (0), and the driver’s door is opened, then closed, there is a delay of about 40 seconds before the control unit goes from the wake-up mode to the sleep mode.
The sleep mode will not function if any door is opened or if a key is in the ignition.
The draw is reduced from 200 mA to less than 35 mA when in the sleep mode.
NOTE: Sleep and Wake-up Mode Test (see page 22-99).
To prevent improper operation, the MICU has a fail-safe function. In the fail-safe mode, the output signal is fixed when
any part of the system malfunctions (for example, a faulty control unit or communication line).
Each control unit has a hardware fail-safe function that fixes the output signal when there is a CPU malfunction, and a
software fail-safe function that ignores the signal from a malfunctioning control unit , which allows the system to
operate normally.
When a CPU problem or a abnormal power supply voltage is detected, the MICU moves to the hardware fail-safe
mode, and each system output load is set to the pre-programmed fail-safe value.
When any of the data from the B-CAN circuit cannot be received within a specified time, or an unusual combination of
the data is recognized, the MICU moves to the software fail-safe mode. The data that cannot be received is forced to a
pre-programmed value.
08/08/21 14:24:09 61SNR030_220_0086
ProCarManuals.com
DYNOMITE -2009-

Page 2031 of 2893

ACURA CSX 2006 Service Repair Manual Power Supply Voltage Monitoring Function
Entry Lights Control System
Lighting System (Headlights, Parking Lights, Fog Lights, Side Marker Lights, License Plate
Lights, and Taillights)
Daytime Running

Power Supply Voltage Monitoring Function
Entry Lights Control System
Lighting System (Headlights, Parking Lights, Fog Lights, Side Marker Lights, License Plate
Lights, and Taillights)
Daytime Running Lights
Turn Signal/Hazard Warning Lights
Door Lock Response Operation
Power Window Key-off Operation
InputOutput
Input Output
Input Output
Input Output
Input Output
Input Output
Input Output
22-85
The MICU monitors the power supply voltage (back-up voltage). If the voltage goes below 10 V, the MICU sends a MICU message and will not
store DTCs.
MICU Battery voltage MICU : MICU internal circuit
The MICU controls the ceiling light ON/OFF and dimming based upon input signals from each switch. MICU IG1 power supply Ignition key switch
Driver’s door switch
Front passenger’s door switch
Left rear door switch
Right rear door switch
Driver’s door lock knob switch (LOCK) Interior light
B-CAN Keyless LOCK signal
The MICU contains the relay circuits for the headlight high/low beams and taillights, and controls the lighting system ON/OFF based upon input
signals from the combination light switch. MICU Headlight OFF switch Headlight ON switch
Fog light switch
Dimmer switch
Combination light switch (parking lights, side marker lights,
license plate lights, and taillights)
Passing switch Headlights (low beam)
Headlights (high beam)
Parking lights
Fog lights
Side marker lights
License plate lights
Taillights
The MICU controls the exterior lights as a daytime running lights based upon input signals from each switch. MICU Headlight OFF switch Headlight ON switch
Dimmer switch
Combination light switch (parking lights, side marker lights,
license plate lights, and taillights)
Passing switch Headlights (low beam)
Headlights (high beam)
Parking lights
Slide marker lights
License plate lights
Taillights
B-CAN Transmission range switch (P position)
The MICU controls the turn signal/hazard warning lights based upon input signals from the turn signal and hazard warning switches. MICU IG1 power supply Turn signal switch (left/right)
Hazard warning switch Turn signal lights (left/right)
The MICU controls the door lock actuators based upon B-CAN signals. B-CAN Door lock signals Door lock actuator (LOCK/UNLOCK) Driver’s door lock actuator (UNLOCK)
Trunk lid release actuator
The MICU controls the power windows key-off operation based upon input signals from each switch. MICU IG1 power supply Ignition key switch
Driver’s door switch
Front passenger’s door switch Power window key-off timer
(cont’d)
08/08/21 14:24:09 61SNR030_220_0087
ProCarManuals.com
DYNOMITE -2009-

Page 2032 of 2893

ACURA CSX 2006 Service Repair Manual Power Door Locks (Vehicle Speed Sense)
Power Door Locks (Normally LOCK/UNLOCK Operation)
Keyless Entry System
Keyless PANIC
InputOutput
Input Output
Input Output
Input Output
22-86Multiplex Integrated

Power Door Locks (Vehicle Speed Sense)
Power Door Locks (Normally LOCK/UNLOCK Operation)
Keyless Entry System
Keyless PANIC
InputOutput
Input Output
Input Output
Input Output
22-86Multiplex Integrated Control System
System Description (cont’d)
The MICU controls the door lock actuators based upon B-CAN signals and input signals from each switch.
MICU IG1 power supply Driver’s door switch
Front passenger’s door switch
Left rear door switch
Right rear door switch
Trunk lid latch switch
Driver’s door lock knob switch (UNLOCK)
Front passenger’s door lock knob switch (UNLOCK)
Left rear door lock knob switch (UNLOCK)
Right rear door lock knob switch (UNLOCK)
Transmission range switch (P position) Door lock (LOCK)
B-CAN Vehicle speed pulse Engine RPM
The MICU controls the door lock actuators based upon input signals from each switch. MICU IG1 power supply Ignition key switch
Driver’s door switch
Front passenger’s door switch
Left rear door switch
Right rear door switch
Trunk lid latch switch
Driver’s door lock knob switch (LOCK)
Driver’s door lock switch (LOCK/UNLOCK)
Driver’s door key cylinder switch (UNLOCK)
Front passenger’s door lock switch (LOCK/UNLOCK) Door lock actuators (LOCK/UNLOCK)
The MICU controls the door lock actuators based upon B-CAN signals and input signals from each switch. MICU IG1 power supply Ignition key switch
Driver’s door switch
Front passenger’s door switch
Left rear door switch
Right rear door switch
Trunk lid latch switch
Driver’s door lock knob switch (LOCK/UNLOCK)
Driver’s door lock switch (LOCK/UNLOCK)
Driver’s door key cylinder switch (UNLOCK)
Front passenger’s door lock switch (LOCK/UNLOCK)
Transmission range switch (P position) Door lock actuator (LOCK/UNLOCK)
Driver’s door lock actuator (UNLOCK)
Trunk lid release actuator
B-CAN Keyless LOCK signal
The MICU controls the keyless PANIC based upon B-CAN signals. B-CAN Keyless PANIC signal (action, headlight low, parking light and horn) Headlights (low beam)
Parking lights
Side marker lights
License plate lights
Taillights
Horn
08/08/21 14:24:09 61SNR030_220_0088
ProCarManuals.com
DYNOMITE -2009-

Page 2033 of 2893

ACURA CSX 2006 Service Repair Manual Security Alarm System
Key-in Reminder
Key Interlock (A/T)
Answer Back Response Operation
Wiper/Washer
Collision Detection Signal (CDS)
InputOutput
Input Output
Input Output
Input Output
Input Output
I

Security Alarm System
Key-in Reminder
Key Interlock (A/T)
Answer Back Response Operation
Wiper/Washer
Collision Detection Signal (CDS)
InputOutput
Input Output
Input Output
Input Output
Input Output
Input Output
22-87
The MICU controls the lighting system and horn based upon B-CAN signals and input signals from the each switch.
MICU IG1 power supply Ignition key switch
Audio switch
Driver’s door switch
Front passenger’s door switch
Left rear door switch
Right rear door switch
Trunk lid latch switch
Driver’s door key cylinder switch (UNLOCK)
Driver’s door lock knob switch (UNLOCK)
Front passenger’s door lock knob switch (UNLOCK)
Left rear door lock knob switch (UNLOCK)
Right rear door lock knob switch (UNLOCK)
Hood switch Horn
Headlights
Parking lights
Side marker lights
License plate lights
Taillights
B-CAN Keyless LOCK signal Door lock signal
The MICU controls the door lock actuators based upon ignition key switch, the driver’s door switch, and driver’s door lock knob switch signals. MICU Ignition key switch Driver’s door switch
Driver’s door lock knob switch Door lock actuator (LOCK/UNLOCK)
Driver’s door lock actuator (UNLOCK)
The MICU controls the key interlock solenoid based upon IG1, transmission range switch, and park-pin switch signals. MICU Ignition switch ACC Transmission range switch (P position)
Park-pin switch Key interlock solenoid
The MICU controls the lighting system and horn based upon B-CAN signals. B-CAN Answer back signals (headlight low, horn, parking lights) Horn Headlights
Parking lights
Side marker lights
License plate lights
Taillights
The MICU controls the wiper motor and the washer motor based upon IG1 and wiper/washer switch signals. MICU IG1 power supply Wiperswitch(INTandLO)
Wiper switch (LO and HI)
Wiper switch (MIST)
Washer switch
Wiper intermittent speed Wiper motor
Washer motor
The MICU controls the door lock actuators based upon IG1 and B-CAN signals. MICU IG1 power supply Door lock (LOCK/UNLOCK)
B-CAN SRS signal (front, side and rear) Impact sensors
(cont’d)
08/08/21 14:24:09 61SNR030_220_0089
ProCarManuals.com
DYNOMITE -2009-

Page 2035 of 2893

ACURA CSX 2006 Service Repair Manual System MenuData List Data List Indication
22-89
LightingDriver’s Door Switch OFF/ON
Hazard Switch OFF/ON
Headlight Switch (OFF) OFF/ON
Headlight Switch (PARKING) OFF/ON
Headlight Switch (HEADLIGHT)

Page 2036 of 2893

ACURA CSX 2006 Service Repair Manual µ
System MenuData List Data List Indication
22-90Multiplex Integrated Control System
System Description (cont’d)
Keyless
Driver’s Door Switch OFF/ON
Front Passenger’s Door Switch OFF/ON
Driver

Page 2037 of 2893

ACURA CSX 2006 Service Repair Manual System MenuData List Data List Indication
22-91
SecurityIgnition Key Cylinder Switch OFF/ON
Driver’s Door Switch OFF/ON
Front Passenger’s Door Switch OFF/ON
Driver’s Rear Door Switch OFF/ON
Pass

Page 2038 of 2893

ACURA CSX 2006 Service Repair Manual •••
Function Test:
System Menu Data List Indication Data List and Operation Time
22-92Multiplex Integrated Control System
System Description (cont’d)
Door Locks
LOCK all doors Outputs LOCK
