2005 SUBARU LEGACY glove box

18
1
14 13 121110 9 8 23 456
7
UBF510CB
1) Parking brake lever (page 7-51)
2) Gear shift lever (MT) (page 7-13)
3) Select lever (AT) (page 7-16)
4) Information display (page 3-37)
5) Clock (page 3-36)
6) Dashboard storage compart-
ment (page 6-7)
7) Glove box (page 6-7)
8) Hazard warning flasher switch
(page 3-7)
9) Audio (page 5-1)
10) Climate control (page 4-1)
11) Cigarette lighter (page 6-16)
12) Ashtray (page 6-19)
13) Tilt steering(page 3-63)
14) Cup holder (page 6-12/page 6- 13)

1-65
Seat, seatbelt and SRS airbags
– CONTINUED –
!Subaru advanced frontal airbag sys- tem
Your vehicle is equipped with a Subaru advanced
frontal airbag system that complies with the new ad-
vanced frontal airbag requirements in the amended
Federal Motor Vehicle Safety Standard (FMVSS) No.
208.
The Subaru advanced frontal airbag system automat-
ically determines the deployment force of the driver’s
SRS frontal airbag at the time of deployment as well as
whether or not to activate the front passenger’s SRS
frontal airbag and, if activated, the deployment force of
the SRS frontal airbag at the time of deployment.
Your vehicle has warning labels on the driver’s and
front passenger’s sun visors beginning with the phrase
“EVEN WITH ADVANCED AIR BAGS” and a tag at-
tached to the glove box lid beginning with the phrase
“Even with Advanced Air Bags”. Make sure that you
carefully read the instructions on the warning labels
and tag.
Always wear your seatbelt. Subaru advanced frontal
airbag system is a supplemental restraint system and
must be used in combination with a seatbelt. All occu-
pants should wear a seatbelt or be seated in an appro-
priate child restraint system.
The driver’s SRS frontal airbag is stowed in the center
portion of the steering wheel. The front passenger’s SRS frontal airbag is stowed near the top of the dash-
board under an “SRS AIRBAG” mark.
In a moderate to severe frontal collision, the driver’s
and front passenger’s SRS frontal airbags deploy and
supplement the seatbelts by reducing the impact on
the driver’s and front passenger’s head and chest.
NEVER INSTALL A REARWARD FACING CHILD
SAFETY SEAT IN THE FRONT SEAT. DOING SO
RISKS SERIOUS INJURY OR DEATH TO THE
CHILD BY PLACING THE CHILD’S HEAD TOO
HG1043BA

2-2
Keys and doors
Keys and doorsKeys
Vehicle with immobilizer system
A) Master key
B) Submaster key
C) Valet key
D) Key number plate
E) Security ID plate Vehicle without immobilizer system
A) Master key
B) Submaster key
C) Valet key
D) Key number plate
Three types of keys are provided for your vehicle.
Master key, submaster key and valet key.
The master key and submaster key fit all locks on your vehicle. " Ignition switch
" Driver’s door
" Glove box
" Trunk lid release lever
D E
C
B
A
UB2227BB
AB C
D
UB2228BB

2-3
Keys and doors
– CONTINUED –
The valet key fits only the ignition switch and door
locks. You can keep the trunk and glove box locked
when you leave your vehicle and valet key at a parking facility.
NOTE
If the key is attached to a keyholder or to a large
bunch of other keys, centrifugal force may act on
it as the vehicle moves, resulting in unwanted
turning of the ignition switch. Also, if a large key-
holder is attached to the key, your knees or hands
may accidentally touch it in a way that turns the ig-
nition switch. !
Key number
A) Key number plate
B) Security ID plate
The key number is stamped on the metal plate at-
tached to the key set. Write down the key number and
keep it in another safe place, not in the vehicle. This
number is needed to make a replacement key if you
lose your key or lock it inside the vehicle.
For information on making replacement keys for vehi-
cle with immobilizer system, refer to the “Immobilizer
(if equipped)” in this chapter.
A B
UB2534BB

6-1
6
Interior equipment
Interior light .................................................. 6-2 Dome light ......................................................... 6-2
Cargo area light (Station wagon) ..................... 6-3
Map light ........................................................ 6-3
Sun visors ..................................................... 6-5 Sun visor extension plate ................................ 6-5
Vanity mirror with light ..................................... 6-6
Storage compartment .................................. 6-7 Glove box ........................................................... 6-7
Center console box ........................................... 6-8
Center panel compartment .............................. 6-10
Overhead console (if equipped) ...................... 6-11
Cup holder .................................................... 6-11 Front passenger’s cup holder ......................... 6-12
Rear passenger’s cup holder ........................... 6-13
Accessory power outlets ............................. 6-14
Cigarette lighter socket ................................ 6-16 Use with a cigarette lighter .............................. 6-17
Using as an accessory power outlet ............... 6-18
Ashtray .......................................................... 6-19 Front ashtray ..................................................... 6-19
Coat hook ...................................................... 6-20 Rear passenger area ......................................... 6-20
Shopping bag hook ...................................... 6-21
Floor mat ....................................................... 6-22
Cargo area cover .......................................... 6-23 Using the cover ................................................. 6-23
To remove the cover housing .......................... 6-24
To remove the rear gate board ........................ 6-24 Stowage of the cargo area cover and rear
gate board ....................................................... 6-25
To install the cover housing ............................ 6-26
To install the rear gate board .......................... 6-27
Stowage boxes (Station wagon) .................. 6-28
Convenient tie-down hooks (if equipped) .. 6-29
Under-floor storage compartment ............... 6-30
HomeLink® Wireless Control System (if equipped) ............................................... 6-31Garage door opener programming in the U.S.A. ............................................................... 6-33
Programming rolling-code-protected garage door openers in the U.S.A. ............................ 6-34
Programming for entrance gates and garage door openers in Canada ................................ 6-36
Programming other devices ............................ 6-37
Operating the HomeLink® Wireless Control System ............................................................ 6-37
Reprogramming a single HomeLink®
button .............................................................. 6-37
Erasing HomeLink® button memory .............. 6-37
In case a problem occurs ................................. 6-38

6-7
Interior equipment
– CONTINUED –
Storage compartment
"Always keep the storage compartment
closed while driving to reduce the risk of injury
in the event of sudden stops or an accident. " Do not store spray cans, containers with
flammable or corrosive liquids or any other
dangerous items in the storage compartment. !
Glove box
A) Lock
B) Unlock
To open the glove box, pull the handle. To close it,
push the lid firmly upward.
To lock the glove box, insert the key and turn it clock-wise.A
B
UB6215BB

9-31
In case of emergency
– CONTINUED –
4. Insert the wrench in the end of the motor shaft.
To lower the moonroof, turn the wrench clockwise.
To close the moonroof, turn the wrench counterclock-wise.
Have your vehicle checked and repaired by an autho-
rized SUBARU dealer.
Station wagon:
1. Take out the hex-headed wrench from the glove
box and screwdriver from the tool bag.
2. If the sun shade is completely open, slide the sun
shade toward the front of the vehicle by taking the fol-
lowing steps. 1) Push the slider at the rear of the rear moonroof
frame toward the rear of the vehicle.
UB9553BAUB9548BA

9-36
In case of emergency
NOTE
When you first receive your vehicle from your
dealer, the hex-headed wrench is stored in the
glove box. We recommend that you take the
wrench out and store it in the tool bucket after you
have received your vehicle.
UB9218BA
