2005 SUBARU IMPREZA fuse

18
„
Instrument panel
12 3 4 5 67
8
9
10
11
12
14
15
16 13
UGF059BB
1) Door locks (page 2-6)
2) Outside mirror switch (page 3-
49)
3) Light control lever (page 3-30)
4) Combination meter (page 3-15)
5) Wiper control lever (page 3-36)
6) Hazard warning flasher switch
(page 3-7)
7) Audio (page 5-1)
8) Gear shift lever (MT) (page 7-
15)/Selector lever (AT) (page 7-
22)
9) Climate control (page 4-1)
10) Cruise control (page 7-38)
11) Horn (page 3-51)
12) SRS airbag (page 1-53)
13) Tilt steering (page 3-50)
14) Fuse box (page 11-65)
15) Hood lock release knob (page
11-5)
16) Power window (page 2-24)

2-5
Keys and doors
– CONTINUED –
„Security indicator light
The security indicator light deters potential thieves by
indicating that the vehicle is equipped with an immobi-
lizer system. It begins flashing (approximately once
every three seconds) about 60 seconds after the igni-
tion switch is turned from the “ON” position to the
“ACC” or “LOCK” position or immediately after the key
is pulled out.
If the security indicator light does not flash, the immo-
bilizer system may be faulty. If this occurs, we recom-
mend that you contact your SUBARU dealer as soon
as possible.
In case an unauthorized key is used (e.g. an imitation
key), the security indicator light comes on.
NOTE
Even if the security indicator light flashes irregu-
larly or its fuse blows (the light does not flash if its
fuse is blown), the immobilizer system will func-
tion normally. „ Key replacement
Your key number and security ID will be required if you
ever need a replacement key made. Any new key
must be registered for use with your vehicle’s immobi-
lizer system before it can be used. Up to four keys can be registered for use with one vehicle.
For security, all the keys registered with your vehicle’s
immobilizer system will have their ID codes erased
and re-registered when a new key is made. Therefore,
all of your vehicle’s keys must be presented when a
new key is registered. Any key that is not re-registered
when a new key is made cannot be used after the oth-
er keys are re-registered. For information on replace-
ment keys and on the registration of keys with your im-
mobilizer system, we recommend that you contact
your SUBARU dealer.
NOTE
This device complies with Part 15 of the FCC
Rules and with RSS-210 of Industry Canada. Oper-
ation is subject to the following two conditions:
(1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interfer-
ence received, including interference that may
cause undesired operation.
NO USER SERVICEABLE PARTS INSIDE.
DO NOT ATTEMPT TO MODIFIED THIS EQUIP-
MENT. IF MODIFIED, YOUR AUTHORITY TO OP-
ERATE THIS EQUIPMENT MIGHT BE VOIDED BY
FCC or Industry Canada.

3-9
Instruments and controls
– CONTINUED –
odometer/trip meter will go off. TOdometer
The odometer shows the total distance that the vehicle
has been driven. T Double trip meter
1) A trip meter
2) B trip meter
The trip meter shows the distance that the vehicle has
been driven since you last set it to zero.
To change the mode indication, briefly push the knob.
Each press of the knob changes the function alter-
nately. To set the trip meter to zero, select the A trip or B trip
meter by pushing the knob and keep the knob pushed for more than 2 seconds.
To ensure safety, do not attempt to change the
function of the indicator during driving, as an
accident could result.
NOTE
If the connection between the combination meter
and battery is broken for any reason such as vehi-
cle maintenance or fuse replacement, the data re-
corded on the trip meter will be lost. „
Tachometer
The tachometer shows the engine speed in thousands
of revolutions per minute.
Do not operate the engine with the pointer of
the tachometer in the red zone. In this range,
1
2
UG3027AB
A trip meter B trip meter

3-16
Instruments and controls
T
Odometer
The odometer shows the total distance that the vehicle
has been driven. T Double trip meter
1) A trip meter
2) B trip meter
The trip meter shows the distance that the vehicle has
been driven since you last set it to zero.
To change the mode indication, briefly push the knob.
Each press of the knob changes the function alter-
nately. To set the trip meter to zero, select the A trip or B trip
meter by pushing the knob and keep the knob pushed
for more than 2 seconds.
To ensure safety, do not attempt to change the
function of the indicator during driving, as an
accident could result.
NOTE
If the connection between the combination meter
and battery is broken for any reason such as vehi-
cle maintenance or fuse replacement, the data re-
corded on the trip meter will be lost. „
Tachometer
The tachometer shows the engine speed in thousands
of revolutions per minute.
Do not operate the engine with the pointer of the tachometer in the red zone. In this range,
1
2
UG3027AB
A trip meter B trip meter

7-10
Starting and operating
If the engine does not start, try the following:
1) Turn the ignition switch to the “OFF” position and
wait for at least 10 seconds. After checking that the
parking brake is firmly set, turn the ignition switch to
the “ON” position while depressing the accelerator
pedal slightly (about a quarter of the full stroke). Re-
lease the accelerator pedal as soon as the engine starts.
2) If this fails to start the engine, turn the ignition
switch back to the “OFF” position and wait for at
least 10 seconds. Then fully depress the accelerator
pedal and turn the ignition switch to the “START”
position. If the engine starts, quickly release the ac-
celerator pedal.
3) If this fails to start the engine, turn the ignition
switch again to the “OFF” position. After waiting for
10 seconds or longer, turn the ignition switch to the
“START” position without depressing the accelera-
tor pedal.
4) If the engine still refuses to start, contact your
nearest SUBARU dealer for assistance.
6. Confirm that all warning and indicator lights have
gone off after the engine has started. The fuel injection
system automatically lowers the idle speed as the en-
gine warms up. „
Automatic transmission vehicle
1. Apply the parking brake.
2. Turn off unnecessary lights and accessories.
3. Shift the selector lever to the “P” or “N” position
(preferably “P” position).
The starter motor will only operate when the select le-
ver is at the “P” or “N” position.
4. Turn the ignition switch to the “ON” position and
check the operation of the warning and indicator lights.
Refer to the “Warning and indicator lights” section
(chapter 3).
5. Turn the ignition switch to the “START” position
without depressing the accelerator pedal. Release
the key immediately after the engine has started.
If the engine does not start, try the following: 1) Turn the ignition switch to the “OFF” position and
wait for at least 10 seconds. After checking that the
parking brake is firmly set, turn the ignition switch to
the “ON” position while depressing the accelerator
pedal slightly (about a quarter of the full stroke). Re-
lease the accelerator pedal as soon as the engine starts.
2) If this fails to start the engine, turn the ignition
switch back to the “OFF” position and wait for at
least 10 seconds. Then fully depress the accelerator
pedal and turn the ignition switch to the “START”
position. If the engine starts, quickly release the ac-

7-11
Starting and operating
– CONTINUED –
celerator pedal.
3) If this fails to start the engine, turn the ignition
switch again to the “OFF” position. After waiting for
10 seconds or longer, turn the ignition switch to the
“START” position without depressing the accelera-
tor pedal.
4) If the engine still refuses to start, contact your
nearest SUBARU dealer for assistance.
6. Confirm that all warning and indicator lights have
gone out after the engine has started. The fuel injec-
tion system automatically lowers the idle speed as the
engine warms up.
While the engine is warming up, make sure that the
selector lever is at the “P” or “N” position and that the
parking brake is applied.
If you restart the engine while the vehicle is
moving, shift the selector lever into the “N” po-sition. Do not attempt to place the selector lever
of a moving vehicle into the “P” position.
Stopping the engine
The ignition switch should be turned off only when the
engine is idling.
Do not stop the engine when the vehicle is mov-
ing. This will cause loss of power to the power
steering and the brake booster, making steer-
ing and braking more difficult. It could also re-
sult in accidental activation of the “LOCK” po-
sition on the ignition switch, causing the steer-
ing wheel to lock.

9-4
In case of emergency
1) Spare fuse
2) FWD connector
NOTE
(If your vehicle is AWD with automatic transmis-
sion, except Turbo models) Before driving your
vehicle with the temporary spare tire, put a spare fuse inside the FWD connector in the main fuse
box located in the engine compartment and con-
firm that the Front-wheel drive warning light
“AWD” in the combination meter comes on. The
all wheel drive capability of the vehicle has now
deactivated. After re-installing the conventional
tire, remove the spare fuse from the FWD connec-
tor in order to reactivate all wheel drive.
Never tow a trailer when the temporary spare
tire is used. The temporary spare tire is not de-
signed to sustain the towing load. Use of the
temporary spare tire when towing can result in
failure of the spare tire and/or less stability of
the vehicle and may lead to an accident.
Never use any temporary spare tire other than
the original. Using other sizes may result in se-
vere mechanical damage to the drive train of
your vehicle.
1
2
USB501BB

11 - 2
Maintenance and service
Types of tires .................................................... 11-47
Tire inspection .................................................. 11-47
Tire pressures and wear .................................. 11-48
Wheel balance ................................................... 11-51
Wear indicators ................................................. 11-51
Tire rotation ....................................................... 11-52
Tire replacement ............................................... 11-53
Wheel replacement ........................................... 11-53
Aluminum wheels ......................................... 11-54
Intercooler water spray (WRX-STi) ............. 11-55
Windshield washer fluid .............................. 11-56
Replacement of wiper blades ...................... 11-57 Windshield wiper blades assembly ................ 11-57
Windshield wiper blade rubber ....................... 11-58
Rear window wiper blade assembly ............... 11-59
Rear window wiper blade rubber .................... 11-60
Battery ........................................................... 11-63
Fuses ............................................................. 11-65
Main fuse ....................................................... 11-68
Installation of accessories .......................... 11-68
Replacing bulbs ............................................ 11-69 Headlights (U.S.-spec. WRX-STi) .................... 11-70
Headlights (Except U.S.-spec. WRX-STi) ....... 11-71
Front turn signal light bulbs ............................ 11-73
Parking light ...................................................... 11-74
Front fog light ................................................... 11-78
Rear combination lights ................................... 11-78
License plate light ............................................ 11-81
Dome light, map light and cargo area light .... 11-81
Trunk light ......................................................... 11-82
High mount stop light ...................................... 11-83
