Replacement of wiper bladesGrease, wax, insects, or other material on the wind-
shield or the wiper blade results in jerky wiper opera-
tion and streaking on the glass. If you cannot remove
the streaks after operating the windshield washer or if
the wiper operation is jerky, clean the outer surface of
the windshield (or rear window) and the wiper blades
using a sponge or soft cloth with a neutral detergent or
mild-abrasive cleaner. After cleaning, rinse the wind-
shield and wiper blades with clean water. The wind-
shield is clean if beads do not form when you rinse the
windshield with water.Do not clean the wiper blades with gasoline or
a solvent, such as paint thinner or benzene.
This will cause deterioration of the wiperblades.
If you cannot eliminate the streaking even after follow-
ing this method, replace the wiper blades using the fol-
lowing procedures:
"Windshield wiper blades assembly1. Raise the wiper arm off the windshield.1) Stopper2. Remove the wiper blade assembly by holding its
pivot area and pushing it in the direction shown by the
arrow while depressing the wiper blade stopper.
3. Install the wiper blade assembly to the wiper arm.
Make sure that it locks in place.
4. Hold the wiper arm by hand and slowly lower it in
position.
1
UGB133BB
ProCarManuals.com
11 - 5 6Maintenance and service
18 February 2004
3. Align the claws of the metal support with the
grooves in the rubber and slide the blade rubber as-
sembly into the metal support until it locks.
1) Stopper4. Be sure to position the claws at the end of the metal
support between the stoppers on the rubber as shown.
If the rubber is not retained properly, the wiper blade
may scratch the windshield."Rear window wiper blade assembly1. Raise the wiper arm off the rear window.
HSB061BA
1
HSB062BB
ProCarManuals.com
11 -5 7
Maintenance and service
– CONTINUED –
11
18 February 2004
2. Turn the wiper blade assembly counterclockwise.3. Pull the wiper blade assembly toward you to re-
move it from the wiper arm.
"Rear window wiper blade rubber1. Pull out the end of the blade rubber assembly to un-
lock it from the plastic support.
UBB554BAUBB555BA
UBB523BA
