Page 331 of 444
11 - 6Maintenance and service
18 February 2004
3. Release the secondary hood release located under
the front grille by moving the lever toward the left.Lift up the hood, release the hood prop from its retain-
er and put the end of the hood prop into the slot in the
hood.
To close the hood:
1. Lift the hood slightly and remove the hood prop
from the slot in the hood and return the prop to its re-
tainer.
2. Lower the hood until it approaches about 5.9 in (15
cm) from the closed position and let it drop.
After closing the hood, be sure the hood is securely
locked.
If this does not close the hood, release it from a slightly
UGB089BA
UGB503BA
ProCarManuals.com
Page 341 of 444
11 - 1 6Maintenance and service
26 December 2003
"Recommended grade and viscosity
under severe driving conditionsIf the vehicle is used in desert areas, in areas with very
high temperatures, or used for heavy-duty applica-
tions such as towing a trailer, use of oil with the follow-
ing grade and viscosities is recommended.API classification SL (or SJ):
SAE viscosity no.: 30, 40, 10W-50, 20W-40, 20W-50
"Synthetic oilYou can use synthetic engine oil that meets the same
requirements given for conventional engine oil. When
using synthetic oil, you must use oil of the same clas-
sification, viscosity and grade shown in this owner’s
manual, and must follow the oil and filter changing in-
tervals shown in the maintenance schedule.
Cooling systemNever attempt to remove the radiator cap until
the engine has been shut off and has cooled
down completely. Since the coolant is under
pressure, you may suffer serious burns from a
spray of boiling hot coolant when the cap is re-moved.!The cooling system has been filled at the fac-
tory with a high quality, corrosion-inhibiting,
year-around coolant which provides protection
against freezing down to –33°F (–36°C). For
adding, use genuine Saab coolant or an equiv-
alent: a mixture of 50% soft water and 50% eth-
ylene-glycol basis coolant. Use of improper
coolants may result in corrosion in the cooling
system. It is important to maintain protection
against freezing and corrosion, even if freezing
temperatures are not expected. Never mix dif-
ferent kinds of coolant.
!Do not splash the engine coolant over paint-
ProCarManuals.com
Page 372 of 444
11 -4 7
Maintenance and service
– CONTINUED –
11
26 December 2003
!Abnormally high tire pressure (tread worn in cen-
ter)
Ride comfort is poor. Also, the tire magnifies the ef-
fects of road-surface bumps and dips, possibly result-
ing in vehicle damage.
If the tire label shows tire pressures for the vehicle
when fully loaded and for the vehicle when towing a
trailer, adjust the tire pressures to the values that
match current loading conditions.Driving at high speeds with excessively low tire
pressures can cause the tires to deform severe-ly and to rapidly become hot. A sharp increase
in temperature could cause tread separation,
and destruction of the tires. The resulting loss
of vehicle control could lead to an accident."Wheel balanceEach wheel was correctly balanced when your vehicle
was new, but the wheels will become unbalanced as
the tires become worn during use. Wheel imbalance
causes the steering wheel to vibrate slightly at certain
vehicle speeds and detracts from the vehicle’s
straight-line stability. It can also cause steering and
suspension system problems and abnormal tire wear.
If you suspect that the wheels are not correctly bal-
anced, have them checked and adjusted by your Saab
dealer. Also have them adjusted after tire repairs and
after tire rotation.NOTELoss of correct wheel alignment* causes the tires
to wear on one side and reduces the vehicle’s run-
ning stability. Contact your Saab dealer if you no-
tice abnormal tire wear.*: The suspension system is designed to hold each wheel at
a certain alignment (relative to the other wheels and to the
road) for optimum straight-line stability and cornering perfor-
mance.
HSB054AA
ProCarManuals.com
Page 382 of 444
11 -5 7
Maintenance and service
– CONTINUED –
11
18 February 2004
2. Turn the wiper blade assembly counterclockwise.3. Pull the wiper blade assembly toward you to re-
move it from the wiper arm.
"Rear window wiper blade rubber1. Pull out the end of the blade rubber assembly to un-
lock it from the plastic support.
UBB554BAUBB555BA
UBB523BA
ProCarManuals.com
