2005 NISSAN 350Z display

shift mode. Shift range can be selected manu-
ally.
In the manual shift mode, the shift range is
displayed on the position indicator in the meter.
Shift ranges up or down one by one as follows:M1→
←
M2→
←
M3→
←
M4→
←
M5
M5 (5th):
Use this position for all normal forward driving.M4 (4th):
For driving up or down long slopes where engine
braking would be advantageous.M3 (3rd) and
M2 (2nd):
Use for hill climbing or engine braking on down-
hill grades.
M1 (1st):
Use this position when climbing steep hills
slowly or driving slowly through deep snow,
sand or mud, or for maximum engine braking on
steep downhill grades.

Remember not to drive at high speeds for
extended periods of time in lower than
M4
range. This reduces fuel economy.

When shifting up, move the selector lever to
the + (up) side. (Shifts to higher range.)
When shifting down, move the selector lever
to the − (down) side. (Shifts to lower range.)

Moving the selector lever to the same side
twice will shift the ranges in succession.
However, if this motion is rapidly done, the
second shifting may not be completed prop-
erly.

In the manual shift mode, the transmis-
sion automatically shifts down to 1st
gear before the vehicle comes to a stop.
When accelerating again, it is necessary
to shift up to the desired range.

When canceling the manual shift mode, re-
turn the selector lever to the D position. The
transmission returns to the normal driving
mode.

In the manual shift mode, the transmis-
sion may not shift to the selected gear.
This helps maintain driving performance
and reduces the chance of vehicle dam-
age or loss of control.
Accelerator downshift
— In D position —For passing or hill climbing, fully depress the
accelerator pedal to the floor. This shifts the
transmission down into the lower gear, depend-
ing on the vehicle speed.
Fail-safeWhen the fail-safe operation occurs, the next
time the key is turned to the ON position, the
warning light will blink for approximately 8
seconds after coming on for 2 seconds. While
the vehicle can be driven under these circum-
stances please note that the gears in the auto-
matic transmission will be locked in 4th gear.
If the vehicle is driven under extreme con-
ditions, such as excessive wheel spinning
and subsequent hard braking, the fail-safe
system may be activated. This will occur
even if all electrical circuits are functioning
properly. In this case, turn the ignition key
OFF and wait for 3 seconds. Then turn the
key back to the ONposition. The vehicle
should return to its normal operating con-
dition. If it does not return to its normal
operating condition, have a NISSAN dealer
check the transmission and repair if neces-
sary.
Starting and driving
5-11


04.8.23/Z33-D/V5.0


Fully depress the clutch pedal before
shifting to help prevent transmission
damage.

Stop your vehicle completely before
shifting into R (Reverse).

When the vehicle is stopped with the
engine running (for example, at a
stop light), shift to N(Neutral) and
release the clutch pedal with the foot
brake applied.
Up-shift indicatorThe manual transmission up-shift indicator is
situated in the tachometer and shows the driver
the time to shift into a higher gear by illuminating.
The engine speed in revolutions per minute
(rpm) for upshifting can be set on the trip
computer display. (See “Trip computer” in the
“2. Instruments and controls” section for the
display setting information.) The use of the up-
shift indicator will help you to upshift at a
constant engine speed (rpm) from any gear.
The up-shift indicator will start flashing when the
engine speed is within about 500 rpm of the set
figure while driving, and then illuminate after theengine speed reaches the set figure.
For example, you can use the up-shift indicator
when driving as follows:

If the maximum engine speed is desired, set
the figure at 6,600 rpm. (The indicator starts
flashing from about 6,100 rpm and comes on
steady at 6,600 rpm.)

If the maximum engine torque is desired, set
the figure at 4,800 rpm. (The indicator starts
flashing from about 4,300 rpm and comes on
steady at 4,800 rpm.)

If you want to break in your vehicle, use of the
up-shift indicator with a rather low figure will
help you to avoid the high engine speed.
To make the up-shift indicator not come on, set
the figure at above 7,200 rpm.
There may be a slight difference between
the timing of the up-shift indicator illumi-
nation and the tachometer indication.
SSD0278
Starting and driving
5-13


04.8.23/Z33-D/V5.0


LOW TIRE PRESSURE WARNING
SYSTEMThis vehicle is equipped with the low tire pres-
sure warning system. It monitors tire pressure of
all tires except the spare. When the low tire
pressure warning light is lit, one or more of your
tires is significantly under-inflated. The system
also displays pressure of all tires (except the
spare tire) on the trip computer by sending a
signal from a sensor that is installed in each
wheel. If the vehicle is being driven with low tire
pressure*, the low tire pressure warning system
will activate and warn you of it by the low tire
pressure warning light (in the meter panel) or the
PSI indicator (on the trip computer). This system
will activate only when the vehicle is driven at
speeds above 20 MPH (32 km/h). For more
details, refer to “Trip computer” and
“Warning/indicator lights and audible remind-
ers” in the “2. Instruments and controls” section
and “Low tire pressure warning system” in the
“5. Starting and driving” section.
*: lower than 26 psi (for 225/50R17 and
235/50R17 tires on
Roadster model)
lower than 28 psi (except for the above)
WARNING

If the low tire pressure warning light
comes on and/or the PSI indicator
flashes while driving, avoid sudden
steering maneuvers or abrupt brak-
ing, reduce vehicle speed, pull off the
road to a safe location and stop the
vehicle as soon as possible. Serious
vehicle damage could occur and may
lead to an accident and could result
in serious personal injury. Check the
tire pressure for all four tires. Adjust
the tire pressure to the recom-
mended COLD tire pressure shown
on the Tire and Loading Information
label to turn the low tire pressure
warning light OFF. If you have a flat
tire, replace it with a spare tire as
soon as possible.

When a spare tire is mounted or a
wheel is replaced, tire pressure will
not be indicated and the low tire
pressure warning system will not
function. Contact a NISSAN dealer assoon as possible for tire replacement
and/or system resetting.

Do not inject any tire liquid or aerosol
tire sealant into the tires, as this may
cause a malfunction of the tire pres-
sure sensors.
CHANGING A FLAT TIREIf you have a flat tire, follow the instructions
below.Stopping the vehicle1. Safely move the vehicle off the road away
from traffic.
2. Turn on the hazard warning flashers.
3. Park on a level surface and apply the parking
brake. Shift the manual transmission into R
(Reverse) position (automatic transmission in
P (Park) position).
4. Turn off the engine.
5. Raise the hood to warn other traffic, and to
signal professional road assistance person-
nel that you need assistance.
6. Have all passengers get out of the vehicle
and stand in a safe place, away from traffic
and clear of the vehicle.
FLAT TIRE6-2
In case of emergency


04.8.23/Z33-D/V5.0


Installing the spare tireThe spare tire is designed for emergency
use. See specific instructions under the
heading “Wheels and tires” in the “8. Main-
tenance and do-it-yourself” section.
1. Clean any mud or dirt from the surface
between the wheel and hub.
2. Carefully put the wheel on and tighten the
wheel nuts finger tight. When replacing a
front tire, make sure the hole in the spare tire
wheel is aligned with the pin on the brake
rotor.
3. With the wheel nut wrench, tighten wheelnuts alternately and evenly in the sequence
illustrated (
1
-5) until they are tight.
4. Lower the vehicle slowly until the tire touches
the ground. Then, with the wheel nut wrench,
tighten the wheel nuts securely in the se-
quence as illustrated. Lower the vehicle com-
pletely.
WARNING

Incorrect wheel nuts or improperly
tightened wheel nuts can cause the
wheel to become loose or come off.
This could cause an accident.

Do not use oil or grease on the wheel
studs or nuts. This could cause the
nuts to become loose.

Retighten the wheel nuts when the
vehicle has been driven for 600 miles
(1,000 km) (also in cases of a flat tire,
etc.).
As soon as possible tighten the wheel nuts
to the specified torque with a torque
wrench.Wheel nut tightening torque:
80 ft-lb (108 N⋅m)
The wheel nuts must be kept tightened to
specification at all times. It is recom-
mended that wheel nuts be tightened to
specification at each lubrication interval.
Adjust tire pressure to the COLD pressure.
COLD pressure:
After vehicle has been parked for three
hours or more or driven less than 1 mile
(1.6 km).
COLD tire pressures are shown on the Tire
and Loading Information label affixed to
the driver’s side center pillar.
For models equipped with the low tire
pressure warning system:
After adjusting tire pressure to the COLD tire
pressure, the display of the tire pressure infor-
mation may show higher pressure than the
COLD tire pressure after the vehicle has been
driven more than 1 mile (1.6 km). This is because
the tire pressurizes as the tire temperature rises.
This does not indicate a system malfunction.
Stowing the tire and toolsSecurely store the spare tire and jacking equip-
ment in the vehicle.
SCE0039
6-6
In case of emergency


04.8.23/Z33-D/V5.0


TIRE PRESSURE
Low tire pressure warning systemThis vehicle is equipped with the low tire pres-
sure warning system. It monitors tire pressure of
all tires except the spare. When the low tire
pressure warning light is lit, one or more of your
tires is significantly under-inflated. The system
also displays pressure of all tires (except the
spare tire) on the trip computer by sending a
signal from a sensor that is installed in each
wheel.
The low tire pressure warning system will acti-
vate only when the vehicle is driven at speeds
above 20 MPH (32 km/h). Also, this system may
not detect a sudden drop in tire pressure (for
example a flat tire while driving).
For more details, refer to “Trip computer” and
“Low tire pressure warning light” in the “2.
Instruments and controls” section, “Low tire
pressure warning system” in the “5. Starting and
driving” section, and “Flat tire” in the “6. In case
of emergency” section.Tire inflation pressureCheck the pressure of the tires (including the
spare) often and always prior to long distance
trips. The recommended tire pressure specifica-
tions are shown on the Tire and Loading Infor-
mation label under the “Recommended ColdTire Inflation Pressure” heading. The Tire and
Loading Information label is affixed to the driver
side center pillar. Tire pressures should be
checked regularly because:

Most tires naturally lose air over time.

Tires can lose air suddenly when driven over
potholes or other objects or if the vehicle
strikes a curbwhile parking.
The tire pressures should be checked when the
tires are cold. The tires are considered COLD
after the vehicle has been parked for 3 or more
hours, or driven less than 1 mile (1.6 km) at
moderate speeds.
Incorrect tire pressure, including under in-
flation, may adversely affect tire life and
vehicle handling.
WARNING

Improperly inflated tires can fail sud-
denly and cause an accident.

The vehicle weight capacity is indi-
cated on the Tire and Loading Infor-
mation label. Do not load your ve-
hicle beyond this capacity.
Overloading your vehicle may resultin reduced tire life, unsafe operating
conditions due to premature tire fail-
ure, or unfavorable handling charac-
teristics and could also lead to a
serious accident. Loading beyond the
specified capacity may also result in
failure of other vehicle components.

Before taking a long trip, or when-
ever you heavily load your vehicle,
use a tire pressure gauge to ensure
that the tire pressures are at the
specified level.

Do not drive your vehicle over 85
MPH (137 km/h) unless it is equipped
with high speed rated tires. Driving
faster than 85 MPH (137 km/h) may
result in tire failure, loss of control
and possible injury.

For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety In-
formation” (Canada) in the Warranty
Information Booklet.
WHEELS AND TIRES
Maintenance and do-it-yourself
8-31


04.8.23/Z33-D/V5.0


Compact Disc (CD) changer operation .............. 4-24
Compact Disc (CD) player (See audio
system) ......................................................................... 4-17
Compact spare tire ................................................... 8-38
Console box................................................................ 2-34
Control panel buttons (models with navigation
system) ........................................................................... 4-2
Controls
Control panel buttons (display with navigation
system)..................................................................... 4-2
Heater and air conditioner controls
(automatic) .............................................................. 4-8
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cruise control............................................................. 5-15
Cup holders ................................................................ 2-33
Curtain side-impact air bag system (See
supplemental side air bag and curtain air bag
system) ......................................................................... 1-37
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and
outside mirror defroster switch.............................. 2-23
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system .............................................. 4-2
Door open warning light .......................................... 2-13
Drive belts ................................................................... 8-17Driving
Cold weather driving ......................................... 5-24
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Precautions when starting and driving ............ 5-2
E
Economy, Fuel............................................................ 5-17
Elapsed time ............................................................... 2-10
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-22
Engine
Before starting the engine .................................. 5-8
Break-in schedule............................................... 5-17
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil and filter ......................... 8-10
Checking engine coolant level........................... 8-8
Checking engine oil level ................................. 8-10
Coolant temperature gauge ............................... 2-6
Engine block heater ........................................... 5-25
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil .............................................................. 8-10
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ...................................... 6-9
Oil pressure gauge ............................................... 2-7
Starting the engine ............................................... 5-8
Event data recorders ................................................ 9-24Exhaust gas (Carbon monoxide).............................. 5-2
F
Filter
Air cleaner housing filter ................................... 8-18
Changing engine oil and filter ......................... 8-10
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat tire, Low tire pressure warning system .......... 5-3
Flat towing .................................................................. 9-20
Floor mat cleaning ....................................................... 7-4
Fluid
Automatic transmission fluid (ATF) ................ 8-12
Brake and clutch fluid ....................................... 8-13
Brake fluid............................................................. 8-14
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Engine coolant ....................................................... 8-8
Engine oil .............................................................. 8-10
Power steering fluid ........................................... 8-13
Window washer fluid ......................................... 8-14
FM-AM radio with Compact Disc (CD)
player ............................................................................ 4-15
FM-AM-SAT radio with cassette player and
Compact Disc (CD) changer ................................. 4-19
Front manual seat adjustment .................................. 1-3
Front power seat adjustment........................... 1-4, 1-5
Fuel
Average fuel consumption ................................ 2-10
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Distance to empty ................................................. 2-9
Filler cap ............................................................... 3-13


04.8.23/Z33-D/V5.0

10-2

Power door lock .................................................... 3-2
Rear floor box ...................................................... 2-35
Top latch lever ..................................................... 3-22
Trunk lid lock........................................................ 3-11
Low tire pressure warning light ............................. 2-14
Low tire pressure warning system .......................... 5-3
Luggage compartment light.................................... 2-41
M
Maintenance
Battery ................................................................... 8-15
General maintenance ........................................... 8-2
Inside the vehicle................................................... 8-3
Maintenance information (display) .................... 4-3
Maintenance precautions .................................... 8-5
Maintenance requirements.................................. 8-2
Outside the vehicle............................................... 8-2
Seat belt maintenance ...................................... 1-16
Under the hood and vehicle ............................... 8-4
Malfunction indicator lamp (MIL) ........................... 2-16
Manual front seat adjustment ................................... 1-3
Meters and gauges ..................................................... 2-3
Meters and gauges, Instrument brightness
control .......................................................................... 2-26
Mirror
Automatic anti-glare inside mirror .................. 3-17
Inside mirror ......................................................... 3-16
Outside mirror control ....................................... 3-18
Outside mirrors ................................................... 3-18N
Net, Ventilated net seats ........................................... 1-6
New vehicle break-in ................................................ 5-17
NISSAN Vehicle Immobilizer System ................... 2-19
Engine start............................................................. 5-7
O
Obtaining an air bag ON/OFF switch ................. 1-13
Odometer ....................................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine oil and filter ......................... 8-10
Checking engine oil level ................................. 8-10
Engine oil .............................................................. 8-10
Engine oil pressure gauge .................................. 2-7
Engine oil viscosity ............................................... 9-5
Opening the top ........................................................ 3-24
Outside air temperature display ............................... 2-9
Outside mirror control .............................................. 3-18
Outside mirrors .......................................................... 3-18
Overheat, If your vehicle overheats ......................... 6-9
Owner’s Manual/Service Manual order
information................................................................... 9-25
P
Parking
Brake check ......................................................... 8-21
Parking brake check .......................................... 5-14
Parking brake operation .................................... 5-14Parking on hills .................................................... 5-14
Parking/parking on hills ........................................... 5-18
Phone, Car phone or CB radio ............................. 4-26
Power
Power door lock .................................................... 3-2
Power front seat adjustment ..................... 1-4, 1-5
Power outlet ......................................................... 2-31
Power steering fluid ........................................... 8-13
Power steering system ...................................... 5-19
Power windows................................................... 2-38
Pre-tensioner seat belt system .............................. 1-39
Precautions
Audio operation ................................................... 4-12
Braking precautions ........................................... 5-20
Child restraints .................................................... 1-17
Cruise control ...................................................... 5-15
Maintenance ........................................................... 8-5
Seat belt usage ................................................... 1-10
Supplemental restraint system ........................ 1-29
When starting and driving .................................. 5-2
Push starting ................................................................. 6-9
R
Radio ............................................................................ 4-11
Car phone or CB radio ..................................... 4-26
FM-AM radio with cassette player and
Compact Disc (CD) changer .......................... 4-19
FM-AM radio with Compact Disc (CD)
player ..................................................................... 4-15
Readiness for inspection/maintenance (I/M)
test (US only) ............................................................. 9-23
Rear floor box ............................................................. 2-35
Rear hatch ..................................................................... 3-9


04.8.23/Z33-D/V5.0

10-4

Temperature display .................................................... 2-9
Temperature gauge, Engine coolant
temperature gauge ...................................................... 2-6
Theft (NISSAN Vehicle Immobilizer System),
Engine start................................................................. 2-20
Three way catalyst ....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-15
Tire
Flat tire ..................................................................... 6-2
Low tire pressure warning system........... 5-3, 6-2
Pressure indicator............................................... 2-10
Pressure, Low tire pressure warning light ... 2-14
Uniform tire quality grading .............................. 9-21
Tires
Spare tire .............................................................. 8-38
Tire and loading information label ...... 8-32, 9-12
Tire chains ............................................................ 8-35
Tire pressure ........................................................ 8-31
Tire rotation .......................................................... 8-36
Types of tires ....................................................... 8-35
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-31
Top
If the top does not open or close
electrically ............................................................. 3-25
Soft top operation .............................................. 3-19
Top latch lever ..................................................... 3-22
Top tether strap child restraint........................ 1-24
Towing
Flat towing ............................................................ 9-20
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-16
Towing load/specification chart ...................... 9-16Towing safety....................................................... 9-17
Traction control system (TCS)............................... 5-22
Traction control system (TCS) off switch ........... 2-29
Trailer towing .............................................................. 9-16
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-42
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Transmission selector lever lock release ...... 5-12
Transmitter (See remote keyless entry system) ... 3-4
Traveling or registering your vehicle in another
country ......................................................................... 9-10
Trip computer ............................................................... 2-8
Trip odometer ............................................................. 2-10
Trunk
Light ....................................................................... 2-41
Interior trunk lid release .................................... 3-12
Secondary trunk lid release ............................. 3-13
Turn signal switch ..................................................... 2-26
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-21
Up-shift indicator (M/T models) ............................ 5-13
Up-shift indicator setting (rpm) (M/T models) ... 2-11
V
Vanity mirror light ...................................................... 2-41Vehicle
Dimensions and weights ..................................... 9-9
Identification number (VIN)............................... 9-10
Loading information............................................ 9-14
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-19
Vehicle dynamic control (VDC) off switch ... 2-29
Vehicle dynamic control (VDC) system ........ 5-22
Ventilated net seats..................................................... 1-6
Ventilators ...................................................................... 4-7
Volt meter ...................................................................... 2-8
W
Warning labels, Air bag warning labels .............. 1-40
Warning light
Air bag warning light .............................. 1-40, 2-15
Anti-lock brake warning light ........................... 2-12
Brake warning light ............................................ 2-13
Door open warning light ................................... 2-13
Low tire pressure warning light ...................... 2-14
Warning lights ............................................................ 2-12
Warning, Hazard warning flasher switch ............ 2-27
Warning, Low tire pressure warning system ........ 5-3
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-12
Warranty, Emission control system warranty ..... 9-22
Washer switch
Rear window wiper and washer switch........ 2-22
Windshield wiper and washer switch ........... 2-22
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-9
Wheel/tire size.............................................................. 9-9


04.8.23/Z33-D/V5.0

10-6
