The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the “8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended
specifications US
measureImp
measureLiter
Fuel 20 gal 16-5/8 gal 76 Unleaded premium gasoline with an octane rating of at least 91 AKI (RON 96)*1
Engine oil (Drain and refill)*2
With oil filter change 5 qt 4-1/8 qt 4.7
API Certification Mark*3, *4

API grade SG/SH, Energy ConservingI&IIorAPIgradeSJorSL,Energy Conserving*3, *4

ILSAC grade GF-I, GF-II & GF-III*2, *3 Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system
With reservoir 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid — — — Genuine Nissan Matic J ATF*5
Manual transmission gear oil — — —Genuine NISSAN Manual Transmission Fluid (MTF) HQ Multi 75W-85 or API GL-4, Viscosity
SAE 75W-85 or 75W-90
Differential gear oil — — — API GL-5, Viscosity SAE 80W-90*6
Power steering fluid (PSF)
Refill to the proper fluid level according to the instructions in
the “8. Maintenance and do-it-yourself” section.Genuine NISSAN PSF or equivalent*7
Brake and clutch fluidGenuine NISSAN Super Heavy Duty Brake Fluid*8 or equivalent DOT 3 (U.S. FMVSS No. 116)
Multi-purpose grease — — — NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant — — — HFC-134a (R-134a)*9
Air conditioning system lubricants — — — NISSAN A/C System Oil Type S or exact equivalent
Windshield washer fluid — — — Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-freeze or equivalent
*1: For additional information, see “Fuel recommendation” later in this chapter.
*2: For additional information, see “Engine oil” in the “8. Maintenance and do-it-yourself” section for changing engine oil.
*3: For additional information, see “Engine oil and oil filter recommendation” later in this chapter.
*4: For additional information, see “Recommended SAE viscosity number” later in this chapter.
*5:Using automatic transmission fluid other than Genuine Nissan Matic J ATF will cause deterioration in driveability and automatic transmission durability,
and may damage the automatic transmission, which is not covered by the NISSAN new vehicle limited warranty.
*6: For hot areas, viscosity SAE 90 is suitable for ambient temperatures above 32°F (0°C).
*7: For Canada, Nissan Automatic Transmission Fluid (ATF), DEXRON
TMIII/MERCON
TMor equivalent ATF may also be used.
*8: Available in mainland US through a NISSAN dealer.
*9: For additional information, see “Vehicle identification” in this section for air conditioner specification label.
CAPACITIES AND
RECOMMENDED FUEL/
LUBRICANTS9-2
Technical and consumer information


04.8.23/Z33-D/V5.0


the proper equipment and to have it
installed.
Trailer lights should comply with federal and/or
local regulations. When wiring the vehicle for
towing, connect the stop and tail light pickup
into the vehicle electrical circuit at a point be-
tween the sensor and stop light or light switch.Trailer brakesIf your trailer is equipped with a braking system,
make sure it conforms to federal and/or local
regulations and that it is properly installed.
WARNING
Never connect a trailer brake system
directly to the vehicle brake system.Pre-towing tips
Be certain a vehicle maintains a level position
when a loaded and/or unloaded trailer is
hitched. Do not drive the vehicle if it has an
unusual nose-up or nose-down condition;
check for improper tongue load, overload,
worn suspension or other possible causes of
these conditions.
Always secure items in the trailer to prevent
load shifts while driving.

Load the trailer so approximately 60% of the
trailer load is in the front half and 40% is in
the back half.

Check your hitch, trailer tire pressure, vehicle
tire pressure, trailer light operation, and trailer
wheel lug nuts every time you attach a trailer
to the vehicle.

Be certain your rear view mirrors conform to
all federal, state and/or local regulations. If
not, install any mirrors required for towing
before driving the vehicle.
Trailer towing tipsIn order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability, and braking per-
formance will be somewhat different than under
normal driving conditions.

Always secure items in the trailer to prevent
load shift while driving.

Avoid abrupt starts, acceleration or stops.

Avoid sharp turns or lane changes.

Always drive a vehicle at a moderate speed.
Some states or provinces have specificspeed limits for vehicles that are towing
trailers. Obey the local speed limits.

When backing up, hold the bottom of the
steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small corrections and back
up slowly. If possible, have someone guide
you when you are backing up.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so,
and if a vehicle is equipped with automatic
transmission, first apply the parking brake
and block the wheels, and then move the
transmission selector lever into the P (Park)
position. If you move the selector lever to the
P (Park) position before blocking the wheels
and applying the parking brake, the transmis-
sion may get damaged.

When going down a hill, shift into a lower
gear and use the engine braking effect.
When going up a long grade, downshift the
transmission to a lower gear and reduce
speed to reduce chances of engine overload-
ing and/or overheating.

If the engine coolant rises to an extremely
high temperature when the air conditioning
system is on, turn off the air conditioner.
Coolant heat can be additionally vented by
Technical and consumer information
9-19


04.8.23/Z33-D/V5.0


Due to legal requirements in some states/
areas, your vehicle may be required to be in what
is called the “ready condition” for an Inspection/
Maintenance (I/M) test of the emission control
system.
The vehicle is set to the “ready condition” when
it is driven through certain driving patterns.
Usually, the “ready condition” can be obtained
by ordinary usage of the vehicle.
If a powertrain system component is repaired or
the battery is disconnected, the vehicle may be
reset to a not “ready condition”. Before taking
the I/M test, check the vehicle’s inspection/
maintenance test readiness condition. Turn the
ignition switch ON without starting the engine. If
the Malfunction Indicator Lamp (MIL) comes on
steady for 20 seconds and then blinks for 10
seconds, the I/M test condition is “not ready”. If
the MIL does not blink after 20 seconds, the I/M
test condition is “ready”.
If the MIL indicates the vehicle is in a “not ready”
condition, drive the vehicle through the following
pattern to set the vehicle to the ready condition.
If you cannot or do not want to perform the
driving pattern, a NISSAN dealer can conduct it
for you.
WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic
conditions and obey all traffic laws.
1. Start the engine. Allow the engine to idle until
the engine coolant temperature gauge needle
points between the C and H (normal operat-
ing temperature).
2. Accelerate the vehicle to 55 MPH (88 km/h),
then quickly release the accelerator pedal
completely and keep it released for at least
10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 to 60 MPH (86 to 96 km/h) for at least 9
minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 minutes.
8. Stop the vehicle. Place the automatic trans-mission gear selector lever in the P (Park) or
N (Neutral) position or the manual transmis-
sion shift lever in the N position.
9. Turn the engine off.
10. Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the engine
until step 7 is completed.
READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)
Technical and consumer information
9-23


04.8.23/Z33-D/V5.0


Compact Disc (CD) changer operation .............. 4-24
Compact Disc (CD) player (See audio
system) ......................................................................... 4-17
Compact spare tire ................................................... 8-38
Console box................................................................ 2-34
Control panel buttons (models with navigation
system) ........................................................................... 4-2
Controls
Control panel buttons (display with navigation
system)..................................................................... 4-2
Heater and air conditioner controls
(automatic) .............................................................. 4-8
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cruise control............................................................. 5-15
Cup holders ................................................................ 2-33
Curtain side-impact air bag system (See
supplemental side air bag and curtain air bag
system) ......................................................................... 1-37
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and
outside mirror defroster switch.............................. 2-23
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system .............................................. 4-2
Door open warning light .......................................... 2-13
Drive belts ................................................................... 8-17Driving
Cold weather driving ......................................... 5-24
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Precautions when starting and driving ............ 5-2
E
Economy, Fuel............................................................ 5-17
Elapsed time ............................................................... 2-10
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-22
Engine
Before starting the engine .................................. 5-8
Break-in schedule............................................... 5-17
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil and filter ......................... 8-10
Checking engine coolant level........................... 8-8
Checking engine oil level ................................. 8-10
Coolant temperature gauge ............................... 2-6
Engine block heater ........................................... 5-25
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil .............................................................. 8-10
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ...................................... 6-9
Oil pressure gauge ............................................... 2-7
Starting the engine ............................................... 5-8
Event data recorders ................................................ 9-24Exhaust gas (Carbon monoxide).............................. 5-2
F
Filter
Air cleaner housing filter ................................... 8-18
Changing engine oil and filter ......................... 8-10
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat tire, Low tire pressure warning system .......... 5-3
Flat towing .................................................................. 9-20
Floor mat cleaning ....................................................... 7-4
Fluid
Automatic transmission fluid (ATF) ................ 8-12
Brake and clutch fluid ....................................... 8-13
Brake fluid............................................................. 8-14
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Engine coolant ....................................................... 8-8
Engine oil .............................................................. 8-10
Power steering fluid ........................................... 8-13
Window washer fluid ......................................... 8-14
FM-AM radio with Compact Disc (CD)
player ............................................................................ 4-15
FM-AM-SAT radio with cassette player and
Compact Disc (CD) changer ................................. 4-19
Front manual seat adjustment .................................. 1-3
Front power seat adjustment........................... 1-4, 1-5
Fuel
Average fuel consumption ................................ 2-10
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Distance to empty ................................................. 2-9
Filler cap ............................................................... 3-13


04.8.23/Z33-D/V5.0

10-2

Filler lid .................................................................. 3-13
Fuel economy ...................................................... 5-17
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Gauge ...................................................................... 2-6
Fuses ............................................................................ 8-22
Fusible links ................................................................ 8-23
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-42
Gas cap ....................................................................... 3-13
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-6
Engine oil pressure gauge .................................. 2-7
Fuel gauge .............................................................. 2-6
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-5
Trip computer ......................................................... 2-8
Volt meter ................................................................ 2-8
General maintenance .................................................. 8-2
Golf bag stowing....................................................... 2-36
H
Hatch, Rear hatch........................................................ 3-9
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-9
Headlights
Bulbreplacement ............................................... 8-27
Headlight switch ................................................. 2-24Xenon headlights ................................................ 2-24
Heated seats .............................................................. 2-28
Heater
Engine coolant heater ....................................... 5-25
Heater and air conditioner (automatic)............ 4-8
HomeLink
Universal Transceiver ......................... 2-42
Hood release ................................................................ 3-9
Horn .............................................................................. 2-27
How to stop alarm, Vehicle security .................... 2-20
I
Ignition switch ............................................................... 5-6
Automatic transmission models................ 5-6, 5-9
Key positions .......................................................... 5-7
Manual transmission models .................. 5-7, 5-12
Immobilizer system .................................................... 2-20
Indicator lights............................................................ 2-16
Inside
Automatic anti-glare mirror............................... 3-17
Mirror...................................................................... 3-16
Inspection/maintenance (I/M) test ........................ 9-23
Instrument brightness control ................................ 2-26
Instrument panel........................................................... 2-2
Interior light replacement......................................... 8-28
Interior lights ............................................................... 2-40
Interior trunk lid release ........................................... 3-12
J
Jump starting................................................................. 6-7K
Keyless entry (See remote keyless entry
system) ........................................................................... 3-4
Keys................................................................................. 3-2
L
Labels
Air bag warning labels ...................................... 1-40
Air conditioner specification label .................. 9-12
Emission control information label ................. 9-11
Engine serial number ......................................... 9-11
F.M.V.S.S./C.M.V.S.S. certification label ...... 9-11
Tire and loading information label ...... 8-32, 9-12
Vehicle identification number (VIN)................ 9-10
License plate, Installing front license plate......... 9-13
Light
Air bag warning light ......................................... 1-40
Bulbreplacement ............................................... 8-26
Headlight switch ................................................. 2-24
Headlights Bulbreplacement .......................... 8-27
Interior lights ........................................................ 2-40
Replacement ........................................................ 8-26
Vanity mirror light ................................................ 2-41
Warning/indicator lights and audible
reminders .................................................. 2-12, 2-16
Xenon headlights ................................................ 2-24
Lights, Exterior and interior light replacement ... 8-28
Loading information (See vehicle loading
information) ................................................................. 9-14
Lock
Door locks ............................................................... 3-2


04.8.23/Z33-D/V5.0

10-3

Temperature display .................................................... 2-9
Temperature gauge, Engine coolant
temperature gauge ...................................................... 2-6
Theft (NISSAN Vehicle Immobilizer System),
Engine start................................................................. 2-20
Three way catalyst ....................................................... 5-3
Tilting passenger’s seat ............................................. 1-7
Tilting steering wheel ............................................... 3-15
Tire
Flat tire ..................................................................... 6-2
Low tire pressure warning system........... 5-3, 6-2
Pressure indicator............................................... 2-10
Pressure, Low tire pressure warning light ... 2-14
Uniform tire quality grading .............................. 9-21
Tires
Spare tire .............................................................. 8-38
Tire and loading information label ...... 8-32, 9-12
Tire chains ............................................................ 8-35
Tire pressure ........................................................ 8-31
Tire rotation .......................................................... 8-36
Types of tires ....................................................... 8-35
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-31
Top
If the top does not open or close
electrically ............................................................. 3-25
Soft top operation .............................................. 3-19
Top latch lever ..................................................... 3-22
Top tether strap child restraint........................ 1-24
Towing
Flat towing ............................................................ 9-20
Tow truck towing ................................................ 6-10
Towing a trailer.................................................... 9-16
Towing load/specification chart ...................... 9-16Towing safety....................................................... 9-17
Traction control system (TCS)............................... 5-22
Traction control system (TCS) off switch ........... 2-29
Trailer towing .............................................................. 9-16
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-42
Transmission
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Transmission selector lever lock release ...... 5-12
Transmitter (See remote keyless entry system) ... 3-4
Traveling or registering your vehicle in another
country ......................................................................... 9-10
Trip computer ............................................................... 2-8
Trip odometer ............................................................. 2-10
Trunk
Light ....................................................................... 2-41
Interior trunk lid release .................................... 3-12
Secondary trunk lid release ............................. 3-13
Turn signal switch ..................................................... 2-26
U
Underbody cleaning .................................................... 7-3
Uniform tire quality grading .................................... 9-21
Up-shift indicator (M/T models) ............................ 5-13
Up-shift indicator setting (rpm) (M/T models) ... 2-11
V
Vanity mirror light ...................................................... 2-41Vehicle
Dimensions and weights ..................................... 9-9
Identification number (VIN)............................... 9-10
Loading information............................................ 9-14
Recovery (freeing a stuck vehicle) ................. 6-12
Security system ................................................... 2-19
Vehicle dynamic control (VDC) off switch ... 2-29
Vehicle dynamic control (VDC) system ........ 5-22
Ventilated net seats..................................................... 1-6
Ventilators ...................................................................... 4-7
Volt meter ...................................................................... 2-8
W
Warning labels, Air bag warning labels .............. 1-40
Warning light
Air bag warning light .............................. 1-40, 2-15
Anti-lock brake warning light ........................... 2-12
Brake warning light ............................................ 2-13
Door open warning light ................................... 2-13
Low tire pressure warning light ...................... 2-14
Warning lights ............................................................ 2-12
Warning, Hazard warning flasher switch ............ 2-27
Warning, Low tire pressure warning system ........ 5-3
Warning, Warning/indicator lights and audible
reminders ..................................................................... 2-12
Warranty, Emission control system warranty ..... 9-22
Washer switch
Rear window wiper and washer switch........ 2-22
Windshield wiper and washer switch ........... 2-22
Washing ......................................................................... 7-2
Waxing............................................................................ 7-3
Weights (See dimensions and weights) ............... 9-9
Wheel/tire size.............................................................. 9-9


04.8.23/Z33-D/V5.0

10-6

1. Engine oil (P.8-10)
2. Brake fluid (P.8-13)
3. Meters and gauges (P.2-3)
4. Fuel filler lid release (P.3-13)
5. Hood release (P.3-9)
6. Seat belt (P.1-10)
7. Door lock/key (P.3-2)
8. Rear hatch release (Coupe) (P.3-10) or
Trunk lid release (Roadster) (P.3-11)
9. Engine coolant (P.8-8)
10. Window washer fluid (P.8-14)
11. Power steering fluid (P.8-13)
12. Battery (P.8-15)
13. Audio system (P.4-11)/
Heater and air conditioner (P.4-8)
14. Soft top (Roadster models) (P.3-19)
15. Fuel (P.3-13, P.9-3)
16. Spare tire (P.6-3, P.8-38)
STI0364
QUICK REFERENCE


04.8.23/Z33-D/V5.0
