2005 MINI Hardtop 2 Door Owner's Manual

15
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
DISPLAY ELEMENTS WITH NAVIGATION SYSTEM
* OR COCKPIT CHRONO PACK
*
1 Indicator and warning lamps, on

page
16 ff
2 Fuel gauge
63
For more information about the navigation
system, refer to the Owner's Manual for
Navigation System.
3 Engine oil temperature4 Engine oil pressure5 Coolant temperature
6 Indicator and warning lamps, on

page
16 ff
7 Fuel gauge
63

16
INDICATOR AND WARNING LAMPS Technology that monitors itselfThe system runs a check on the indicator
and warning lamps marked by
+ each time
you switch on the ignition. They each light
up once for different periods of time.
If a malfunction should occur in one of
these systems, the corresponding lamp
does not go out after the engine is started
or it lights up while the vehicle is moving.
You will see below the correct way to react
to this.
Red: stop immediately
Battery charge current
+
The battery is no longer being
charged. Indicates a defective alter
-
nator drive belt or a problem with the
charge circuit. Please contact your MINI
Dealer.
If the drive belt is defective, do not continue driving. The engine could be
damaged due to overheating. When the
power-assist is deactivated, increased
steering effort is required. +
The engine oil pressure is too low.
Pull over immediately and switch
off the engine. Please contact your MINI
Dealer.Do not continue driving; otherwise, the engine could be damaged
because of inadequate lubrication.<
Brake warning lamp
+
Lights up although the parking
brake is released. The brake fluid
level is too low. Before driving further, be
sure to comply with the information on
pages 96 and
111
. Have the system
checked immediately.
Display of the malfunction described above in Canadian mod
-
els.
If equipped with a navigation system or
Cockpit Chrono Pack:
Coolant temperature warning lamp in the navigation system or
Cockpit Chrono Pack
+
Lights up while driving:

Engine is too hot. Pull over to the side of
the road immediately, switch off the
engine and allow it to cool down, refer also
to page
64. Have the system checked
immediately.

17
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
INDICATOR AND WARNING LAMPSYellow: stop immediately
Flat Tire Monitor
+
The warning lamp indicates a flat
tire or a system malfunction. In the
event of a flat tire, an acoustic signal also
sounds.
Reduce speed immediately and stop the
vehicle.It is possible that the acoustic signal was
not heard. In this case, in order to deter
-
mine if there is a flat tire or a system mal
-
function:1. Switch off the ignition, ignition key posi
-
tion 0
2. Switch the ignition back on, ignition key
position 2, or start the engine.If an acoustic signal sounds, you have a flat
tire. Otherwise, the system has a malfunc
-
tion or has failed.For instructions on how to proceed further,
refer to Flat Tire Monitor starting on
page
71.Depending on the equipment ver
-
sion, the indicator lamp is in the area
of the navigation system or the Cockpit
Chrono Pack.<
Red and yellow: continue driving
cautiously
Brake warning light

together with yellow indicator
lamp for ABS, CBC, EBD and ASC/
DSC:

The driving stability control has
failed. Drive cautiously and defen
-
sively. Avoid full brake applications.

Have the system checked as soon
as possible.

More information on pages
68, 69
.
Display of the malfunction described above in Canadian mod
-
els.


Red: an important reminder
Brake warning lamp

with parking brake applied.

More information on the parking
brake on page
53.
Warning lamp in Canadian models.

Fasten safety belts
+
Lights up for several seconds or
until the driver has fastened his or
her safety belt.

A signal
* also sounds depending on the
version.
More information on page
45.
Depending on the equipment ver
-
sion, the indicator lamp is in the area
of the navigation system or the Cockpit
Chrono Pack.
Lights up when the bonnet and/or
tailgate are open.

More information on pages
29, 105
.

18
INDICATOR AND WARNING LAMPSRed: check as soon as possible
Airbags
+
There is a malfunction in the airbag
system. Have the system checked
as soon as possible.

More information on page
73.
Depending on the equipment ver
-
sion, the indicator lamp is in the area
of the navigation system or the Cockpit
Chrono Pack.
The brake pads have reached the
minimum safe limit for lining wear.
Have the brake pads replaced immediately.

More information on page
96.
Depending on the equipment ver
-
sion, the indicator lamp is in the area
of the navigation system or the Cockpit
Chrono Pack.<
Yellow: check as soon as possible
Antilock Brake System (ABS)
+
The ABS has failed. Conventional
braking efficiency is available. Have
the system checked as soon as possible.

More information on page
70.
Display of the malfunction described above in Canadian mod
-
els.All Season traction Control (ASC)/Dynamic Stability Control (DSC)
+
Indicator lamp flashes:

System active: drive and braking forces are
regulated.

The indicator lamp stays lit: ASC/DSC deac
-
tivated with button or defective.

In the event of a defect: Have the system
checked as soon as possible.

More information on pages
68, 69
.
Engine
+
The exhaust emissions have deteri
-
orated.

Have the vehicle checked as soon as possi
-
ble.
Display of the malfunction described above in Canadian mod
-
els.Engine electronics
* +
The engine electronics are mal
-
functioning. You can continue to
drive with reduced engine output or engine
speed. Have the vehicle checked as soon as
possible.

19
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
INDICATOR AND WARNING LAMPSYellow: for your information
The warning lamp
* comes on.

The gas cap is not correctly closed
or missing. Check if the gas cap is
correctly closed.Depending on the equipment ver
-
sion, the indicator lamp is in the area
of the navigation system or the Cockpit
Chrono Pack.<
Green: for your information
Turn signal indicator

Flashes when turn signal indicator
is on.

Rapid flashing: at least one of the turn sig
-
nal indicators has failed.

More information on page
58.
Cruise control

Lights up when the cruise control is
activated: operation via the multi
-
function steering wheel or multifunction
sports steering wheel.

More information on page
61.
Blue: for your information
High beams

Comes on when the high beams
are on or the headlamp flasher is
actuated.
More information on page
58.

20
MULTIFUNCTION STEERING WHEELS
*
Steering wheels with multifunctionsThe control buttons integrated within the
multifunction steering wheel and the mul
-
tifunction sports steering wheel have been
designed to allow you to operate a number
of accessories both quickly and safely,
without taking your eyes from the road:>Some audio source functions>Cruise control.
Steering wheel1 Call up and continue cruise control2 Activate/interrupt/deactivate cruise
control3 Store and accelerate cruise control 4 Store and decelerate cruise control Right:5Volume6 Changing between radio, CD or cassette
Left:5 Operation of:>Radio

Press briefly: next/previous station
stored in memory

Extended pressure: station scan>CD/MD

Press briefly: jump to next track

Extended pressure: search within cur
-
rent title>Cassette

Press briefly: jump to next track or
stop fast forward

Extended pressure: fast forward/
rewind
If the Wave radio is installed, the above options for cassette
player operation are not available.<

21
OVERVIEW REPAIRS OPERATION CONTROLS DATA INDEX
MULTIFUNCTION STEERING WHEELS
*
Sports steering wheel1 Call up and continue cruise control2 Store and accelerate cruise control 3 Activate/interrupt/deactivate cruise
control4 Store and decelerate cruise control
5 Fast forward/rewind>Radio

Press briefly: next/previous station
stored in memory

Extended pressure: station scan>CD/MD

Press briefly: jump to next track

Extended pressure: search within cur
-
rent title>Cassette

Press briefly: jump to next track or
stop fast forward

Extended pressure: fast forward
If the Wave radio is installed, the above options for cassette
player operation are not available.<
6Volume

22
