Page 106 of 215
105 Telephone*
Telephone operation
On the multifunction steering wheel
Presst
.
The desired phone number has to be en-
tered when placing an outgoing call.
The following options are available:
entering a phone number directly
initiating redial (
page 106)
selecting an entry in the accepted and
missed calls list (
page 107)
selecting an entry in the dialed calls list
(page 108)
using speed dial (
page 110)
opening the phone book and selecting
an entry (
page 114)
Entering a phone number
Open the Telephone main menu
(page 102).
Use " - ! to enter the phone num-
ber.
In case of erroneous entry, you can de-
lete the last or more digits.
Press the
Delete
soft key as often as
required.
After entering the phone number,
press 0.
The telephone dials the entered num-
ber.
The call is activated the moment the
other party answers the call. Communi-
cation is conducted via the hands-free
system.
The volume can be adjusted
(page 30).
For other user functions, see “Active
call” (
page 110).
iIt is also possible to accept, refuse or
end a call from the cell phone
(Telephone Operation Guide).
Placing an outgoing call
Page 131 of 215
130 Navigation*Destination entry1Character display
You can see which characters can be
entered when using the keys.
Each additional depression moves you
to the next available character.
The selected character appears black.
Wait until the character display disap-
pears, or press .
The character is entered.
Deleting a character
Press the
Delete
soft key if necessary.
The character last accepted by the sys-
tem is deleted.Confirming the data entry
After entering all the characters the data
entry must be confirmed.
Press and hold for approx. 2 sec-
onds;
or
Use or to select the sym-
bol and press .
.
iDo not confuse the
Delete
soft key (de-
letion of the last character) with the
Back
soft key (deletion of the complete
entry).
iThe symbol can only be selected if
the system has recognized the entry.
ok
ok
Page 136 of 215
135 Navigation*
Destination entry
Use or to select a region.
The selected region appears black.
Press .
Selecting a different region deletes the
city last entered. The first city of the
newly selected region appears (in al-
phabetical order).
The Destination entry menu (
page 133)
represents the starting point.
Enter city (USA)
appears in the status bar.
The characters in parenthesis indicate the
selected region (page 134).Accepting the displayed destination
Press and hold for approx. 2 sec-
onds.
Entering a different city
Use the keypad menu or the 12 button
keypad to enter the data of the city
(page 129).
After entering the city a selection list of
cities appears indicated by
Select city
displayed in the status bar. Now contin-
ue with selecting a city.
Entering a city
iDo not confuse the button with the
symbol in the main screen. ok
Page 144 of 215
143 Navigation*
Destination entry
Enter house number menu
Use , , , , + or ( to
select the numbers. Press after
each selection;
or
Press 3 - " to enter the numbers.
Press the
Delete
soft key if necessary.
The number last accepted by the sys-
tem is deleted.
Press and hold for approx. 2 sec-
onds to confirm the input;
or
Use or to select the sym-
bol and press .
The house number list appears. Now a
house number range can be selected.
iThe
Hse. no.
soft key is only available
when registered house numbers are
stored on the navigation DVD for the
selected street.
iDo not confuse the
Delete
soft key (de-
letion of the last number) with the
Back
soft key (deletion of the complete en-
try).
iThe symbol can only be selected if
the system has recognized the house
number.
ok
ok
Page 177 of 215
176 Navigation*Last destinations and destination memoryTo select lower or upper case or to select
special characters, the following shift
fields on the display are available:
= upper case
= lower case
= special characters
Use , or to select one of
the shift fields.
Press .
Use , , , , + or ( to
select the characters. Press after
each selection.
If necessary, press the
Delete
soft key
to delete the character last entered.
Upon completion of the name entry
press and hold for approx. 2 sec-
onds;
or
Use or to select the sym-
bol and press .
The system will save the entry.
ABCabc...
iDo not confuse the
Delete
soft key (de-
letion of the last character) with the
Back
soft key (deletion of the complete
entry).
ok
