2005 MERCEDES-BENZ SL55AMG set clock

131 Controls in detail
Instrument cluster
Instrument cluster
For a full view illustration of the instrument
cluster, see “Instrument cluster”
(page 24).
The instrument cluster is activated when
you


open a door


switch on the ignition


press the reset button (
page 24)


switch on the exterior lamps
Opening a door will activate the instrument
cluster only for about 30 seconds.
You can change the instrument cluster set-
tings in the Instrument cluster submenu of
the control system (
page 148).
Instrument cluster illumination
Use the reset button to adjust the illumina-
tion brightness for the instrument cluster
and the switches on the center console.
To brighten illumination
Turn the reset button in the instrument
cluster (
page 24) clockwise.
The instrument cluster illumination will
brighten.
To dim illumination

Turn the reset button in the instrument
cluster (
page 24) counterclockwise.
The instrument cluster illumination will
dim.
Coolant temperature gauge
iThe instrument cluster illumination is
dimmed or brightened to suit ambient
light conditions.
Warning
G


Driving when your engine is badly over-
heated can cause some fluids which
may have leaked into the engine com-
partment to catch fire. You could be se-
riously burned.


Steam from an overheated engine can
cause serious burns an can occur just by
opening the hood. Stay away from the
engine if you see or hear steam coming
from it.
Turn off the engine, get out of the vehicle
and do not stand near the vehicle until the
engine has cooled down.

151 Controls in detail
Control system
Setting the time (minutes)
This function is only available if the func-
tion
Time sync. with head unit

(
page 149) has been set to
Off
. The time
is then not set automatically by the
COMAND and must be set manually if re-
quired.

Move the selection marker with the
æ or ç button to the
Time

submenu.

Press button j or k repeatedly
until the message
Set time Minutes

appears in the multifunction display.
The selection marker is on the minute
setting.

Press button æ or ç to set the
hour.

Press the reset button in the instru-
ment cluster (
page 25) to confirm
the setting.
Selecting time display mode

Move the selection marker with the
æ or ç button to the
Inst.
cluster
submenu.

Press button j or k repeatedly
until the message
Clock
appears in the
multifunction display.
The selection marker is on the current
setting.

Press æ or ç to set the
12-hour

or
24-hour
time display mode.
iFor information on setting the time, re-
fer to the separate COMAND operating
instructions.

384 Practical hintsReplacing bulbsHigh beam/ high beam flasher bulbs
Press ends of headlamp cover tab to-
gether and remove high beam head-
lamp cover 2.

Pull the electrical connector off.

Turn locking mechanism 5 counter-
clockwise and take out the bulb.

Insert the new bulb so that the base lo-
cates in the recess on the holder.

Turn locking mechanism 5 clockwise.

Plug the connector onto the bulb.

Align high beam headlamp cover 2
and click it into place.Parking and standing lamp bulbs

Press ends of cover tab together and
remove high beam headlamp cover 2.

Pull out bulb socket 6 with the bulb.

Pull the bulb out of bulb socket 6.

Insert a new bulb in bulb socket 6.

Reinstall bulb socket 6.

Align high beam headlamp cover 2
and click it into place.Side marker bulbs

Carefully slide the side marker lamp to-
wards rear.

Remove the front end first.

Turn the bulb socket counterclockwise
and pull it out.

Pull the bulb out of the bulb socket.

Insert the new bulb in socket.

Reinstall the bulb socket, push it in,
and turn it clockwise.

To reinstall the side marker lamp, set
the rear end in bumper and let the front
end snap into place.

393 Practical hints
Flat tire
Mounting the spare wheel Preparing the vehicle
Prepare the vehicle as described
(
page 388).

Turn spare wheel bracket counter-
clockwise to loosen.

Take the spare wheel out of the trunk.
Lifting the vehicle

Prevent the vehicle from rolling away
by blocking wheels with wheel chocks
(not included) or other sizable objects.
When changing wheel on a level sur-
face:
Place one chock in front of and one
behind the wheel that is diagonally
opposite to the wheel being
changed.
When changing wheel on a hill:

Place chocks on the downhill side
blocking both wheels of the other
axle.

Take the vehicle tool kit and the jack
out of the storage compartment under
the trunk floor (
page 372).
Warning!
G
The dimensions of the spare wheel are dif-
ferent from those of the road wheels. As a
result, the vehicle handling characteristics
change when driving with a mounted spare
wheel. Adapt your driving style accordingly.
The spare wheel is for temporary use only.
When driving with spare wheel mounted, en-
sure proper tire inflation pressure and do
not exceed vehicle speed of 50 mph
(80 km/h).
Drive to the nearest Mercedes-Benz Center
as soon as possible to have the spare wheel
replaced with a regular road wheel.
Never operate the vehicle with more than
one spare wheel mounted.
Warning!
G
The jack is designed exclusively for jacking
up the vehicle at the jack tubes built into
both sides of the vehicle. To help avoid per-
sonal injury, use the jack only to lift the ve-
hicle during a wheel change. Never get
beneath the vehicle while it is supported by
the jack. Keep hands and feet away from the
area under the lifted vehicle. Always firmly
set parking brake and block wheels before
raising vehicle with jack.
Do not disengage parking brake while the
vehicle is raised. Be certain that the jack is
always vertical (plumb line) when in use, es-
pecially on hills. Always try to use the jack
on level surface. Be sure that the jack arm is
fully inserted in the jack tube. Always lower
the vehicle onto sufficient capacity jack-
stands before working under the vehicle.


448 IndexCenter air vents 29
Center console
Lower part 30
Upper part 29
Centigrade
Setting temperature units 148
Central locking
Automatic 110
Central locking switch 111
Switching on/off (control
system) 156
Unlocking from inside 111
Central locking switch 29
Central unlocking switch 29
Changing
Batteries (SmartKey with
KEYLESS-GO*) 378
Batteries (SmartKey) 377
SmartKey setting 96
SmartKey with KEYLESS-GO*
settings 103
Vehicle level 222Charging
Vehicle batteries 404
CHECK ENGINE
Messages in display 351
CHECK ENGINE malfunction indicator
lamp 27, 327, 328
Checking
Coolant level 276
Oil level 269, 272
Tire inflate pressure 269
Vehicle lighting 269
Child safety
Airbags 64
Automatic child seat recognition 76
Infant and child restraint systems 62
Cigarette lighter 29, 233
Cleaning
Cup holder 320
Gear selector lever 320
Hard plastic trim items 320
Headlamps 178Headliner 320
Leather upholstery 321
Plastic and rubber parts 321
Seat belts 320
Steering wheel 320
Upholstery 321
Windshield 53
Wood trims 321
Cleaning tires 281
Clock 23
Closing
Hood 271
Power window with
KEYLESS-GO* 195
Retractable hardtop (SmartKey) 201
Retractable hardtop (switch) 198
Side windows 194, 195
Sunshade 204
Trunk lid 109
Windows 193
Windows with KEYLESS-GO* 195

450 Index
Air recirculation mode 188
Alarm 90
Anti-theft alarm system 89
Automatic climate control 191
Central locking (control system) 156
Cruise control 206
Distance warning function* 217
Distronic* 215
Engine with KEYLESS-GO* 59
Engine with the SmartKey 58
ESP 83
Exterior lamps 123
Hazard warning flasher 129
Headlamps 57, 123
Immobilizer 88
Interior light delayed switch-off 155
Parktronic* 226
Rear window defroster 189
Residual heat 190
Seat heating 117, 118Seat ventilation* 119
Tow-away alarm 90
Deactivating manual shift program 177
Deep water see Standing water
Defrosting windshield 187
Delayed switch-off
Exterior lamps 154
Interior lighting 155
Department of Transportation see DOT
Digital clock 23
Direction of rotation (tires) 282
Displays
Distronic* 210
Maintenance service indicator 312
Messages 273, 354
Parktronic* 225
Distance to empty (range)
Calling up 161
Distance warning function* 216
Activating 217Deactivating 217
Intermittent warning sound 216
Symbol 142, 212
Distance warning function* switch 30
Distronic indicator lamp* 25
Distronic* 208, 440
“Resume” function 215
Activating 213
Calling up settings 142, 212
Cleaning system sensors 318
Cruise control lever 213
Deactivating 215
Deceleration 211
Decreasing time interval 216
Displays 210
Distance warning function 216
Distance warning function switch 30
Driving hints 217
DTR warning lamp 210
Increasing time interval 216

461 Index
Service System see Vehicle Maintenance
System
Setting 150
Convenience functions 157
Daytime running lamp mode 152
Digital clock 23
Distronic* time interval 216
Exterior rear view mirror parking
position 158
Instrument lighting 131
Interior lighting delayed
switch-off 155
Key-dependent memory 158
Lamps and lighting (control
system) 152
Locator lighting 153
Lower speed in cruise control 207
Miles/kilometers in
speedometer 148
Multifunction display language 149
Night security illumination 154
Radio station 140
Slower speed in cruise control 207Speedometer display mode 148
Suspension tuning 220
Temperature (interior) 185
Temperature indicator 148
Time (control system) 149
Time display mode 151
Tire inflation pressure units 156
Units
Temperature 148
Tire inflation pressure 156
Units in speedometer 148
Vehicle level control 221
Setting current speed
Cruise control 206
Setting last stored speed
Distronic* 215
Setting speed
Cruise control 207
Distronic* 214
Setting the time (hours) 150
Setting the time (minutes) 151Setting to last stored speed
Cruise control 208
Settings
Calling up Distronic* 142, 212
Convenience functions 157
Factory (SmartKey) 96
Resetting all (control system) 145
Selective (SmartKey) 96
Settings menu
Individual vehicle settings 144
Submenus 145
Shifting
Gear selector lever 164
Gear selector lever positions 168
Into optimal gear range (Automatic
transmission) 166
Shoulder support
Seat adjustment 116
Side air vents 29
Side marker lamps 381, 384
