2005 MERCEDES-BENZ CLK500 COUPE keyless entry

ContentsSafety and Security........................... 59
Occupant safety................................... 60
Air bags .......................................... 61
Seat belts ....................................... 67
Children in the vehicle .................... 70
Blocking of
rear side window operation ............ 82
Panic alarm .......................................... 83
Activating ....................................... 83
Deactivating ................................... 83
Driving safety systems ......................... 84
ABS ................................................ 84
BAS ................................................ 85
ESP ................................................. 86
Anti-theft systems................................ 89
Immobilizer..................................... 89
Anti-theft alarm system .................. 90
Tow-away alarm ............................. 91
Controls in detail............................... 93
Locking and unlocking ......................... 94
SmartKey ....................................... 94
SmartKey with KEYLESS-GO* ........ 99
Opening the doors
from the inside ............................. 105
Opening the trunk ........................ 106
Closing the trunk.......................... 107
Trunk lid emergency release ........ 109
Automatic central locking ............ 110
Locking and unlocking
from the inside ............................. 110
Seats ................................................. 112
Easy-entry/exit feature ................ 112
Removing and installing
front seat head restraints............. 113
Rear seat head restraints ............. 115
Multicontour seat* ....................... 118
Seat heating* ............................... 119
Seat ventilation* .......................... 120
Memory function ............................... 121
Storing positions into memory ..... 122
Recalling positions from memory . 122
Storing exterior rear view
mirror parking position................. 123Lighting ............................................. 124
Exterior lamp switch .................... 124
Combination switch ..................... 129
Cornering fog lamps*
(CLK 320 with
Bi-Xenon* headlamps) ................. 130
Hazard warning flasher ................ 131
Interior lighting ............................ 132
Door entry lamps ......................... 133
Trunk lamp ................................... 133
Instrument cluster ............................. 134
Instrument cluster illumination .... 134
Coolant temperature indicator ..... 135
Trip odometer .............................. 135
Tachometer .................................. 136
Outside temperature indicator ..... 136

40 Getting startedAdjustingFolding backrests forward
Pull release lever1 forward and fold
the backrest forward.
The head restraint will automatically
move down.
Folding backrests back

Fold and press the backrest rearward
until it engages in driving position.
The head restraint returns to its previ-
ous position.
For more information, see “Easy-entry/ex-
it feature” (
page 112).
Steering wheel Steering wheel adjustment
The stalk for steering wheel adjustment is
located on the steering column (lower left).
1Adjusting steering column, in or out
2Adjusting steering column, up or down

Switch on ignition (
page 34).
or

Open the driver’s door.
Warning!
G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing could cause the driver to lose control of
the vehicle.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch, or the SmartKey with KEYLESS-GO*
removed from the vehicle, the steering
wheel adjustment feature can be operated
when the driver’s door is open. Therefore,
do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Unsupervised use of vehicle equipment may
cause an accident and/or serious personal
injury.

112 Controls in detailSeatsFor information on seat adjustment, see
“Adjusting” (
page 37).
Easy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle.
The easy-entry/exit feature can be
activated or deactivated in the Convenience
submenu of the control
system (
page 159).When exiting the vehicle, with the
easy-entry/exit feature activated and
depending on your selection, the steering
wheel tilts upwards and/or the driver’s
seat moves a few inches to the rear when
you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1 or the KEYLESS-GO* start/stop
button (
page 35) in position1.
Warning!
G
You must make sure that no one can be-
come trapped or injured by the moving
steering wheel and driver’s seat when the
easy-entry / exit feature is activated.
To cancel seat /steering wheel movement,
do one of the following:

Press seat adjustment switch
(page 37).


Move steering column stalk
(page 40).


Press memory position switch
(page 122)
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
iIf the current position for the steering
wheel is in the uppermost tilt position,
the steering wheel will no longer be
able to move upward when the
easy-entry/exit feature is activated.

113 Controls in detailSeats
When entering the vehicle, with the
easy-entry/exit feature activated, the
steering wheel or, depending on your
selection, the steering wheel and driver’s
seat will return to their last set position or
a factory-set maximum forward position
when you:

close the driver’s door with the ignition
switched on.
or


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 35) once
with driver’s door closed.Removing and installing front seat
head restraints
For information on head restraint adjust-
ment, see “Seats” (
page 37). If the current seat position falls into a
factory-set position range and the
system recognizes the current seat
position to be rearward enough for
easy entry and exit, the driver’s seat
will not move to the rear when the
easy-entry/exit feature is activated.
iFor safety reasons, the driver’s seat will
not return to its last set position with
the easy-entry/exit feature activated if
the system recognizes the last set posi-
tion as an extreme forward position.
Instead, the driver’s seat will remain at
or move to a factory-set maximum
forward position. To again fully return
the driver’s seat to your last set posi-
tion or to memory position, adjust the
seat to the desired position or press
and hold the respective memory
position switch (
page 122).
iAdjust the head restraint in such a way
that it is as close to the head as
possible.Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.


461 Index
A
ABS 25, 84, 455
Malfunction indicator lamp 354
Messages in display 365
Accelerator position,
automatic transmission 171
Accessory weight 338
Accident
In case of 54
Activating
Air conditioning (cooling) 192, 204
Air recirculation mode 190, 201
Anti-theft alarm system 90
Automatic climate control 195
Central locking (control system) 158
Charcoal filter 203
Climate control 185
Climate control system 187
Defrosting 189
Automatic climate control 200
Easy-entry/exit feature 159
Electric air pump 417
ESP 88Exterior headlamps 50
Exterior lamps 125
Exterior rear view
mirror parking position 180
Front and rear fog lamp 128
Hazard warning flasher 131
Headlamps 50
High beams 129
Ignition 34
Ignition with KEYLESS-GO* 36
Immobilizer 56, 89
Rear window defroster 183
Residual heat 205
Seat heating* 119
Seat ventilation* 120
Tow-away alarm 91, 92
Windshield wipers 52
Adding
Coolant 313
Engine oil 312
Additional turn signals 404
Adjustable air vents, rear
passenger compartment 193, 206Adjusting 37
Air distribution 188, 198
Air volume 199
Backrest tilt 38
Exterior rear view mirror 41
Head restraint height 38
Head restraint tilt 39
Instrument cluster illumination 134
Interior rear view mirror 41
Mirrors 41
Multicontour seat* 118
Seat cushion depth 118
Seat cushion tilt 38
Seat fore and aft adjustment 38
Seat height 38
Seats 37
Steering column in/out 41
Steering column up/down 41
Steering wheel 40
Aids for changing fuses 430

467 Index
Convenience submenu 158
Activating
easy-entry/exit feature 159
Setting key-dependency 160
Setting parking position for
exterior rear view mirror 160
Coolant 313, 452
Adding 313
Anticorrosion/antifreeze
quantity 452
Capacities 447
Checking level 313
Messages in display 375
Temperature 304
Temperature indicator 135
Warning lamp 357, 376
Coolant level
Checking 313
Cornering fog lamps* 130
Driving forward 130
Driving rearward 131Cruise control 255, 456
Canceling 257
Driving downhill 257
Driving uphill 257
Fine adjustment 259
Messages in display 367
Setting current speed 256
Setting to last stored speed
("Resume" function) 259
Cruise control lever 255
Cup holder
Cleaning 351
Closing 275
In rear seat armrest 275
In the dashboard 275
Opening 275
Curb weight 338
Customer Assistance Center (CAC) 455D
Date (day)
Setting 153
Date (month)
Setting 153
Date (year)
Setting 154
Daytime running lamp mode 126
Setting 155
Deactivating
Air conditioning (cooling) 192, 204
Air recirculation mode 191, 202
Alarm 91
Anti-theft alarm system 91
Automatic climate control 195
Central locking (control system) 158
Charcoal filter 203
Climate control 185
Climate control system 187
Defrost 200
Defrosting 189
Engine with KEYLESS-GO* 57
Engine with the SmartKey 56
ESP 87
Exterior lamps 125
Hazard warning flasher 131

469 Index
E
Easy-entry/exit feature 112
Activating 159
Electrical fuses 429
Electrical outlet in
rear passenger compartment 278
Electrical system
Technical data 444
Electronic Stability Program see ESP
Emergency call
911 245
Emergency call system* 280
Emergency calls
Initiating an emergency call 282
With Tele Aid 281
Emergency operation
(Limp Home Mode) 177
Emergency operations
Closing
power tilt/sliding sunroof* 401
Locking the vehicle 398
Opening
power tilt/sliding sunroof* 401
Remote door unlock 286
Unlocking the vehicle 397Emergency tensioning device see ETD
Emission control 304
Emission control information label 436
Ending
A call (telephone) 163
Engine
Compartment 308
Message in display 356
Starting 47
Starting with KEYLESS-GO* 47
Starting with the SmartKey 47
Technical data 438
Turning off 56
Engine cleaning 349
Engine compartment 308
Fuse box in 431
Hood 308
Engine malfunction
indicator lamp 25, 356
Engine number 436, 456Engine oil 309, 449
Adding 312
Additives 449
Checking level 310
Consumption 309
Filler cap 312
Filler neck 312
Message in display 379
Messages in display 311
Viscosity 456
Engine oil level see Oil level
ESP 25, 86, 456
Messages in display 367
Switching off 87
Switching on 88
Warning lamp 358
ETD 69, 456
Safety guidelines 64
Exterior lamp switch 124
Exterior rear view mirrors
Adjusting 41
Parking position for 160

474 Index
Maintenance service indicator 344
Parktronic system*
warning indicators 262
Seat belts 359
SRS 61, 359
Turn signals 25
Language
Multifunction display 150
Setting 150
LATCH child seat anchors 80
Folding back 81
Folding out 81
Layout of poly-V-belt drive 437
Leather upholstery
Cleaning 352
License plate lamps
Messages in display 383
Replacing bulbs 405, 410
Light alloy wheels
Cleaning 351
Technical data 440
Light sensor 383
Lighter see Cigarette lighterLighting 124
Automatic headlamp mode 125
Combination switch 129
Cornering fog lamps* 130
Daytime running lamp mode 126
Door entry lamps 133
Exterior lamp switch 124
Front fog lamps 128
High beam flasher 129
High beams 129
Instrument cluster illumination 134
Interior 132
Locator lighting 127
Low beam 124
Manual headlamp mode 125
Night security illumination 127
Parking lamps 124
Rear fog lamp 128
Settings (control system) 154
Limiting the gear range 168
Limp Home Mode 177
Line of fall 457Loading 264
Cargo tie-down rings 271
Instructions 269
Roof rack 264
Ski sack* 264
Split rear bench seat 267
Loading terminology 338
Loading the vehicle 319
Locator lighting 127
Setting 156
Lock buttons 457
Door handle (KEYLESS-GO*) 58
Locking 55, 94
Fuel filler flap 305
Global with KEYLESS-GO* 101
Global, SmartKey 96
The vehicle with KEYLESS-GO* 103
Vehicle in an emergency 398
Loss of Service and
Warranty Information Booklet 435
Loss of SmartKey 98
Loss of SmartKey
with KEYLESS-GO* 105
