ContentsPanorama roof with power
tilt/sliding panel* .............................. 241
Opening and closing the roller
sunblinds for the panorama roof
with power tilt/sliding panel ........ 241
Opening and closing the panorama
roof with power tilt/sliding panel . 242
Synchronizing the panorama roof
with power tilt/sliding panel and
the roller sunblinds....................... 246
Driving systems ................................. 247
Cruise control............................... 247
Loading .............................................. 250
Roof rack* .................................... 250
Split rear bench seat .................... 250
Luggage cover .............................. 252
Loading instructions ..................... 252
Cargo tie-down rings .................... 253
Useful features .................................. 254
Storage compartments................. 254
Ashtrays ....................................... 257
Cigarette lighter ........................... 259
Electrical outlet ............................ 260
Telephone*................................... 260
Tele Aid* ...................................... 261
Garage door opener* ................... 269
Operation......................................... 275
The first 1000 miles (1500km) .......... 276
Driving instructions............................ 277
Drive sensibly – save fuel ............. 277
Drinking and driving ..................... 277
Pedals .......................................... 277
Power assistance ......................... 277
Brakes .......................................... 278
Driving off .................................... 279
Parking ......................................... 279
Tires ............................................. 280
Hydroplaning ................................ 281
Tire traction.................................. 281
Tire speed rating .......................... 282
Winter driving instructions ........... 283
Standing water ............................. 284
Passenger compartment .............. 284
Driving abroad.............................. 284
Control and operation of radio
transmitter ................................... 284
Catalytic converter ....................... 285
Emission control .......................... 286
Coolant temperature .................... 286At the gas station .............................. 288
Refueling ...................................... 288
Check regularly and before a
long trip ....................................... 290
Engine compartment ......................... 291
Hood ............................................ 291
Engine oil ..................................... 292
Transmission fluid level ................ 296
Coolant level ................................ 296
Battery ......................................... 297
Windshield washer system and
headlamp cleaning system*......... 299
Tires and wheels................................ 300
Important guidelines .................... 300
Tire care and maintenance........... 301
Direction of rotation..................... 303
Loading the vehicle ...................... 303
Recommended tire inflation
pressure ....................................... 309
Checking tire inflation pressure ... 311
Tire labeling ................................. 313
Load identification ....................... 317
DOT, Tire Identification Number
(TIN) ............................................. 318
Maximum tire load ....................... 319
Maximum tire inflation pressure .. 320

33 Getting started
Unlocking
Starter switch positions
Starter switch0For removing SmartKey
The steering is locked when the Smart-
Key is removed from the starter switch.
If necessary, move steering wheel
slightly to allow the locking mechanism
to engage.
1Power supply to some electrical con-
sumers, such as seat adjustment2Ignition (power supply for all electrical
consumers) and driving position. All
lamps (except low beam headlamp in-
dicator lamp, high beam headlamp indi-
cator lamp, and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If
a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 340).
3Starting position
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.

127 Controls in detail
Control system
Menus, submenus and functions
Menu1
Menu2
Menu3
Menu4
Menu5
Menu6
Menu7
Standard
display
AUDIO
NAV*
Vehicle status
message memory
Settings
Trip computer
Telephone*
(page 128)
(page 129)
(page 131)
(page 132)
(page 133)
(page 151)
(page 153)
Commands/submenusDigital
speedometer or
outside tempera-
ture
Select radio sta-
tion
Activate route
guidance
Call up vehicle mal-
function, warning
and system status
messages stored
in memory
Reset to factory
settings
Fuel consump-
tion statistics af-
ter start
Load phone
book
Call up mainte-
nance service
display
Select satellite
radio station*
(USA only)
Instrument clus-
ter submenu
Fuel consump-
tion statistics
since the last
reset
Search for name
in phone book
Check engine oil
level
Operate the
CD player*
Time/Date
submenu
Call up range
Lighting
submenuVehicle
submenuConvenience
submenu

290 OperationAt the gas stationCheck regularly and before a long trip
1Coolant level
2Brake fluid (fuse box cover removed)
3Windshield washer and headlamp
cleaning system*Brake fluid
Remove fuse box cover before checking
brake fluid (
page 410).
Engine oil level
For more information on engine oil, see
“Engine oil” (page 292).
Opening hood, see (
page 291).Coolant
For normal replenishing, use water (pota-
ble water quality). For more information on
coolant, see “Coolant level” (
page 296)
Vehicle lighting
Check function and cleanliness. For infor-
mation on replacing light bulbs, see “Re-
placing bulbs” (
page 384).
Exterior lamp switch, see (
page 110).
Tire inflation pressure
For information on tire inflation pressure,
see “Checking tire inflation pressure”
(
page 311).
Windshield washer and headlamp
cleaning system*
For more information on filling up the
washer reservoir, see “Windshield washer
system and headlamp cleaning system*”
(page 299).
!If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately. Noti-
fy an authorized Mercedes-Benz Center
immediately. Do not add brake fluid as
this will not solve the problem. For
more information, see “Practical Hints”
(page 341).

405 Practical hints
Jump starting
The battery is located in the engine com-
partment on the right hand side. The
terminals for jump starting are located in
front of the battery.
Make sure the two vehicles do not
touch.

Turn off the engine.
On both vehicles:

Turn off all electrical consumers.

Apply parking brake.

Shift gear selector lever to positionP
(manual transmission to Neutral).1Positive terminal of charged battery
2Positive under hood terminal in front of
discharged battery
3Negative terminal of charged battery
4Negative under hood terminal in front
of discharged battery

Connect positive terminal1 of the
charged battery with positive under
hood terminal2 in front of the dis-
charged battery with the jumper ca-
bles. Clamp cable to charged
battery1 first.

Start engine of the vehicle with the
charged battery and run at idle speed.

Connect negative terminal3 of the
charged battery with negative under
hood terminal4 in front of the dis-
charged battery with the jumper
cables. Clamp cable to charged
battery3 first.

Start the engine of the disabled
vehicle.
Now you can turn on the electrical con-
sumers. Do not turn on the lights under
any circumstances.

Remove the jumper cables first from
negative terminals4 and3 and then
from positive terminals2 and1.
You can now turn on the lights.

Have the battery checked at the
nearest authorized Mercedes-Benz
Center.
Warning!
G
Keep flames or sparks away from battery.
Do not smoke.
Observe all safety instructions and precau-
tions when handling automotive batteries
(page 297).
!Vehicles with automatic transmission:
Do not tow-start the vehicle.

446 IndexBolts
For spare wheel 376
Brake
Indicator lamp 25
Brake assist system (BAS) 437
Brake fluid 290, 428
Checking 290
Message in display 358
Brake lamp bulbs 385
Brake pads
Message in display 358
Brakes 278
Warning lamp 341
Break-in period 276
Bulbs, replacing 384
Additional turn signals 385
Brake lamps 385
Fog lamps 385
Front lamps 385
High beam 385
High beam flasher 385
License plate lamps 385, 392
Low beam 385
Parking lamps 385, 388, 390
Rear fog lamp 385, 390
Rear lamps 385Side marker lamp 391
Side marker lamps 385, 390
Standing lamps 385, 388, 390
Tail lamp assemblies 385
Tail lamp unit 390
Turn signal lamps 385
Button
Audio system 198
C
CAC (Customer Assistance Center) 437
Calling up
Range (distance to empty) 152
Service indicator 331
CAN system 437
Capacities
Fuels, coolants, lubricants, etc. 426
Cargo compartment
Lighting 118
Tie-down rings 253
Cargo tie-down rings 253
Catalytic converter 285
CD changer* 213
CD changer* operation 215
CD player
Operating 131
CD* operation 213Center console 27
Front passenger front air bag off indica-
tor lamp 27, 76, 345
Lower part 28
Upper part 27
Centigrade
Setting temperature units 137
Central locking
Automatic 97
From inside 98
Switch 98
Switching on/off (control
system) 148
Unlocking from inside 98
Central locking switch 98
Changing
CDs 213
Key setting 148
Charcoal filter 191
Activating 191
Deactivating 192
Charging
Vehicle battery 402
CHECK ENGINE malfunction indicator
lamp 342

454 IndexInstrument cluster 24, 119, 439
Cleaning 337
Coolant temperature display 120
Illumination 119
Lamps in 343–344
Multifunction display 123
Outside temperature indicator 121
Selecting language 138
Instrument lighting 119
Instruments and controls see Cockpit
Interior lighting 117
Activating automatic control 117
Deactivating automatic control 117
Delayed shut-off (Control
system) 147
Manual operation 118
Interior rear view mirror
Adjusting 42
Antiglare (manual) 167
Interior storage spaces
Armrest 255
Cup holders 256
Intermittent wiping 54J
Jack 373
Jump starting 404
K
Key dependency memory
Settings 149
Key positions in starter switch 33
Key, mechanical 377
Key, SmartKey
Battery check lamp 92
Checking the batteries 93
Factory setting 92
Global locking 92
Global unlocking 92
Loss of 94
Messages in display 365
Positions in starter switch 33
Remote control 90
Restoring to factory setting 93
Selective setting 92
Starting the engine 48, 49
Unlocking with 32
Kickdown 165, 439
Kilometers/miles in speedometer 137
Kilopascal 324
Km/h or mph in speedometer 137L
Labels, identification 416
Lamp bulbs, exterior 384
Lamps, exterior
Front 385
Light sensor 367
Messages in display 366–370
Rear 385
Lamps, indicator and warning
ABS 340
Air bag Off 66
Battery (SmartKey) 92
Brake 25
Brakes 341
CHECK ENGINE 342
Engine diagnostics 342, 344
ESP 343
Fuel reserve 344
Instrument cluster 343–344
Low beam 25
Seat belts 344
Service indicator 330
SRS 61, 344
Language
Multifunction display 138
Setting 138

467 Index
Useful features 254
Ashtrays 257, 258
Cigarette lighter 259
Electrical outlet 260
Storage compartments 254
Tele Aid* 261
Telephone* 260
V
Vehicle
Individual settings 133, 136
Locking 27
Locking in an emergency 379
Lowering 400
Performance in cold weather 431
Performance in hot weather 432
Service battery 401
Towing 406
Unlocking 27
Unlocking in an emergency 377
With flexible fuel 431
Vehicle battery 401
Vehicle capacity weight 326Vehicle care 333
Cup holders 337
Engine cleaning 335
Gear selector lever 337
Hard plastic trim items 337
Headlamps 335
Instrument cluster 337
Leather upholstery 338
Light alloy wheels 336
MB Tex upholstery 338
Ornamental moldings 335
Paintwork 334
Plastic and rubber parts 338
Power washer 334
Seat belts 337
side markers 335
Steering wheel 337
Tail lamps 335
Tar stains 334
Turn signals 335
Upholstery 338
Vehicle washing 335
Window cleaning 336
Wiper blades 336
Wood trims 338Vehicle jack 374
Vehicle lighting
Checking 290
Vehicle loading terminology 323
Vehicle maximum load on the tire 326
Vehicle status message memory 132
Vehicle tool kit 373
Air pump 373
Alignment bolt 373
Collapsible wheel chock 373
Gloves 373
Spare fuses 373
Special fuse puller 373
Towing eye bolt 373
Vehicle jack 373
Wheel bolts 373
Wheel wrench 373
Vehicle washing 335
VIN (Vehicle Identification Number) 441
Viscosity
Engine oil 438
Voice control system*
Hands-free microphone 29
