2005 MERCEDES-BENZ C CLASS COUPE climate control

192 Controls in detailAutomatic climate control*Deactivating
Press buttone (
page 183).
The indicator lamp on the button goes
out.
Air conditioning
The air conditioning is operational while
the engine is running and cools the interior
air to the temperature set by the operator. Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the automatic
climate control system. The air in the
vehicle will then no longer be cooled or
dehumidified.
Automatic climate control panel
design A

Press button
° (
page 183).
The indicator lamp on the button
comes on.
The cooling function switches off after
a short delay.
Automatic climate control panel
design B

Press button 2 (
page 183).
The indicator lamp on the button goes
out.
The cooling function switches off after
a short delay.
iIf you keep button e pressed, the
side windows and panorama roof with
power tilt/sliding panel* will return to
their previous position.
iCondensation may drip out from under-
neath the vehicle. This is normal and
not an indication of a malfunction.Warning!
G
If you turn off the cooling function, the
vehicle will not be cooled when weather
conditions are warm. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.

193
Controls in detail
Automatic climate control*
Activating
Moist air can fog up the windows. You can
dehumidify the air with the air condi-
tioning.
Automatic climate control panel
design A
Press button
° (
page 183) again.
The indicator lamp on the button goes
out.
The cooling function is switched on.
Automatic climate control panel
design B

Press button 2 (
page 183) again.
The indicator lamp on the button
comes on.
The cooling function is switched on.
The air conditioning uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer. Residual heat and ventilation
(available on automatic climate control
panel design A only)
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.
Activating
Switch off the ignition (
page 58).

Press button
° (
page 183).
The indicator lamp on the button
comes on. Deactivating

Press button
° (
page 183).
The indicator lamp on the button goes
out.
The residual heat is automatically turned
off:


when the ignition is switched on


after about 30 minutes


if the battery voltage drops
!If the air conditioning cannot be turned
on again, this indicates that the air
conditioning is losing refrigerant. The
compressor has turned itself off.
Have the air conditioning checked at
the nearest authorized Mercedes-Benz
Center.
iHow long the system will provide
heating depends on

the coolant temperature


the temperature set by the operator
The blower will run at speed setting 1
regardless of the air distribution
control setting.

194 Controls in detailAutomatic climate control*Rear passenger compartment adjustable air vents
The air conditioning for the rear passenger
compartment is controlled via the auto-
matic climate control panel (
page 183).
The air vents for the rear passenger
compartment are located in the rear
center console. 1
Left center air vent
2 Thumbwheel for air volume control for
center air vents
3 Right center air vent Adjusting air distribution

Push the slide for the left center
vent
1 or right center vent 3 to the
left, right, up, or down.
The air flow is directed in the
corresponding direction.
Adjusting air volume

Turn thumbwheel 2 up or down.
The air volume is increased or
decreased.
iThe temperature at the center air vents
for the rear passenger
compartment 1 and 3 i s t h e s a m e a s
at the dashboard center air vents.
iFor draft-free ventilation, push
slides 1 and 3 upward.

238 Controls in detailPower windows
Switch on the ignition (
page 33).Opening the windows

Press switch
1 or 2 to the resistance
point.
The corresponding window will move
downwards until you release the
switch.
Closing the windows

Pull switch 1 or 2 to the resistance
point.
The corresponding window will move
upwards until you release the switch. Fully opening the windows
(Express-open)

Press switch
1 or 2 past the resis-
tance point and release.
The corresponding window opens com-
pletely.
Fully closing the windows
(Express-close)

Pull switch 1 or 2 past the resis-
tance point and release.
The corresponding window closes com-
pletely.
iYou can also open or close the power
windows using the SmartKey (summer
opening/convenience closing feature)
(page 239).
You can close and reopen the windows
using the air recirculation button ,
in the climate control panel
(page 173) or automatic climate
control panel (
page 183).
You can close and reopen the windows
using the charcoal filter button e in
the automatic climate control
panel*(
page 183).
Warning
G
If you pull and hold the switch up when clos-
ing the window, and upward movement of
the window is blocked by some obstruction
including but not limited to arms, hands, fin-
gers, etc., the automatic reversal will not op-
erate.

244 Controls in detailPanorama roof with power tilt/sliding panel*
Switch on the ignition (
page 33).Opening and closing the panorama roof
with power tilt/sliding panel

To open, close, raise, or lower the
tilt/sliding panel, move the roof panel
switch to resistance point in the re-
quired direction of arrows
1to4 .
Release the roof panel switch when the
tilt/sliding panel has reached the de-
sired position.
Fully opening (Express-open) the
panorama roof with power tilt/sliding
panel

Move the roof panel switch past the
resistance point in the direction of
arrow 4 and release.
The tilt/sliding panel opens
completely.
Stopping the panorama roof with power
tilt/sliding panel during Express-open

Move the roof panel switch in any
direction. Opening the panorama roof with power
tilt/sliding panel with the SmartKey
The power windows (
page 237) will also
be opened or closed when you operate the
tilt/sliding panel with the SmartKey.
iYou can also open or close the tilt/slid-
ing panel using the SmartKey (summer
opening/convenience closing feature)
(page 244).
You can close and reopen the tilt/slid-
ing panel using the air recirculation
button , in the climate control pan-
el (page 173) or automatic climate
control panel (
page 183).
You can close and reopen the tilt/slid-
ing panel using the charcoal filter but-
ton e in the automatic climate
control panel*(page 183).
Warning!
G
Never operate the windows or tilt/sliding
panel if there is the possibility of anyone be-
ing harmed by the opening or closing proce-
dure.
In the event that the procedure causes po-
tential danger, the procedure can be imme-
diately halted by releasing the button on the
SmartKey. To reverse direction of move-
ment, press Œ for opening or ‹ for
closing.

321
Operation
Tires and wheels
Quality grades can be found, where appli-
cable, on the tire sidewall between tread
shoulder and maximum section width. For
example:
All passenger car tires must conform to
federal safety requirements in addition to
these grades.
Treadwear
The treadwear grade is a comparative rat-
ing based on the wear rate of the tire when
tested under controlled conditions on a
specified government test course. For ex-
ample, a tire graded 150 would wear one
and one-half (1
1/2) times as well on the
government course as a tire graded 100.
The relative performance of tires depends
upon the actual conditions of their use,
however, and may depart significantly
from the norm due to variations in driving
habits, service practices and differences in
road characteristics and climate. Traction
The traction grades, from highest to low-
est, are AA, A, B, and C. Those grades rep-
resent the tire’s ability to stop on wet
pavement as measured under controlled
conditions on specified government test
surfaces of asphalt and concrete. A tire
marked C may have poor traction perfor-
mance.
Treadwear
Traction
Temperature
200
AA
A
Warning!
G
The traction grade assigned to this tire is
based on straight-ahead braking traction
tests, and does not include acceleration,
cornering, hydroplaning, or peak traction
characteristics.

443
Index
A
ABS 25, 81, 437
Malfunction indicator lamp 340
Messages in display 353
Warning lamp 340
Accelerator position, automatic transmission* 165
Accessory weight 323
Accident In case of 55
Activating Air conditioning (cooling) 193Climate control 179
Air recirculation mode 189 Climate control 177
Anti-theft alarm system 86
Automatic climate control* 183
Central locking (control system) 148
Charcoal filter 191
Climate control 173
Climate control system 175
Defrosting 188 Climate control 177
Easy-entry/exit feature* 148
Electric air pump 399
ESP 85 Exterior headlamps 51
Exterior lamps 111
Exterior rear view mirror parking
position* 169
Hazard warning flasher 116
Headlamps 51
High beams 114
Ignition 33
Immobilizer 86
Rear fog lamp 113
Rear window defroster 170
Residual heat 193
Seat heating* 106
Tow-away alarm 88
Windshield wipers 53
Adding Coolant 296, 297
Engine oil 294
Headlamp cleaning fluid 299
Windshield washer fluid 299
Additional turn signals 385
Adjustable air vents, rear passenger compartment 194Climate control 180 Adjusting 35
Air distribution 186 Climate control 176
Air volume 187 Climate control 176
Backrest tilt 36, 38
Exterior rear view mirrors 42
Head restraint height 37, 38
Head restraint height, rear seats 103
Head restraint tilt 37, 39
Head restraint tilt, rear seats 105
Head restraints, rear seats Folding back 104
Placing upright 105
Instrument cluster illumination 119
Interior rear view mirror 42
Manual seat 36
Mirrors 42
Rear seat head restraints 103
Seat cushion tilt 36, 38
Seat fore and aft adjustment 36, 38
Seat height 36, 38
Seats 35
Steering column height 42
Steering column length 42
Steering wheel 40

444 IndexAdjusting sound functions 199
Adjusting the volume 199
Air bags 61Children 62
Front 65
Front passenger front air bag off indica-tor lamp 27, 76, 345
Passenger 65
Safety guidelines 64
Side impact 66
Window curtain 66
Air conditioner refrigerant 428
Air conditioning (cooling) Turning off 192 Climate control 179
Turning on 192 Climate control 179
Air distribution Adjusting 186 Climate control 176
Air pressure 323
Air pressure see Tire inflation pressure
Air pump, electric Turning on 399 Air recirculation mode 189
Activating 189Climate control 177
Deactivating 190 Climate control 178
Air vents, rear passenger compartment Adjustable 194Climate control 180
Air volume Adjusting 187Climate control 176
Alarm Audible 80, 87, 88
Canceling 87, 88
Visual 86
Alarm system Anti-theft 86
Alignment bolt 396
Alignment bolt (vehicle tool kit) 437
Anticorrosion/antifreeze 433
Antiglare Automatic* 168
Manual 167
Antilock brake system (ABS) 437 Anti-theft alarm system
Arming 86
Canceling alarm 87, 88
Disarming 87
Anti-theft systems 86 Anti-theft alarm system 86
Immobilizer 86
Tow-away alarm 87
Aquaplaning 281
Armrest Storage spaces 255
Ashtrays Center console 257
Rear seat 258
Aspect ratio 323
ATF (automatic transmission fluid) 296
AUDIO menu 129 Selecting radio station 130
Selecting satellite radio* station 130
