2005 MERCEDES-BENZ C CLASS COUPE remote control

273
Controls in detail
Useful features
Step 9:
Press “training” button on the garage
door opener motor head unit.
The “training light” is activated.
You have 30 seconds to initiate the
following step.
Step 10:

Firmly press, hold for two seconds and
release the programmed integrated
signal transmitter button ( 2, 3
or 4 ).
Step 11:

Press, hold for two seconds and
release same button a second time to
complete the training process.
Some garage door openers (or other rolling
code equipped devices) may require you to
perform this procedure a third time to
complete the training.
Step 12:

Confirm the garage door operation by
pressing the programmed integrated
signal transmitter button ( 2, 3
or 4 ).
Step 13:

To program the remaining two buttons,
repeat the steps above starting with
step 3.
Gate operator/Canadian programming
Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission
which may not be long enough for the inte-
grated signal transmitter to pick up the
signal during programming. Similar to this
Canadian law, some U.S. gate operators
are designed to “time-out” in the same
manner.
If you live in Canada or if you are having
difficulties programming a gate operator
(regardless of where you live) by using the
programming procedures, replace step 4
with the following: Step 4:

Continue to press and hold the inte-
grated signal transmitter button (
2,
3 or 4) while you press and re-press
(“cycle”) your hand-held remote con-
trol transmitter 6 every two seconds
until the frequency signal has been
learned. Upon successful training, the
indicator lamp 1 will flash slowly and
then rapidly after several seconds.

Proceed with programming step 5 and
step 6 to complete.
Operation of integrated remote control

Switch on the ignition.

Select and press the appropriate inte-
grated signal transmitter button ( 2,
3 or 4) to activate the remote con-
trolled device.
The integrated remote control trans-
mitter continues to send the signal as
long as the button is pressed – up to
20 seconds.

274 Controls in detailUseful featuresErasing the remote control memory
Switch on the ignition.

Simultaneously hold down the signal
transmitter buttons2 and 4, for
approximately 20 seconds, until the
indicator lamp 1 blinks rapidly. Do not
hold for longer than 30 seconds.
The codes of all three channels are
erased. Reprogramming a single integrated
signal transmitter button
To program a device using a signal trans-
mitter button previously trained, follow
these steps:

Press and hold the desired signal trans-
mitter button (
2, 3 or 4). Do not
release the button.

The indicator lamp will begin to flash af-
ter 20 seconds. Without releasing the
integrated signal transmitter button,
proceed with programming starting
with step 3.
iIf you sell your vehicle, erase the codes
of all three channels.

288 OperationAt the gas stationRefuelingThe fuel filler flap is located on the
right-hand side of the vehicle towards the
rear. Locking/unlocking the vehicle with
the remote control automatically
locks/unlocks the fuel filler flap.
1 To open the fuel filler flap
2 Supplemental tire inflation pressure
table
3 To insert the fuel filler cap

Turn off the engine.

Remove the SmartKey from the starter
switch.
Warning!
G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious inju-
ry. Whenever you are around gasoline, avoid
inhaling fumes and skin contact, extinguish
all smoking materials. Never allow sparks,
flame or smoking materials near gasoline!
Warning!
G
Flexible Fuel Vehicles (identified by a label
reading Premium gasoline or E85 only! on
fuel filler flap):
Ethanol fuel (E85) and its vapors are highly
flammable, poisonous and burn easily. Etha-
nol fuel can cause serious injuries if ignited
or if you come into contact with it or inhale
fumes of it. Avoid inhalation of ethanol
fumes and skin contact with ethanol. Extin-
guish all open flames before refueling. Never
smoke or create sparks close to ethanol.

450 IndexDownhill drivingCruise control 248
Downshifting Automatic transmission* 160
Manual transmission 158
Drinking and driving 277
Driving Aquaplaning 281
General instructions 44, 277
In winter 283
Problems 55
Safety systems 81
Through standing water 284
Driving abroad 284
Driving instructions 277
Driving off 279
Driving safety systems ABS 81
BAS 82
ESP 83
Driving systems 247 Cruise control 247
Driving safety systems 81 E
Easy-entry/exit feature* 100
Activating 148
Electrical fuses 410
Electrical outlet 260
Electrical system Technical data 423
Electronic Stability Program see ESP 438
Emergency call system* 262
Emergency calls "911" 234
Initiating an emergency call 264
With Tele Aid* 263
Emergency operation (Limp Home Mode) 166
Emergency operations Closing panorama roof with power tilt/sliding panel* 381
Locking the vehicle 379
Opening panorama roof with power tilt/sliding panel* 381
Releasing trunk lid from inside 96
Remote door unlock 268
Unlocking the Trunk lid 378
Unlocking the vehicle 377 Emergency tensioning device see
ETD 438
Emission control 286
Emission control label 416
Ending A call (telephone*) 154
Engine Compartment 291
Starting with automatic transmission* 49
Starting with manual transmission 48
Starting with the SmartKey 48, 49
Technical data 418
Turning off with the key 58
Engine cleaning 335
Engine compartment 291 Fuse box in 411
Hood 291
Engine malfunction indicator lamp 25, 342
Engine number 438

454 IndexInstrument cluster 24, 119, 439Cleaning 337
Coolant temperature display 120
Illumination 119
Lamps in 343–344
Multifunction display 123
Outside temperature indicator 121
Selecting language 138
Instrument lighting 119
Instruments and controls see Cockpit
Interior lighting 117 Activating automatic control 117
Deactivating automatic control 117
Delayed shut-off (Control system) 147
Manual operation 118
Interior rear view mirror Adjusting 42
Antiglare (manual) 167
Interior storage spaces Armrest 255
Cup holders 256
Intermittent wiping 54 J
Jack 373
Jump starting 404
K
Key dependency memory
Settings 149
Key positions in starter switch 33
Key, mechanical 377
Key, SmartKey Battery check lamp 92
Checking the batteries 93
Factory setting 92
Global locking 92
Global unlocking 92
Loss of 94
Messages in display 365
Positions in starter switch 33
Remote control 90
Restoring to factory setting 93
Selective setting 92
Starting the engine 48, 49
Unlocking with 32
Kickdown 165, 439
Kilometers/miles in speedometer 137
Kilopascal 324
Km/h or mph in speedometer 137 L
Labels, identification 416
Lamp bulbs, exterior 384
Lamps, exterior
Front 385
Light sensor 367
Messages in display 366–370
Rear 385
Lamps, indicator and warning ABS 340
Air bag Off 66
Battery (SmartKey) 92
Brake 25
Brakes 341
CHECK ENGINE 342
Engine diagnostics 342, 344
ESP 343
Fuel reserve 344
Instrument cluster 343–344
Low beam 25
Seat belts 344
Service indicator 330
SRS 61, 344
Language Multifunction display 138
Setting 138

460 IndexRange (distance to empty)Calling up 152
Reading lamp 29
Rear bench seat Foldable 250
Rear fog lamp 385 Bulb 385
Switching on 113
Rear lamp bulbs Replacing 390
Rear lamps Messages in display 366–370
Rear lamps see Tail lamps
Rear passenger compartment Adjustable air vents 194
Rear passenger compartment, adjustable air ventsClimate control 180
Rear seat head restraints 103 Adjusting 103
Adjusting tilt 105
Folding back 104
Installing 105
Placing upright 105
Removing 105
Seats 105 Rear seats
Adjusting head restraint height 103
Head restraints 103
Rear view mirrors see Mirrors
Rear window defroster 170 Activating 170
Deactivating 170
Recommended tire inflation pressure 325
Reconnecting Vehicle battery 403
Refilling Coolant 296
Headlamp cleaning system* 299
Refrigerant Air conditioner 428
Refuelling 288
Regular checks 290
Reinstalling vehicle battery 402
Remote control SmartKey 90
Remote door unlock With Tele Aid* 268 Removing
Spare wheel 375
Vehicle battery 402
Wheel 396
Wiper blades 393
Replacing Backup lamp bulbs 390
Batteries (SmartKey) 382, 383
Brake lamp bulbs 390
Bulbs 384
Front lamp bulbs 385, 386
Front turn signal bulbs 388, 389
High beam bulbs (xenon-type* headlamps) 389
License plate lamp bulbs 392
Low beam bulbs 387
Parking lamp bulbs 388, 390
Rear fog lamp bulb 390
Rear lamp bulbs 385, 390
Rear turn signal bulbs 390
Side marker lamp bulbs 390, 391
Standing lamp bulbs 388, 390
Wiper blades 393
Reset button in the instrument cluster 134, 135
