2005 MAZDA MODEL 3 HATCHBACK Quick Tips (in English)

SEATS
Always check the Owner’s Manual for more operating information and safety features
1. Air flow selections
= air to dash
= air to dash and floor
= air to floor
= air to floor and windshield
= defrost, air to windshield
2. Fan control
Rotate knob right/left to
increase/decrease speed, turn
to 0to shut system off
3. Temperature control
Rotate knob to blue for cool,
red for warm
4. Air Conditioning*
Press to activate/deactivate
Tip: Floor position
and both defrost positions
/ : A/C turns ON, air
intake switches to fresh air
5. Air Intake Control
Push switch to select
= recirculate inside air;
use for maximum heating/
cooling or to keep odors out
= fresh air
WARNING: Do not use
position in cold weather;
windows will fog and
hamper vision
6. Rear window defogger
Press to activate/deactivate
Child-safety seat
To install in rear outboard
seats: Use dual locking mode
retractor seat belts; see
Owner’s Manual for proper
installation and child seat
tether and LATCH system
instructions
Control positions for
maximum defrost
Fan to maximum, temperature to
maximum hot, air flow selector
knob to
Tips: When selected, air is
dried when temperature is
above 39°F
To prevent moisture buildup,
never drive with system off
Objects placed under the front
seats may interfere with air
flow to the rear
WARNING: Use age
appropriate child restraints,
see Owner’s Manual and
state or province laws
Seats
Climate
Controls
Quick Tips Mazda MAZDA3 page 16
page 17
MODE
04132
A/C
546
123
*If equipped
Split fold-down
rear seatbacks
To fold: Push release knob (1),
push seatback down
To return and lock: Push
seatback firmly until latched,
make sure seatbelts are returned
to original positionsTip: 4-Door has seatback
locks as part of trunk
security
11


RADIO/COMPACT DISC
Always check the Owner’s Manual for more operating information and safety features
CD: Press to select
next/previous track
Tape: Press to automatically
advance tape to beginning of
next selection/replay selection;
to stop this operation, press
button again
6. Scan
Press to briefly sample next
listenable selections; functions
in all modes
7. RPT
Press to replay current CD/
tape selection
8. Clock
To set: With ignition in ACC or
ON position, press (8) and hold
until beep sounds; 12 hr/24 hr
will be displayed; press SET (9)
to select; press (8) again while
selection is flashing: Hr ADJUST
displays; press SET (9) to select
hr; press (8) when done, do
the same to set minutes
/
/
Audio systems1. Power/Volume
Press to turn on/off; rotate
to increase/decrease volume
2. Program Random
†Press to enable/cancel
random play
3. Tune/Auto-Memory display
Radio: Press and hold until a beep
sound is heard; system auto-
matically scans and temporarily
stores six strong stations in each
band; press again to switch to
another preset station
Tune: Rotate counterclockwise/
clockwise for lower frequency/
higher frequency
4. Program
Press to change cassette
tape-play direction
5. SEEK/TRACK/APC
Radio: Press to
automatically seek higher/
lower frequency
/
11. SAT*
Satellite ready capability
12. CD
Press to play CD
13. Tape*/MD*
Press to play Mini-disc Player/
cassette tape
14. LOAD*
To load multiple discs: Press
and hold LOAD (14) until beep
sound is heard; insert CD
when “In” is displayed
To eject disc: Press Eject (16)
To eject specific disc: Press and
hold Eject (16) until beep sound
is heard; within five seconds
press the desired tray
number 1-6 (17)
15. CD slot
16. CD eject button
17. Memory preset buttons
To set: Tune to station, press and
hold until beep sound is heard 9. SET
Clock setting button,
see Clock (8)
10. FM/AM
Press to turn radio on and
select between FM1/FM2/AM
station preset buttons (17)
21. Cassette door*
22. Eject button*
23. Dolby
®Noise
Reduction*
Reduces tape noise and hiss;
press to activate/deactivate
24. Mini Disc slot*
25. Text/Audio Control
Audio control: Press to select
ALC/BASS/MID/TREBLE/FADE/
BAL/BEEP ON/ILLM ON
Rotate right/left to adjust
selected feature
Tip: Automatic Level Control
(ALC) automatically adjusts
audio volume depending
on vehicle speed
26. Reverse
Press to reverse through
a track
18. Disc up†
Press to skip forward to
beginning of next CD
19. Disc down
†
Press to skip back to beginning
of previous CD
20. Fast forward
Press to fast forward
through a track
Audio
Systems
Audio
Systems
Quick Tips Mazda MAZDA3 page 18
page 19
*If equipped†For use with CD, or CD changer*
LOADCLOCK
SCAN
PROGRPT
RDM
1
42
53
6
VOL
FM /AM SET SAT CD TAPE/MD
3122625
8910111214151613
65
7
4
1819202223
2224
21
17 . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .


TRUNK/CARGO AREA
Always check the Owner’s Manual for more operating information and safety features
Trunk/
Cargo Area
Trunk/
Cargo Area
Quick Tips Mazda MAZDA3 page 20
page 21
Luggage
compartment
internal safety
release
Allows you to escape
should you become locked in trunk
Slide illuminated release lever in
direction of arrow; lever will glow
if it has been exposed to light
Located on interior trunk lid MAZDA3 5-Door
1. Temporary spare tire
Stored under panel in trunk;
to change flat tire: Follow
instructions in Owner’s Manual
WARNING: Do not exceed
50 mph with temporary spare
Tip: Do not use temporary
spare tire for long periods
of time
Tire economy and tips
Check pressure at least monthly
when tires are cold
Tires should be of the same
make, kind and dimension
Maintain correct front-end
alignment and tire balance;
rotate tires at 7,500-mile
intervals; see Owner’s Manual
for rotation chartTire pressure
Decal on driver’s door provides
tire pressure information
Tire chains*
†Use only SAE Class “S” chains;
install on front tires as tightly
as possible and re-tighten
periodically; do not use chains
on dry roads, aluminum wheels,
or with tire pressure monitor
system, damage may occur,
use on steel wheels only2. Lug wrench
3. Jack handle
4. Cargo securing loops
5. Jack
6. Cargo light
7. Front tiedown eyelet
8. Cargo area cover
MAZDA3 4-Door
1. Temporary spare tire
Stored under panel in trunk;
to change flat tire: Follow
instructions in Owner’s Manual
WARNING: Do not exceed
50 mph with temporary spare
Tip: Do not use temporary
spare tire for long periods
of time
2. Lug wrench
3. Front tiedown eyelet
4. Jack
5. Jack handle
6. Cargo securing loops
7. Rear seatback lock
(4-Door only)
Lock or unlock: Move lever
8. Cargo light
164432587
2
8
415
76 76
3
*If equipped†See Owner’s Manual


UNDER HOOD
Always check the Owner’s Manual for more operating information and safety features
Under Hood
Quick Tips Mazda MAZDA3 page 22
page 23
1. Engine coolant reservoir
Level should be between COLD
FILL RANGE indicator marks
WARNING: Never remove
coolant reservoir cap while
engine is running or hot;
remove only when safe
2. Engine oil filler cap
See Owner’s Manual for
recommended engine oil viscosity
Break-in period
First 600 miles: Avoid heavy
braking and acceleration; drive at
varying road and engine speeds
Tip: Follow the same procedures
with newly overhauled engine
or when brakes are replaced
Tip: For additional service
intervals and complete details,
see Owner’s Manual
3. Brake/clutch fluid reservoir
Fill to MAX mark with DOT 3
fluid; check with cap on
Tip: Clutch uses same
reservoir as brakes
4. Automatic transaxle
fluid dipstick*
Check with transaxle in park,
engine on and at operating
temperature
Maintenance notes:
Rotate tires every 7,500
miles or sooner if needed
A. Replace: Engine oil/filter
B. Inspect: Cooling system, fuel
lines and hoses, brake lines,
hoses and connections,
steering operation and linkages,
front and rear suspension
and ball joints, drive-shaft
dust boots
Replace: Air filter
C. Inspect: Drive belts (tension)
D. Inspect: Hoses and tubes for
emission system
Replace: Engine coolant
E. Inspect: Engine valve clearance
Replace: Spark plugs
F. Inspect: Disc brakes
G. Inspect: Exhaust system and
heat shields 5. Battery
6. Fuse panel
Push latch in, lift cover must
be between the indicator
marks on the dipstick
7. Air filter
8. Hood latch
Pull up to release hood
9. Engine oil dipstick
Fluid should be between F and
L on dipstick; do not fill above F
10. Power steering fluid
reservoir
Level should be between
MIN and MAX lines
11. Windshield washer reservoir
Fill with windshield
washer fluidTip: Check all fluids with
vehicle parked on a level
surface and engine off
unless otherwise stated
12345
81110976
2.0/2.3-liter Engine
*If equipped†See Owner’s Manual
NORMAL SERVICE INTERVALS
5,000 miles†
7,500 miles
15,000 miles
22,500 miles
30,000 miles
37,500 miles
45,000 miles
52,500 miles
60,000 miles
67,500 miles
75,000 miles
82,500 miles
90,000 miles
A BF G A
A
C E F A A
B D F A A
F G A C A
BF A
A F A
A
