INTRODUCTION
320
NOTICE

Remember that battery and ignition cables carry high
currents or voltages. Be careful of accidentally causing a short circuit.

Add only ªT oyota Super Long Life Coolantº or similar
high quality ethylene glycol based non±silicate, non± amine, non±nitrite, and non±borate coolant withlong±life hybrid organic acid technology to fill theradiator. ªToyota Super Long Life Coolantº is a mix-ture of 50% coolant and 50% deionized water (for the
U.S.A.) or 55% coolant and 45% deionized water (forCanada).

If you spill some of the coolant, be sure to wash it offwith water to prevent it from damaging the parts orpaint.

Before closing the engine hood, check to see that you
have not forgotten any tools, rags, etc.

Do not drive with the air cleaner removed, or excessive engine wear could result. Also backfiringcould cause a fire in the engine compartment.

Do not overfill automatic transmission fluid, or thetransmission could be damaged.

Be careful not to scratch the glass surface with thewiper frame.
PARTS AND TOOLS
Here is a list of parts and tools you will need to perform
do±it±yourself maintenance. Remember all Lexus parts are
designed in metric sizes, so your tools must be metric.
CHECKING THE ENGINE OIL LEVEL
Parts (if level is low):

ªToyota Genuine Motor Oilº or equivalent
Oil grade: API grade SL ªEnergy±Conservingº or ILSAC
multigrade engine oil. For recommended oil viscosity, see page 335.
Tools:

Rag or paper towel

Funnel (only for adding oil)
CHECKING THE ENGINE COOLANT LEVEL
Parts (if level is low):

ªToyota Super Long Life Coolantº or similar high quality
ethylene glycol based non±silicate, non±amine, non±nitrite,
and non±borate coolant with long±life hybrid organic acid technology.
ªToyota Super Long Life Coolantº is a mixture of 50%
coolant and 50% deionized water (for the U.S.A.) or 55% coolant and 45% deionized water (for Canada).
Tools:

Funnel (only for adding coolant)
04 06.30

SECTION 6 ± 2
325
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications326
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 329
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel pump shut off system 331
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . .
Facts about engine oil consumption 331
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . .
Used engine oil 333
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the engine oil level 333
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . .
Checking the engine coolant level 337
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Checking the radiator and condenser 338
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Spark plugs 339
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
04 06.30

ENGINE
328± COOLING SYSTEM
Capacity
7.5 L (7.9 qt., 6.6 lmp.qt.)
Coolant typeªToyota Super Long Life Coolantº or similar high quality ethylene glyco\
l
based non±silicate, non±amine, non±nitrite, and non±borate c\
oolant with
long±life hybrid organic acid technology. (Coolant with long±life hybrid
organic acid technology is a combination of low phosphates and organic
acids.)
Do not use plain water alone.
NOTE:
ªToyota Super Long Life Coolantº is used in your Lexus vehicle at facto\
ry fill. In order to avoid technical problems, only use ªToyota
Super Long Life Coolantº or similar high quality ethylene glycol based non±\
silicate, non±amine, non±nitrite, and non±borate coolant
with long±life hybrid organic acid technology. (Coolant with long±life hybrid organic acid technology is a combin\
ation of low
phosphates and organic acids.) Do not use plain water alone. Please con\
tact your Lexus dealer for further details.
± FUEL
Fuel type
Unleaded gasoline only
Octane rating91 (Research octane number 96) or higher
± IGNITION SYSTEMSpark plug ± Make DENSO ± Gap
SK16R±P11
1.1 mm (0.043 in.)
± ELECTRICAL SYSTEM
Battery ± Open voltage at 20 C (68F):
Charging rates
12.7 V Fully charged
12.3 V Half charged
11.9 V Discharged
[Voltage that is checked 20 minutes after the key is removed with all the
lights turned off]
5A max.
04 06.30

ENGINE
332The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way the
vehicle is driven.
More oil is consumed under driving conditions such as high
speeds and frequent acceleration and deceleration.
A new engine consumes more oil, since its pistons, piston rings
and cylinder walls have not become conditioned.
Oil consumption:
Max. 1.0L per 1000 km (1.1 qts./600 miles,
0.9 Imp. qts./600 miles)
When judging the amount of oil consumption, keep in
mind that the oil may have become diluted, making it
difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips and
consumes a normal amount of oil, the dipstick may not show
any drop in the oil level at all, even after 1000 km (600 miles)
or more. This is because the oil is gradually becoming diluted
with fuel or moisture, making it appear that the oil level has not
changed.
The diluting ingredients evaporate out when the vehicle is then
driven at high speeds, as on an expressway, making it appear
that oil is excessively consumed after driving at high speeds.
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum level so
that oil function will not be impaired. Therefore, it is essential
that the oil level be checked regularly. Lexus recommends that
the oil level be checked every time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to serious engine trouble due to insufficient oil.
For detailed information on oil level check, see ªChecking the
engine oil levelº on page 333.
04 06.30

ENGINE
333
USED ENGINE OIL
CAUTION
Used engine oil contains potentially harmful
contaminants which may cause skin disorders such
as inflammation or skin cancer, so care should be
taken to avoid prolonged and repeated contact with
it. To remove used engine oil from your skin, wash
thoroughly with soap and water.
 Do not leave used oil within the reach of children.
 Dispose of used oil and used oil filters only in a safe
and acceptable manner. Do not dispose of used oil
and used oil filters in household trash, in sewers or
onto the ground. Call your Lexus dealer or a service
station for information concerning recycling or
disposal.
CHECKING THE ENGINE OIL LEVEL
SV62004
With the engine at operating temperature and turned off,
check the oil level on the dipstick.
1. To get a correct reading, the vehicle should be on level
ground. After turning off the engine, wait a few minutes for the
oil to drain back into the bottom of the engine.
2. Pull the dipstick out, hold a rag under the end and wipe it
clean.
3. Reinsert the dipstick and push it in as far as it will go, or the
reading will not be correct.
04 06.30

ENGINE
334
SV62002

1Add oil 2O.K. 3Too full
4. Pull the dipstick out and look at the oil level while holding a
rag under the end. If it is between the low level mark ( 4 ) and
the full level mark ( 5 ), it is O.K.
NOTICE
Be careful not to drop engine oil on the vehicle
components.
SV62008
If the oil level is below or only slightly above the low level
mark, add engine oil of the same type as already in the
engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil.
The approximate quantity of oil needed to raise the level
between low and full on the dipstick is indicated below for
reference.
When the level reaches within the correct range, return the
filler cap and turn the cap clockwise until you hear a click.
Oil quantity. L (qt., lmp. qt.) 1.8 (1.9, 1.6)
04 06.30

ENGINE
335
NOTICE
Be careful not to spill engine oil on the vehiclecomponents.
Avoid overfilling, or the engine could be damaged.Check the oil level on the dipstick once again afteradding the oil.
Engine oil selection
ªToyota Genuine Motor Oilº is used in your Lexus vehicle. Use
Lexus approved ªToyota Genuine Motor Oilº or equivalent to
satisfy the following grade and viscosity.
Oil grade:
API grade SL ªEnergy±Conservingº or ILSAC multigrade
engine oil.
Recommended viscosity (SAE):
SOIL14
Outside temperature
SAE 5W±30 is the best choice for good fuel economy, and
good starting in cold weather.
If SAE 5W±30 oil is not available, SAE 10W±30 oil may be
used. However, it should be replaced with SAE 5W±30 at
the next oil change.
04 06.30

ENGINE
337
CHECKING THE ENGINE COOLANTLEVEL
SV62006

1Reservoir cap 2Upper line 3Lower line
Look at the see±through coolant reservoir when the
engine is cold. The coolant level is satisfactory if it is
between theªFULLº and ªLº lines on the reservoir. If the
level is low, add the coolant. (For the coolant type, see
ªCoolant type selectionº described below.)
The coolant level in the reservoir will vary with engine
temperature. However, if the level is on or below the ªLº line,
add coolant. Bring the level up to the ªFULLº line.
If the coolant level drops within a short time after replenishing,
there may be a leak in the system. Visually check the radiator,
hoses, engine coolant filler cap, radiator cap and drain cock
and water pump. If you can find no leak, have your Lexus dealer test the cap
pressure and check for leaks in the cooling system.
CAUTION
To prevent burning yourself, do not remove the radiator
cap when the engine is hot.
Coolant type selection
Use of improper coolants may damage your engine cooling
system.
Only use ªToyota Super Long Life Coolantº or similar high
quality ethylene glycol based non±silicate, non±amine,
non±nitrite, and non±borate coolant with long±life hybrid
organic acid technology.
(Coolant with long±life hybrid organic
acid technology is a combination of low phosphates and
organic acids.)
For the U.S.A.ЪToyota Super Long Life Coolantº is a mixture
of 50% coolant and 50% deionized water. This coolant
provides protection down to about ±35 C (±31F).
For the CanadaЪToyota Super Long Life Coolantº is a
mixture of 55% coolant and 45% deionized water. This coolant
provides protection down to about ±42 C (±44F).
NOTICE
Do not use plain water alone.
