KEYS AND DOORS
23

1Lock2Unlock
Turn the key towards the front of the vehicle to lock and
towards the back to unlock.
All the side doors and back door lock and unlock
simultaneously with the driver's door. In the driver's door lock,
turning the key once will unlock the driver's door and twice in
succession will unlock all the side doors and back door
simultaneously.*
NOTE: * The 2±step unlocking function can be changed. Ask your Lexus dealer for details.
Together with the activation of unlocking, the personal lights
and center interior light come on for 15 seconds if the personal
light and center interior light switches are in the ªDOORº
positions, and the running board lights come on for about 15
seconds. However, this function does not work when the
ignition key is in the ªONº position. For further information, see
ªIlluminated entry systemº on page 90.
Locking with inside lock button

1Lock2Unlock
Push in the lock button to lock and unlock the door.
The front doors can be opened by pulling the inside handles
even if the lock buttons are in the locked position.

KEYS AND DOORS
24
CAUTION
Do not pull the inside handle of the front doors while
driving. The doors will open and an accident may occur.
Lexus strongly recommends that all children be placed
in the rear seat of the vehicle.
Closing the door with the lock button pushed in will also lock the
door. Be careful not to lock your keys in the vehicle. Doors
cannot be locked when either front door is open and the key is
in the ignition.
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle in an accident. It also
helps prevent the doors from being opened
unintentionally.
Locking with power door lock switch

1Lock2Unlock
To lock all the side doors and back door simultaneously,
push the power door lock switch down on the front side.
Pushing down on the rear side will unlock them.
The same switch is also located on the front passenger's side.
If you do any of the following, no door can be unlocked with the
power door lock switch.
 Lock all the doors with the key or wireless remote control
when all the doors are closed.
 Open the driver's door or front passenger's door and move
the inside lock buttons of both front doors to the lock
position, then close the front doors.

INTERIOR EQUIPMENT
98
GARAGE DOOR OPENER
The garage door opener (Universal
Transceiver) is manufactured under license from
HomeLink
 and can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting
systems, and security systems, etc.
(a) Programming the HomeLink
1Indicator light2Buttons
The HomeLink in your vehicle has 3 buttons and you can
store one program for each button.
To ensure correct programming into the HomeLink
, install a
new battery in the hand±held transmitter prior to programming. The battery side of the hand±held transmitter must be pointed
away from the HomeLink
 during the programming process.
For Canadian users, follow the procedure in ªProgramming an
entrance gate/programming all devices in the Canadian
marketº.
1. Decide which of 3 HomeLink
 buttons you want to program.
2. Place your hand±held garage transmitter 25 to 75 mm (1 to
3 in.) away from the surface of the HomeLink
.
Keep the indicator light on the HomeLink
 in view while
programming.
3. Simultaneously press and hold the hand±held garage
transmitter button along with the selected HomeLink
 button.
4. When the indicator light on the HomeLink
 changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
5. Test the operation of the HomeLink
 by pressing the newly
programmed button. If programming a garage door opener,
check to see if the garage door opens and closes.
If the garage door does not operate, identify if your garage
transmitter is of the ªRolling Codeº type. Press and hold the
programmed HomeLink
 button. The garage door has the
rolling code feature if the indicator light (on the HomeLink)
flashes rapidly and then remains lit after 2 seconds. If your
garage transmitter is the ªRolling Codeº type, proceed to the
heading ªProgramming a rolling code systemº.

INTERIOR EQUIPMENT
100
Programming an entrance gate/programming
all devices in the Canadian market
1. Decide which of the 3 HomeLink buttons you want to
program.
2. Place your hand±held gate/device transmitter 25 to 75 mm
(1 to 3 in.) away from the surface of the HomeLink
.
Keep the indicator light on the HomeLink
 in view while
programming.
3. Press and hold the selected HomeLink
 button.
4. Continuously press and release (cycle) the hand±held
gate/device transmitter button every two seconds until step 5
is complete.
5. When the indicator light on the HomeLink
 changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
6. Test the operation of the HomeLink
 by pressing the newly
programmed button. Check to see if the gate/device operates
correctly.
7. Repeat steps 1 through 6 for each remaining HomeLink

button to program another device.
Programming other devices
To program other devices such as home security systems,
home door locks or lighting, contact your authorized Lexus
dealer for assistance.
Reprogramming a button
Individual HomeLink buttons cannot be erased, however, to
reprogram a single button, follow the procedure ªProgramming
the HomeLink
º.
(b) Operating the HomeLink
To operate the HomeLink, press the appropriate HomeLink
button to activate the programmed device. The HomeLink
indicator light should come on. The HomeLink continues to
send the signal for up to 20 seconds as long as the button is
pressed.

INTERIOR EQUIPMENT
101
(c) Erasing the entire HomeLink memory (all
three programs)
To erase all previously programmed codes at one time, press
and hold down the 2 outside buttons for 20 seconds until the
indicator light flashes.
If you sell your vehicle, be sure to erase the programs stored
in the HomeLink
 memory.
CAUTION
 When programming the HomeLink Universal
Transceiver, you may be operating a garage door or
other device. Make sure people and objects are out
of the way of the garage door or other device to
prevent potential harm or damage.
 Do not use this HomeLink Universal Transceiver
with any garage door opener that lacks the safety
stop and reverse feature as required by federal safety
standards. (This includes any garage door opener
model manufactured before April 1, 1982.) A garage
door opener which cannot detect an object (signaling
the door to stop and reverse), does not meet current
federal safety standards. Using a garage door opener
without these features increases risk of serious
injury or death.

OCCUPANT RESTRAINT SYSTEMS
161
To connect the extender to the seat belt, insert the tab into
the seat belt buckle so that the ªPRESSº signs on the
buckle release buttons of the extender and the seat belt
are both facing outward as shown.
You will hear a click when the tab locks into the buckle.
When releasing the seat belt, press on the buckle release
button on the extender, not on the seat belt. This helps prevent
damage to the vehicle interior and extender itself.
As far as the seat belt extender on the front passenger side is
concerned, do not fail to disconnect the extender from the seat
belt after the above operation in order to activate the front
passenger airbag correctly when getting into the vehicle next
time.
When not in use, remove the extender and store in the vehicle
for future use.
CAUTION
 After inserting the tab, make sure the tab and buckle
are locked and that the lap and shoulder portions of
the belt and the seat belt extender are not twisted.
 Do not insert coins, clips, etc. in the buckle as this
may prevent you from properly latching the tab and
buckle.
 If the seat belt does not function normally,
immediately contact your Lexus dealer. Do not use
the seat until the seat belt is fixed, because it cannot
protect an adult occupant or your child from injury.

OCCUPANT RESTRAINT SYSTEMS
2242. Take off the cover on the seat cushion.
3. Widen the slits of the seat cushion a little and confirm
the position of the lower anchorages near the buttons on
the seatback.
4. Type A Ð Latch the hooks of lower straps onto the
anchorages and tighten the lower straps.
4. Type B Ð Latch the buckles onto the anchorages.
For owners in Canada Ð
The symbol on a child restraint
system indicates the presence of a lower connector system.
If your child restraint system has a top strap, it should be
anchored. (For the installation of the top strap, see ªUsing a top
strapº on page 219.)
For installation details, refer to the instruction manual equipped
with each product.
CAUTION
 When using the lower anchorages for the child
restraint system, be sure that there are no irregular
objects around the anchorages or that the seat belt is
not caught.
 Push and pull the child restraint system in different
directions to be sure it is secure. Follow all the
installation instructions provided by its
manufacturer.
 Do not install a child restraint system on the second
seat if it interferes with the lock mechanism of the
front seats. This can cause death or serious injury to
the child and front passenger in case of sudden
braking or a collision.

AIR CONDITIONING
247
(a) Climate control
SETTING OPERATION Ð automatic control
1. Push the ªAUTOº button.
An indicator light will illuminate to show that the automatic
operation mode has been selected.
Air flow quantity, switching of the diffusers, on±off of the air
conditioning and switching of the air intake between
RECIRCULATED AIR and OUTSIDE AIR are automatically
adjusted. The operation status is shown by each indicator.
When one of the manual control buttons is depressed while
operating in automatic mode, the operation corresponding to
the button depressed is set. Other conditions continue to be
adjusted automatically.
Push the ªOFFº button to turn the air conditioning system off.
2. Use the ªTEMPº or ªPASSENGER TEMPº button to set
the desired temperature.
The ªTEMPº or ªPASSENGER TEMPº button is used to set the
desired temperature. The temperature will be controlled on the
driver and passenger sides simultaneously or individually.
ªTEMPº button Ð Changes the temperature on the driver and
passenger sides simultaneously or the driver side only.
ªPASSENGER TEMPº button Ð Changes the temperature
settings separate from driver side.
ªDUALº button Ð Changes the mode of the temperature
setting.
The indicator on the ªDUALº button has two modes:
 With the indicator on Ð For individual temperature setting
 With the indicator off Ð For simultaneous temperature
setting
