INTERIOR EQUIPMENT
108
WARNING REFLECTOR HOLDER
1To disengage2To engage
This belt is designed to hold the warning reflector. To
disengage or engage the belt, do as shown above.
Although the warning reflector itself is not included as original
equipment, this auxiliary box can be used to store the warning
reflector.
Make sure the warning reflector is securely held.
COAT HOOKS
To use the coat hook, push the hook.
CAUTION
Do not hook a hanger, heavy or sharp pointed object on
the coat hook. If the curtain shield airbag inflates, those
items will be hurled away with great force or the curtain
shield airbag may not activate correctly. When you
hang clothes, hang them on the coat hook directly.

INTERIOR EQUIPMENT
109
LUGGAGE COVER
Using luggage cover
To use the luggage cover, pull out the luggage cover and
hook it on the anchors.
CAUTION
Do not place anything on the luggage cover. Such items
may be thrown about and possibly injure people in the
vehicle during sudden braking or an accident.
Removing luggage cover
To remove the luggage cover, retract and release the both
ends, and lift it out.
After remove the luggage cover, place it somewhere other than
the passenger compartment. This will prevent passengers
from injury in the event of a sudden stop or accident.
When installing the luggage cover, keep the ªTOPº mark
of the luggage cover ends upward.

INTERIOR EQUIPMENT
11 0
TIE±DOWN HOOKSTo secure your luggage, use the tie±down hooks as shown
above.
See ªStowage precautionsº on page 485 for precautions when
loading luggage.
NOTICE
Do not use the third seat anchors instead of thetie±down hooks.

SECTION 1 ± 5
111
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel tank cap 11 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon roof 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quarter windows 11 9
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Roof luggage carrier 120
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear step bumper 123
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EXTERIOR EQUIPMENT
11 2
HOOD
1. To open the hood, pull the hood lock release lever under
the instrument panel. The hood will spring up slightly.
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. Then lower the hood and make
sure it locks.
CAUTION
Before driving, be sure that the hood is closed and
securely locked. Otherwise, the hood may open
unexpectedly while driving and an accident may occur.

EXTERIOR EQUIPMENT
11 3
FUEL TANK CAP
This indicates that the fuel filler door is on the left side of
your vehicle.
1. To open the fuel filler door, pull the lever under the
instrument panel.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refuelling. The fumes are flammable.
 When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.

EXTERIOR EQUIPMENT
11 4
2. To remove the fuel tank cap, turn the cap
counterclockwise by 90 degrees (to the pressure point
1), and then turn it an additional 30 degrees (to point
2). Pause slightly before removing it.
It is not unusual to hear a slight swoosh when the cap is
opened.
15PY017
3. The removed cap can be stored on the back side of the
fuel filler door.
Position the cap so that the hooks point to the left and right or
up and down, and set it in the receptacle on the back side of
the door.

EXTERIOR EQUIPMENT
11 5
When installing the cap, turn the cap clockwise until you
hear a click. When you hear the click, the cap is fully
closed.
If the cap is not tightened securely, the malfunction indicator
lamp comes on. Make sure the cap is tightened securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
CAUTION

Make sure the cap is installed securely to prevent fuel
spillage in the event of an accident.
 Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
NOTICE
To prevent damage to the cap, apply force only in the
turning direction to the cap. Do not pull or pry it.
