Knowing your vehicle
CAUTION
If the “PASSENGER AIRBAG
OFF” indicator illuminates or
blinks continuously when a per-
son of adult size sits in the front
passenger’s seat, it could be
because that person isn’t sitting
properly in the seat.
If this happens, turn the vehicle
off, place the seat back in the
full upright position, sit upright
in the seat, centered on the seat
cushion, with legs comfortably
extended. Restart the vehicle
and have the person remain in
this position for about 30 sec-
onds. This will allow the system
to detect the person and enable
the passenger’s airbag.
Condition and operation in the front passenger occupant
classification systemCondition detected by
the occupant classifi-
cation system
1. Adult *
1
2. Child *
2
3. Unoccupied
(unbelted)
4. Unoccupied
(belted)
5. There is a malfunc-
tion in the system Off
On
Off
On
OnOff
Off
Off
Off
OnActivated
Deactivated
Deactivated
Deactivated
Deactivated
"PASSENGER AIRBAG
OFF" indicator light
SRS warning lightFront passenger
airbag Indicator/Warning light Devices
*1The system judges a person of adult size as an adult. When a smaller adult
sits in the front passenger seat, the system may recognize him/her as a
child depending on his/her physique and posture
*2When a larger child who has outgrown a child restraint system sits in the
front passenger seat, the system may recognize him/her as an adult
depending on his/her physique or posture.
