2005 INFINITI FX35 set clock

TRANSMISSION ASSEMBLY AT-271
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
10. Remove crankshaft position sensor (POS) from transmission
assembly.
CAUTION:

Do not subject it to impact by dropping or hitting it.

Do not disassemble.

Do not allow metal filings, etc. to get on the sensor's front
edge magnetic area.

Do not place in an area affected by magnetism.
11. Remove starter motor. Refer to SC-18, "
VQ35DE ENGINE
MODELS (2WD)" .
12. Remove fluid cooler tube.
13. Remove rear plate cover. Refer to EM-30, "
Removal and Installation (2WD Model)" .
14. Remove rear cover plate. Refer to EM-30, "
Removal and Installation (2WD Model)" .
15. Turn crankshaft, and remove the four tightening bolts for drive plate and torque converter.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
16. Support transmission assembly with a transmission jack. CAUTION:
When setting the transmission jack, be careful not to allow
it to collide against the drain plug.
17. Remove rear engine mounting member with power tool.
18. Remove air breather hose. Refer to AT- 2 6 8 , "
Removal and
Installation" .
19. Disconnect A/T assembly connector.
20. Remove A/T fluid charging pipe from transmission assembly.
21. Plug up openings such as the fluid charging pipe hole, etc.
22. Remove bolts fixing transmission assembly to engine assembly with power tool.
23. Remove transmission assembly from vehicle with a transmis- sion jack.

Secure torque converter to prevent it from dropping.

Secure transmission assembly to a transmission jack.
INSPECTION
Installation and Inspection of Torque Converter

After inserting a torque converter to a transmission, be sure to
check distance “A” to ensure it is within the reference value limit.
SCIA2155E
SCIA2288E
SCIA0499E
Distance “A”: 25.0 mm (0.98 in) or more
SAT017B

TRANSMISSION ASSEMBLY AT-275
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
11. Remove crankshaft position sensor (POS) from transmission
assembly.
CAUTION:

Do not subject it to impact by dropping or hitting it.

Do not disassemble.

Do not allow metal filings, etc., to get on the sensor's
front edge magnetic area.

Do not place in an area affected by magnetism.
12. Remove starter motor. Refer to SC-19, "
VQ35DE ENGINE
MODELS (AWD)" or SC-17, "VK45DE ENGINE MODELS" .
13. Disconnect fluid cooler tube from transmission assembly.
14. Remove rear plate cover. Refer to EM-36, "
Removal and Instal-
lation (AWD Model)" (for VQ35DE models) or EM-185,
"Removal and Installation" (for VK45DE models).
15. Turn crankshaft, and remove the four tightening bolts for drive plate and torque converter.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from
the front of the engine.
16. Remove dynamic damper (for VQ35DE models). Refer to EM-
11 7 , "Removal and Installation (AWD Model)" .
17. Support transmission assembly with a transmission jack. CAUTION:
When setting the transmission jack, be careful not to allow
it to collide against the drain plug.
18. Remove rear engine mounting member with power tool.
19. Tilt the mission slightly to keep the clearance between body and mission, and then disconnect air breather hose from charging
pipe. Refer to AT- 2 6 8 , "
Removal and Installation" .
20. Disconnect A/T assembly connector and transfer assembly con- nector.
21. Remove A/T fluid charging pipe.
22. Plug up openings such as the fluid charging pipe hole, etc.
23. Remove bolts fixing transmission assembly to engine with power tool.
SCIA2011E
SCIA5326E
SCIA2010E
SCIA2202E

AV-74
INTEGRATED DISPLAY SYSTEM
Revision: 2005 July 2005 FX
On Board Self-Diagnosis FunctionAKS005U8
DESCRIPTION

Diagnosis function consists of the self-diagnosis mode performed automatically.

Self-diagnosis mode checks for connections between the units constituting this system, analyzes each
individual unit at the same time, and displays the results on the LCD screen.
DIAGNOSIS ITEM
Self-Diagnosis ModeAKS005U9
OPERATION PROCEDURES
1. Start the engine.
2. Turn the audio system off.
3. While pressing the “MUTE/ II ” switch, turn the volume control
dial clockwise or counterclockwise for 30 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
4. Display unit connection check screen.
5. Select each connecting unit (CHANGER, SATELLITE RADIO).
13 (G/W) Ground Steering SW
B Input ON Press POWER
switch. Approx. 0 V
Audio steering
wheel switches
do not function.
Press SEEK
DOWN switch. Approx. 1.7 V
Press VOL DOWN
switch. Approx. 3.3 V
Except for above Approx. 5 V
14 (B/Y) — Steering SW
ground —— — — Audio steering
wheel switches
do not function.
Terminal No.
(Wire color) Item Signal
input/
output Condition
Voltage Example of
symptom
+– Ignition
switch Operation
Mode Item Description Reference page
Self-diagnosis NETWORK CHECK
Check network between control unit and switch connected
from display unit via communication line. AV-75, "
NETWORK CHECK"
PARTS CHECK
Perform diagnosis and setting of display unit.

Perform self-diagnosis for auto air conditioner system. AV- 7 5 , "PARTS CHECK"
VERSION CHECK Displays version of each unit.
AV- 7 6 , "VERSION CHECK"
CAN DIAG MNTR Display unit displays CAN communication status. AV- 7 6 , "CAN DIAG MNTR
(CAN DIAG MONITOR)"
PKIB4131E
SKIA5921E

BRAKE PEDAL BR-7
C
D E
G H
I
J
K L
M A
B
BR
Revision: 2005 July 2005 FX
ADJUSTMENT
1. Loosen stop lamp switch and ASCD cancel switch (or brake
switch) by turning it counterclockwise by 45 °.
2. Loosen lock nut (A) on input rod, then rotate input rod to set pedal to the specified height, and tighten lock nut (A).
CAUTION:
Make sure the threaded end of input rod stays inside clevis.
3. With pedal pulled and held by hand, press stop lamp switch and ASCD cancel switch (or brake switch) until its threaded end con-
tacts stopper rubber.
4. With the threaded end of stop lamp switch and ASCD cancel switch (or brake switch) contacting stopper rubber, rotate switch
clockwise by 45 ° to secure.
CAUTION:
Make sure that the clearance (C) between stopper rubber
and threaded end of stop lamp switch and ASCD cancel
switch (or brake switch) is within the standard.
5. Check pedal play. CAUTION:
Make sure that stop lamps go off when pedal is released.
6. Start engine to check brake pedal depressed height.
Removal and InstallationAFS001MU
COMPONENT PARTS LOCATION
Lock nut (A) :
Refer to BR-16, "
Removal and Installation"
SFIA0160E
SFIA1940E

DI-2Revision: 2005 July 2005 FX
Oil Pressure Warning Lamp Does Not Turn Off (Oil
Pressure Is Normal) ............................................. ... 52
Component Inspection ......................................... ... 53
OIL PRESSURE SWITCH ................................ ... 53
A/T INDICATOR ..................................................... ... 54
Wiring Diagram — AT/IND — .............................. ... 54
A/T Indicator Is Malfunction ................................. ... 56
WARNING CHIME .................................................. ... 58
System Description .............................................. ... 58
FUNCTION ....................................................... ... 58
IGNITION KEY WARNING CHIME (WITHOUT
INTELLIGENT KEY) ......................................... ... 58
IGNITION KEY WARNING CHIME (WITH INTEL-
LIGENT KEY) ................................................... ... 59
LIGHT WARNING CHIME ................................ ... 59
SEAT BELT WARNING CHIME ........................ ... 59
CAN Communication System Description ........... ... 60
CAN Communication Unit .................................... ... 60
Component Parts and Harness Connector Location ... 61
Schematic ............................................................ ... 62
Wiring Diagram — CHIME — .............................. ... 63
Terminals and Reference Value for BCM ............. ... 66
Terminals and Reference Value for Unified Meter
and A/C Amp. ...................................................... ... 67
Terminals and Reference Value for Combination
Meter ................................................................... ... 67
Trouble Diagnosis ................................................ ... 68
HOW TO PERFORM TROUBLE DIAGNOSIS . ... 68
PRELIMINARY CHECK .................................... ... 68
CONSULT-II Function (BCM) ............................... ... 69
DIAGNOSTIC ITEMS DESCRIPTION .............. ... 69
CONSULT-II BASIC OPERATION PROCEDURE
... 69
DATA MONITOR ............................................... ... 70
ACTIVE TEST .................................................. ... 70
SELF-DIAGNOSTIC RESULTS ........................ ... 71
All Warnings Are Not Operated ........................... ... 71
Key Warning Chime and Light Warning Chime Does
Not Operate (Seat Belt Warning Chime Does Oper-
ate) ...................................................................... ... 72
Key Warning Chime Does Not Operate (Without
Intelligent Key) ..................................................... ... 73
Key Warning Chime Does Not Operate (With Intel-
ligent Key, When Mechanical Key Is Used) ......... ... 75
Key Warning Chime Does Not Operate (With Intel-
ligent Key, When Intelligent Key Is Carried With The
Driver) .................................................................. ... 77
Light Warning Chime Does Not Operate ............. ... 79
Seat Belt Warning Chime Does Not Operate ...... ... 80
LANE DEPARTURE WARNING SYSTEM ............. ... 82
Precautions for Lane Departure Warning (LDW)
system ................................................................. ... 82
System Description .............................................. ... 82
LDW SYSTEM OPERATION ............................ ... 82
POWER SUPPLY AND GROUND CIRCUIT .... ... 84
CAN Communication ........................................... ... 84
SYSTEM DESCRIPTION ................................. ... 84
CAN COMMUNICATION UNIT ......................... ... 85
Action Test ........................................................... ... 85 LDW SYSTEM RUNNING TEST ......................
... 85
Camera Aiming Adjustment ................................. ... 86
OUTLINE .......................................................... ... 86
PREPARATION ................................................. ... 86
TARGET SETTING ........................................... ... 86
VEHICLE HEIGHT CHECK .............................. ... 89
AIMING ADJUSTMENT .................................... ... 89
Component Parts and Harness Connector Location ... 93
Schematic ............................................................ ... 94
Wiring Diagram — LDW — .................................. ... 95
Terminals and Reference Value for LDW Camera
Unit ....................................................................... ... 98
CONSULT-II Function (LDW) ............................... ... 98
DESCRIPTION ................................................. ... 98
CONSULT-II BASIC OPERATION .................... ... 98
WORK SUPPORT ............................................ ... 99
SELF-DIAG RESULTS ...................................... ... 99
DATA MONITOR ............................................... .100
ACTIVE TEST ................................................... .101
Trouble Diagnosis ................................................ .102
HOW TO PERFORM TROUBLE DIAGNOSIS . .102
SYMPTOM CHART ........................................... .102
Preliminary Inspection .......................................... .103
Power Supply and Ground Circuit Inspection ...... .104
DTC [C1B00] CAMERA UNIT MALF ................... .104
DTC [C1B01] CAM AIMING INCMP .................... .104
DTC [C1B02] VHCL SPD DATA MALF ................ .105
DTC [C1B03] ABNRML TEMP DETECT ............. .105
DTC [U1000] CAN COMM CIRCUIT ................... .105
DTC [U1010] CONTROL UNIT (CAN) ................. .105
LDW Chime Circuit Inspection ............................. .106
LDW Switch Circuit Inspection ............................. .107
LDW Indicator Lamp Circuit Inspection ................ .109
Turn Signal Input Inspection ................................ .110
Removal and Installation for LDW Camera Unit .. . 111
REMOVAL ......................................................... . 111
INSTALLATION ................................................. . 111
Removal and Installation for LDW Chime ............ . 111
REMOVAL ......................................................... . 111
INSTALLATION ................................................. . 111
Removal and Installation for LDW Switch ............ . 111
CLOCK ................................................................... .112
Wiring Diagram — CLOCK — .............................. .112
Removal and Installation of Clock ........................ .113
REMOVAL ......................................................... .113
INSTALLATION ................................................. .113
REAR VIEW MONITOR .......................................... .114
System Description .............................................. .114
POWER SUPPLY AND GROUND .................... .114
AV COMMUNICATION LINE ............................ .114
REAR VIEW CAMERA OPERATION ............... .114
Component Parts and Harness Connector Location .115
Schematic ............................................................ .116
Wiring Diagram — R/VIEW — ............................. .117
Terminals and Reference Value for Rear View Cam-
era Control Unit .................................................... .120
CONSULT-II Function (REARVIEW CAMERA) ... .121
CONSULT-II BASIC OPERATION .................... .121
WORK SUPPORT ............................................ .122

EC-70
[VQ35DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2005 July 2005 FX
ON BOARD DIAGNOSTIC SYSTEM FUNCTION
The on board diagnostic system has the following three functions.
When there is an open circuit on MIL circuit, the ECM cannot warn the driver by lighting up MIL when there is
malfunction on engine control system.
Therefore, when electrical controlled throttle and part of ECM related diagnoses are continuously detected as
NG for 5 trips, ECM warns the driver that engine control system malfunctions and MIL circuit is open by means
of operating fail-safe function.
The fail-safe function also operates when above diagnoses except MIL circuit are detected and demands the
driver to repair the malfunction.
MIL Flashing Without DTC
When any SRT codes are not set, MIL may flash without DTC. For the details, refer to EC-63, "How to Display
SRT Status" .
HOW TO SWITCH DIAGNOSTIC TEST MODE
NOTE:

It is better to count the time accurately with a clock.

It is impossible to switch the diagnostic mode when an accelerator pedal position sensor circuit
has a malfunction.

Always ECM returns to Diagnostic Test Mode I after ignition switch is turned OFF.
How to Set Diagnostic Test Mode II (Self-Diagnostic Results)
1. Confirm that accelerator pedal is fully released, turn ignition switch ON and wait 3 seconds.
2. Repeat the following procedure quickly 5 times within 5 seconds.
a. Fully depress the accelerator pedal.
b. Fully release the accelerator pedal.
3. Wait 7 seconds, fully depress the accelerator pedal and keep it for approx. 10 seconds until the MIL starts blinking.
Diagnostic Test
Mode KEY and ENG.
Sta tus Function Explanation of Function
Mode I Ignition switch in ON position
Engine stopped BULB CHECK This function checks the MIL bulb for damage (blown,
open circuit, etc.).
If the MIL does not come on, check MIL circuit.
Engine running MALFUNCTION WARNING This is a usual driving condition. When a malfunction is
detected twice in two consecutive driving cycles (two trip
detection logic), the MIL will light up to inform the driver
that a malfunction has been detected.
The following malfunctions will light up or blink the MIL in
the 1st trip.

Misfire (Possible three way catalyst damage)

One trip detection diagnoses
Mode II Ignition switch in ON position
Engine stopped SELF-DIAGNOSTIC
RESULTS This function allows DTCs and 1st trip DTCs to be read.
Engine operating condition in fail-safe mode Engine speed will not rise more than 2,500 rpm due to the fuel cut

EC-762
[VK45DE]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2005 July 2005 FX
–Test values
HOW TO SWITCH DIAGNOSTIC TEST MODE
NOTE:

It is better to count the time accurately with a clock.

It is impossible to switch the diagnostic mode when an accelerator pedal position sensor circuit
has a malfunction.

Always ECM returns to Diagnostic Test Mode I after ignition switch is turned OFF.
How to Set Diagnostic Test Mode II (Self-diagnostic Results)
1. Confirm that accelerator pedal is fully released, turn ignition switch ON and wait 3 seconds.
2. Repeat the following procedure quickly five times within 5 seconds.
a. Fully depress the accelerator pedal.
b. Fully release the accelerator pedal.
3. Wait 7 seconds, fully depress the accelerator pedal and keep it for approx. 10 seconds until the MIL starts blinking.
NOTE:
Do not release the accelerator pedal for 10 seconds if MIL may start blinking on the halfway of this
10 seconds. This blinking is displaying SRT status and is continued for another 10 seconds. For
the details, refer to EC-754, "
How to Display SRT Status" .
4. Fully release the accelerator pedal. ECM has entered to Diagnostic Test Mode II (Self-diagnostic results).
NOTE:
Wait until the same DTC (or 1st trip DTC) appears to confirm all DTCs certainly.
How to Set Diagnostic Test Mode II (Heated Oxygen Sensor 1 Monitor)
1. Set the ECM in Diagnostic Test Mode II (Self-diagnostic results). Refer to EC-762, "How to Set Diagnostic
Test Mode II (Self-diagnostic Results)" .
2. Start Engine. ECM has entered to Diagnostic Test Mode II (Heated oxygen sensor 1 monitor).
ECM will start heated oxygen sensor 1 monitoring from the bank 1 sensor.
How to Switch Monitored Sensor From Bank 1 to Bank 2 or Vice Versa
1. Fully depress the accelerator pedal quickly and then release it immediately.
2. Make sure that monitoring sensor has changed by MIL blinking as follows.
PBIB0092E
PBIB0093E

FRONT TIMING CHAIN CASE EM-55
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
16. Remove collared O-ring from front timing chain case (left and
right side).
17. Remove rocker covers (right and left banks). Refer to EM-51, "
ROCKER COVER" .
NOTE:
When only timing chain (primary) is removed, rocker cover does not need to be removed.
18. Obtain No. 1 cylinder at TDC of its compression stroke as follows:
NOTE:
When timing chain is not removed/installed, this step is not required.
a. Rotate crankshaft pulley clockwise to align timing mark (grooved line without color) with timing indicator.
b. Make sure that intake and exhaust cam noses on No. 1 cylinder (engine front side of right bank) are located as shown in the fig-
ure.

If not, turn crankshaft one revolution (360 degrees) and align
as shown in the figure.
NOTE:
When only timing chain (primary) is removed, rocker cover does
not need to be removed. To make sure that No. 1 cylinder is at
its compression TDC, remove front timing chain case first. Then
check mating marks on camshaft sprockets. Refer to EM-73,
"INSTALLATION" .
19. Remove crankshaft pulley as follows:
a. Remove rear cover plate (2WD) or starter motor (AWD) and set ring gear stopper [SST] as shown in the figure. Refer to SC-10,
"STARTING SYSTEM" .
PBIC2631E
KBIA1717J
SEM418G
PBIC1098E
