2005 INFINITI FX35 check engine

BRC-4
[VDC/TCS/ABS]
PRECAUTIONS
Revision: 2005 July 2005 FX

If there is a radio, antenna, or antenna lead-in wire (including wiring) near control module, VDC/TCS/ABS
function may have a malfunction or error.

If aftermarket parts (car stereo, CD player, etc.) have been installed, check for incidents such as harness
pinches, open circuits, and improper wiring.

If the following components are replaced with non-genuine components or converted, VDC OFF indicator
lamp and SLIP indicator lamp may turn on or the VDC system may not operate properly. Components
related to suspension (shock absorber, strut, spring, bushing, etc.), Tires, wheels (exclude specified size),
components related to brake (pad, rotor, caliper, etc.), components related to engine (muffler, ECM, etc.),
components related to body reinforcement (roll bar, tower bar, etc.).

Driving in the condition of breakage or excessive wear of suspension, tires or components related to the
brakes may cause VDC OFF indicator lamp and SLIP indicator lamp turn on, and the VDC system may
not operate properly.

When the TCS or VDC is activated by sudden acceleration or sudden turn, some noise may occur. The
noise is a result of the normal operation of the TCS and VDC.

When driving on roads which have extreme slopes (such as mountainous roads) or high banks (such as
sharp carves on a freeway), the VDC may not operate normally, or VDC OFF indicator lamp and SLIP
indicator lamp may turn on. However, this is not a malfunction, if normal operation can be resumed after
restarting engine.

Sudden turns (such as spin turns, acceleration turns), drifting, etc. When VDC function is OFF (VDC OFF
SW ON) may cause the G sensor system indicate a malfunction. However, this is not a malfunction, if nor-
mal operation can be resumed after restarting engine.

SYSTEM DESCRIPTION BRC-9
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX

When starting engine, or just after starting vehicle, brake pedal may vibrate or motor operating noises
may be heard from engine compartment. This is a normal status of operation check.

Stopping distance may be longer than that of vehicles without ABS when vehicle drives on rough, gravel,
or snow-covered (fresh, deep snow) roads.
EBD FunctionAFS001SF

Electronic brake distributor is a function that detects subtle slippages between front and rear wheels dur-
ing braking, and it improves handling stability by electronically controlling the brake fluid pressure which
results in reduced rear wheel slippage.

In case of electrical system malfunction, the fail-safe function is activated, EBD and ABS becomes inoper-
ative, and ABS warning lamp and brake warning lamp are turned on.

Electrical system diagnosis by CONSULT-II is available.

During EBD operation, brake pedal lightly vibrates and a mechanical noise may be heard. This is normal.

When starting engine, or just after starting vehicle, brake pedal may vibrate or motor operating noises
may be heard from engine compartment. This is a normal status of operation check.

Stopping distance may be longer than that of vehicles without EBD when vehicle drives on rough, gravel,
or snow-covered (fresh, deep snow) roads.
Fail-Safe FunctionAFS001SG
VDC / TCS SYSTEM
In case of malfunction in the VDC/TCS system, VDC OFF indicator lamp and SLIP indicator lamp are turned
on, and the condition of vehicle is the same as the condition of vehicles without VDC/TCS system. In case of
malfunction in the VDC/TCS system, the ABS control continues to operate normally without VDC/TCS control.
CAUTION:
If the fail-safe function is activated, then perform the self-diagnosis for VDC/TCS/ABS control system.
ABS, EBD SYSTEM
In case of electrical malfunctions with the ABS, ABS warning lamp, VDC OFF indicator lamp and SLIP indica-
tor lamp will turn on. In case of electrical malfunctions with the EBD, brake warning lamp, ABS warning lamp,
VDC OFF indicator lamp and SLIP indicator lamp will turn on. Simultaneously, the VDC/TCS/ABS become one
of the following conditions of the fail-safe function.
1. For malfunction of ABS, only the EBD is activated and the condition of vehicle is the same condition of vehicles without TCS/ABS system.
2. For malfunction of EBD, EBD and ABS become inoperative, and the condition of vehicle is the same as the condition of vehicles without TCS/ABS, EBD system.
NOTE:
In condition 1 described above, an ABS self-diagnosis sound may be heard. That is a normal condition
because a self-diagnosis for “Ignition switch ON” and “The first starting” are being performed.

TROUBLE DIAGNOSIS BRC-23
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
Control Unit Input/Output Signal StandardAFS001SP
REFERENCE VALUE FROM CONSULT-II
CAUTION:
The display shows ABS actuator and electric unit (control unit) calculation data, so a normal value
might be displayed even in the event the output circuit (harness) is open or short-circuited.
Monitor item Display content Data monitor
Check item
Condition Reference value in
normal operation
SLCT LVR POSI A/T shift position P: P position
R: R position
N: N position
D: D position
—
GEAR A/T gear position 1: 1st gear
2: 2nd gear
3: 3rd gear
4: 4th gear
5: 5th gear
FR RH SENSOR
FR LH SENSOR
RR RH SENSOR
RR LH SENSOR Wheel speed Vehicle stopped 0 [km/h (MPH)]
BRC-37, "
Inspection 1:
Wheel Sensor Circuit"Vehicle running (Note 1) Almost in accor-
dance with speed-
ometer display
(within ±10 %)
ACCEL POS SIG Open/close condition
of throttle valve (linked
with accelerator pedal). Accelerator pedal not
depressed (ignition switch is
ON) 0 %
Communication circuit
between VDC/TCS/ABS
control unit and ECM
Depress accelerator pedal
(ignition switch is ON) 0 to 100 %
ENGINE SPEED With engine running With engine stopped 0 rpm
EC section
Engine running Almost in accor-
dance with
tachometer display
STR ANGLE SIG Steering angle
detected by steering
angle sensor Straight-ahead Approx. 0 deg
BRC-42, "
Inspection 5:
Steering Angle Sensor
Circuit"Steering wheel turned –756 to 756 deg
YAW RATE SEN Yaw rate detected by
yaw rate sensor Vehicle stopped Approx. 0 d/s
BRC-44, "
Inspection 6:
Yaw Rate/Side G Sensor
(2WD Model), Yaw Rate/
Side/Decel G sensor
(AWD Models) Circuit"
Vehicle running –100 to 100 d/s
SIDE G-SENSOR Transverse G detected
by side G sensor Vehicle stopped
Approx. 0 m/s
2BRC-44, "Inspection 6:
Yaw Rate/Side G Sensor
(2WD Model), Yaw Rate/
Side/Decel G sensor
(AWD Models) Circuit"
Vehicle running–16.7 to 16.7 m/s2
PRESS SENSOR Brake fluid pressure
detected by pressure
sensor With ignition switch turned ON
and brake pedal released Approx. 0 bar
BRC-40, "Inspection 4:
Pressure Sensor Circuit"With ignition switch turned ON
and brake pedal depressed 0 to 170 bar
BATTERY VOLT Battery voltage sup-
plied to ABS actuator
and electric unit (con-
trol unit) Ignition switch ON 10 to 16 V BRC-48, "
Inspection 9:
ABS Actuator and Elec-
tric Unit (Control Unit)
Power Supply and
Ground Circuit"
STOP LAMP SW Brake pedal operation
Brake pedal depressed ON
BRC-50, "
Inspection 10:
Stop Lamp Switch Cir-
cuit"Brake pedal not depressed OFF

BRC-24
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
OFF SW VDC OFF switch
ON/OFF status VDC OFF switch ON
(When VDC OFF indicator
lamp is ON) ON
BRC-53, "VDC OFF
SWITCH"VDC OFF switch OFF
(When VDC OFF indicator
lamp is OFF) OFF
ABS WARN LAMP ABS warning lamp ON
condition (Note 2) ABS warning lamp ON ON
BRC-37, "
BASIC
INSPECTION 3: ABS
WARNING LAMP, VDC
OFF INDICATOR LAMP,
SLIP INDICATOR LAMP
and BRAKE WARNING
LAMP INSPECTION"
ABS warning lamp OFF OFF
MOTOR RELAY Operation status of
motor and motor relay Ignition switch ON or engine
running (ABS not operated) OFF
BRC-47, "
Inspection 8:
Actuator Motor Circuit"Ignition switch ON or engine
running (ABS operated) ON
ACTUATOR RLY Actuator relay opera-
tion status Actuator (solenoid) is active
(“ACTIVE TEST” with CON-
SULT-II) ON
BRC-47, "
Inspection 8:
Actuator Motor Circuit"When actuator relay is inactive
(in fail-safe mode) OFF
OFF LAMP VDC OFF indicator
lamp status (Note 3) When VDC OFF indicator
lamp is ON ON
BRC-37, "
BASIC
INSPECTION 3: ABS
WARNING LAMP, VDC
OFF INDICATOR LAMP,
SLIP INDICATOR LAMP
and BRAKE WARNING
LAMP INSPECTION"
When VDC OFF indicator
lamp is OFF OFF
SLIP LAMP SLIP indicator lamp
status (Note 4) When SLIP indicator lamp is
ON ON
When SLIP indicator lamp is
OFF OFF
FR LH IN SOL
FR LH OUT SOL
FR RH IN SOL
FR RH OUT SOL
RR RH IN SOL
RR RH OUT SOL
RR LH IN SOL
RR LH OUT SOL Solenoid valve opera-
tion Actuator (solenoid) is active
(“ACTIVE TEST” with CON-
SULT-II) and actuator relay is
active (ignition switch ON) ON
BRC-46, "
Inspection 7:
Solenoid and VDC
Change-Over Valve Cir-
cuit"
When actuator (solenoid) is
not active or actuator relay is
inactive (in fail-safe mode) OFF
CV1
CV2
SV1
SV2 VDC/TCS switch-over
valve status When actuator (switch-over
valve) is active (“ACTIVE
TEST” with CONSULT-II) and
actuator relay is active (ignition
switch ON) ON
When actuator (switch-over
valve) is not active or actuator
relay is inactive (in fail-safe
mode) OFF
DECEL G-SEN Longitudinal accelera-
tion detected by Decel
G sensor [Note 5] Vehicle stopped approx. 0 G
BRC-44, "
Inspection 6:
Yaw Rate/Side G Sensor
(2WD Model), Yaw Rate/
Side/Decel G sensor
(AWD Models) Circuit"
Vehicle running -1.7 to +1.7 G
Monitor item Display content
Data monitor
Check item
Condition Reference value in
normal operation

TROUBLE DIAGNOSIS BRC-27
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
6. Select the required diagnostic location from the “SELECT DIAG
MODE” screen.
For further information, see CONSULT-II Operation Manual.
SELF-DIAGNOSIS
Description

If an error is detected in the system, ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp
on the combination meter turn on. In this case, perform self-diagnosis as follows:

While CONSULT-II is used, ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp may be
turned on in a case of no malfunctioning.
Operation Procedure
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector. CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which perform CAN communication.
3. Turn ignition switch ON.
4. Start engine and drive at approximately 30 km/h (19 MPH) or more for approximately 1 minute.
5. After stopping vehicle, with the engine running, touch “START (NISSAN BASED VHCL)”, “ABS”, “SELF- DIAG RESULTS” in order on the CONSULT-II screen.
CAUTION:
If “START (NISSAN BASED VHCL)” is touched immediately after starting engine or turning on the
ignition switch, “ABS” might not be displayed in the System Selection screen. In this case, repeat
the operation from step 1. If it can not be shown after several attempts, ABS actuator and electric
unit (control unit) may have malfunctioned.
6. The self-diagnostic results are displayed. (If necessary, the self-diagnostic results can be printed out by touching “PRINT”.)

When “NO FAILURE” is displayed, check ABS warning lamp, VDC OFF indicator lamp and SLIP indica-
tor lamp.
7. Perform the appropriate inspection from the display item list, and repair or replace the malfunctioning component.
8. Drive the vehicle at approximately 30 km/h (19 MPH) or more for approximately 1 minute. CAUTION:

In a case that a wheel sensor is malfunctioning, ABS warning lamp, VDC OFF indicator lamp,
SLIP indicator lamp will turn on. If vehicle is not driven at approximately 30 km/h (19 MPH) or
more for at least approximately 1 minute after repair of the wheel sensor system, ABS warning
lamp, VDC OFF indicator lamp and SLIP indicator lamp may not turn off even if everything is
normal. Check again to make sure that there is no malfunction on other parts.
9. Turn ignition switch OFF to prepare for erasing the memory.
10. Start engine and touch “START (NISSAN BASED VHCL)”, “ABS”, “SELF-DIAG RESULTS”, “ERASE MEMORY” in order on the CONSULT-II screen to erase the error memory.
If “ABS” is not indicated, go to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAUTION:
If the error memory is not erased, re-perform the operation from step 5.
11. For final inspection, drive at approximately 30 km/h (19 MPH) or more for approximately 1 minute and confirm that ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp are OFF.
SFIA2436E

BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
Note 1: After completing repairs of shorted sensor circuit, when turning ignition switch ON, ABS warning lamp
turned on. Make that ABS warning lamp turned off while driving vehicle at approximately 30 km/h (19 MPH) or
more for approximately 1 minute according to self-diagnosis procedure. In addition, if wheel sensor 2 is dis-
played for wheels, check wheel sensor circuit and also check ABS actuator and electric unit (control unit)
power voltage.
Note 2: If multiple malfunctions are detected including CAN communication line [U1000], perform diagnosis for
CAN communication line first.
Note 3: “ACTUATOR RLY” on the CONSULT-II self-diagnostic results indicates the malfunction of actuator
relay or circuit. Actuator relay is imbedded in ABS actuator and electric unit (control unit).
DATA MONITOR
Operation Procedure
1. After turning ignition switch OFF, connect CONSULT-II and CONVERTER to data link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which performs CAN communication.
2. Turn ignition switch ON.
3. Touch “START (NISSAN BASED VHCL)”, “ABS”, “DATA MONITOR” in order on the CONSULT-II screen. If “ABS” is not indicated, go to GI-39, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAN COMM CIRCUIT
[U1000]

CAN communication line is open or shorted.

ABS actuator and electric unit (control unit) internal malfunc-
tion

Battery voltage for EMC is suddenly interrupted for approxi-
mately 0.5 seconds or more. BRC-53, "
Inspection 14:
CAN Communication
Circuit" (Note 2)
BR FLUID LEVEL LOW
[C1155] Brake fluid level drops or circuit between ABS actuator and elec-
tric unit (control unit) and brake fluid level switch is open or
shorted. BRC-51, "
Inspection 11:
Brake Fluid Level Switch
Circuit"
VARIANT CODING
[C1170] V coding is not functioning. ABS actuator and elec-
tric unit (control unit) and
circuit
G - SENSOR (AWD model)
[C1113] Decel G sensor is malfunctioning, or signal line of Decel G sen-
sor is open or shorted. BRC-44, "
Inspection 6:
Yaw Rate/Side G Sensor
(2WD Model), Yaw Rate/
Side/Decel G sensor
(AWD Models) Circuit"
ENGINE SIGNAL 1
[C1130] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine fuel cut system is malfunction-
ing. –
ENGINE SIGNAL 2
[C1131] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine ETC system is malfunctioning. –
ENGINE SIGNAL 3
[C1132] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine CAN system is malfunctioning. –
ENGINE SIGNAL 4
[C1133] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine torque down system is malfunc-
tioning. –
ENGINE SIGNAL 6
[C1136] Based on the signal from ECM, ABS actuator and electric unit
(control unit) judges that engine control system is malfunctioning. –
ACTUATOR RLY
[C1140] (Note 3)

Actuator solenoid valve relay is ON, even if control unit sends
off signal.

Actuator solenoid valve relay is OFF, even if control unit sends
on signal. BRC-47, "
Inspection 8:
Actuator Motor Circuit"
DECEL G SEN SET (AWD model)
[C1160] Neutral position correction of Decel G sensor is not finished. BRC-52, "
Inspection 13:
When “DECEL G SEN
SET” Appears on Self-
diagnostic Results Dis-
play (AWD Model)"
Self-diagnostic item Malfunction detecting condition Check system

TROUBLE DIAGNOSIS BRC-35
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
For Fast and Accurate DiagnosisAFS001SR
PRECAUTIONS FOR DIAGNOSIS

Before performing diagnosis, always read precautions. Refer to BRC-12, "How to Proceed with Diagno-
sis" .

If ABS actuator and electric unit (control unit), steering angle sensor, steering system parts or suspension
system parts have been replaced, or if alignment has been adjusted, be sure to adjust neutral position of
steering angle sensor before driving. Refer to BRC-6, "
Adjustment of Steering Angle Sensor Neutral Posi-
tion" .

After diagnosis is finished, be sure to erase memory. Refer to BRC-27, "SELF-DIAGNOSIS" .

When checking continuity and voltage between units, be sure to check for disconnection, looseness,
bend, or collapse of connector terminals. If any malfunction is found, repair or replace connector termi-
nals.

For intermittent symptoms, possible cause is malfunction in harness, harness connector, or terminals.
Move harness, harness connector, and terminals to check for poor connections.

If a circuit tester is used for the check, be careful not to forcibly extend any connector terminal.

To use CONSULT-II to perform self-diagnosis of ABS actuator and electric unit (control unit), active tests,
or work support, first stop work, then connect CONSULT-II and select “ABS”.

While self-diagnostic results of CONSULT-II shows malfunction, if CONSULT-II active test is performed,
an engine system error may be indicated. In this case, start engine to resume the normal screen.

VDC/TCS/ABS system electronically controls brake operation and engine output. The following symptoms
may be caused by normal operations:
Symptom Symptom description Result
Motor operation noise This is noise of motor inside ABS actuator and electric unit (control unit).
Slight noise may occur during VDC, TCS, and ABS operation.
Normal
When the vehicle speed goes over 20 km/h (12.5 MPH), motor and
valves operating noise may be heard. It happens only once after IGN
(ignition) is ON. This is a normal status of the system operation check.
System operation check
noise When engine starts, slight “click” noise may be heard from engine room.
This is normal and is part of system operation check. Normal
VDC/TCS operation
(SLIP indicator lamp blink-
ing) TCS may activate momentarily if wheel speed changes when driving
over location where friction coefficient varies, when up/downshifting, or
when fully depressing accelerator pedal.
Normal
Cancel the VDC/TCS
function for the
inspection on a chas-
sis dynamometer.
For inspection of speedometer or other instruments, press
VDC OFF SW to turn VDC/TCS function off.
When accelerator pedal is depressed on a chassis dynamometer (fixed
front-wheel type), vehicle speed will not increase. This is not normal. It is
result of TCS being activated by stationary front wheels. Warning lamp
may also illuminate to indicate “sensor system error”. This is also nor-
mal, and is the result of the stationary front wheels being detected. To be
certain, restart engine, and drive vehicle at 30 km/h (19 MPH) or more.
Make sure warning lamp does not illuminate.
ABS operation (Longer stop-
ping distance) On roads with low friction coefficients, such as snowy roads or gravel
roads, vehicles with ABS may require a longer stopping distance. There-
fore, when driving on such roads, avoid overconfidence and keep speed
sufficiently low. Normal
Insufficient feeling of accel-
eration Depending on road conditions, driver may feel that feeling of accelera-
tion is insufficient. This is because traction control, which controls
engine and brakes to achieve optimal traction, has the highest priority
(for safety). As a result, there may be times when acceleration is slightly
less than usual for the same accelerator pedal operation. Normal

BRC-36
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
ON and OFF Timing for ABS Warning Lamp, VDC OFF Indicator Lamp, SLIP Indicator Lamp,
Brake Warning Lamp
× : ON –: OFF
NOTE:
1. Brake warning lamp will turn on in case of operating parking brake (switch turned on) or of actuating brake fluid level switch (brake fluid is insufficient).
2. After starting engine, turn OFF.
Basic InspectionAFS001SS
BASIC INSPECTION 1: BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir tank. If fluid level is low, refill brake fluid.
2. Check brake piping and around ABS actuator and electric unit (control unit) for leaks. If there is leaking or oozing fluid, check the following items.

If ABS actuator and electric unit (control unit) connection is loose, tighten piping to the specified torque
and re-perform the leak inspection to make sure there are no leaks.

If there is damage to the connection flare nut or ABS actuator and electric unit (control unit) screw,
replace the damaged part and re-perform the leak inspection to make sure there are no leaks.

When there is fluid leaking or oozing from a part other than ABS actuator and electric unit (control unit)
connection, if fluid is just oozing out, use a clean cloth to wipe off the oozing fluid and re-check for
leaks. If fluid is still oozing out, replace the damaged part.

When there is fluid leaking or oozing at ABS actuator and electric unit (control unit), if fluid is just oozing
out, use a clean cloth to wipe off oozing fluid and re-check for leaks. If fluid is still oozing out, replace
ABS actuator and electric unit (control unit) body.
CAUTION:
ABS actuator and electric unit (control unit) body can not be disassembled.
3. Check brake pad degree of wear. Refer to BR-20, "
PAD WEAR INSPECTION" in “Front Disc Brake” and
BR-26, "
PAD WEAR INSPECTION" in “Rear Disc Brake”
BASIC INSPECTION 2: POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPEC-
TION
Make sure battery positive cable, negative cable and ground connection are not loose. If looseness is
detected, tighten the cables. In addition, check the battery voltage to make sure it has not dropped and alter-
nator is normal.
Condition ABS warning
lamp VDC OFF indi-
cator lamp SLIP indicator
lamp Brake warning
lamp [Note 1] Remarks
Ignition switch OFF. – – – — —
Approx. 2 seconds after igni-
tion switch is turned ON. ××××
[Note 2] —
Approx. 2 seconds later after
ignition switch ON. –––
× [Note 2] Go out 2 seconds after
ignition switch is turned
ON.
VDC OFF SW is turned ON.
(VDC/TCS function is OFF.) –
× –— —
VDC/TCS/ABS error. ××× — There is an ABS actua-
tor and electric unit
(control unit) error.
(Power, ground or sys-
tem malfunction)
When VDC/TCS is not func-
tioning normally. –
×× ——
EBD error. ×××× —
