Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use a mild soap solution or
lukewarm water. Do not remove the belts from the car to
wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
FUSE AND RELAY CENTER
Your vehicle is equipped with a fuse and relay center
located in the engine compartment near the battery.
Located on the underside of the cover is a label that
identifies each component.
1. Disconnect the battery negative (-) cables from the
right and left batteries before removing the cover.
MAINTAINING YOUR VEHICLE 383
7

2. Use specified fuses only.
3. Always properly reinstall the cover.
VEHICLE STORAGE
If you are storing your vehicle for more than 21 days, we
recommend that you take the following steps to mini-
mize the drain on your vehicle’s battery:
•Disconnect the Ignition-Off Draw fuse (I.O.D.) fuse
located in the Fuse and Relay Center, located in the
engine compartment. The I.O.D. cavity includes a
snap-in retainer that allows the fuse to be discon-
nected, without removing it from the fuse block.
•The electronic shift transfer case should be placed in
the 4HI mode and kept in this position to minimize the
battery drain.
•As an alternative to the above steps you may, discon-
nect the negative cables from both batteries.
REPLACEMENT LIGHT BULBS
LIGHT BULBS — Inside Bulb No.
Overhead Console Lights............... TS212-2
Dome Light............................7679
All of the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved.
LIGHT BULBS — Outside Bulb No.
Back-Up..............................3057
Center High Mounted Stop Lamp............. 912
Fog Lamp...........................9006LL
Headlamp (Halogen)...................9007QL
Park & Turn Signal...................3157NAK
Rear License Plate Lamp................... 168
Rear Cargo Light......................... 912
Tail & Stop............................3057
Cab Clearance Lights...................... 168
Dual Rear Wheel Sidemarker Light............ 168
Dual Rear Wheel Tailgate ID Lights (3)......... 168
384 MAINTAINING YOUR VEHICLE

Exterior Lighting........................ 116
Fan .................................. 365
Filters
Engine Oil.....................343,346,398
Flashers
Turn Signal.......................... 118
Flat Tire Stowage.....................317,326
Fluid, Brake........................... 399
Fluid Capacities......................... 397
Fluid Level Checks
Brake............................... 367
Manual Transmission................... 370
Power Steering........................ 356
Transfer Case......................... 370
Fog Lights.......................... 117,396
Fold Flat Load Floor..................... 148
Four Wheel Drive....................... 243
Four-Way Hazard Flasher.................. 314Freeing A Stuck Vehicle................... 331
Front Axle..........................358,369
Fuel..............................281,315
Diesel.........................281,315,398
Gauge.............................. 168
Requirements......................... 281
Specifications......................... 284
Tank Capacity........................ 397
Fuses................................ 383
Garage Door Opener..................... 134
Gauges............................... 169
Coolant Temperature.................... 165
Fuel................................ 168
Oil Pressure.......................... 164
Speedometer......................... 164
Tachometer.......................... 163
Voltmeter............................ 162
Gear Ranges........................... 237
436 INDEX

Tips ................................ 297
Trailer and Tongue Weight................ 294
Trailer Towing Guide..................... 295
Trailer Weight.......................... 295
Transfer Case
Fluid............................... 399
Transmission
Automatic........................237,370
Fluid............................... 399
Maintenance.......................... 370
Manual..........................241,370
Shifting............................. 237
Transmitter, Garage Door Opener............ 134
Tread Wear Indicators.................... 274
Trip Computer.......................... 128
Trip Odometer.......................167,168
Turn Signals................... 118,163,385,389
Underhood Fuses........................ 383Universal Transmitter..................... 134
Variance, Compass....................... 133
Vehicle Identification Number................ 7
Vehicle Loading......................265,286
Vehicle Modifications/Alterations.............. 8
Vehicle Storage......................... 384
Voltmeter............................. 162
Warning Lights (Instrument Cluster Description) . 162
Warnings and Cautions..................... 6
Warranty Information..................... 426
Washers, Windshield..................121,359
Washing Vehicle......................... 379
Wheel Alignment and Balance............... 276
Wheel and Wheel Trim.................... 381
Wheel Changing........................ 317
Wheel Mounting........................ 318
Wheel Nut Torque....................322,326
INDEX 445
