2005 DODGE NEON SRT battery replacement

General Information
This device complies with FCC rules part 15. Operation is
subject to the following two conditions: (1) This device
may not cause harmful interference and (2) This device
must accept any interference that may be received, in-
cluding interference that may cause undesired operation.
If your transmitter fails to operate from a normal dis-
tance, check for these two conditions.
1. Weak batteries in transmitter. The expected life of
batteries is from one to two years.
2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, and some mobile or CB radios.
Transmitter Battery Service
The recommended replacement battery is 2016 or its
equivalent.
NOTE:Do not touch the battery terminals that are on
the back housing or the printed circuit board.1. With the transmitter buttons facing down, use a thin
coin or similar object to pry the two halves of the
transmitter apart. Make sure not to damage the rubber
gasket during removal.
2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.
Separating Transmitter Halves
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Turbo Charged Engine Compartment....141

Onboard Diagnostic System—OBD II......142

Emissions Inspection And Maintenance
Programs
............................143

Replacement Parts.....................144

Dealer Service........................144

Maintenance Procedures.................145
▫Engine Oil..........................145
▫Ignition Wiring System.................151
▫Crankcase Emission Control System........151
▫Fuel Filter..........................151
▫Air Cleaner Element (Filter)..............151▫Maintenance-Free Battery................152
▫Air Conditioner Maintenance.............153
▫Power Steering Fluid Check..............154
▫Front Suspension Ball Joints..............154
▫Body Lubrication.....................155
▫Windshield Wiper Blades................155
▫Windshield Wiper Blade Replacement.......156
▫Windshield Washer Aiming..............156
▫Windshield Washer Reservoir.............156
▫Exhaust System......................156
▫Cooling System.......................157
7

EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS
In some localities, it may be a legal requirement to pass
an inspection of your vehicle’s emissions control system.
Failure to pass could prevent vehicle registration.
For states which have an I/M (Inspection and
Maintenance) requirement, this check verifies the
following: the MIL (Malfunction Indicator Lamp)
is functioning and is not on when the engine is running,
and that the OBD (On Board Diagnostic) system is ready
for testing.
Normally, the OBD system will be ready. The OBD
system maynotbe ready if your vehicle was recently
serviced, if you recently had a dead battery, or a battery
replacement. If the OBD system should be determined
not ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition key actuated test
which you can use prior to going to the test station. To
check if your vehicle’s OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.2. Turn the ignition to the ON position, but do not crank
or start the engine.
3. If you crank or start the engine, you will have to start
this test over.
4. As soon as you turn your key to the ON position, you
will see your MIL symbol come on as part of a normal
bulb check.
5. Approximately 15 seconds later, one of two things will
happen:
a. The MIL will flash for about 10 seconds and then
return to being fully illuminated until you turn off
the ignition key or start the engine. This means that
your vehicle’s OBD system isnot readyand you
shouldnotproceed to the I/M station.
b. The MIL will not flash at all and will remain fully
illuminated until you turn off the ignition key or
start the engine. This means that your vehicle’s OBD
system isreadyand you can proceed to the I/M
station.
MAINTAINING YOUR VEHICLE 143
7

If your OBD system isnot ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
you may need to do nothing more than drive your
vehicle as you normally would in order for your OBD
system to update. A recheck with the above test routine
may then indicate that the system is now ready.
Regardless of whether your vehicle’s OBD system is
ready or not ready, if the MIL symbol is illuminated
during normal vehicle operation, you should have your
vehicle serviced before going to the I/M station. The I/M
station can fail your vehicle because the MIL symbol is on
with the engine running.REPLACEMENT PARTS
Use of genuine Mopar parts for normal/scheduled main-
tenance and repairs is highly recommended to insure the
designed performance. Damage or failures caused by the
use of non-Mopar parts for maintenance and repairs will
not be covered by the manufacturer warranty.
DEALER SERVICE
Your dealer has the qualified service personnel, special
tools and equipment to perform all service operations in
an expert manner. Service manuals are available which
include detailed service information for your vehicle.
Refer to these manuals before attempting any procedure
yourself.
NOTE:Intentional tampering with emissions control
systems can result in civil penalties being assessed
against you.
144 MAINTAINING YOUR VEHICLE

VEHICLE STORAGE
If you will not be using your vehicle for more than 21
days you may want to take steps to preserve your battery.
You may:
•Disengage the mini fuse in the Power Distribution
Center labeled IOD (Ignition Off-Draw).
•Or, disconnect the negative cable from the battery.
REPLACEMENT BULBS
LIGHT BULBS—Inside Bulb No.
ABS Indicator.......................... LED
Airbag Indicator........................ LED
Brake System Warning Indicator............. LED
Climate Controls........................ LED
Console Gear Selector...................PC194
Dome Light............................T579
Glove Box............................PC194
Front Fog Indicator...................... LED
High Beam Indicator....................PC194
Instrument Cluster Illumination............PC194
Low Fuel Indicator....................... LEDLow Oil Pressure Indicator................. LED
Rear Cargo............................T906
Seat Belt Indicator....................... LED
Security Alarm Indicator................... LED
Malfunction Indicator Light................ LED
TRAC OFF Indicator..................... LED
Turn Signal Indicator....................PC194
Voltage Indicator........................ LED
All the inside bulbs are brass or glass wedge base.
Aluminum base bulbs are not approved and should not
be used for replacement.
LIGHTS BULBS—Outside Bulb No.
Headlight.............................9007
Front Park/Turn Signal Light.............3457AK
Front Side Marker Light.................... 168
Front Fog Light......................9145/H10
Center High Mounted Stop Light
(CHMSL).........................921–W16W
Rear Tail/Stop/Turn Signal Light......3157–P27/7W
Backup Light......................921–W16W
License Light........................... 168
MAINTAINING YOUR VEHICLE 173
7

ABS (Anti-Lock Brake) System............. 102
Adding Engine Coolant (Antifreeze)......... 159
Adding Fuel.......................... 124
Air Cleaner, Engine (Engine Air Cleaner Filter) . 151
Air Conditioner Maintenance.............. 153
Air Conditioning........................ 84
Air Conditioning Controls................. 84
Air Conditioning Refrigerant...........153,154
Air Conditioning System................. 153
Air Pressure, Tires...................... 113
Airbag................................ 30
Airbag Deployment...................... 35
Airbag Light.......................38,46,71
Airbag Maintenance...................... 37
Airbag, Side........................... 36
Alarm, Panic........................... 19
Alarm System........................21,71
Alignment and Balance.................. 118
Alterations/Modifications, Vehicle............ 6
Antenna, Satellite Radio................... 83
Antifreeze (Engine Coolant).........158,176,177
Capacities........................... 176
Anti-Lock Brake System (ABS)............. 102Anti-Lock Warning Light.................. 69
Anti-Theft Security Alarm................. 21
Appearance Care....................... 165
Arming Theft System..................... 21
Ashtrays and Lighter..................... 63
Automatic Door Locks.................... 15
Ball Joints............................ 154
Battery............................... 152
Keyless Transmitter Replacement.......... 20
Belts, Drive........................... 149
Belts, Engine.......................... 150
Body Mechanism Lubrication.............. 155
B-Pillar Location....................... 108
Brake Fluid........................... 177
Brake, Parking......................... 100
Brake System.......................102,162
Anti-Lock........................... 102
Hoses.............................. 162
Master Cylinder...................... 163
Parking............................ 100
Warning Light........................ 69
Brakes............................102,162
204 INDEX

Alignment.......................... 118
Chains............................. 119
Changing........................... 130
Compact Spare....................... 115
General Information................... 112
High Speed.......................... 114
Inflation Pressures.................... 113
Jacking............................. 130
Load Capacity....................108,109
Quality Grading...................... 201
Radial.............................. 115
Replacement......................... 117
Rotation............................ 120
Safety.............................. 112
Sizes............................... 105
Snow Tires.......................... 119
Spinning............................ 116
Tread Wear Indicators.................. 117
Towing
Disabled Vehicle...................... 138
Transaxle
Manual...........................95,98
Transmitter Battery Service................ 20Transporting Pets........................ 44
Tread Wear Indicators.................... 117
Trip Odometer Reset Button................ 72
Trunk Release Button..................... 17
Trunk Release, Emergency................. 17
Trunk Release Remote Control.............. 17
Turbo Boost Gauge...................91,121
Turbo Cool Down....................... 97
Turn Signals.........................57,70
Underhood Fuses....................... 170
Uniform Tire Quality Grades.............. 201
Untwisting Procedure, Seat Belt............. 28
Vacuum/Vapor Harnesses................ 161
Vehicle Identification Number............... 6
Vehicle Loading........................ 125
Vehicle Modifications/Alterations............ 6
Vehicle Storage......................... 173
Warning Lights (Instrument Cluster Description) . 69
Warnings and Cautions.................... 6
Warranty Information.................... 198
INDEX 213
