2005 DODGE NEON SRT engine coolant

RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology)
Engine Oil Use API Certified SAE 5W-30 Engine Oil. Refer to your engine oil filler cap
for correct SAE grade meeting DaimlerChrysler Material Standard MS-6395.
Engine Oil Filter Mopar 4781452AA or equiv.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection 91 Octane.
Chassis
Component Fluids, Lubricants and Genuine Parts.
Manual Transmission Fluid MoparATF+4 Automatic Transmission Fluid. Plus 4 oz. Mopar Limited
Slip Additive Friction Modifier.
Brake Master Cylinder MoparDOT 3 and SAE J1703 should be used. If DOT 3 brake fluid is not
available, then DOT 4 or DOT 4+ is acceptable. Use only recommended
brake fluids.
Power Steering Reservoir MoparATF+4 Automatic Transmission Fluid.
MAINTAINING YOUR VEHICLE 177
7

NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first, and follow schedule“B”of the
Maintenance Schedulessection of this manual.
NOTE:IFANYof these apply to you then flush and
replace the engine coolant every 102,000 miles (163 000
km) or 60 months, whichever comes first, and follow
schedule“B”of theMaintenance Schedulessection of
this manual.
NOTE:Most vehicles are operated under the conditions
listed for ScheduleB.
Second is Schedule“A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
uleB
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
At Each Stop for Fuel
•
Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
•Check the windshield washer solvent and add if
required.
MAINTENANCE SCHEDULES 181
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Once a Month
•
Check tire pressure and look for unusual wear or
damage.
•Inspect the battery and clean and tighten the terminals
as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder and transaxle and add as needed.
•Check all lights and all other electrical items for correct
operation.
•Check rubber seals on each side of the radiator for
proper fit.
At Each Oil Change
•
Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints and front suspension compo-
nents.
•Check the manual transaxle fluid level and fill plug
condition.
•Check the coolant level, hoses, and clamps.
182 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

SCHEDULE“B”
Follow schedule“B”If you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F(0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Trailer towing.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert operation.
•If equipped for and operating with E-85 (ethanol)
fuel.
NOTE:IfANYof these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first, and follow schedule“B”of the
Maintenance Schedulessection of this manual.
NOTE:IFANYof these apply to you then flush and
replace the engine coolant every 102,000 miles (163 000
km) or 60 months, whichever comes first, and follow
schedule“B”of theMaintenance Schedulessection of
this manual.
If none of these apply to you, then change your engine oil
at every interval shown on scheduleAof theMainte-
nance Schedulessection of this manual.
SCHEDULE“B”183
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 57,000 60,000 63,000 66,000 69,000 72,000
(Kilometers) (91 000) (96 000) (101 000) (106 000) (110 000) (115 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Rotate tires. X X X
Inspect the brake linings. X X
Replace theengine air cleaner filter.X
Replace thespark plugs and ignition cables.X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if neces-
sary. Not required if previously changed. *‡X
Replace themake-up air filter(located inside
the air cleaner).X
Adjust the generator drive belt tension. X
Replace manual transaxle fluid.X
Flush and replace engine coolant at 60
months, if not done at 102,000 miles.X
SCHEDULE“B”187
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 35,000 40,000 45,000 50,000 55,000
(Kilometers) (56 000) (64 000) (72 000) (80 000) (88 000)
[Months] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter.XXXXX
Rotate tires.XXXXX
Inspect the brake linings. X
Flush and replace the engine coolant at 60 months, if
not done at 100,000 miles.X
SCHEDULE“A”191
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 90,000 95,000 100,000 105,000
(Kilometers) (144 000) (156 000) (160 000) (168 000)
[Months] [108] [114] [120] [126]
Change engine oil and engine oil filter. X X X X
Rotate tires. X X X X
Inspect the brake linings. X
Replace theengine air cleaner filter.X
Replace thespark plugs.X
Adjust the generator drive belt tension. X
Inspect the tie rod ends and boot seals. X
Inspect thePCV valveand replace if necessary. Not required if
previously changed. *‡X
Flush and replace the engine coolant, if not done at 60 months. X
Replace themake-up air filter(located inside the air cleaner). X
Replace theengine timing belt.X
Replace manual transaxle fluid. X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
SCHEDULE“A”193
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

ABS (Anti-Lock Brake) System............. 102
Adding Engine Coolant (Antifreeze)......... 159
Adding Fuel.......................... 124
Air Cleaner, Engine (Engine Air Cleaner Filter) . 151
Air Conditioner Maintenance.............. 153
Air Conditioning........................ 84
Air Conditioning Controls................. 84
Air Conditioning Refrigerant...........153,154
Air Conditioning System................. 153
Air Pressure, Tires...................... 113
Airbag................................ 30
Airbag Deployment...................... 35
Airbag Light.......................38,46,71
Airbag Maintenance...................... 37
Airbag, Side........................... 36
Alarm, Panic........................... 19
Alarm System........................21,71
Alignment and Balance.................. 118
Alterations/Modifications, Vehicle............ 6
Antenna, Satellite Radio................... 83
Antifreeze (Engine Coolant).........158,176,177
Capacities........................... 176
Anti-Lock Brake System (ABS)............. 102Anti-Lock Warning Light.................. 69
Anti-Theft Security Alarm................. 21
Appearance Care....................... 165
Arming Theft System..................... 21
Ashtrays and Lighter..................... 63
Automatic Door Locks.................... 15
Ball Joints............................ 154
Battery............................... 152
Keyless Transmitter Replacement.......... 20
Belts, Drive........................... 149
Belts, Engine.......................... 150
Body Mechanism Lubrication.............. 155
B-Pillar Location....................... 108
Brake Fluid........................... 177
Brake, Parking......................... 100
Brake System.......................102,162
Anti-Lock........................... 102
Hoses.............................. 162
Master Cylinder...................... 163
Parking............................ 100
Warning Light........................ 69
Brakes............................102,162
