2005 DODGE NEON SRT windshield wipers

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS

Mirrors..............................49
▫Inside Day/Night Mirror.................49
▫Outside Mirror—Driver’s Side............49
▫Outside Mirror—Passenger’s Side..........49
▫Electric Remote-Control Mirrors............50

Seats................................50
▫Front Seat Adjustment...................50
▫Reclining Bucket Seats...................51
▫Folding Rear Seat......................52

To Open And Close The Hood.............53

Lights...............................54▫Front Map/Reading Lights...............54
▫Interior Lights........................55
▫Multi-Function Control Lever..............56
▫Headlights, Parking Lights, Instrument Panel
Lights..............................56
▫Daytime Running Lights (Canada Only)......57
▫Lights-On Reminder....................57
▫Fog Lights...........................57
▫Turn Signals..........................57
▫Headlight Dimmer Switch................57
▫Passing Light.........................57

Windshield Wipers And Washers...........58
3

▫Windshield Washers....................58
▫Mist Function.........................58
▫Intermittent Wiper System................59
▫Lo Speed Wipers.......................59
▫Hi Speed Wipers.......................59

Tilt Steering Column.....................59

Power Sunroof—If Equipped.............60
▫Sunroof Maintenance....................61
▫Wind Buffeting........................62

Console Features.......................62
▫Ash Receiver And Cigar Lighter............63
48 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by a switch
in the control lever. Move the control lever up to
select the desired wiper speed.
Windshield Washers
To use the washer, pull the control lever toward you and
hold while spray is desired. If the lever is pulled while in
the delay range, the wiper will operate in low speed for
two wipe cycles after the lever is released, and then
resume the intermittent interval previously selected.
If the lever is pulled while in the OFF position, the wipers
will operate for two wipe cycles, then turn OFF.
CAUTION!
•In cold weather, always turn off the wiper switch
and allow the wipers to return to the park position
before turning off the engine. If the wiper switch
is left on and the wipers freeze to the windshield,
damage to the wiper motor may occur when the
vehicle is restarted.
Mist Function
Push down on the wiper control lever to activate a single
wipe to clear the windshield of road mist or spray from
a passing vehicle. The wiper blade will continue to wipe
until you release the stalk.
Windshield Wiper/Washer Control
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Body Lubrication
Locks and all body pivot points, including such items as
seat tracks, doors, trunk and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to insure proper function. When performing other
underhood services, the hood latch, release mechanism
and safety catch should be cleaned and lubricated.
The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as MoparLock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
Clean the rubber edges of the wiper blades and the
windshield periodically with a sponge or soft cloth and a
mild non abrasive cleaner, or use the washer solvent. This
will remove accumulations of salt or road film and help
reduce streaking and smearing.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield. Avoid using the wiper blades to
remove frost or ice from the windshield. Make sure that
they are not frozen to the glass before turning them on to
avoid damaging the blade. Keep the blade rubber out of
contact with petroleum products such as engine oil,
gasoline, etc.
MAINTAINING YOUR VEHICLE 155
7

Washer, Adding Fluid................... 156
Washers, Windshield..................... 58
Washing Vehicle........................ 165
Wheel Alignment and Balance............. 118
Wheel and Wheel Trim Care............... 166
Wind Buffeting......................... 62
Window Fogging........................ 89
Windows
Power.............................. 22
Windshield Washer Aiming............... 156
Windshield Washers..................... 58
Fluid.............................. 156
Windshield Wiper Blades................. 155
Windshield Wipers...................... 58
Wiper Blade Replacement................. 156
Wipers, Intermittent...................... 59
Wiring, Ignition........................ 151
214 INDEX
