2005 DODGE GRAND CARAVAN washer fluid

Electronic Vehicle Information Center (EVIC) — If
Equipped
The Electronic Vehicle Information Center, when the
appropriate conditions exist, displays the following
WARNING messages and symbols. Each message is
accompanied by a single chime:
• TURN SIGNALS ON (with graphic)
• PERFORM SERVICE
• DOOR AJAR (one or more, with graphic)
• LIFTGATE AJAR (with graphic)
• WASHER FLUID LOW (with graphic)
• 1,2,3 OR 4 LOW TIRE(S) PRESSURE (Refer to “ Starting
And Operating, Tire Section ” )
• 1,2,3 OR 4 TIRE(S) HIGH PRESSURE (Refer to “ Start-
ing And Operating, Tire Section ” ) • CHECK TPM SYSTEM (Refer to “ Starting And Oper-
ating, Tire Section ” )
• MEMORY SEAT DISABLED (Not in Park) — If
Equipped
• ADJUSTABLE PEDAL DISABLED/CRUISE EN-
GAGED
• ADJUSTABLE PEDAL DISABLED/VEHICLE IN RE-
VERSE
• REAR PARK ASSIST (Shown in Reverse only with a
single chime) — If Equipped
NOTE: Tire pressure menu items are available only on
vehicles equipped with the Tire Pressure Monitor Sys-
tem. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155
3

CAUTION!Driving with a hot engine cooling system could
damage your vehicle. If temperature gauge reads (H),
pull over and stop the vehicle. Idle the vehicle with
the air conditioner turned off until the pointer drops
back into the normal range. If the pointer remains on
the “ H ” , and you hear continuous chimes, turn the
engine off immediately, and call for service. WARNING!A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call a service center if your
vehicle overheats. If you decide to look under the
hood yourself, see Section 7 of this manual. Follow
the warnings under the Cooling System Pressure
Cap paragraph.
17. Washer Fluid Light
This light turns on when the washer fluid level
falls below approximately 1/4 filled. The light will
remain on until fluid is added.
18. Transmission Range Indicator
This display indicator shows the automatic transaxle gear
selection. UNDERSTANDING YOUR INSTRUMENT PANEL 201
4

Intermittent Rear Wiper Operation — Automatic
Temperature Control Only
When this button is pressed and the ignition
switch is in the ON position, the rear wiper will
operate at a fixed interval of about 8 seconds. As
vehicle speed increases, the time delay will shorten. The
switch position as well as an indicator light will show
when the wiper is ON.
Rear Washer Operation — Automatic
Temperature Control Only
Press and hold the button as long as spray is
desired. If the switch is depressed while the wipers
are on, the wipers will operate for a few seconds
after the switch is released then resume the previously set
mode of intermittent wiper or continuous wipe. If the
switch is depressed when the wipers are off, the wipers
will operate for two cycles, then turn off. NOTE: The washers will stop spraying if the switch is
pressed longer than 10 seconds.
Adding Washer Fluid
The fluid reservoir for the windshield washers and the
rear window washer is shared. It is located in the front of
the engine compartment on the passenger side and
should be checked for fluid level at regular intervals. Fill
the reservoir with windshield washer solvent (not radia-
tor antifreeze) and operate the system for a few seconds
to flush out the residual water.286 UNDERSTANDING YOUR INSTRUMENT PANEL

The washer fluid reservoir will hold a full gallon of fluid
when the Low Washer Fluid Light illuminates. Electric Rear Window Defroster — If Equipped
Press this button to turn on the rear window
defroster and the optional heated mirrors. A light
will show that the defroster is on. The defroster automati-
cally turns off after about 10 minutes of operation.
If your vehicle is equipped with Infrared Three-Zone
Automatic Temperature Control the rear defroster sym-
bol will show in the display screen when the rear
window defroster is on.
Washer Fluid Reservoir UNDERSTANDING YOUR INSTRUMENT PANEL 287
4

▫ Steering Shaft Seal ....................391
▫ Steering Linkage ......................391
▫ Drive Shaft Universal Joints ..............391
▫ Body Lubrication .....................391
▫ Windshield Wiper Blades ................392
▫ Windshield And Rear Window Washers .....392
▫ Exhaust System ......................393
▫ Cooling System .......................394
▫ Hoses And Vacuum/Vapor Harnesses .......399
▫ Brakes .............................399
▫ Master Cylinder — ABS Brakes Brake
Fluid Level Check .....................401
▫ Fuel System Hoses ....................402 ▫ Automatic Transmission ................402
▫ Front And Rear Wheel Bearings ...........406
▫ Appearance Care And Protection
From Corrosion ......................406
▫ Cleaning The Instrument Panel And Underseat
Cup Holders ........................410

Integrated Power Module (IPM) ............412

Vehicle Storage ........................415

Replacement Light Bulbs .................415

Bulb Replacement ......................416
▫ Headlights ..........................416
▫ Front Park/Turn Signal And
Sidemarker Lights .....................418
▫ Front Fog Light ......................419372 MAINTAINING YOUR VEHICLE

The external lock cylinders should be lubricated twice a
year, preferably in the fall and spring. Apply a small
amount of a high quality lubricant such as Mopar  Lock
Cylinder Lubricant directly into the lock cylinder.
Windshield Wiper Blades
The rubber edges of the wiper blades and the windshield
should be cleaned periodically with a sponge or soft cloth
and a mild nonabrasive cleaner. This will remove accu-
mulations of salt or road film.
Operation of the wipers on dry glass for long periods
may cause deterioration of the wiper blades. Always use
washer fluid when using the wipers to remove salt or dirt
from a dry windshield.
Avoid using the wiper blades to remove frost or ice from
the windshield. Keep the blade rubber out of contact with
petroleum products such as engine oil, gasoline, etc. Windshield and Rear Window Washers
The fluid reservoir for the windshield washers and the
rear window washer is shared. It is located in the engine
compartment and should be checked for fluid level at
regular intervals. Fill the reservoir with windshield
washer solvent (not radiator antifreeze) and operate the
system for a few seconds to flush out the residual water.
The washer fluid reservoir will hold a full gallon of fluid
when the Low Washer Fluid Light illuminates.392 MAINTAINING YOUR VEHICLE

Exhaust System
The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.
Whenever a change is noticed in the sound of the exhaust
system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is
damaged, have a competent mechanic inspect the com-
plete exhaust system and adjacent body areas for broken,
damaged, deteriorated, or mispositioned parts. Open
seams or loose connections could permit exhaust fumes
to seep into the passenger compartment. In addition,
inspect the exhaust system each time the vehicle is raised
for lubrication or oil change. Replace as required.
WARNING!Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing CO, fol-
low the preceding safety tips.Washer Fluid Reservoir MAINTAINING YOUR VEHICLE 393
7

Adding Fuel ........................... 334
Adding Washer Fluid .................. 286,392
Additives, Fuel ......................... 332
Adjustable Pedals ....................... 146
Air Conditioner Maintenance ............... 388
Air Conditioning ..................... 262,267
Air Conditioning Controls ................. 262
Air Conditioning Filter ................. 284,389
Air Conditioning, Operating Tips ............ 284
Air Conditioning, Rear Zone ............. 270,279
Air Conditioning Refrigerant ............... 388
Air Conditioning System .......... 262,267,272,388
Air Conditioning System, Zone Control ........ 263
Air Pressure, Tires ....................... 317
Airbag ................................ 53
Airbag Deployment ....................... 65
Airbag Light ................... 57,58,68,84,199
Airbag Maintenance ....................... 67
Airbag, Window ......................... 54 Alarm Light ........................... 200
Alarm System ........................... 27
Alignment and Balance ................... 324
Alterations/Modifications, Vehicle ............. 7
Antenna, Satellite Radio ................... 257
Antifreeze (Engine Coolant) ........... 395,396,421
Disposal ............................ 397
Anti-Lock Brake System (ABS) .............. 303
Anti-Lock Warning Light .................. 199
Anti-Theft Security Alarm .................. 27
Appearance Care ........................ 406
Arming Theft System ...................... 27
Ashtray ............................... 171
Auto Down Power Windows ................ 40
Automatic Dimming Mirror ................. 92
Automatic Door Locks ................... 19,20
Automatic Headlights .................... 136
Automatic Temperature Control ............. 272
Automatic Transaxle ...................... 297458 INDEX
