2005 CHRYSLER SEBRING CONVERTIBLE Owners Manual

You will first loosen the adjusters on the lower straps and
on the tether strap so that you can more easily attach the
hooks or connectors to the vehicle anchorages. Next
attach the lower hooks or connectors over the top of the
anchorage bars, pushing aside the seat cover material.
Then lift the carpet flap to expose the tether anchor
directly behind the seat where you are placing the child
restraint and attach the tether strap to provide the most
direct path between the anchor and the child restraint.
Finally, tighten all three straps as you push the child
restraint rearward and downward into the seat, remov-
ing slack in the straps according to the child restraint
manufacturer’s instructions.
WARNING!
Improper installation of a child restraint to the
LATCH anchorages can lead to failure of an infant or
child restraint. The child could be badly injured or
killed. Follow the manufacturer’s directions exactly
when installing an infant or child restraint.
Installing Child Restraints Using the Vehicle Seat
Belts
The passenger seat belts are equipped with cinching latch
plates which are designed to keep the lap portion tight
around the child restraint so that it is not necessary to use
a locking clip. Pulling up on the shoulder portion of the
lap/shoulder belt will tighten the belt. The cinching latch
plate will keep the belt tight, however, any seat belt
system will loosen with time, so check the belt occasion-
ally and pull it tight if necessary.
In the rear seat, you may have trouble tightening the
lap/shoulder belt on the child restraint because the
buckle or latch plate is too close to the belt path opening
on the restraint. Disconnect the latch plate from the
buckle and twist the short buckle-end belt several times
to shorten it. Insert the latch plate into the buckle with the
release button facing out.
If the belt still can’t be tightened, or if by pulling and
pushing on the restraint loosens the belt, you may need
to do something more. Disconnect the latch plate from
the buckle, turn the buckle around, and insert the latch
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
2

plate into the buckle again. If you still can’t make the
child restraint secure, try a different seating position.
To attach a child restraint tether strap:
1. Lift the carpet flap to expose the anchor directly behind
the seat where you are placing the child restraint.2. Route the tether strap to provide the most direct path
for the strap between the anchor and the child seat.
3. Attach the tether strap hook (A) of the child restraint to
the anchor and remove slack in the tether strap (B)
according to the child restraint manufacturer’s instruc-
tions.
Child Tether Anchor LocationTether Strap Mounting
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor positions directly behind
the child seat to secure a child restraint top tether
strap.
Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
ENGINE BREAK-IN RECOMMENDATIONS
The engine in your new vehicle does not require a long
break-in period.
Drive moderately during the first 300 miles (500 km).
After the initial 60 miles (100 km), speeds up to 50 or 55
mph (80 or 90 km/h) are desirable.
While cruising, brief full-throttle acceleration, within the
limits of local traffic laws, contributes to a good break-in.
Wide open throttle acceleration in low gear can be
detrimental and should be avoided.
The crankcase oil installed in the engine at the factory is
a high quality energy conserving type lubricant. Oil
changes should be consistent with expected climate con-
ditions under which vehicle operations will occur. The
recommended viscosity and quality grades are in Section
7 of this manual.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
2

Do not use non-detergent or straight mineral oils.
A new engine may consume some oil during its first few
thousand miles of operation. This is a normal part of the
break-in and not an indication of a problem.
SAFETY TIPS
Exhaust Gas
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide (CO) which is colorless and odorless.
Breathing it can make you unconscious and can
eventually poison you. To avoid breathing (CO)
follow the safety tips below.
•Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in
or out of the area.
•If it is necessary to sit in a parked vehicle with the
engine running, adjust your heating or cooling con-
trols to force outside air into the vehicle. Set the blower
at high speed.
•To avoid drawing exhaust gases into the vehicle, close
the trunk while driving. However, if for some reason it
must remain open, close all windows. Adjust the
heating or cooling system to force outside air into the
vehicle. Set the blower at high speed.
Safety Checks You Should Make Inside the
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Safety belt assemblies must be replaced after a collision if
they have been damaged (bent retractor, torn webbing,
etc.). If there is any question regarding belt or retractor
condition, replace the belt.
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Airbag Light
The light should come on and remain on for 6 to
8 seconds as a bulb check when the ignition
switch is first turned ON. If the bulb is not lit
during starting, have it replaced. If the light stays on or
comes on while driving, have the system checked by an
authorized dealer.
Defrosters
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
the Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect for tread cuts or sidewall
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
water, oil, or other fluid leaks. Also, if gasoline fumes are
present, the cause should be corrected immediately.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45
2

UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS

Convertible Top Operation................49
▫To Lower The Top......................49
▫To Raise The Top......................51
▫Top Cover Installation...................52
▫Top Cover Removal.....................57

Console Features.......................57

Mirrors..............................58
▫Inside Day/Night Mirror—If Equipped......58
▫Automatic Dimming Mirror—If Equipped....59
▫Electric Remote-Control Mirrors............60
▫Illuminated Vanity Mirrors................61

Seats................................61
▫Manual Front Seat Adjustments............61
▫Power Driver’s Seat.....................63
▫Heated Seats—If Equipped..............63
▫To Fold The Front Seatback Forward.........64
▫Easy Entry System.....................64
▫Adjustable Head Restraints...............65

To Open And Close The Hood.............65

Lights...............................67
▫Front Map/Reading Lights...............67
▫Interior Lights........................67
3

▫Multi-Function Control Lever..............69
▫Headlights, Parking Lights, Instrument Panel
Lights..............................69
▫Automatic Headlights—If Equipped.........70
▫Daytime Running Lights (Canada Only)......70
▫Lights-On Reminder....................70
▫Fog Lights—If Equipped................70
▫Turn Signals..........................70
▫Headlight Beam Select Switch.............71
▫Flash To Pass.........................71
▫Headlight Time Delay...................71

Windshield Wipers And Washers...........71
▫Mist................................72
▫Speed Sensitive Intermittent Wiper System....72

Tilt Steering Column.....................73

Traction Control—If Equipped.............73

Electronic Speed Control—If Equipped......74
▫To Activate...........................74
▫To Set At A Desired Speed................75
▫To Deactivate.........................75
▫To Resume Speed......................75
▫To Vary The Speed Setting................75
▫To Accelerate For Passing................76
▫Using Speed Control On Hills.............76

Garage Door Opener—If Equipped.........77
▫Programming The Universal Transceiver......78
▫“Rolling Code”Programming.............79
▫Canadian Programming/Gate Programming . . .81
▫Operation............................81
▫Reprogramming A Single Button...........81
▫Security.............................81

Electrical Power Outlet...................82
48 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
