2005 CHRYSLER 300 SRT Owners Manual

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS

Instruments And Controls................132

Premium Instrument Cluster..............133

Instrument Cluster Descriptions...........134

Electronic Vehicle Information Center
(EVIC)
..............................140
▫Trip Functions.......................142
▫Compass Display.....................143
▫Telephone — If Equipped...............145
▫Navigation — If Equipped...............146
▫System Warnings (Customer Information
Features)...........................147▫Personal Settings (Customer Programmable
Features)...........................147

Setting The Analog Clock................151

Sales Code RAK – AM/FM/Cassette/CD
(6-Disc) Radio With Optional Satellite Radio,
Hands Free Phone, Video, MP3, And WMA
Capabilities
..........................151
▫Operating Instructions - Radio Mode.......151
▫Operating Instructions — Tape Player.......155
▫Seek Button.........................155
▫Fast Forward (FF).....................155
▫Rewind (RW)........................155
▫Tape Eject...........................156
4

▫Scan Button.........................156
▫Changing Tape Direction................156
▫Metal Tape Selection...................156
▫Pinch Roller Release...................156
▫Noise Reduction......................156
▫Operation Instructions - (CD Mode For
CD Audio Play)......................156
▫Load/Eject Button (CD Mode For
CD Audio Play)......................157
▫Notes On Playing MP3 Files.............159
▫Operation Instructions - (CD Mode For MP3
And WMA Audio Play).................161
▫Load/Eject Button (CD Mode For MP3 And
WMA Play).........................161

Satellite Radio — If Equipped.............163
▫System Activation.....................163▫Electronic Serial Number/Sirius Identification
Number (ESN/SID)....................163
▫Selecting Satellite Mode In REF And
RAK Radio..........................164
▫Selecting a Channel....................164
▫Storing And Selecting Pre-Set Channels......165
▫Using The PTY (Program Type) Button (If
Equipped)..........................165
▫PTY ButtonScan.....................165
▫PTY ButtonSeek.....................165
▫Satellite Antenna......................165
▫Reception Quality.....................165

Navigation System (Sales Code REC) — If
Equipped
............................166

Remote Sound System Controls...........166
▫Radio Operation......................167
▫Tape Player.........................167
130 UNDERSTANDING YOUR INSTRUMENT PANEL

▫CD Player..........................168
▫Satellite............................168

Radio General Information...............168
▫Radio Broadcast Signals.................168
▫Two Types Of Signals..................168
▫Electrical Disturbances..................169
▫AM Reception.......................169
▫FM Reception........................169

Cassette Tape And Player Maintenance......169

CD/DVD Disc Maintenance..............170

Radio Operation And Cellular Phones.......171

Climate Controls......................171
▫Automatic Temperature Control...........171
▫Summer Operation....................176
▫Winter Operation.....................177
▫Vacation Storage......................177
▫Window Fogging.....................177
▫Outside Air Intake....................177
▫A/C Air Filter — If Equipped............177
▫Operating Tips.......................178
UNDERSTANDING YOUR INSTRUMENT PANEL 131
4

INSTRUMENTS AND CONTROLS
132 UNDERSTANDING YOUR INSTRUMENT PANEL

PREMIUM INSTRUMENT CLUSTER
UNDERSTANDING YOUR INSTRUMENT PANEL 133
4

INSTRUMENT CLUSTER DESCRIPTIONS
1. Oil Pressure Warning Light
This light shows low engine oil pressure. The
light should turn on momentarily when the
engine is started. If the light turns on while driving,
stop the vehicle and shut off the engine as soon as
possible. A continuous chime will sound when this
light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked under the hood.
2. Low Fuel Indicator Light
The Low Fuel Light will turn on when there is
approximately 2 gallons (9 liters) of fuel remain-
ing in the tank. This light will remain on until
fuel is added.
3. Front Fog Light Indicator
This light shows the front fog lights are ON.4. Turn Signal Indicators
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle has
traveled about one mile with the turn signals on, a chime
will sound to alert you to turn the signals off. If either
indicator flashes at a rapid rate, check for a defective
outside light bulb.
5. Speedometer
Indicates vehicle speed.
6. Electronic Vehicle Information Center Display
When the appropriate conditions exist, this display
shows the Electronic Vehicle Information Center (EVIC)
messages. Refer to Electronic Vehicle Information Center
for specific messages.
7. Tachometer
The red segments indicate the maximum permissible
engine revolutions-per-minute (r.p.m. x 1000) for each
gear range. Before reaching the red area, ease up on the
accelerator.
134 UNDERSTANDING YOUR INSTRUMENT PANEL

8. Engine Temperature Warning Light
This light illuminates, and will be accompanied
by a single chime to warn of an overheated
engine condition. The engine temperature is
critically hot, and the vehicle should be turned off
immediately. The vehicle should be serviced as soon
as possible.
9. Anti-Lock Brake Light
This light monitors the Anti-Lock Brake System.
The light will turn on when the ignition switch
is turned to the ON position and may stay on for as
long as four seconds.
If the ABS light remains on or turns on while driving, it
indicates that the Anti-Lock portion of the brake system
is not functioning and that service is required. However,
the conventional brake system will continue to operate
normally if the BRAKE warning light is not on.
If the ABS light is on, the brake system should be serviced
as soon as possible to restore the benefits of Anti-Lock
brakes. If the ABS light does not turn on when the
Ignition switch is turned to the ON position, have the
light inspected by an authorized dealer.
10. Electronic Stability Program (ESP)/Brake Assist
System (BAS) Warning Light
The yellow ESP warning light in the instru-
ment cluster and the yellow BAS malfunc-
tion indicator light both come on with the
key in the ignition switch turned to the
“ON” position. They should go out with the engine
running. If the ESP/BAS malfunction indicator light
comes on continuously with the engine running, a
malfunction has been detected in either the ESP or the
BAS system. If this light stays illuminated, have the
ESP and BAS checked at your authorized dealer as
soon as possible.
11. Airbag Light
This light turns on and remains on for 6 to 8
seconds as a bulb check when the ignition
switch is first turned ON. If the light is not
on during starting, stays on, or turns on
while driving, have the system inspected by an autho-
rized dealer as soon as possible.
UNDERSTANDING YOUR INSTRUMENT PANEL 135
4

12. Brake System Warning Light
This light monitors various brake functions,
including brake fluid level and parking
brake application. If the brake light turns on,
it may indicate that the parking brake is
applied, there is a low brake fluid level or there is a
problem with the anti-lock brake system.
The dual brake system provides a reserve braking capac-
ity in the event of a failure to a portion of the hydraulic
system. Failure of either half of the dual brake system is
indicated by the Brake Warning Light which will turn on
when the brake fluid level in the master cylinder has
dropped below a specified level.
The light will remain on until the cause is corrected.
NOTE:The light may flash momentarily during sharp
cornering maneuvers which change fluid level condi-
tions. The vehicle should have service performed, and
the brake fluid level checked.
If brake failure is indicated, immediate repair is neces-
sary.
WARNING!
Driving a vehicle with the brake light on is danger-
ous. Part of the brake system may have failed. It will
take longer to stop the vehicle. You could have an
accident. Have the vehicle checked immediately.
Vehicles equipped with Anti-Lock brakes (ABS), are also
equipped with Electronic Brake Force Distribution (EBD).
In the event of an EBD failure, the Brake Warning Light
will turn on along with the ABS Light. Immediate repair
to the ABS system is required.
The operation of the Brake Warning Light can be checked
by turning the ignition switch from the OFF position to
the ON position. The light should illuminate for approxi-
mately two seconds. The light should then turn off unless
the parking brake is applied or a brake fault is detected.
If the light does not illuminate, have the light inspected
by an authorized dealer.
