2005 BMW MOTORRAD K 1200 S headlight bulb

A defective bulb places
your safety at risk be-
cause it is easier for other
users to oversee you and
your motorcycle.
Replace defective bulbs as
soon as possible; always
carry a complete set of spare
bulbs if possible.
Low-beam headlight, high-
beam headlight, side-light or
turn-indicator bulb defective.
Replacing low-beam head-
light bulb ( 112)
Replacing high-beam head-
light bulb ( 114)
Replacing parking-light bulb
( 115)
Replacing front turn indicat-
or bulb ( 117)
Replacing rear turn indicator
bulb ( 117) Bulbs defective
General warning light
lights up yellow.
LAMPS!
warning appears on
the display.
A defective bulb places
your safety at risk be-
cause it is easier for other
users to oversee you and
your motorcycle.
Replace defective bulbs as
soon as possible; always
carry a complete set of spare
bulbs if possible.
A combination of the bulb de-
fects described above has
occurred.
See the fault descriptions
above.
Ice warning Ice warning symbol ap-
pears on the display. The air temperature measured
at the motorcycle is lower
than 3 °C.
The ice warning does
not mean that there is
no risk of black ice forming
at measured temperatures
above 3 °C.
Always take extra care and
think well ahead when tem-
peratures are low; remember
that the danger of black ice
is particularly high on bridges
and where the road is in the
shade.
Ride carefully and think well
ahead.
Anti-theft alarm battery
weak Battery symbol appears
on the display, accom-
panied by the letters
DWA
.
327zStatus indicators

Press the lever down to the
ground.BulbsGeneral instructionsThe 'bulb defect' symbol ap-
pears in the display if a bulb
is defective. If the brake or
rear light fails, the symbol is
accompanied by the general
warning light, which lights up
yellow. If the rear light fails
the second filament of the
brake light shines at reduced
brightness to double as a rear
light. Even though you havethis substitute rear light, the
indicators in the display tell
you that a bulb defect has oc-
curred.
A defective bulb places
your safety at risk be-
cause it is easier for other
users to oversee you and
your motorcycle.
Replace defective bulbs as
soon as possible; always
carry a complete set of spare
bulbs if possible.
The bulb is pressurised
and can cause injury if
damaged.
Wear protective goggles
and gloves when changing
bulbs.
The types of bulb fitted
to your motorcycle are
listed in the section entitled
"Technical data". Do not touch the glass
of new bulbs with your
fingers. Use a clean, dry cloth
to hold the bulbs when hand-
ling them. Dirt deposits, in
particular oil and grease, in-
terfere with heat radiation
from the bulb. This leads to
overheating and shortens the
bulb's operating life.
Replacing low-beam
headlight bulb
If it is not standing firmly,
the motorcycle could
topple in the course of the
operations described below.
Always make sure that the
motorcycle is stable and
firmly supported.
Turn the handlebars to
the left to facilitate ac-
cess.
7112zMaintenance

When installing, make sure
that tab5is pointing up.Replacing high-beam
headlight bulb
If it is not standing firmly,
the motorcycle could
topple in the course of the
operations described below.
Always make sure that the
motorcycle is stable and
firmly supported.
Turn the handlebars to
the left to facilitate ac-
cess. Make sure the ground is
level and firm and place the
motorcycle on its stand.
Switch off the ignition.
Turn cover
1counter-
clockwise and remove
it. Disconnect plug
2.
Release spring clip 3at left
and right and swing it up.
7114zMaintenance

Remove bulb4.
Installation of the bulb is the
reverse of the removal pro-
cedure.
Use a clean, dry cloth to
hold the new bulb. When installing, make sure
that tab
5is pointing up.
Position in headlightSide-light bulb 1is accessible
through 2.
Replacing parking-light
bulb
If it is not standing firmly,
the motorcycle could
topple in the course of the
operations described below.
Always make sure that the
motorcycle is stable and
firmly supported.
Make sure the ground is
level and firm and place the
motorcycle on its stand.
Switch off the ignition.
Pull off the connector 3be-
neath the headlight.
7115zMaintenance

Remove the bulb holder4
from the headlight hous-
ing by turning it counter-
clockwise.
Twist the bulb 5to remove
it from the bulb holder.
Installation of the bulb is the
reverse of the removal pro-
cedure.
Use a clean, dry cloth to
hold the new bulb.Replacing the brake light
and rear light bulbs
If it is not standing firmly,
the motorcycle could
topple in the course of the
operations described below.
Always make sure that the
motorcycle is stable and
firmly supported.
Make sure the ground is
level and firm and place the
motorcycle on its stand.
Removing the seat ( 50) Switch off the ignition.
Remove screw
1.
Pull the bulb housing to the
rear until it is clear of hold-
ers 2. Turn bulb holder
3counter-
clockwise to remove it from
the bulb housing.
Press the bulb into
its socket and turn it
counter-clockwise to
remove.
Installation of the brake light
and rear light bulbs is the
reverse of the removal pro-
cedure.
Use a clean, dry cloth to
hold the new bulb.
7116zMaintenance

Lighting
High-beam headlight bulb, standard designa-
tionH7 halogen bulb
High-beam headlight bulb, voltage 12 V
High-beam headlight bulb, power 55 W
Low-beam headlight bulb, standard designa-
tion H7 halogen bulb
Low-beam headlight bulb, voltage 12 V
Low-beam headlight bulb, power 55 W
Parking light bulb, standard designation W5W
Parking light bulb, voltage 12 V
Parking light bulb, power 5 W
Tail light / brake light bulb, standard designa-
tion P21W
Tail light / brake light bulb, voltage 12 V
Tail light / brake light bulb, power 21 W
Front flashing turn indicator bulbs, standard
designation W16W
Front flashing turn indicator bulbs, voltage 12 V
Front flashing turn indicator bulbs, power 10 W
9140zTechnical data
