Turn the lock strap
buckles1of the lock straps
out.
Pull the lock straps up and
out.
This expands the case to
maximum volume. Close the lock straps.
Press the lock straps
against the case body.
The case volume adapts to
the contents.
Removing the caseTurn the case lock until it
is at an angle of 45° to the
forward direction of travel.
Key cannot be removed.
Case locked.
Cases can be removed.
Pull the black release lever
(RELEASE) up.
687zAccessories
Pull the case out of the top
holder.
Lift the case out of the bot-
tom holder.
Installing casesTurn the case lock until it
is at an angle of 45° to the
forward direction of travel.
Key cannot be removed.
Case locked.Hook the case into bottom
holder
2.
Pull the black release lever
(RELEASE) up.
Press the case into top
holder 3.
Push the black release lever
(RELEASE) down.
The case is locked into
place.
Lock the case.
Check that it is correctly en-
gaged.
688zAccessories
