2005 Acura RL engine

The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.Af ter removing the right engine
compartment cover (see page ),
check the level on the side of the
reservoir when the engine is cold.
The f luid should be between the
UPPER LEVEL and LOWER LEVEL.
If not, add power steering f luid to the
UPPER LEVEL mark.Pour the f luid slowly and caref ully so
you do not spill any. Clean up any
spill immediately; it could damage
components in the engine
compartment.
Always use Honda Power Steering
Fluid. You may use another power
steering f luid as an emergency
replacement, but have the power
steering system f lushed and ref illed
with Honda PSF as soon as possible.
A low power steering f luid level can
indicate a leak in the system. Check
the f luid level f requently, and have
the system inspected as soon as
possible.
304
Power Steering Fluid
Brake Fluid, Power Steering Fluid
312
MAX MIN
UPPER LEVEL
LOWER LEVEL

CONT INUED
Remove the electrical connector
f rom the bulb by pushing on the
tab and pulling the connector
down.
Remove the bulb by turning it one-
quarter turn counterclockwise.
Remove the left or right side
engine compartment cover f rom
thesideyouareworkingonby
caref ully pulling the cover out (see
page ).
If youarereplacingthebulbon
the driver’s side, remove the
battery cover (see page ), then
remove the battery hold-down by
removing the two nuts with a10
mm wrench. Then caref ully slide
the battery toward the engine to
access the bulb. 2.
3.
304
332
1.
Lights
Maint enance
315
NUTS
BULB
BATTERY HOLD-DOWN

Insert the new bulb into the hole
and turn it one-quarter turn clock-
wise to lock it in place.
Turn on the headlights to test the
new bulb.
(Driver’s side)
Reinstall the engine compartment
side cover. Push the electrical connector back
onto the bulb. Make sure it is on
all the way.Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Push the bulb in slightly, and turn
it counterclockwise.
Reinstall the battery in the reverse
order of removal, and reinstall the
cover on the battery. Remove the left or right side
engine compartment cover f rom
thesideyouareworkingonby
caref ully pulling the cover out (see
page ).
If you are replacing a driver’s side
bulb, slide the battery toward the
engine to get more clearance (see
page ).
2.
1.
4.
5.
6.
7.
8.
3.
304
332
Lights
Replacing a Front T urn Signal
Bulb
316
SOCKET
BULB

Install the new bulb into the
socket.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
(Driver’s side)Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.
Pull the bulb straight out of its
socket.
Remove the left or right side
engine compartment cover (see
page ).
(Passenger’s side)
Use a f lat-tipped screwdriver to
remove the holding clip f rom the
windshield washer reservoir. If you are replacing a driver’s side
bulb, slide the battery toward the
engine to get more clearance (see
page ).
Reinstall the battery and the
battery cover.
Reinstall the engine compartment
side cover. 1.
2.
4.
5.
6.
7.
8.
3.
4.
304
332
CONT INUED
Lights
Replacing a Front Position/Side
Marker L ight Bulb
Maint enance
317
BULB
HOLDING CLIP

Use a Phillips-head screwdriver to
remove the two mounting bolts
and remove the holding clip with a
f lat-tipped screwdriver.
Caref ully push up the side under
cover into the bumper.
Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth.
Install the new bulb into the
socket.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
(Driver’s side)
Reinstall the battery and the
battery cover.
Reinstall the windshield washer
reservoir. (Passenger’s side)
Reinstall the engine compartment
side cover.
1.
2.
5.
6.
7.
8.
9.
Lights
Replacing a Front Fog L ight Bulb
318
BOLTS
CLIP
Halogen bulbs get very hot when lit. Oil,
perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.

If you need to park your vehicle f or
an extended period (more than 1
month), there are several things you
should do to prepare it f or storage.
Proper preparation helps prevent
deterioration and makes it easier to
get your vehicle back on the road. If
possible, store your vehicle indoors.Fill the f uel tank.
Change the engine oil and f ilter. Block the rear wheels.
If the vehicle is to be stored f or a
longer period, it should be
supported on jackstands so the
tires are of f the ground.
Leave one window open slightly (if
the vehicle is being stored
indoors).
Disconnect the battery.
Support the f ront wiper blade
arms with a f olded towel or rag so
they do not touch the windshield.
To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehiclebodywaxtothepainted
surfaces that mate with the door
and trunk seals.Cover the vehicle with a
‘‘breathable’’ cover, one made
f rom a porous material such as
cotton. Non-porous materials, such
as plastic sheeting, trap moisture,
which can damage the paint.
If possible, periodically run the
engine until it reaches f ull
operating temperature (the
cooling f ans cycle on and of f
twice). Pref erably, do this once a
month.
Wash and dry the exterior
completely.
Cleantheinterior.Makesurethe
carpeting, floor mats, etc., are
completely dry.
Leave the parking brake off. Put
the transmission in Park.
Vehicle Storage
Maint enance
333

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .336
....................
Changing a Flat Tire .337
.............
If the Engine Won’t Start . 341
................................
Jump Starting .343
..............
If the Engine Overheats . 345
.........
Low Oil Pressure Indicator . 348
..........
Charging System Indicator . 348
.......
Malf unction Indicator Lamp . 349
...............
Brake System Indicator . 350
Opening the Fuel Fill Door ....................................
Manually .351
..............................................
Fuses .352
..............................
Fuse Locations .357
......................
Emergency Towing .360
..........
If Your Vehicle Gets Stuck . 361
Taking Care of the Unexpected
T aking Care of t he Unexpect ed
335

You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run.When you turn the ignition switch to
START (III), you do not hear the
normal noise of the engine trying to
start. You may hear a clicking sound
or series of clicks, or nothing at all.
Turn the ignition switch to START
(III). If the headlights do not dim,
check the condition of the f uses. If
thefusesareOK,thereis
probably something wrong with
the electrical circuit f or the
ignition switch or starter motor.
You will need a qualif ied
technician to determine the
problem (see
on page ).
If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal
connections (see page ). You
canthentryjumpstartingthe
vehicle from a booster battery
(see page ).
Check these things:
Make sure the remote is with you,
inside the vehicle.
Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to START (III):
Check the transmission interlock.
The transmission must be in Park
or neutral or the starter will not
operate.
Turn the ignition switch to ON (II).
Turn on the headlights, and check
their brightness. If the headlights
areverydimordonotcomeonat
all, the battery is discharged. Seeon page .343 343
360
331
Nothing Happens or the Starter
Motor Operates Very Slowly
Emergency T owing
Jump Starting
If theEngineWon’tStart
T aking Care of t he Unexpect ed
341
