2004 SUZUKI GRAND VITARA switch

YH4
GRAND
VITARA
INFLATE TIRES TO
RECOMMENDED PRESSURE
ROAD TEST VEHICLE ON LEVEL
UNCROWNED ROAD IN
BOTH DIRECTIONS
SWITCH FRONT TIRES
SIDE TO SIDE AND
ROAD TEST AGAIN
LEADS IN SAME
DIRECTIONLEAD CORRECTED
IF ROUGHNESS RESULTS,
REPLACE TIRESLEAD REVERSES
DIRECTION
PUT TIRES BACK IN
ORIGINAL POSITION
AND CHECK ALIGNMENTINSTALL A KNOWN GOOD TIRE ON
ONE FRONT SIDE
LEAD CORRECTED
REPLACE TIRELEAD REMAINS
INSTALL A KNOWN GOOD TIRE IN
PLACE OF OTHER FRONT TIRE
LEAD CORRECTED
REPLACE TIRELEAD REMAINS
KNOWN GOOD TIRES ARE NOT GOOD
STEERING, SUSPENSION, WHEELS AND TIRES 3-7
1. Ride vehicle to determine if the waddle is coming from the front
or rear.
2. Install tires and wheels that are known to be good (on similar ve-
hicle) in place of those on the offending end of the vehicle. If the
waddle cannot be isolated to front or rear, substitute the rears.
3. Road test again. If improvement is noted, install originals one at
a time until offender is found. If no improvement is noted, install
known good tires in place of all four. Then install originals one
at a time until offender if found.

YH4
GRAND
VITARA
3B1
POWER STEERING (P / S) SYSTEM 3B1-1
GENERAL DESCRIPTION3B1- 2 . . . . . . . . . . . . . .
Power Steering System 3B1- 2. . . . . . . . . . . . . . . . .
Steering Gear Box 3B1- 3. . . . . . . . . . . . . . . . . . . . . .
Power Steering (P / S) Pump 3B1- 4. . . . . . . . . . . . . .
DIAGNOSIS3B1- 5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Diagnosis Table 3B1- 5. . . . . . . . . . . . . . . .
Steering Wheel 3B1- 7. . . . . . . . . . . . . . . . . . . . . . . .
Steering Wheel Play Check 3B1- 7. . . . . . . . . . . .
Steering Force Check 3B1- 7. . . . . . . . . . . . . . . . .
Power Steering Fluid 3B1- 7. . . . . . . . . . . . . . . . . . . .
Power Steering Fluid Level Check 3B1- 7. . . . . .
Power Steering Pump Drive Belt 3B1- 8. . . . . . . . .
Belt Tension Check 3B1- 8. . . . . . . . . . . . . . . . . . .
Belt Tension Adjustment 3B1- 8. . . . . . . . . . . . . . .
Idle Up System 3B1- 9. . . . . . . . . . . . . . . . . . . . . . . . .
Idle Up System Check 3B1- 9. . . . . . . . . . . . . . . .
Fluid 3B1- 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Leakage Check 3B1- 9. . . . . . . . . . . . . . . . . Hydraulic Pressure in P / S Circuit 3B1-10. . . . . . . . .
Hydraulic Pressure Check 3B1-10. . . . . . . . . . . . .
Boot 3B1-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Rack Boot Check 3B1-11. . . . . . . . . . . . .
Tie-Rod End Boot Check 3B1-12. . . . . . . . . . . . . .
Air Bleeding Procedure 3B1-12. . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE3B1-13 . . . . . . . . . . . . . . . .
Tie-Rod End 3B1-13. . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Steering Gear Box Assembly 3B1-14. . . . . .
Rack Boot and Tie-Rod (Except Canvas
Top LH Model) 3B1-16. . . . . . . . . . . . . . . . . . . . . . . .
Rack Boot and Tie-Rod (For Canvas
Top LH Model) 3B1-17. . . . . . . . . . . . . . . . . . . . . . . .
Power Steering Pump 3B1-19. . . . . . . . . . . . . . . . . . .
TIGHTENING TORQUE SPECIFICATION3B1-26 . . .
REQUIRED SERVICE MATERIAL3B1-26 . . . . . . . .
SPECIAL TOOL3B1-26 . . . . . . . . . . . . . . . . . . . . . . .
SECTION 3B1
POWER STEERING (P/S) SYSTEM
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System:

Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to ªAir Bag System Components and Wiring Location Viewº under ªGener-
al Descriptionº in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and ªService Precau-
tionsº under ªOn-Vehicle Serviceº in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.

Technical service work must be started at least 90 seconds after the ignition switch is turned to the
ªLOCKº position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
NOTE:

Some parts in the Power Steering Gear Box cannot be disassembled or adjusted. For detailed informa-
tion, refer to the description of ªPOWER STEERING GEAR BOX ASSEMBLYº.

All steering gear fasteners are important attaching parts in that they could affect the performance of vital
parts and systems, and / or could result in major repair expense. They must be replaced with one of the
same part number or with an equivalent part if replacement becomes necessary. Do not use a replace-
ment part of lesser quality or substitute design. Torque values must be used as specified during reas-
sembly to assure proper retention of these parts.

Although the figures in this section show only the left-hand steering vehicle, the same work procedure
and data apply to the right-hand steering vehicle.
CONTENTS

YH4
GRAND
VITARA
1. Pin
2. Stub shaft (Rotor)
3. Torsion bar
4. Sleeve
5. Bearing
6. Pinion
7. Gear box
8. Rack
9. Ferrule
10. Valve case
POWER STEERING (P / S) SYSTEM 3B1-3
STEERING GEAR BOX
The steering gear box consists of two sections: one including a cyl-
inder and the other a valve. Main components of the cylinder sec-
tion are a gear box, a rack and a tube and those of the valve section
are a valve case, a sleeve and a stub shaft. The sleeve is linked with
the pinion through a pin and the valve and stub shaft are integrated
into one unit. Then the pinion and the stub shaft are linked to each
other by means of the torsion bar.
Thus, when the stub shaft moves, the valve changes its position,
thereby switching the hydraulic passage from the pump to the cylin-
der to help steering operation.
When turning the steering wheel feels heavy due to P / S fluid leak-
age or for some other reason (i.e., when in the manual steering
mode), the stub shaft and pinion are in direct linkage and the force
is output directly through the pinion and rack.

YH4
GRAND
VITARA
1. Suction connector
2. O-ring
3. Pressure switch
4. Flow control valve
(Relief valve)
5. Spring
6. Plug
7. Pump cover
8. Cam ring
9. Vane
10. Rotor
11. Snap ring
12. Side plate
13. Pulley (pump shaft)
14. Oil seal
15. Pump body
16. Flow control valve Assembly
3B1-4 POWER STEERING (P / S) SYSTEM
POWER STEERING (P / S) PUMP
The power steering pump is a vane type and is driven by the V-ribbed belt from the crankshaft.
ModelVane type
Hydraulic
pressure
controlRelieved
pressure
6500 kPa (65 kg / cm2, 924 psi)
G16 Type engine . . . . . . . . . . . . . . . . . . . . . .
7000 kPa (70 kg / cm
2, 995 psi)
J20 Type engine . . . . . . . . . . . . . . . . . . . . . . .
7350 kPa (73.5 kg / cm
2, 1045 psi)
H25 Type engine . . . . . . . . . . . . . . . . . . . . . .
ControlFlow control valve
deviceRelief valve
Power steering
pressure switch
Switch turns on (closes) when the
pressure is higher than 2500 ± 3500 kPa
(25 ± 35 kg / cm
2, 356 ± 498 psi).
ECM uses this signal for idle speed control.
Capacity0.70 ± 0.75

(1.48 / 1.23 ± 1.58 / 1.32 US / Imp. pt)
Specified fluidDEXRON
II, DEXRON
III A / T fluid
or equivalent
FLOW CONTROL VALVE
As the discharge rate of the P/S pump increases in proportion to the
pump revolution speed, a flow control valve is added to control it so
that the optimum amount of fluid for steering operation is supplied
according to the engine speed (driving condition).
Described below is its operation at different engine speed.

YH4
GRAND
VITARA
3B1-6 POWER STEERING (P / S) SYSTEM
ConditionPossible CauseCorrection
Vehicle pulls to
one side during
straight driving
Mismatched or uneven tire

Low or uneven tire inflation pressure

Brake dragging in one wheel

Front end alignment out of order

Rear end alignment out of order

Malfunction of control valve in gear boxReplace tire.
Inflate tires to proper pressure or
adjust right & left tires inflation
pressure.
Repair.
Check and adjust front end
alignment.
Check and adjust rear end
alignment.
Replace gear box.
Steering wheel
play is large and
vehicle wanders
Refer to ªDiagnosisº in Section 3.
Fluid leakage
Loose joints of (hydraulic pressure)
pipes and hoses

Deformed or damaged pipes or hosesRetighten.
Replace defective part.
Abnormal noise
Air drawn in due to insufficient amount of fluid

Air mixed into fluid from pipes or hoses

Slipping (loose) P / S belt

Worn P / S belt

Loose gear box fastening bolt

Loose linkage or joints

Pipes or hoses in contact with part of
vehicle body

Vanes of P / S pump defective

Malfunction of control valve in gear box

Bearing of P / S pump shaft defectiveAdd fluid and purge air.
Replace pipes or hoses.
Adjust belt tension.
Replace belt.
Retighten bolts.
Retighten.
Install pipes and hoses correctly.
Replace defective part.
Replace gear box.
Replace bearing.
No idle up
Power steering pressure switch defectiveReplace power steering
pressure switch.

YH4
GRAND
VITARA
POWER STEERING (P / S) SYSTEM 3B1-9
IDLE UP SYSTEM
IDLE UP SYSTEM CHECK
1) Warm up engine to normal operating temperature.
2) Turn A / C switch OFF, if equipped.
3) Turn steering wheel fully and check idle speed.
Engine idle speed drops a little momentarily when steering
wheel is turned fully but returns to its specified level immediately.
If power steering pressure switch connector is connected, check
the same with that connector disconnected. Momentary drop of
engine idle speed should be less when it is connected than when
disconnected.
FLUID
FLUID LEAKAGE CHECK
Start engine and turn steering wheel fully to the right and left so that maximum hydraulic pressure is provided. Then
visually check gear box, P / S pump and P / S fluid reservoir themselves and each joint of their connecting pipes for
leakage.
CAUTION:
Never keep steering wheel turned fully for longer than 10 seconds.

YH4
GRAND
VITARA
3B1-20 POWER STEERING (P / S) SYSTEM
1. P/S fluid
reservoir
2. Suction hose
1. P / S pulley
2. Mounting bolt
9. Vane
10. Rotor
11. Snap ring
12. Side plate
13. Pulley (pump shaft)
14. Oil seal
15. Pump body
16. Flow control
valve Assembly 1. Suction connector
2. O-ring
3. Pressure switch
4. Flow control valve
(Relief valve)
5. Spring
6. Plug
7. Pump cover
8. Cam ring
REMOVAL
NOTE:
Be sure to clean each joint of suction and discharge sides
thoroughly before removal.
1) Remove suction hose from pump, then disconnect battery nega-
tive cable.
2) Remove P / S fluid reservoir with suction hose.
3) Remove union bolt. Then disconnect high pressure pipe from
pump.
NOTE:
As fluid flows out of disconnected joints, put a receptacle
under joints or a plug to pipe.
4) Disconnect pressure switch lead wire at switch terminal.
5) Loosen related bolts and remove power steering drive belt.
6) Remove P / S pump mounting bolt (s).
7) Remove P / S pump.
NOTE:
Plug each port of removed pump to prevent dust or any oth-
er foreign matter from entering.
DISASSEMBLY
1) Clean its exterior thoroughly.
2) With aluminum plates placed on vise first, grip pump body with
it.
3) Remove suction connector bolt, suction connector and O-ring
from pump body.
4) Remove power steering pressure switch (terminal set) from
pump body.
5) Remove plug, flow control spring and relief valve (flow control
valve) from pump body.
6) Remove cover bolts, pump cover and O-ring from pump body.
7) Remove snap ring from pump shaft.
8) Remove vanes from rotor.
9) Remove cam ring, rotor, side plate and O-rings from pump
body.
10) Pull out pulley from pump body.
11) Remove oil seal from pump body.

YH4
GRAND
VITARA
3B1-24 POWER STEERING (P / S) SYSTEM
1. Pump cover
1. Pressure switch
1. Suction connector
2. O-ring
1. Suction connector
15) Gradually tighten new pump cover bolts to specified torque.
NOTE:
After installing pump cover, check to make sure that shaft
can be turned by hand.
Tightening Torque
(a): 23 N
.m (2.3 kg-m, 17.0 lb-ft)
16) Apply power steering fluid to O-ring of terminal switch.
17) Install pressure switch to pump body.
Tightening Torque
(a): 28 N
.m (2.8 kg-m, 20.0 lb-ft)
18) Apply power steering fluid to relief valve (flow control valve).
19) Install relief valve (flow control valve) to pump body.
20) Install flow control spring.
21) Apply power steering fluid to O-rings of plug.
22) Install O-rings to plug.
23) Tighten plug to specified torque.
Tightening Torque
(a): 60 N
.m (6.0 kg-m, 43.5 lb-ft)
24) Apply power steering fluid to O-ring of suction connector.
25) Install O-ring to suction connector.
26) Install suction connector to pump body as shown in figure.
Tighten new suction connector bolts to specified torque.
Tightening Torque
(a): 10 N
.m (1.0 kg-m, 7.5 lb-ft)
