2004 PONTIAC GRAND PRIX radio controls

Setting the Tone (Bass/Treble)
AUDIO:Push the AUDIO knob until BASS, MID, or
TREB appears on the display. Turn the knob to increase
or to decrease. If a station is weak or noisy, you may
want to decrease the treble.
To adjust bass, midrange, or treble to the middle position,
select BASS, MID, or TREB and push and hold the
AUDIO knob. The radio will produce one beep and adjust
the display level to zero.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone or
speaker control is displayed. The radio will produce one
beep and CENTERED will appear on the display.
AUTO EQ (Automatic Equalization):Press this button
to choose between bass, midrange, and treble
equalization settings designed for country, jazz, talk,
pop, rock, and classical program types.
To return to the manual mode (CUSTOM), press the
AUTO EQ button until CUSTOM appears on the display.
Then you will be able to manually adjust the bass,
midrange, and treble using the AUDIO knob.
Adjusting the Speakers (Balance/Fade)
AUDIO:To adjust the balance between the right
and the left speakers, push the AUDIO knob until BAL
appears on the display. Turn the knob to move the
sound toward the left or the right speakers.
To adjust the fade between the front and rear speakers,
push and hold the AUDIO knob until FAD appears on
the display. Turn the knob to move the sound toward the
front or the rear speakers.
To adjust the balance and the fade to the middle
position, select balance or fade and push and hold
the AUDIO knob. The radio will beep once and
will adjust the display level to the middle position.
To adjust all tone and speaker controls to the middle
position, push and hold the AUDIO knob when no tone
or speaker controls are displayed. The radio will
produce one beep and CENTERED will appear on
the display.
3-117

Audio Steering Wheel Controls
If your vehicle has this feature, you can control certain
radio functions using the buttons on your steering wheel.
wtux(Seek):Press the up arrow to seek to
the next station and the down arrow to seek to the
previous station. The sound will mute while seeking.
When playing a cassette tape press either arrow to
go to the previous or next selection on the cassette tape.
Your tape must have at least three seconds of silence
between each selection for previous to work.When playing a compact disc press either arrow to go
to the previous or next selection on the CD if more than
eight seconds have passed. If you press either arrow
more than once, the player will continue moving
backward or forward through the disc.
BAND:Press this button to choose FM1, FM2, AM, or
XM1 or XM2 (USA only, if equipped).
1-6:Press this button to scan your radio preset
stations. The radio will scan to the ®rst preset station
stored on your pushbuttons, play for a few seconds, then
go on to the next preset station. The radio will scan
only to stations that are in the selected band and only to
those with a strong signal. Press this button again to
stop scanning.
$(Mute):Press this button to silence the system.
Press it again to turn on the sound.
r(Play):Press this button to play a cassette tape or
compact disc when listening to the radio.
wux(Volume):Press the up or down arrow to
increase or decrease volume.
3-129

Circuit
Breakers Usage
RR DEFOG Rear Window Defogger
DR LK/TRUNK Door Lock/Trunk
ONSTAR/ALDL Onstar
ž/Diagnostic Link
CANNISTER Fuel Tank Solenoid Cannister
PK LAMPS Parking Lamps
RADIO/AMP Radio Ampli®er
RFA/MODRemote Funtion Activator
(Remote Keyless Entry)
DISPLAYS Instrument Panel Dispays/HUD/DIC
INT LIGHT Interior Lamps
HVAC Climate Controls
Circuit
Breakers Usage
CHMSL/BKUPCenter High Mounted Stop
Lamp/Back-Up Lamps
PWR WDO Power Windows
SPRING COIL
2Steering Wheel Control Switches
PWR SEAT Power Seat
TURN/HAZTurn Signals/Hazard Warning
Lamps
PWR MIRS Power Mirrors
HTD SEAT Heated Seat
To reinstall the end panel, position the lower section
with the edge, on the side opening and press the sides
of the panel until it snaps into place.
5-101

A
A/C OFF FOR ENGINE PROTECTION..............3-65
Accessory Power Outlets.................................3-23
Adding Washer Fluid.......................................5-44
Additional Program Information........................... 7-9
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment............................5-99
Adjusting the Speakers
(Balance/Fade)........................3-92, 3-103, 3-117
Air Bag
Readiness Light..........................................3-34
Air Bag Systems.............................................1-48
How Does an Air Bag Restrain?....................1-54
Servicing Your Air Bag-Equipped Vehicle.........1-56
What Makes an Air Bag In¯ate?....................1-53
What Will You See After an
Air Bag In¯ates?......................................1-54
When Should an Air Bag In¯ate?...................1-53
Where Are the Air Bags?..............................1-50
Air Cleaner/Filter, Engine.................................5-22
Air Conditioning..............................................3-27
AJAR............................................................3-66
AM .............................................................3-130
Antenna, Backglass.......................................3-132
Antenna, XMŸ Satellite Radio
Antenna System........................................3-132
Anti-lock Brake System (ABS)............................ 4-7
Anti-Lock Brake, System Warning Light..............3-37Appearance Care............................................5-90
Care of Safety Belts....................................5-93
Chemical Paint Spotting...............................5-96
Cleaning the Inside of Your Vehicle................5-90
Cleaning the Outside of Your Vehicle..............5-93
Finish Damage............................................5-95
GM Vehicle Care/Appearance Materials..........5-96
Sheet Metal Damage...................................5-95
Underbody Maintenance...............................5-96
Weatherstrips..............................................5-93
Arming Con®rmation........................................2-15
Arming with the Power Lock Switch...................2-14
Arming with the Remote Keyless
Entry Transmitter.........................................2-15
Ashtray.........................................................3-24
Assist Handles...............................................2-38
Audio System(s).............................................3-88
Audio Steering Wheel Controls....................3-129
Backglass Antenna.....................................3-132
Care of Your Cassette Tape Player...............3-130
Care of Your CD Player..............................3-131
Care of Your CDs......................................3-131
Radio with Cassette and CD.......................3-100
Radio with CD............................................3-89
Radio with Six-Disc CD..............................3-114
Setting the Time..........................................3-88
Theft-Deterrent Feature...............................3-128
Understanding Radio Reception...................3-130
XMŸ Satellite Radio Antenna System...........3-132
1

OnStaržSystem.............................................2-35
OnStaržVirtual Advisor....................................2-36
Other Warning Devices...................................... 3-5
Outlet Adjustment............................................3-29
Outside
Convex Mirror.............................................2-34
Power Mirrors.............................................2-34
Overhead Console Reading Lamps....................3-18
Overhead Console..........................................2-36
Overheated Engine Protection Operating Mode.....5-30
Overseas ± Customer Assistance........................ 7-5
Owners, Canadian............................................... ii
Owner's Information........................................7-11
P
PARK LAMPS ON..........................................3-78
Park (P)
Shifting Into................................................2-28
Shifting Out of............................................2-30
Parking
Brake........................................................2-27
Over Things That Burn.................................2-30
Parking Brake and Automatic Transaxle
Park (P) Mechanism Check...........................6-13
PARKING BRAKE ON.....................................3-78
Parking on Hills..............................................4-43Part A - Scheduled Maintenance Services............ 6-4
Part B - Owner Checks and Services................6-10
Part C - Periodic Maintenance Inspections..........6-14
Part D - Recommended Fluids and Lubricants....6-16
Part E - Maintenance Record...........................6-17
Passing.................................................4-16, 4-41
PASS-Key
žIII ................................................2-15
PASS-KeyžIII Operation..................................2-16
Performance Shifting with TAP-ShiftŸ................2-25
Plan Ahead When Possible................................ 7-7
Playing a Cassette Tape................................3-109
Playing a Compact Disc...............3-98, 3-111, 3-123
Playing a Speci®c Loaded
Compact Disc............................................3-124
Playing the Radio........................3-90, 3-101, 3-115
Power
Accessory Outlets........................................3-23
Door Locks.................................................. 2-8
Electrical System.........................................5-99
Lumbar Controls........................................... 1-5
Seat............................................................ 1-4
Steering Fluid.............................................5-42
Windows....................................................2-13
Power Steering...............................................4-14
Pretensioners, Safety Belt................................1-28
Programmable Automatic Door Locks.................. 2-9
10

Setting the Time.............................................3-88
Setting the Tone (Bass/Treble).......3-92, 3-103, 3-117
Sheet Metal Damage.......................................5-95
Shifting Into Park (P).......................................2-28
Shifting Out of Park (P)...................................2-30
Shoulder Belt Height Adjuster...........................1-17
Skidding........................................................4-18
Some Other Rainy Weather Tips.......................4-22
Special Fabric Cleaning Problems.....................5-91
Speci®cations, Capacities...............................5-104
Speedometer..................................................3-33
Split Folding Rear Seat..................................... 1-8
Stabilitrak
žPlus System..................................4-13
STABILITY CONTROL ACTIVE.........................3-85
STABILITY CONTROL OFF..............................3-85
Starter Switch Check.......................................6-12
STARTING DISABLED DUE TO
ELECTRONIC THROTTLE CONTROL............3-86
STARTING DISABLED DUE TO
THEFT SYSTEM.........................................3-86
Starting Your Engine.......................................2-19
Steering........................................................4-14
Steering in Emergencies..................................4-15
Steering, Suspension and Front Drive Axle
Boot and Seal Inspection..............................6-14
Steering Tips..................................................4-14
Steering Wheel Controls, Audio.......................3-129Storage Areas
Center Console Storage Area........................2-37
Convenience Net.........................................2-38
Front Seat Storage Net................................2-37
Glove Box..................................................2-36
Overhead Console.......................................2-36
Storing the Flat Tire and Tools..........................5-87
Storing the Spare Tire and Tools.......................5-88
Stuck in Sand, Mud, Ice or Snow......................4-32
Sun Visors.....................................................2-13
Sunglasses Storage Compartment.....................2-37
Sunroof.........................................................2-39
T
3800 V6 Engine.............................................5-12
3800 V6 Supercharged Engine.........................5-14
Tachometer....................................................3-33
Taillamps
Turn Signal, and Stoplamps..........................5-64
TCS Warning Light..........................................3-38
Temperature...................................................3-27
THEFT SYSTEM NOT PROGRAMMED.............3-86
Theft-Deterrent, Radio....................................3-128
Theft-Deterrent Systems...................................2-14
Content Theft-Deterrent................................2-14
PASS-Key
žIII .............................................2-15
PASS-KeyžIII Operation..............................2-16
13
