2004 NISSAN XTERRA Owners Manual

Indicator
lightName Page
4-wheel drive
indicator light
(if so equipped)2-13
High beam in-
dicator light
(Blue)2-13
Malfunction
indicator lamp
(MIL)2-14
Overdrive off
indicator light
(automatic
transmission
only)2-14
Slip indicator
light (if so
equipped)2-14
Indicator
lightName Page
Turn
signal/hazard
indicator lights2-15
Vehicle dy-
namic control
off indicator
light (if so
equipped)2-15
Illustrated table of contents0-11
ZREVIEW COPY:Ð2004 Xterra(xtr)
Owners Manual(owners)ÐUSA English(nna)
10/23/03Ðdebbie
X

0-12Illustrated table of contents
MEMO

1 Safety—Seats, seat belts and
supplemental air bags
Seats............................................1-2
Front manual seat adjustment....................1-2
Rear seat adjustment (Type A)...................1-4
Rear seat adjustment (Type B)...................1-6
Head restraint adjustment.......................1-8
Supplemental restraint system......................1-8
Precautions on supplemental restraint
system........................................1-8
Supplemental air bag warning labels.............1-19
Supplemental air bag warning light..............1-19
Seat belts.......................................1-21
Precautions on seat belt usage..................1-21
Child safety...................................1-23
Pregnant women..............................1-24Injured persons................................1-24
Three-point type seat belt with retractor..........1-25
Two-point type seat belt without retractor
(center of rear seat)............................1-28
Seat belt extenders............................1-29
Seat belt maintenance.........................1-30
Child restraints...................................1-30
Precautions on child restraints..................1-30
Installation on rear seat center position...........1-32
Installation on rear seat outboard positions.......1-35
LATCH (Lower Anchors and Tethers for
CHildren) system..............................1-39
Top tether strap child restraint..................1-41
Installation on front passenger seat..............1-43
ZREVIEW COPY:Ð2004 Xterra(xtr)
Owners Manual(owners)ÐUSA English(nna)
10/23/03Ðdebbie
X

WARNING
cDo not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident,
you could be thrown into it and receive
neck or other serious injuries. You
could also slide under the lap belt and
receive serious internal injuries.cFor the most effective protection when
the vehicle is in motion, the seat should
be upright. Always sit well back in the
seat and adjust the seat properly. See
“Precautions on Seat Belt Usage” later
in this section.
FRONT MANUAL SEAT
ADJUSTMENT
WARNING
cDo not adjust the driver’s seat while
driving so full attention may be given to
vehicle operation. The seat may move
suddenly and could cause loss of con-
trol of the vehicle.
cAfter adjustment, gently rock in the seat
to make sure it is securely locked.
ARS1152
SEATS
1-2Safety—Seats, seat belts and supplemental air bags
ZREVIEW COPY:Ð2004 Xterra(xtr)
Owners Manual(owners)ÐUSA English(nna)
10/23/03Ðdebbie
X

Forward and backward
Pull the lever up and hold it while you slide the
seat forward or backward to the desired position.
Release the lever to lock the seat in position.
Reclining
To recline the seatback, pull the lever up and lean
back. To bring the seatback forward, pull the lever
up and lean your body forward. Release the lever
to lock the seatback in position.
The reclining feature allows adjustment of the
seatback for occupants of different sizes to help
obtain proper seat belt fit (see “Precautions on
seat belt usage” later in this section) . Also, the
seatback can be reclined to allow occupants to
rest when the vehicle is stopped.
WARNING
After adjustment, gently rock in the seat to
make sure it is securely locked.
WRS0175WRS0176
Safety—Seats, seat belts and supplemental air bags1-3
ZREVIEW COPY:Ð2004 Xterra(xtr)
Owners Manual(owners)ÐUSA English(nna)
10/23/03Ðdebbie
X

Seat lifter (if so equipped for driver’s
seat)
Turn either dial to adjust the angle and height of
the seat cushion to the desired position.
Lumbar support (if so equipped for
driver’s seat)
The lumbar support feature provides lower back
support to the driver. Move the lever forward or
backward to adjust the seat lumbar area.
REAR SEAT ADJUSTMENT (Type A)
Folding
s1Pull outward on the 2 straps at the bottom of
the seat cushions.
s2Lift the front of the seat cushion up and
remove the seat cushion. Store the seat
cushion in a secure place.
WRS0131WRS0389WRS0180
1-4Safety—Seats, seat belts and supplemental air bags
ZREVIEW COPY:Ð2004 Xterra(xtr)
Owners Manual(owners)ÐUSA English(nna)
10/23/03Ðdebbie
X

s3Pull the ring on top of the seatback up.
s4Fold down the seatback.
s5To return the rear seatback to a seating
position, push the seatback up until it
latches.s6Hold the seat belts above the seat cushion.
s7Slide the seat cushion back.
s8Push down the seat cushion until it latches.
WARNING
cNever allow anyone to ride in the cargo
area or on the rear seat when it is in the
fold-down position. Use of these areas
by passengers without proper restraints
could result in serious injury in an acci-
dent or sudden stop.
WRS0181WRS0182WRS0183
Safety—Seats, seat belts and supplemental air bags1-5
ZREVIEW COPY:Ð2004 Xterra(xtr)
Owners Manual(owners)ÐUSA English(nna)
10/23/03Ðdebbie
X

cDo not allow people to ride in any area
of your vehicle that is not equipped with
seats and seat belts. Be sure everyone
in your vehicle is in a seat and using a
seat belt properly. Never ride in the rear
seat unless the seat bottom cushions
are in place and latched.
cProperly secure all cargo with ropes or
straps to help prevent it from sliding or
shifting. In a sudden stop or collision,
unsecured cargo could cause personal
injury.
cWhen returning the seatbacks to the
upright position, be certain they are
completely secured. If they are not com-
pletely secured in the latched position,
passengers may be injured in an acci-
dent or sudden stop.
REAR SEAT ADJUSTMENT (Type B)
Folding
s1Lift the front of the seat cushion up and
remove the seat cushion. Store the seat
cushion in a secure place.
s2Pull the ring on top of the seatback up.
s3Fold down the seatback.
WRS0184WRS0185
1-6Safety—Seats, seat belts and supplemental air bags
