2004 NISSAN TITAN service indicator

Security indicator light
The security indicator light blinks whenever the
ignition switch is in the LOCK, OFF or ACC
position. This function indicates the NISSAN Ve-
hicle Immobilizer System (NVIS) is operational.
If the NVIS is malfunctioning, the light will remain
on while the ignition key is in the ON position.
If the light still remains on and/or the en-
gine will not start, see a NISSAN dealer for
NVIS service as soon as possible. Please
bring all NVIS keys that you have when
visiting your NISSAN dealer for service.
SWITCH OPERATION
The windshield wiper and washer operates when
the ignition switch is in the ON position.
Push the lever down to operate the wiper at the
following speed:
s1Intermittent — intermittent operation can be
adjusted by turning the knob toward
sA
(Slower) orsB(Faster) . Also, the intermit-
tent operation speed varies in accordance
with the vehicle speed. (For example, when
the vehicle speed is high, the intermittent
operation speed will be faster.)NOTE:
You can turn on or turn off the driving
speed dependent intermittent wiper func-
tion. Refer to “Personalized settings
menu” (vehicles without navigation sys-
tem) or “Vehicle electronic systems” (ve-
hicles with navigation system) in the “Dis-
play screen, heater, air conditioner and
audio systems” section later in this manual.
s2Low — continuous low speed operation
s3High — continuous high speed operation
Push the lever up
s4to have one sweep opera-
tion of the wiper.
Pull the lever toward you
s5to operate the
washer. The wiper will also operate several times.
WARNING
In freezing temperatures the washer solu-
tion may freeze on the windshield and
obscure your vision which may lead to an
accident. Warm the windshield with the
defroster before you wash the windshield.
CAUTION
cDo not operate the washer continu-
ously for more than 30 seconds.
LIC0474LIC0386
WINDSHIELD WIPER AND WASHER
SWITCH
2-22Instruments and controls
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
02/20/04Ðtbrooks
X

The last station played will also come on when
the Power/Volume control knob is depressed to
ON.
No satellite radio reception is available and “NO
SAT” is displayed when the SAT button is
pressed unless optional satellite receiver and
antenna are installed (retrofit unavailable without
factory satellite radio pre-wiring) , and an XMTor
SIRIUS™ satellite radio service subscription is
active.
If a compact disc is playing when the FM, AM or
SAT radio select button is pushed, the compact
disc will automatically be turned off and the last
radio station played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically change
from stereo to monaural reception.
FM/AM/SAT band select (type B and D
only):
Pushing the RADIO button will change the band
as follows:
AMÃ!FM or SAT (Satellite)
When the RADIO button is pushed while the
ignition switch is in the ACC or ON position, the
radio will come on at the station last played.The last station played will also come on when
the POWER/VOLUME control knob is de-
pressed to ON.
No satellite radio reception is available and “NO
SAT” is displayed when the RADIO button is
pressed to access satellite radio stations unless
optional satellite receiver and antenna are in-
stalled (retrofit unavailable without factory satel-
lite radio pre-wiring) , and an XMTor SIRIUS™
satellite radio service subscription is active.
If a compact disc is playing when the RADIO
button is pushed, the compact disc will automati-
cally be turned off and the last radio station
played will come on.
The FM stereo indicator ST will glow during FM
stereo reception. When the stereo broadcast
signal is weak, the radio will automatically change
from stereo to monaural reception.
TUNE (Tuning):
WARNING
The radio should not be tuned while driv-
ing so full attention may be given to ve-
hicle operation.
To manually tune the radio, push the TUNE button
(
or) or turn the tuning knob to right
or left.To move quickly through the channels, hold either
the
orbutton down for more than
1.5 seconds.
SEEK tuning:
Push the SEEK/TRACK button (
or)
for less than 1.5 seconds to tune from high to low
or low to high frequencies and stop at the next
broadcasting station.
SCAN tuning:
Push the
orbutton for more than
1.5 seconds to stop at each broadcasting station
for 5 seconds. Pushing the button again during
this 5 second period will stop SCAN tuning and
the radio will remain tuned to that station. If
the
orbutton is not pushed within 5
seconds, SCAN tuning moves to the next station.
Station memory operations:
18 stations can be set for the FM, AM and SAT
(Satellite-if so equipped) radio to the A, B and C
preset button in any combination of AM or FM
stations.
1. Choose preset channel A, B or C using the
preset select button.
Display screen, heater, air conditioner and audio systems4-31
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
02/23/04Ðdebbie
X

2. Tune to the desired station using manual,
SEEK or SCAN tuning. Push and hold any of
the desired station memory buttons (1 - 6)
until a beep sound is heard.
3. The channel indicator will then come on and
the sound will resume. Memorizing is now
complete.
4. Other buttons can be set in the same man-
ner.
If the battery cable is disconnected, or if the fuse
blows, the radio memory will be canceled. In that
case, reset the desired stations.
Radio data system (RDS):
RDS stands for Radio Data System, and is a data
information service transmitted by some radio
stations on the FM band (not AM band) and/or
SAT radio encoded within a regular radio broad-
cast. Currently, most RDS stations are in large
cities, but many stations are now considering
broadcasting RDS data.
RDS can display:
cStation call sign, such as “WHFR 98.3”.
cStation name, such as “The Groove”.
cMusic or programming type such as “Clas-
sical”, “Country”, or “Rock”.
cTraffic reports about delays or construction.If the station broadcasts RDS information, the
RDS icon is displayed.
Program type (PTY):
PTY can be used to search for a certain program
type. Certain areas have a limited number of
stations that transmit RDS. Many stations trans-
mit call letters and frequencies only.
Searching or scanning by program type may yield
a limited number of selections.
When PROG/RPT button is pressed for more
than 1.5 seconds during FM or SAT (if so
equipped) mode, the PTY name of the current
tuned station is displayed. During this time if the
PTY data code is zero or the data is unreadable,
the display will show NONE.
To change the PTY:
1. Press the PROG/RPT button.
2. Press the TUNE button (
or)to
chose a specific program type. Refer to the
illustration.
The display will show “SEEK, SCAN?”
LHA0275
4-32Display screen, heater, air conditioner and audio systems
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
02/23/04Ðdebbie
X

1. Wear indicator
2. Location mark
Tire wear and damage
WARNING
cTires should be periodically inspected
for wear, cracking, bulging or objects
caught in the tread. If excessive wear,
cracks, bulging or deep cuts are found,
the tire(s) should be replaced.cThe original tires have built-in tread
wear indicators. When the wear indica-
tors are visible, the tire(s) should be
replaced.
cImproper service of the spare tire may
result in serious personal injury. If it is
necessary to repair the spare tire, con-
tact a NISSAN dealer.
cFor additional information regarding
tires, refer to “Important Tire Safety In-
formation” (US) or “Tire Safety Informa-
tion” (Canada) in the Warranty Informa-
tion Booklet.
Replacing wheels and tires
When replacing a tire, use the same size, tread
design, speed rating and load carrying capacity
as originally equipped. Recommended types and
sizes are shown in “Wheels and tires” in the
“Technical and consumer information” section of
this manual.
WARNING
cThe use of tires other than those recom-
mended or the mixed use of tires of
different brands, construction (bias,
bias-belted or radial) , or tread patterns
can adversely affect the ride, braking,
handling, ground clearance, body-to-
tire clearance, tire chain clearance,
speedometer calibration, headlight aim
and bumper height. Some of these ef-
fects may lead to accidents and could
result in serious personal injury.
cIf the wheels are changed for any rea-
son, always replace with wheels which
have the same off-set dimension.
Wheels of a different off-set could
cause premature tire wear, degrade ve-
hicle handling characteristics and/or
interference with the brake
discs/drums. Such interference can
lead to decreased braking efficiency
and/or early brake pad/shoe wear. Re-
fer to “Wheels and tires” in the “Techni-
cal and consumer information” section
of this manual for wheel off-set
dimensions.
WDI0259
Maintenance and do-it-yourself8-37
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
02/23/04Ðdebbie
X

10 Index
4WD warning light...............2-14
A
Adjusting pedal position............3-13
Air bag (See supplemental restraint system). .1-11
Air bag system
Front (See supplemental front impact air
bag system).................1-18
Air bag warning labels.............1-25
Air bag warning light...........1-26, 2-16
Air cleaner housing filter............8-16
Air conditioner
Air conditioner operation..........4-15
Air conditioner service...........4-19
Air conditioner specification label.....9-11
Air conditioner system refrigerant and
lubrication recommendations........9-6
Heater and air conditioner controls. . . .4-12
Servicing air conditioner..........4-19
Air flow charts..................4-16
Alarm system
(See vehicle security system).........2-20
Anchor point locations.............1-45
Antenna.....................4-38
Anti-lock brake system (ABS).........5-28
Anti-lock brake warning light..........2-13
Audible reminders................2-19
Audio system..................4-19
AM-FM-SAT radio with compact disc (CD)
changer...................4-29Compact Disc (CD) changer.......4-33
Compact disc (CD) player.........4-24
FM-AM radio with compact disc (CD)
player....................4-22
Radio....................4-19
Rear audio controls.............4-37
Steering wheel audio control switch. . . .4-36
Autolight switch.................2-24
Automatic
Automatic drive positioner.........3-21
Automatic power window switch.....2-44
Automatic transmission position indicator
light.....................2-16
Driving with automatic transmission.....5-9
Transmission selector lever lock
release....................5-15
Automatic anti-glare inside mirror.......3-16
Automatic transmission fluid temperature
gauge.......................2-7
AUX jack.....................4-35
B
Battery......................8-13
Charge warning light............2-14
Battery replacement
(See remote keyless entry system) . . .3-10, 8-23
Before starting the engine............5-8
Belts (See drive belts).............8-15
Brake
Anti-lock brake system (ABS).......5-28Brake booster................8-21
Brake fluid..................8-12
Brake light (See stop light).........8-26
Brake pedal.................8-20
Brake system................5-27
Brake warning light.............2-13
Brake wear indicators........2-19, 8-20
Parking brake check............8-20
Parking brake operation..........5-16
Self-adjusting brakes............8-20
Break-in schedule................5-19
Brightness control
Instrument panel..............2-26
Bulb check/instrument panel..........2-12
Bulb replacement................8-26
C
Capacities and recommended
fuel/lubricants...................9-2
Car phone or CB radio.............4-47
Cargo light switch...............2-28
Cargo (See vehicle loading information) . . .9-12
CD care and cleaning.............4-35
CD changer (See audio system)........4-33
CD player (See audio system).........4-24
Check engine indicator light
(See malfunction indicator lamp).......2-17
Child restraint with top tether strap......1-45
Child restraints.......1-29, 1-30, 1-36, 1-43
Precautions on child restraints.......1-36
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
03/01/04Ðdebbie
X

M
Maintenance
General maintenance............8-2
Inside the vehicle...............8-3
Maintenance precautions..........8-5
Outside the vehicle..............8-2
Seat belt maintenance...........1-36
Under the hood and vehicle.........8-4
Malfunction indicator lamp (MIL)........2-17
Manual front seat adjustment.......1-2, 1-3
Manual windows................2-45
Map lights....................2-49
Map pocket...................2-38
Meters and gauges................2-3
Instrument brightness control.......2-26
Mirror
Automatic anti-glare inside mirror.....3-16
Inside mirror.................3-15
Outside mirrors...............3-16
Vanity mirror.................3-15
N
NISSAN mobile entertainment system
(MES)......................4-38
Nissan vehicle immobilizer system
(NVIS).................2-21, 3-2, 5-8
O
Octane rating (See fuel octane rating).....9-3
Odometer.....................2-4Oil
Capacities and recommended
fuel/lubricants.................9-2
Changing engine oil.............8-9
Changing engine oil filter..........8-10
Checking engine oil level..........8-8
Engine oil...................8-8
Engine oil and oil filter recommendation . .9-4
Engine oil viscosity..............9-5
Outside mirrors.................3-16
Overheat
If your vehicle overheats..........6-10
Owner’s manual order form..........9-35
Owner’s manual/service manual order
information....................9-35
P
Parking
Parking brake check............8-20
Parking brake operation..........5-16
Parking/parking on hills...........5-26
Pedal position adjustment...........3-13
Personal lights.................2-49
Power
Front seat adjustment............1-5
Power door locks...............3-4
Power outlet.................2-32
Power rear windows............2-44
Power steering fluid.............8-11
Power steering system...........5-27
Power windows...............2-43
Rear power windows............2-44
Precautions
Maintenance precautions..........8-5On-pavement and off-road driving
precautions..................5-3
Precautions on child restraints.......1-36
Precautions on seat belt usage......1-27
Precautions on supplemental restraint
system....................1-11
Precautions when starting and driving . . .5-2
Pre-tensioner seat belt system.........1-24
Push starting..................6-10
R
Radio
Car phone or CB radio...........4-47
Compact Disc (CD) changer.......4-33
FM-AM radio with compact disc (CD)
player....................4-22
Rear audio controls.............4-37
Steering wheel audio control switch. . . .4-36
Readiness for inspection maintenance (I/M)
test........................9-34
Rear audio controls...............4-37
Rear power windows..............2-44
Rear sliding window..............2-45
Rear sonar system off switch.........2-31
Recorders
Event data..................9-34
Refrigerant recommendation..........9-6
Registering your vehicle in another country. . .9-9
Remote controller (See NISSAN mobile
entertainment system).............4-40
Remote keyless entry system..........3-7
Reporting safety defects (US only)......9-33
10-4
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
03/01/04Ðdebbie
X

S
Safety
Child safety rear door lock..........3-6
Child seat belts...............1-36
Reporting safety defects (US only). . . .9-33
Screen (See NISSAN mobile entertainment
system).....................4-40
Seat adjustment
Front manual seat adjustment.....1-2, 1-3
Front power seat adjustment........1-5
Seat belt
Child safety.................1-29
Infants and small children.........1-30
Injured Person................1-30
Larger children...............1-30
Precautions on seat belt usage......1-27
Pregnant women..............1-30
Pre-tensioner seat belt system.......1-24
Seat belt extenders.............1-35
Seat belt maintenance...........1-36
Seat belts..................1-27
Shoulder belt height adjustment......1-33
Three-point type with retractor.......1-31
Two-point type without retractor
(rear center lap belt)............1-34
Seat belt warning light.............2-16
Seatback pockets................2-38
Seats
Adjustment..................1-2
Automatic drive positioner.........3-21
Front seats..................1-2
Heated seats................2-29
Manual front seat adjustment.....1-2, 1-3
Security indicator light..........1-20, 2-18Security system (Nissan vehicle immobilizer
system) , engine start.........2-21, 3-2, 5-8
Self-adjusting brakes..............8-20
Service manual order form...........9-35
Servicing air conditioner............4-19
Shift lock release................5-15
Shifting
Automatic transmission.......5-11, 5-13
Shoulder belt height adjustment........1-33
Side air bag system (See supplemental side air
bag, curtain and rollover air bag systems). . .1-23
Spark plug replacement............8-15
Speedometer...................2-4
SRS warning label...............1-25
Starting
Before starting the engine..........5-8
Jump starting.................6-8
Precautions when starting and driving . . .5-2
Push starting................6-10
Starting the engine..............5-9
Steering
Power steering fluid.............8-11
Power steering system...........5-27
Tilting steering wheel............3-13
Steering wheel audio control switch......4-36
Stop light....................8-26
Storage.....................2-34
Lockable bedside storage
compartment................2-42
Overhead storage compartment......2-38
Storage bin...................2-39
Storage tray...................2-34
Sun visors....................3-14
Sunglasses case................2-37
Sunglasses holder...............2-37
Sunroof.....................2-46Supplemental air bag warning labels.....1-25
Supplemental air bag warning light . . .1-26, 2-16
Supplemental front impact air bag system . .1-18
Supplemental restraint system
Information and warning labels.......1-25
Precautions on supplemental restraint
system....................1-11
Supplemental restraint system
(Supplemental air bag system).........1-11
Switch
Autolight switch...............2-24
Automatic power window switch.....2-44
Electronic locking rear differential system
switch....................2-30
Fog light switch...............2-27
Hazard warning flasher switch.......2-27
Headlight and turn signal switch......2-23
Heated mirror switch............2-23
Ignition switch................5-7
Power door lock switch...........3-4
Rear sonar system off switch.......2-31
Vehicle dynamic control (VDC) off
switch....................2-29
Windshield wiper and washer switch . . .2-22
T
Tachometer....................2-5
Tailgate latch..................3-19
Temperature gauge
Engine coolant temperature gauge.....2-5
Theft (Nissan vehicle immobilizer system) ,
engine start..............2-21, 3-2, 5-8
Three-way catalyst................5-2
Tie down hooks.................3-21
10-5
ZREVIEW COPY:Ð2004 Titan(tzw)
Owners Manual(owners)ÐUSA English(nna)
03/01/04Ðdebbie
X
