The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
described in the “Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended Fluids and Lubricants
US measure Imp measure Liter
Fuel 20.1 gal 16-3/4 gal 76 Unleaded gasoline with an octane rating of at least 87 AKI (RON 91)*1
Engine oil *8
Drain and Refill
With oil filter change 4-1/4 qt 3-1/2 qt 4.0• API Certification Mark *2 *3
• API grade SL, Energy Conserving *2 *3
• ILSAC grade GF-III*2 *3 Without oil filter change 3-7/8 qt 3-1/4 qt 3.7
Cooling system
With reservoir 11-1/8 qt 10-1/4 qt 10.550% Genuine NISSAN Long Life Anti-freeze Coolant or equivalent
50% Demineralized or distilled water
Automatic transmission fluid
Refill to the proper level according to the instructions in the
“Maintenance and do-it-yourself” section. 4 SpeedGenuine Nissan Matic D ATF (Continental U.S. and Alaska) or Canada NISSAN Automatic
Transmission Fluid.*4
5 SpeedGenuine Nissan Matic K ATF *5
Power steering fluid (PSF)Genuine NISSAN PSF or equivalent.*9
Brake fluidGenuine NISSAN Super Heavy Duty Brake Fluid*6 or equivalent DOT 3 (US FMVSS No. 116)
Multi-purpose grease———NLGINo.2(Lithium Soap base)
Air conditioning system refrigerant— — — HFC-134a (R-134a)*7
Air conditioning system lubricants— — — NISSAN A/C System Lubricant Type DH-PS or equivalent*7
Windshield washer fluid (shared between front
and rear wipers)1-1/4 gal 1 gal 4.5 Genuine NISSAN Windshield Washer Concentrate Cleaner & Anti-freeze or equivalent
*1: For further details, see “Fuel recommendation.”
*2: For further details, see “Engine oil and oil filter recommendations.”
*3: For further details, see “Recommended SAE engine oil viscosity.”
*4: Dexron™ III/Mercon™ or equivalent may also be used. Outside the Continental United States and Alaska contact a NISSAN dealership for more information regarding suitable fluids, including recommended
brand(s) of Dexron™ III/Mercon™ Automatic Transmission Fluid.
*5: Using automatic transmission fluid other than Genuine Nissan Matic K ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the NISSAN new vehicle warranty.
*6: Available in mainland USA through your NISSAN dealer.
*7: For further details, see “Air conditioner specification label.”
*8: For further details, see “Changing engine oil.”
*9: For Canada, NISSAN Automatic Transmission Fluid (ATF) , Dexron™ III/Mercon™, or equivalent ATF may also be used.
CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2Technical and consumer information
ZREVIEW COPY:Ð2004 Quest(van)
Owners Manual(owners)ÐUSA English(nna)
10/08/03Ðtbrooks
X
Pre-tensioner seat belt system.........1-28
Push starting...................6-9
R
Radio
Car phone or CB radio...........4-53
Compact Disc (CD) changer.......4-39
Rear audio controls.............4-43
Steering wheel audio control switch. . . .4-41
Readiness for inspection maintenance (I/M)
test........................9-20
Rear audio controls...............4-43
Rear center seat belt..............1-37
Rear seat air conditioner............4-29
Rear sonar system off switch.........2-22
Rear window and outside mirror defroster
switch......................2-15
Rear window wiper and washer switches . . .2-14
Refrigerant recommendation..........9-6
Registering your vehicle in another country. . .9-9
Remote controller
(See DVD entertainment system).......4-46
Remote keyless entry system..........3-9
Reporting safety defects (US only)......9-19
S
Safety
Child safety rear door lock..........3-9
Child safety sliding door lock........3-9
Child seat belts...............1-40
Reporting safety defects (US only). . . .9-19
Screen (See DVD entertainment system) . . .4-46Seat adjustment
Front manual seat adjustment........1-2
Front power seat adjustment........1-5
Second row captain’s chair.........1-6
Third row bench seat..........1-8, 1-9
Seat belt
Child safety.................1-33
Infants and small children.........1-34
Injured Person................1-34
Larger children...............1-34
Precautions on seat belt usage......1-31
Pregnant women..............1-34
Pre-tensioner seat belt system.......1-28
Rear center seat belt............1-37
Seat belt extenders.............1-40
Seat belt maintenance...........1-40
Seat belts..................1-31
Shoulder belt height adjustment......1-39
Three-point type with retractor.......1-35
Seat belt warning light..............2-9
Seatback pockets................2-30
Seats
Adjustment..................1-2
Automatic drive positioner.........3-25
Front seats..................1-2
Heated seats................2-21
Manual front seat adjustment........1-2
Second row captain’s chair adjustment.....1-6
Security indicator light.............2-11
Security system
(Nissan vehicle immobilizer system) ,
engine start..............2-12, 3-2, 5-6
Self-adjusting brakes..............8-22
Service manual order form...........9-21
Servicing air conditioner............4-30
Shift lock release.................5-9Shifting
Automatic transmission...........5-8
Shoulder belt height adjustment........1-39
Side air bag system
(See supplemental side air bag
and curtain side-impact air bag system) . . .1-27
Skyview™ roof..................2-39
Sliding door
Manual sliding door.............3-5
Power sliding door..............3-7
Sliding door locks
Child safety sliding door locks........3-9
Spark plug replacement............8-17
Speedometer...................2-4
SRS warning label...............1-29
Starting
Before starting the engine..........5-6
Jump starting.................6-7
Precautions when starting and driving . . .5-2
Push starting.................6-9
Starting the engine..............5-7
Steering
Power steering fluid.............8-13
Power steering system...........5-15
Tilting steering wheel............3-21
Steering wheel audio control switch......4-41
Stop light....................8-27
Storage.....................2-25
Storage bin.........2-27, 2-31, 2-33, 2-34
Storage compartment.............2-25
Storage tray...............2-26, 2-27
Sun visors....................3-22
Sunglasses case................2-28
Sunglasses holder...............2-28
Sunroof.....................2-39
Supplemental air bag warning labels.....1-29
10-5
