2004 MERCEDES-BENZ SLK32AMG wheel bolt torque

187 Operation
Tires and wheels
Tire pressure changes by approximately
1.5 psi (0.1 bar) per 18°F (10°C) of air
temperature change. Keep this in mind
when checking tire pressure where the
temperature is different from the outside
temperature.
The tire temperature and with it the tire
pressure is increased also while driving,
depending on the driving speed and the
tire load.Check the spare tire periodically for condi-
tion and inflation. Spare tires will age and
b e c o m e w o r n o v e r t i m e e v e n i f n e v e r u s e d ,
and thus should be inspected and replaced
when necessary.
Rotating wheels
The wheels can be rotated every 3 000 to
6 000 miles (5 000 to 10 000 km), or soon-
er if necessary, according to the degree of
tire wear. The same direction of tire rota-
tion must be retained.Rotate the wheels before the characteris-
tic tire wear pattern becomes visible
(shoulder wear on front wheels and tread
center wear on rear wheels).
Thoroughly clean the inner side of the
wheels after each rotation. Check and en-
sure proper tire inflation pressure.
Warning!
G
Follow recommended inflation pressure.
Do not overinflate tires. Overinflated tires
can result in sudden deflation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes,
etc.
Do not underinflate tires. Underinflated tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.
Do not overload the tires by exceeding the
specified vehicle capacity weight (as indicat-
ed by the label on the pillar in the driver’s
door opening). Overloading the tires can
overheat them, possibly causing a blowout.Warning!
G
Rotate front and rear wheels only if they are
of the same size.
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
80 lb-ft (110 Nm).
Use only genuine Mercedes-Benz wheel
bolts specified for your vehicle's rims.

248 Practical hintsFlat tire

Unscrew the alignment bolt, install last
wheel bolt and tighten slightly.
Lowering the vehicle

Lower vehicle by turning crank coun-
terclockwise until vehicle is resting ful-
ly on its own weight.

Pull the jack out of the jack support
tube.

Install jack tube cover.1 - 5Wheel bolts

Tighten the five wheel bolts evenly, fol-
lowing the diagonal sequence illustrat-
ed (1to5), until all bolts are tight.
Observe a tightening torque of 80 lb-ft
(110 Nm).
Warning!
G
Always replace wheel bolts that are dam-
aged or rusted.
Never apply oil or grease to wheel bolts.
Damaged wheel hub threads should be re-
paired immediately. Do not continue to drive
under these circumstances! Contact an au-
thorized Mercedes-Benz Center or call
Roadside Assistance.
Incorrect mounting bolts or improperly
tightened mounting bolts can cause the
wheel to come off. This could cause an acci-
dent. Be sure to use the correct mounting
bolts.
Warning!
G
Use only genuine equipment
Mercedes-Benz wheel bolts. Other wheel
bolts may come loose.
Do not tighten the wheel bolts when the ve-
hicle is raised. Otherwise the vehicle could
tip over.
Warning!
G
Have the tightening torque checked after
changing a wheel. The wheels could come
loose if they are not tightened to a torque of
80 lb-ft (110 Nm).

290 Technical termsRetractable hardtop
Hardtop that can be opened and closed
at the push of a button and stored in
the trunk.
Roll bar
Occupant protection system which
consists of tubular steel sheathed in
plastic.
RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.Shift lock
When the vehicle is parked, this lock
prevents the transmission selector le-
ver from being moved out of positionP
without key turned and brake pedal de-
pressed.
SRS
(S
upplemental R
estraint S
ystem)
Seat belts, emergency tensioning de-
vice and airbags. Though independent
systems, they are closely interfaced to
provide effective occupant protection.
Tele Aid System
(T
elematic A
larm I
dentification on
D
emand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, roadside assistance
and information. Tele Aid is initially ac-
tivated by completing a subscriber
agreement and placing an acquain-
tance call.The Tele Aid system is operational pro-
vided that the vehicle’s battery is
charged, properly connected, not dam-
aged and cellular and GPS coverage is
available.
Tightening torque
Force times lever arm (e.g. a lug
wrench) with which threaded fasteners
such as wheel bolts are tightened.
TIREFIT
Accessory for emergency and tempo-
rary tire repair. The TIREFIT kit consists
of a container with sealant material, a
filler hose, a valve stem tool, a valve in-
sert, and an air compressor.

308 Index
Brake fluid 279
Coolant 277
Coolants 281
Electrical system 274
Engine 268
Engine oil 279
Engine oil additives 279
Fuel requirements 280
Fuels 277
Gasoline additives 280
Lubricants 277
Main dimensions 275
Premium unleaded gasoline 280
Rims and tires 269
Weights 276
Windshield and headlamp washer*
system 278, 283
Tele Aid 144
Emergency calls 146
Information 149
Initiating an emergency call
manually 147
Remote door unlock 151Roadside assistance 148
Stolen vehicle tracking services 152
System self-check 145
Tele Aid System 145
Upgrade signals 150
Tele Aid System 290
Telephone* 143
Hands-free microphone 25
Operation 125
Telescoping steering column*
Adjusting 34
Temperature
Grades of tires 285
Setting interior temperature 104
Tires 187
Tightening torque 290
Tightening torque (Wheel bolts) 248
Tire inflation pressure 242
Checking 173, 186Tire speed rating 166, 291
Tire traction 165
TIREFIT 290
TIREFIT kit
Sealing tires with TIREFIT 235, 240
TIREFIT kit 1 235
TIREFIT kit 2 240
TIREFIT-Kit
Adding TIREFIT 237
Inflating the tire 238
Preparing TIREFIT 236, 241
Tires 185, 269
Collapsible 287
Consumer information 284
Direction of rotation 186
Driving instructions 164
Retreads 185
Rims and tires 269
Service life 186
Temperature 187

310 IndexV
Vehicle
Battery 251
Locking 23
Lowering 248
Proper use of 14
Towing 256, 258, 259
Unlocking 23
Unlocking in an emergency 216
Vehicle battery 251
Vehicle care 192
Cloth upholstery 197
Cup holder 196
Engine cleaning 194
Gear selector lever 196
Hard plastic trim items 196
Headlamps 194
Instrument cluster 196
Leather upholstery 197
Light alloy wheels 196
Ornamental moldings 194
Paintwork 193Plastic and rubber parts 197
Power washer 193
Rear window cleaning 195
Seat belts 197
Steering wheel 196
Tail lamps 194
Tar stains 193
Turn signals 194
Vehicle washing 194
Window cleaning 195
Wiper blades 195
Vehicle Identification Number (VIN) 266
Vehicle lighting
Checking 173
Vehicle tool kit 212
Alignment bolt 212
Spare fuses 212
Special fuse puller 212
Towing eye bolt 212
Vehicle jack 212
Wheel bolts 212
Wheel wrench 212
Vehicle washing 194VIN (Vehicle Identification Number) 266,
291
Voice control system* 25, 291
Hands-free microphone 25
W
Warning sounds
Drivers seat belts 57
Parking brake 42
Warranty coverage 265
Washer fluid see Windshield washer fluid
Washing the vehicle 192
Wear pattern (tires) 187
Weights 276
Wheel change
Tightening torque 248
Wheels
Rotating 187
Tires and wheels 185
Wind screen 135, 291
Installing 135
Removing 135
