2004 MERCEDES-BENZ SLK32AMG oil level

Contents
Tele Aid ........................................ 144
Garage door opener ..................... 153
Operation......................................... 159
The first 1000 miles (1500 km) ......... 160
Driving instructions............................ 161
Drive sensibly – save fuel............. 161
Drinking and driving ..................... 161
Pedals .......................................... 161
Power assistance ......................... 162
Brakes .......................................... 162
Driving off .................................... 163
Parking......................................... 163
Tires ............................................. 164
Hydroplaning................................ 165
Tire traction ................................. 165
Tire speed rating .......................... 166
Winter driving instructions ........... 167
Standing water ............................. 168
Passenger compartment .............. 168
Driving abroad.............................. 168
Control and operation of radio
transmitter ................................... 168
Catalytic converter....................... 169
Emission control .......................... 170Coolant temperature..................... 170
At the gas station ............................... 171
Refueling....................................... 171
Check regularly and before a
long trip ........................................ 172
Engine compartment .......................... 174
Hood ............................................. 174
Engine oil ...................................... 175
Transmission fluid level................. 180
Coolant ......................................... 180
Battery .......................................... 183
Windshield washer system and
headlamp cleaning system*.......... 184
Tires and wheels................................. 185
Important guidelines ..................... 185
Life of tire ..................................... 186
Direction of rotation...................... 186
Checking tire inflation pressure .... 186
Rotating wheels ............................ 187
Winter driving ..................................... 188
Winter tires ................................... 188
Block heater (Canada only) ........... 189
Snow chains.................................. 189
Maintenance....................................... 190
Clearing the service indicator ....... 190
Service term exceeded ................. 191Calling up the service indicator .... 191
Resetting the service indicator ..... 191
Vehicle care ....................................... 192
Cleaning and care of vehicle ......... 192
Practical hints.................................. 199
What to do if … ................................... 200
Lamps in instrument cluster ......... 200
Additional indicators in the
speedometer display .................... 210
Lamp in center console ................ 211
Where will I find ...? ............................ 212
First aid kit.................................... 212
Vehicle tool kit, vehicle jack ......... 212
Spare wheel (SLK 230
Kompressor, SLK 320) .................. 213
TIREFIT kit (SLK 32 AMG only) ...... 214
Unlocking/locking in an emergency .. 216
Unlocking the vehicle ................... 216
Locking the vehicle ....................... 217
Changing batteries in remote
control .......................................... 218
Synchronizing remote control ....... 219
Fuel filler flap ................................ 219

21 At a glance
Instrument cluster
Item
Page
1
Left indicator lamps
with:W
Low windshield
washer and head
lamp washer* sys-
tem fluid level warn-
ing lamp
206
/
Low engine coolant
level warning lamp
207
N
Low engine oil level
warning lamp
206
1
Supplemental Re-
straint System
(SRS) indicator
lamp
52,
203
2
Brake pad wear in-
dicator lamp
209
?
Engine malfunction
indicator lamp
205
_
Telescoping steer-
ing column warning
lamp
206
Item
Page
2
Display with:D
Coolant tempera-
ture gauge
89
A
Fuel gauge
207
Outside temperature
indicator
91
3
Knob for:

Instrument cluster illu-
mination
89


Resetting trip odome-
ter
90


Activating Flexible Ser-
vice System (FSS) indi-
cator
190
Item
Page
4
Speedometer with:L
Left turn signal indi-
cator lamp
K
Right turn signal in-
dicator lamp
v
Electronic Stability
Program (ESP)
warning lamp
68,
200
Trip odometer
90
Main odometer
5
Knob for:

Setting clock
91
6
Tachometer with:Selector lever position
41, 90
Clock
91

172 OperationAt the gas station
Replace the fuel cap by turning it to the
right.
You will hear when the fuel cap is tight-
ened.

Close the fuel filler flap.
You should hear the latch close shut.
Check regularly and before a long trip
1Windshield washer and headlamp
cleaning system*
More information on filling up the res-
ervoir can be found in the “Operation”
section (
page 184).
2Brake fluid3Coolant level
More information on coolant can be
found in the “Operation” section
(
page 180).
4Engine oil level
More information on engine oil can be
found in the “Operation” section
(page 175).
Opening hood (
page 174).
Warning!
G
Overfilling of the fuel tank may create pres-
sure in the system which could cause a gas
discharge. This could cause the gas to spray
back out when removing the fuel pump noz-
zle, which could cause personal injury.iLeaving the engine running and the fuel
cap open can cause the? lamp to
illuminate.
More information can be found in the
“Practical hints” section (
page 205).
!If you find that the brake fluid in the
brake fluid reservoir has fallen to the
minimum mark or below, have the
brake system checked for brake pad
thickness and leaks immediately. Noti-
fy an authorized Mercedes-Benz Center
immediately. Do not add brake fluid as
this will not solve the problem. For
more information, (
page 204).


176 OperationEngine compartmentChecking engine oil level via display
(SLK 320, SLK 32 AMG only)
When checking the oil level the vehicle
must

be parked on level ground


be at normal operating temperature


have been stationary for at least five
minutes with the engine turned off
To check the engine oil level via the display
in the speedometer, do the following:

Turn the key in the steering lock to
position2.
1Button

Wait until the symbols: andI
appear in the speedometer display.

Within one second press button1
twice.
One of the following messages will
subsequently appear in the display:

OKThe oil level is correct. Engine oil
does not to be added.


-1.0 Q(Canada:
-1.0 L
)

Add 1.0 quart (Canada:
1.0 liter) of engine oil.


-1.5 Q

(Canada:
-1.5 L
)

Add 1.5 quarts (Canada:
1.5 liters) of engine oil.


-2.0 Q(Canada:
-2.0 L
)

Add 2.0 quarts (Canada:
2.0 liters) of engine oil.For adding engine oil see (
page 179).
More information on engine oil can be
found in the “Technical data” section
(
page 277) and (
page 279).
Other display messages
If there is excess engine oil with the engine
at normal operating temperature, a signal
sounds and the following message will
blink in the display:
HIThe oil level is too high.
Have excess oil siphoned or drained
off. Contact your authorized Mer-
cedes-Benz Center.!If the message
-2.0 Q

(Canada:
-2.0 L
) blinks and a signal
sounds, add oil according to amount
displayed.

177 Operation
Engine compartment
TheI symbol flashes in the
speedometer display if a proper oil level
check cannot be performed.
If engine is at normal operating
temperature, wait five minutes before
repeating check procedure.

If engine is not yet at normal operating
temperature, wait 30 minutes before
repeating check procedure.See the “Practical hints” section
(
page 199) if the low engine oil level
warning lamp in the instrument cluster
comes on.
Checking engine oil level with the oil
dipstick
When checking the oil level the vehicle
must


be parked on level ground


be at normal operating temperature


have been stationary for at least five
minutes with the engine turned off
!Excess oil must be siphoned or drained
off. It could cause damage to the
engine and catalytic converter not
covered by the Mercedes-Benz Limited
Warranty.
iPerform the engine oil level check with
the dipstick if it cannot be completed
via the speedometer display
(page 177).
In this case we recommend that you
have the system checked at a
Mercedes-Benz Center.
iIf the: andI symbols are
continuously illuminated after pressing
button1 (
page 176) twice, and if
there is no change in the speedometer
display or the low engine oil level
warning lamp comes on, a malfunction
has occurred to the system.
Perform the engine oil level check with
the dipstick (page 177).
Visually check for oil leaks. If no obvi-
ous oil leaks are noted, drive to the
nearest authorized Mercedes-Benz
Center to have the system checked.
iThe engine oil level can be checked by
either the oil dipstick or via the
speedometer display (SLK 320,
SLK 32 AMG only) in the instrument
cluster (
page 176). The amount of
engine oil needed is shown more
precisely in the speedometer display.

178 OperationEngine compartmentTo check the engine oil level with the oil
dipstick, do the following:
Open the hood (
page 174).

Pull out oil dipstick1 (
page 179)

Wipe oil dipstick1 clean.

Fully insert oil dipstick1 into the
dipstick guide tube.

Pull out oil dipstick1 again after
approximately three seconds to obtain
accurate reading.
Oil dipstickThe oil level is correct when it is between
the lower (min) and upper (max) mark of
the oil dipstick.

If necessary, add engine oil.
For adding engine oil see (
page 179).
More information on engine oil can be
found in the “Technical data” section
(
page 277) and (
page 279).
See the “Practical hints” section
(
page 199) if the low engine oil level
warning lamp in the instrument cluster
comes on.
iThe filling quantity between the upper
and lower marks on the oil dipstick is
approximately 2.1 US qt. (2.0 l).

180 OperationEngine compartmentBe careful not to spill any oil when adding.
Avoid environmental damage caused by oil
entering the ground or water.
Screw filler cap2 back on filler neck.
More information on engine oil can be
found in the “Technical data” section
(
page 277) and (
page 279).
Transmission fluid level
The transmission fluid level does not need
to be checked. If you notice transmission
fluid loss or gear shifting malfunctions,
have an authorized Mercedes-Benz Center
check the transmission.Coolant
The engine coolant is a mixture of water
and anticorrosion/antifreeze. To check
the coolant level, the vehicle must be
parked on level ground and the engine
must be cool.
The coolant expansion tank is located on
the passenger side of the engine compart-
ment.
!Excess oil must be siphoned or drained
off. It could cause damage to the
engine and catalytic converter not
covered by the Mercedes-Benz Limited
Warranty.
Warning!
G
In order to avoid any possibly serious burns:

Use extreme caution when opening the
hood if there are any signs of steam or
coolant leaking from the cooling system,
or if the coolant temperature gauge indi-
cates that the coolant is overheated.


Do not remove pressure cap on coolant
reservoir if engine temperature is above
194°F (90°C). Allow engine to cool
down before removing cap. The coolant
reservoir contains hot fluid and is under
pressure.


Using a rag, slowly open the cap approx-
imately ½ turn to relieve excess pres-
sure. If opened immediately, scalding
hot fluid and steam will be blown out un-
der pressure.


Do not spill antifreeze on hot engine
parts. Antifreeze contains ethylene gly-
col which may burn if it comes into con-
tact with hot engine parts.


191 Operation
Maintenance
Service term exceeded
If you have exceeded the suggested
service term:

the9 or´ appears in the
display2 for 30 seconds and a signal
sounds after switching on the ignition.


it is preceded by a “-” (minus symbol)
The Mercedes-Benz Center will reset the
service indicator following a completed
service.
Calling up the service indicator
Within one second press knob1
(page 190) twice.
The service symbol and the service
deadline appear in the display2.
Resetting the service indicator
In the event that the service on your vehi-
cle is not carried out by an authorized
Mercedes-Benz Center, you can reset the
service indicator yourself.
Switch ignition on (key in steering lock
position 2) and immediately press
knob1 (
page 190) twice within
1 second.
The present status for days or distance
is displayed.

Within ten seconds turn key in steering
lock to position0.

Press and hold knob1 while turning
key in steering lock to position2 again.
The present status for days and dis-
tance is displayed once more.
Continue to hold knob1 until you
hear a signal.

Release knob1.
The service indicator now displays the
reset interval.
iIf the service indicator was inadvertent-
ly reset, have a Mercedes-Benz Center
correct it.
Only reset if the proper service has
been performed. Resetting the system
without performing proper service as
called for by the FSS will cause the FSS
to incorrectly determine the next ser-
vice interval which will result in engine
damage not covered by the Mer-
cedes-Benz Limited Warranty.
If the battery is disconnected, the days
of disconnection will not be included in
the count shown by the service indica-
tor. To arrive at the true service dead-
line, you will need to subtract these
days from the days shown in the ser-
vice indicator.
Do not confuse the service indicator
with the engine oil level indicator:.
