2004 MERCEDES-BENZ SLK CLASS remote start

Contents
Introduction......................................... 7
Product information ................................ 7
Operator’s Manual .................................. 8
Service and warranty information ..... 8
Important notice for California
retail buyers and lessees of
Mercedes-Benz automobiles ............. 9
Maintenance .................................. 10
Roadside Assistance ...................... 10
Change of address or ownership.... 10
Operating your vehicle outside the
USA or Canada.............................. 11
Where to find it .................................... 12
Symbols ............................................... 13
Operating safety .................................. 14
Proper use of the vehicle ............... 14
Problems with your vehicle .................. 15
Reporting safety defects...................... 16
Reporting safety defects ................ 16
At a glance.......................................... 17
Cockpit ................................................. 18
Instrument cluster ................................ 20
Center console ..................................... 23
Upper part ...................................... 23
Lower Part ...................................... 24
Overhead control panel ........................ 25Getting started................................... 27
Unlocking ............................................. 28
Unlocking with the remote control.. 28
Adjusting .............................................. 30
Seats............................................... 30
Telescoping steering column* ........ 34
Mirrors ............................................ 35
Driving .................................................. 37
Fastening the seat belts.................. 37
Starting the engine ......................... 40
Switching on headlamps ................. 43
Turn signals and high beam ............ 43
Windshield wipers ........................... 44
Problems while driving .................... 45Parking and locking .............................. 47
Parking brake ................................. 47
Switching off headlamps................. 48
Turning off engine ........................... 48
Safety and Security........................... 51
Occupant safety ................................... 52
Airbags ........................................... 53
Seat belts ....................................... 57
Children in the vehicle .................... 60
Panic alarm .......................................... 65
Activating........................................ 65
Deactivating.................................... 65
Driving safety systems ......................... 66
ABS ................................................. 66
BAS ................................................. 67
ESP ................................................. 68
Anti-theft systems ................................ 71
Immobilizer ..................................... 71
Anti-theft alarm system .................. 71
Tow-away alarm .............................. 72

28 Getting startedUnlocking
The “Getting started” section provides an
overview of the vehicle’s most basic func-
tions. First-time Mercedes-Benz owners
should pay special attention to the infor-
mation given here.
If you are already familiar with the basic
functions described here, the “Controls in
detail” section will help you with further in-
formation. The corresponding page refer-
ences are at the end of each segment.
Unlocking
Unlocking with the remote controlRemote control with folding key1Release button for key
2‹Lock button
3ŒUnlock button
4ÂPanic button (
page 65)

Press unlock buttonΠon the re-
mote control.
All turn signal lamps blink once. The
locking knobs in the doors move up.

Press release button1 on the remote
control.
The key folds out.

Get in the vehicle and insert the key in
the steering lock (
page 29).
More information can be found in the
“Controls in detail” section (
page 74).

49 Getting started
Parking and locking

Press the seat belt release button
(page 38).
Allow the retractor to completely rewind
the seat belt by guiding the latch plate.

After exiting the vehicle, press the lock
button‹on the remote control
(page 28).
The turn signal lamps blink three times.
The locking knobs on the doors move
down.More information can be found in the
“Controls in detail” section (
page 74).
iVehicles with automatic transmission:
The key can only be removed from the
steering lock with the gear selector
lever in positionP.!With the key removed and the driver’s
door open, a warning sounds if the ve-
hicle’s exterior lamps (except standing
lamps) are not switched off.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the door
openings when closing the doors. Be espe-
cially careful when small children are
around.
Before closing doors, make sure there is no
possibility of someone getting caught in a
door during closing.
Warning!
G
When leaving the vehicle, always remove the
key from the steering lock and lock your ve-
hicle. Do not leave children unattended in
the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.

71 Safety and Security
Anti-theft systems
Anti-theft systems
Immobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
Activating

Removing the key from the steering
lock activates the immobilizer.
Deactivating


Inserting the key in the steering lock
deactivates the immobilizer.
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens

a door


the trunk


the hood
The alarm system will also be triggered
when


someone attempts to raise the vehicle.Arming the alarm system
The alarm system is armed within approxi-
mately ten seconds after locking the vehi-
cle. The indicator lamp in the switch for the
tow-away alarm (
page 72) will then
blink.
Disarming the alarm system
The alarm system is disarmed when you
unlock your vehicle with the remote con-
trol.
Canceling the alarm
To cancel the alarm:

Insert the key in the steering lock.
or

Press theŒ or‹button.
The alarm is canceled.
iIn case the engine cannot be started
(yet the vehicle’s battery is charged),
the system is not operational. Contact
an authorized Mercedes-Benz Center
or call 1-800-FOR-MERCedes (in the
USA), or 1-800-387-0100 (in Canada).
iIf the alarm stays on for more than
20 seconds, an emergency call is initi-
ated automatically by the Tele Aid sys-
tem provided Tele Aid service was
subscribed to and properly activated,
and that necessary cellular service and
GPS coverage are available.

74 Controls in detailLocking and unlocking
In the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed in your vehicle.
If you are already familiar with the basic
functions of your vehicle, this section will
be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are giv-
en at the beginning of each segment.
Locking and unlocking
Keys
Your vehicle comes supplied with two re-
mote controls with folding key.
The remote control provides an extended
operating range. To prevent theft, howev-
er, it is advisable to only unlock the vehicle
when you are in close proximity to it.
The remote control centrally locks and un-
locks:

the doors


the trunk


the fuel filler flap


the storage compartment in armrest
You can lock and unlock each individual
lock with the key.
Remote control with folding key1ŒUnlock button
2
‹
Lock button
3Release button for key
4Battery check lamp
5ÂPanic button (
page 65)
!To prevent possible malfunction, avoid
exposing the remote control to high
levels of electromagnetic radiation.

80 Controls in detailLocking and unlockingActivating
Check that the ignition is switched on.
All the lamps in the instrument cluster
light up.

Press and hold upper part1 of the
central locking switch for approximate-
ly five seconds.
The automatic central locking is acti-
vated.
Deactivating

Check that the ignition is switched on.
All the lamps in the instrument cluster
light up.

Press and hold lower part2 of the
central locking switch for approximate-
ly five seconds.
The automatic central locking is deacti-
vated.
Locking and unlocking from the inside
You can lock or unlock the vehicle from in-
side using the central locking switch. This
can be useful, for example, if you want to
unlock the passenger door from the inside
or want to lock the vehicle before starting
to drive.Locking

Press upper part1 of central locking
switch (
page 79).
If all the doors are closed, the vehicle
locks.
Unlocking

Press lower part2 of central locking
switch (
page 79).
The vehicle unlocks.
Warning!
G
When leaving the vehicle, always remove the
key from the steering lock and lock the vehi-
cle. Do not leave children unattended in the
vehicle, or with access to an unlocked vehi-
cle. Unsupervised use of vehicle equipment
may cause an accident and/or serious per-
sonal injury.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked using the remote control, it will
not unlock using the central locking
switch.

148 Controls in detailUseful features
Roadside Assistance button•
Located below the center armrest cover is
the Roadside Assistance button•.
Press and hold the button (for longer
than two seconds).
A call to a Mercedes-Benz Roadside
Assistance dispatcher will be initiated.
The button will flash while the call is in
progress.
The Tele Aid system will transmit data gen-
erating the vehicle identification number,
model, color and location (subject to avail-
ability of cellular and GPS signals).
A voice connection between the Roadside
Assistance dispatcher and the occupants
of the vehicle will be established.

Describe the nature of the need for as-
sistance.
The Mercedes-Benz Roadside assistance
dispatcher will either dispatch a qualified
Mercedes-Benz technician or arrange to
tow your vehicle to the nearest
Mercedes-Benz Center. For services such as labor and/or towing, charges may ap-
ply. Refer to the Roadside Assistance man-
ual for more information.
These programs are only available in the
USA:


Sign and Drive services: Services such
as jump start, a few gallons of fuel or
the replacement of a flat tire with the
vehicle spare tire are obtainable.


Remote Vehicle Diagnostics: This func-
tion permits the Mercedes-Benz Road-
side Assistance dispatcher to
download malfunction codes and actu-
al vehicle data.
Warning!
G
If you feel at any way in jeopardy when in the
vehicle (e.g. smoke or fire in the vehicle, ve-
hicle in a dangerous road location), please
do not wait for voice contact after you have
pressed the emergency button. Carefully
leave the vehicle and move to a safe loca-
tion. The Response Center will automatically
contact local emergency officials with the
vehicle’s approximate location if they re-
ceive an automatic SOS signal and cannot
make voice contact with the vehicle occu-
pants.

155 Controls in detail
Useful features
Step 3:
Hold the end of the hand-held remote
control transmitter6 of the device
you wish to train approximately 2 to
5 in (5 to12 cm) away from the surface
of the integrated remote control locat-
ed on the interior rear view mirror,
keeping the indicator lamp4 in view.
Step 4:

Using both hands, simultaneously
press the hand-held transmitter
button5 and the desired integrated
signal transmitter button (1, 2
or3). Do not release the buttons until
completing step 5.
The indicator lamp4 on the integrat-
ed remote control will flash, first slowly
and then rapidly.Step 5:

When the indicator lamp4 flashes
rapidly, release both buttons.
Step 6:

Press and hold the just-trained inte-
grated signal transmitter button and
observe the indicator lamp4.
If the indicator lamp4 stays on con-
stantly, programming is complete and
your device should activate when the
integrated signal transmitter button is
pressed and released.Step 7:

To program the remaining two buttons,
repeat the steps above starting with
step 3.
iThe indicator lamp4 flashes the first
time the signal transmitter button is
programmed. If this button has already
been programmed, the indicator lamp
will only start flashing after 20 sec-
onds.
iIf the indicator lamp4 blinks rapidly
for about two seconds and then turns
to a constant light, continue with pro-
gramming steps 8 through 12 as your
garage door opener may be equipped
with the “rolling code” feature.
