2004 MERCEDES-BENZ SLK CLASS charging

Contents
Manually unlocking the
transmission selector lever .......... 220
Opening/closing in an emergency ..... 221
Raising retractable hardtop
manually ...................................... 221
Replacing bulbs ................................. 226
Bulbs ............................................ 226
Replacing bulbs for front lamps.... 228
Replacing bulbs for rear lamps ..... 230
Adjusting headlamp aim
(Halogen headlamps only) ............ 231
Replacing wiper blades ...................... 233
Removing wiper blades ................ 233
Installing wiper blades.................. 234
Flat tire .............................................. 235
Preparing the vehicle.................... 235
Sealing tires with TIREFIT kit 1 ..... 235
Sealing tires with TIREFIT kit 2 ..... 240
Mounting the spare wheel ............ 244
Battery ............................................... 251
Disconnecting the battery ............ 252
Removing the battery ................... 252
Charging and reinstalling battery . 252
Reconnecting the battery ............. 252
Jump starting ..................................... 254Towing the vehicle ............................. 256
Towing eye ................................... 258
Installing towing eye bolt ............. 259
Fuses ................................................. 260
Main fuse box............................... 260
Auxiliary fuse box ......................... 261
Technical data................................. 263
Spare parts service ............................ 264
Warranty coverage............................. 265
Loss of Service and Warranty
Information Booklet ..................... 265
Identification labels ........................... 266
Layout of poly-V-belt drive ................. 267
SLK 230 Kompressor ................... 267
SLK 320 ....................................... 267
SLK 32 AMG................................. 267
Engine................................................ 268
Rims and Tires ................................... 269
Same size tires ............................. 270
Mixed size tires ............................ 271
Spare wheel with collapsible tire.. 273
Electrical system ............................... 274
Main Dimensions ............................... 275
Weights.............................................. 276Fuels, coolants, lubricants etc. .......... 277
Capacities .................................... 277
Engine oils ................................... 279
Engine oil additives ...................... 279
Air conditioning refrigerant .......... 279
Brake fluid.................................... 279
Premium unleaded gasoline ......... 280
Fuel requirements ........................ 280
Gasoline additives ........................ 280
Coolants ...................................... 281
Windshield washer system and
headlamp washer system* .......... 283
Consumer information ....................... 284
Uniform tire quality grading ......... 284
Technical terms............................... 287Index................................................. 293

201 Practical hints
What to do if …
Problem
Possible cause
Suggested solution
-
The yellow ABS malfunction indi-
cator lamp and warning comes
on while driving.
The ABS has detected a malfunction and has
switched off. The BAS and ESP are also
switched off. Both indicator lamps come on
with the engine running.
The brake system is still functioning normally
but without the ABS available.

Continue driving with added caution.
Wheels will lock during hard braking
reducing steering capability.

Have the system checked at an autho-
rized Mercedes-Benz Center as soon
as possible.
Failure to follow these instructions in-
creases the risk of an accident.
The charging voltage has fallen below
10 volts and the ABS has switched off.

When the voltage is above this value
again, the ABS is operational again.

If necessary, have the alternator and
battery checked.

203 Practical hints
What to do if …
Problem
Possible cause
Suggested solution
¿
The yellow BAS/ESP malfunction
indicator lamp comes on while
driving.
The charging voltage has fallen below
10 volts and the BAS has switched off.

When the voltage is above this value
again, the BAS is operational again.

If necessary, have the alternator and
battery checked.
1
The red SRS indicator lamp lights
up while driving.
There is a malfunction in the restraint sys-
tems. The airbags or emergency tensioning
device (ETDs) could deploy unexpectedly or
fail to activate in an accident.

Drive with added caution to the
nearest authorized Mercedes-Benz
Center.
Warning!
G
In the event a malfunction of the SRS is indi-
cated as outlined above, the SRS may not be
operational. For your safety, we strongly
recommend that you visit an authorized
Mercedes-Benz Center immediately to have
the system checked. Otherwise the SRS
may not be activated when needed in an ac-
cident, which could result in serious or fatal
injury, or it might deploy unexpectedly and
unnecessarily which could also result in an
accident and/or injury to you or to others.

208 Practical hintsWhat to do if …Problem
Possible cause
Suggested solution
#
The red charge indicator lamp
lights up while the engine is
running.
The battery was charged with a battery
charger or jump started.

Have the battery checked at a service
station.
The battery is no longer charging.
Possible causes:

alternator malfunctioning


broken poly-V-belt

Stop immediately and check the
poly-V-belts.
If one is broken:

Do not continue to drive. Otherwise
the engine will overheat due to an in-
operative water pump which may re-
sult in damage to the engine. Notify
an authorized Mercedes-Benz Center.
If it is intact:

Drive immediately to the nearest
authorized Mercedes-Benz Center.
Adjust driving to be consistent with
reduced braking responsiveness.

252 Practical hintsBatteryDisconnecting the battery
Depress parking brake firmly or move
gear selector lever to positionP (man-
ual transmission to Neutral).

Turn off all electrical consumers.

Remove key from steering lock.

Open the hood (
page 174).

Disconnect the battery negative lead.

Remove the cover2 from the positive
terminal.

Disconnect the battery positive lead.
Removing the battery
Remove the screw on the swivel bar.

Remove the swivel bar.

Take out the battery.
Charging and reinstalling battery
Charge battery in accordance with the
instructions of the battery charger
manufacturer.

Reinstall the charged battery. Follow
the previously described steps in re-
verse order.
Reconnecting the battery
Turn off all electrical consumers.

Connect the positive lead and fasten its
cover2.

Connect the negative lead.
Warning!
G
With a disconnected battery

you will no longer be able to turn the key
in the steering lock


automatic transmission: the gear selec-
tor lever will remain locked in positionP
Warning!
G
Never charge a battery while still installed in
the vehicle. Gases may escape during charg-
ing and cause explosions that may result in
paint damage, corrosion or personal injury.
!Never invert the terminal connections!!The battery, its filler caps and the vent
tube must always be securely installed
when the vehicle is in operation.

295 Index
BAS/ESP
Malfunction indicator lamp 200
Batteries, Remote control
Check lamp 75
Batteries, remote control
Changing 218
Battery discharged
Jump starting 254
Battery, vehicle 183, 251
Charging 252
Disconnecting 252
Reconnecting 252
Reinstalling 252
Removing 252
Block heater 189
Bolts
For spare wheel 213
Brake assist system (BAS) 287
Brake fluid 279
Brake lamp bulbs 227
Brake lamp, high mounted 227
Brakes 162
Warning lamp 204Break-in period 160
Bulbs, replacing 226
Additional turn signals 226
Backup lamps 227
Brake lamps 227
Fog lamps 226
Front lamps 226
High beam 226
High mounted brake lamp 227
License plate lamps 227, 231
Low beam 226
Parking lamps 226, 227, 229
Rear fog lamp 227
Rear fog lamps 230
Side marker lamps 226, 230
Standing lamps 226, 227, 229
Tail lamp assemblies 227, 230
Turn signal lamps 226, 227
Button
Audio system 115C
CAC (Customer Assistance Center) 287
California
Important notice 9
Calling up
Service indicator 191
CAN system 287
Capacities
Fuels, coolants, lubricants, etc. 277
Casette mode
Playing cassettes 118
Catalytic converter 169
CD changer* 122, 215
Removing and installing 122
CD mode 121
Center console 23
AIRBAG OFF indicator lamp 211
Lower part 24
Storage compartment 140
Upper part 23

296 IndexCentral locking
From inside 80
Unlocking from inside 80
Certification label 266
Changing CDs
CD mode 121
Charging
Vehicle battery 252
CHECK ENGINE malfunction indicator
lamp 205
Checking
Coolant level 173, 180
Oil level 172, 175
Tire inflation pressure 173
Vehicle lighting 173
Child safety 60
Airbags 54
Infant and child restraint systems 57,
60
Cigarette lighter 143
Cleaning
Cloth upholstery 197Cup holder 196
Gear selector lever 196
Hard plastic trim items 196
Headliner 197
Instrument cluster 196
Leather upholstery 197
Light alloy wheels 196
Plastic and rubber parts 197
Rear window 195
Seat belts 197
Steering wheel 196
Windows 195
Windshield 45
Wiper blades 195
Cleaning*
Headlamps 99
Climate control 102
Adjusting air distribution 105
Adjusting air volume 105
Air conditioning 106
Air recirculation mode 106
Deactivating the climate control
system 110
Defogging windshield 110
Defrosting 109Reactivating the climate control
system 110
Rear window defroster 101
Residual heat utilization 107
Residual ventilation 107
Setting the temperature 104
Clock 21
Setting 91
Closing
Glove box 139
Hood 175
Retractable hardtop 221
Side windows 128
Trunk lid 78
Windows 128
Closing hardtop
In an emergency 221
Cloth upholstery
Cleaning 197
Cockpit 18, 287
Coin holder 142
Collapsible tire 287
