2004 MERCEDES-BENZ SLK CLASS Owners Manual

81 Controls in detail
Seats
Seats
Information on seat adjustment can be
found in the “Getting started” section
(page 27).
Removing and installing head
restraints
1Release button
Removing head restraint

Open the retractable hardtop
(page 130).

Pull head restraint to its highest
position.

Push button1 and pull out head re-
straint.Installing head restraint

Insert head restraint and push it down
to the stop.

Push button1 and adjust head re-
straint to desired position.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an ac-
cident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.iSLK 32 AMG has integrated,
non-removable head restraints.
Warning!
G
Be sure to install the head restraint so that
it is facing in the right direction. Otherwise
you could damage the mounting.
In addition, a head restraint installed in the
wrong direction will not provide the intend-
ed protection and can cause injury in an ac-
cident or similar situation.

82 Controls in detailSeatsHeated seats*
Both switches are located in the center
console.
1Normal heating
2Rapid heating
Make sure the ignition is switched on.
All the lights in the instrument cluster
come on.Switching on seat heating

Press upper switch position1.
A red indicator lamp on the switch
lights up.
Switching off seat heating

Press upper switch position1 again.
Switching on rapid seat heating

Press lower switch position2.
Both red indicator lamps on the switch
light up.Switching off rapid seat heating

Press lower switch position2 again.
iThe seat heater will be automatically
switched off after approximately
30 minutes.iThe system switches over to normal
heating mode after approximately five
minutes. Only one indicator lamp re-
mains lit.
!If one or both of the indicator lamps on
the seat heater switch are blinking,
there is insufficient voltage available
since too many electrical consumers
are turned on. The seat heater switches
off automatically.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.

83 Controls in detail
Lighting
Lighting
For notes on how to switch on the head-
lamps and use the turn signals, see the
“Getting started” section (
page 43).
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
MOff
CParking lamps (also side marker
lamps, tail lamps, license plate
lamps, instrument panel lamps)
Canada only: When engine is run-
ning, the low beam is also switched
on.
BLow beam plus parking lamps or
high beam headlamps (combination
switch pushed forward).ˆStanding lamps, right (turn left one
stop)
‚Standing lamps, left (turn left two
stops)
iIf you remove the key and open the
driver’s door while the parking lamps or
low beam headlamps are switched on,
a warning sounds.iWith the daytime running lamp mode
activated and the engine running, the
low beam headlamps cannot be
switched off manually.

84 Controls in detailLightingDaytime running lamp mode (Canada
only)
Vehicles with automatic transmission
When the engine is running, the low beam
headlamps are automatically switched on.
In low ambient light conditions the parking
lamps will also switch on.
When you shift from a driving position to
positionN orP, the low beam switches off
(two seconds delay).
Vehicles with manual transmission
With the engine running, the low beam
headlamps are automatically switched on.
For nighttime driving you should turn the
exterior lamp switch to positionB to
permit activation of the high beam head-
lamps.Switching on front fog lamps

Make sure the low beam headlamps
are switched on.

Pull out exterior lamp switch to first
stop.
The green indicator lamp‡ in the
lamp switch lights up.Switching on rear fog lamp

Make sure the low beam headlamps
are switched on.

Pull out exterior lamp switch to second
stop.
The yellow indicator lamp† in the
lamp switch lights up.
iThe high beam flasher is always avail-
able.
iFog lamps will operate with the parking
lamps and/or low beam headlamps on.
Fog lamps should only be used in con-
junction with low beam headlamps.
Consult your State or Province Motor
Vehicle Regulations regarding allow-
able lamp operation.

85 Controls in detail
Lighting
Combination switch
The combination switch is located on the
left side of the steering column.
1High beam
2High beam flasherSwitching on high beams

Turn exterior lamp switch to
positionB.

Push the combination switch in
direction1.
The high beam symbol is illuminated on
the instrument cluster.High beam flasher

Pull the combination switch briefly in
direction2.

86 Controls in detailLightingHazard warning flasher
The hazard warning flasher can be activat-
ed with the ignition switched on or off. It is
activated automatically when an airbag is
deployed.
The switch is located on the center
console.
1Hazard warning flasher switchSwitching on hazard warning flasher

Press hazard warning flasher
switch1.
All the turn signals will blink.
Switching off hazard flasher

Press hazard warning flasher switch1
again.

87 Controls in detail
Lighting
Interior lighting
The controls are located in the overhead
control panel.
1Switch for automatic control
2Switch for interior lightingActivating Automatic control

Turn switch1 to the right.
Interior lighting is switched on in dark-
ness, even when you:

unlock the vehicle


open a door


open the trunk lid
The interior lighting switches itself off
again after a short pause.Deactivating Automatic control

Turn switch1 to the left.
The interior lighting remains switched
off in darkness, even when you:

unlock the vehicle


open a door


open the trunk lid
iIf the door remains open, the interior
lamps switch off automatically after ap-
proximately five minutes, when the key
is removed or in the starter switch
position0.
An interior lamp switched on manually
does not go out automatically.

88 Controls in detailLightingManual control
Activating and deactivating
Press switch2.
The interior lighting is switched on.

Press switch2 again.
The interior lighting is switched off.Night security illumination
If you exit the vehicle after driving with the
exterior lighting on, it switches on again for
added security for approximately
30 seconds after closing the last door.iIf the interior lighting is switched on
manually, it will not go out automatical-
ly. This could cause the battery to be-
come discharged.
iThe trunk lighting is switched on and
off simultaneously with the interior
lighting.
