2004 MERCEDES-BENZ CLK320 COUPE remote control

28 At a glanceDoor control panel
Door control panel
Item
Page
1
Door handle
95
2
Seat adjustment
35,
107
3
Memory function (for stor-
ing seat, exterior mirror
and steering wheel set-
tings)
116
4
Switches for opening/clos-
ing front door windows
212
5
Rear window override
switch
74
6
Switches for opening/clos-
ing rear windows
212
7
Remote trunk lid release
switch
Trunk lid opening/closing
system switch*
97
98

30 Getting startedUnlocking
The “Getting started” section provides an
overview of the vehicle’s most basic func-
tions. First-time Mercedes-Benz owners
should pay special attention to the infor-
mation given here.
If you are already familiar with the basic
functions described here, the “Controls in
detail” section will provide you with further
information. The corresponding page refer-
ences are located at the end of each seg-
ment.
Unlocking
Unlocking with the SmartKeySmartKey with remote control 1‹Lock button
2ŠOpening button for trunk lid
3ŒUnlock button
4ÂPanic button (
page 75)

Press unlock button Πon the
SmartKey.
All turn signal lamps flash once. The
locking knobs in the doors move up.

Get in the vehicle and insert the
SmartKey in the starter switch.
For more information, see “Locking and
unlocking” (
page 86).
iOpening a door causes the windows on
that side of the car to open slightly.
They will return to the up position when
the door is closed.

86 Controls in detailLocking and unlocking
In the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed on your vehi-
cle. If you are already familiar with the
basic functions of your vehicle, this section
will be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are giv-
en at the beginning of each segment.
Locking and unlocking
SmartKeys
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key. The locking
tabs for the mechanical key portion of the
two SmartKeys are a different color to help
distinguish each SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors


the trunk


the fuel filler flap
SmartKey with remote controls1‹ Lock button
2Š Opening button for trunk lid
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 75)
!To prevent possible malfunction, avoid
exposing the SmartKey to high levels of
electromagnetic radiation.
iYou can also open and close the power
windows (
page 212) and slid-
ing/pop-up roof* (
page 216) using
the SmartKey.

89 Controls in detail
Locking and unlocking
The trunk can also be opened from its in-
side in an emergency, see “Trunk lid emer-
gency release” (
page 103).Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:

Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.

Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
Specially equipped vehicles come with two
SmartKeys with KEYLESS-GO, each with
remote control and a removable mechani-
cal key. The locking tabs for the mechani-
cal key portion of the two SmartKeys are a
different color to help distinguish each
SmartKey unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you pull a door
handle.
If the SmartKey with KEYLESS-GO* is valid,
your vehicle unlocks

the doors


the trunk lid
iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 104).
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 97). The
turn signals will flash three times to
confirm locking.
!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.

90 Controls in detailLocking and unlocking

the fuel filler flap
SmartKey with remote controls1‹ Lock button
2Š Opening button for trunk lid
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 75)
For more information on using the
SmartKey buttons, see “SmartKeys”
(
page 86) Important notes on using KEYLESS-GO*


You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 86).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the remote control).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with:

electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.iYou can also open and close the power
windows (
page 212) and slid-
ing/pop-up roof* (
page 216) using
the SmartKey.
iIf the vehicle has been parked for a
longer period of time, you must pull the
door handle in order to activate the
KEYLESS-GO function.

97 Controls in detail
Locking and unlocking
Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
The switch is located on the driver’s door.
1Remote trunk lid switch with indicator
lamp
Press remote trunk lid switch1.
The trunk lid opens. The indicator lamp
in the switch remains lit as long as the
trunk is open.The trunk can also be opened using the
SmartKey (
page 88) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 103).
Closing the trunk
1Handle
Lower trunk lid by pulling firmly on
handle1.

Close trunk lid with hands placed flat
on it.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 104)
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 97). The
turn signals will flash three times to
confirm locking.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.

98 Controls in detailLocking and unlocking
Trunk lid opening/closing system*
Opening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
The switch for opening and closing the
trunk is located on the driver’s door.
1Remote trunk lid opening switch
2Remote trunk lid closing switch
Press remote trunk lid opening
switch1 until the trunk lid begins to
open.The trunk lid opens. The indicator lamp
in the switch comes on and remains lit
until the trunk is closed.
Warning!
G
Only drive with the trunk closed. Among oth-
er dangers, such as your view being blocked,
exhaust fumes may enter the vehicle
interior.iDo not place the SmartKey in the open
trunk. You may lock yourself out.iVehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO* is
recognized inside the vehicle or in the
trunk.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance. To stop
the opening procedure, press the re-
mote trunk lid opening or closing
switch.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 104)
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 97). The
turn signals will flash three times to
confirm locking.

99 Controls in detail
Locking and unlocking
The trunk can also be opened using the
SmartKey (
page 88) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 103).
Limiting opening height of trunk lid
The trunk lid opening height can be limited
when transporting goods on a roof rack
(e.g. presence of an MB sport luggage con-
tainer). When activated, the trunk lid opens
to approximately the height of the roof
edge.

With the trunk lid closed, press the re-
mote trunk lid closing switch2
(page 99) and hold for at least five
seconds.
Depending on its previous status, the
opening height limitation is then
switched on or off.
You can activate or deactivate the opening
height limitation with the control system,
see “Setting trunk lid opening limiter (vehi-
cles with trunk lid opening/closing sys-
tem*)” (page 149).Closing the trunk from the inside

Press the remote trunk lid closing
switch2 (
page 98) until the indica-
tor lamp in the switch goes out and the
trunk lid is closed.
To interrupt the closing procedure:

Release remote trunk lid closing
switch2.
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.Warning!
G
Only drive with the trunk closed. Among oth-
er dangers, such as your view being blocked,
exhaust fumes may enter the vehicle
interior.
Warning!
G
Maintain sight of trunk area while operating
the door mounted switch. Monitor the clos-
ing procedure carefully to ensure that no
one is in danger of being injured.
To interrupt the closing procedure, release
the door mounted remote trunk lid closing
switch.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with you and lock your vehicle. Do
not leave children unattended in the vehicle,
or with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.
