2004 MERCEDES-BENZ C CLASS COUPE headlamp

243
Operation
Engine compartment
Windshield washer system and headlamp cleaning system
Fluid for the windshield washer system and
the headlamp cleaning system is supplied
from the windshield washer reservoir. It
has a capacity of

Vehicles without headlamp cleaning
system: approx. 3.2 US qt. (3 l).


Vehicles with headlamp cleaning sys-
tem: approx. 6.4 US qt. (6 l).
During all seasons, add MB Windshield
Washer Concentrate “S” to water. Premix
the windshield washer fluid in a suitable
container.

Refill the reservoir with MB Windshield
Washer Concentrate and water (or
commercially available premixed wind-
shield washer solvent / antifreeze, de-
pending on ambient temperatures). Always use washer solvent/antifreeze
where temperatures may fall below
f r e e z i n g p o i n t . F a i l u r e t o d o s o c o u l d r e -
sult in damage to the washer sys-
tem/reservoir.
For more information see “Windshield
washer system and headlamp cleaning
system” (
page 338). 1
Washer fluid reservoir
Warning!
G
Washer solvent / antifreeze is highly flam-
mable. Do not spill washer
solvent / antifreeze on hot engine parts, be-
cause it may ignite and burn. You could be
seriously burned.
!Only use washer fluid which is suitable
for plastic lenses. Improper washer flu-
id can damage the plastic lenses of the
headlamps.

247
Operation
Winter driving
 Winter driving
Before the onset of winter, have your vehi-
cle winterized at an authorized
Mercedes-Benz Center. This service in-
cludes:

Check of anticorrosion and antifreeze
concentration.


Addition of cleaning concentrate to the
water of the windshield and headlamp
cleaning system. Add MB Concentrate
“S” to a premixed windshield washer
solvent / antifreeze which is formulated
for temperatures below freezing point
(page 338).


Battery test. Battery capacity drops
with decreasing ambient temperature.
A well charged battery helps to ensure
that the engine can be started, even at
low ambient temperatures.


Tire change. Mercedes-Benz recom-
mends M+S rated radial-ply tires with a
minimum tread depth of approximately 1/6 in (4 mm) on all four wheels for the
winter season.
Winter tires
Always use winter tires at temperatures
below 45°F (7°C) and whenever wintry
road conditions prevail. Use of winter tires
is the only way to achieve the maximum ef-
fectiveness of the ABS and ESP in winter
operation.
For safe handling, ensure that all mounted
winter tires are of the same make and have
the same tread design. Always observe the speed rating of the
winter tires installed on your vehicle. If the
maximum speed for which your tires are
rated is below the speed rating of your ve-
hicle, you must place a notice to this effect
where it will be seen by the driver. Such no-
tices are available at your tire dealer or any
authorized Mercedes-Benz Center.
Warning!
G
Winter tires with a tread depth under
1/6 in
(4 mm) must be replaced. They are no long-
er suitable for winter operation.

253
Operation
Vehicle care
Engine cleaning
Prior to cleaning the engine compartment
make sure to protect electrical compo-
nents and connectors from the intrusion of
water and cleaning agents.
Corrosion protection, such as MB Anticor-
rosion Wax, should be applied to the en-
gine compartment after every engine
cleaning. Before applying, all control link-
age bushings and joints should be lubricat-
ed. The poly-V-belt and all pulleys should
be protected from any wax.
Vehicle washing
Do not use hot water or wash your vehicle
in direct sunlight. Use only a mild car wash
detergent, such as Mercedes-Benz ap-
proved Car Shampoo.
Thoroughly spray the vehicle with a dif-
fused jet of water. Direct only a very weak
spray towards the ventilation intake. Use
plenty of water and rinse the sponge and
chamois frequently.
Rinse with clear water and thoroughly dry
with a chamois. Do not allow cleaning
agents to dry on the finish.
Due to the width of the vehicle, fold in ex-
terior rear view mirrors prior to running the
vehicle through an automatic car wash to
prevent damage to the mirrors.
In the winter, thoroughly remove all traces
of road salt as soon as possible.
When washing the underbody, do not for-
get to clean the inner sides of the wheels. Ornamental moldings
For regular cleaning and care of very dirty
chrome-plated parts, use a chrome clean-
er.
Headlamps, tail lamps, side markers,
turn signal lenses
Use a mild car wash detergent, such as
Mercedes-Benz approved Car Shampoo,
with plenty of water.
To prevent scratches, never apply strong
force and use only a soft, non-scratchy
cloth when cleaning the lenses. Do not at-
tempt to wipe dirty lenses with a dry cloth
or sponge.

278 Practical hintsWhat to do if …Display symbol
Display message
Possible cause
Possible solution
.
FRONT FOGLIGHT, L
CHECK LIGHT!
The left front fog lamp is malfunctioning.

Replace the bulb as soon as possible.
FRONT FOGLIGHT, R
CHECK LIGHT!
The right front fog lamp is malfunctioning.

Replace the bulb as soon as possible.
REAR FOGLIGHT
CHECK LIGHT!
The rear fog lamp is malfunctioning.

Replace the bulb as soon as possible.
HIGH BEAM, L
CHECK LIGHT!
The left high beam lamp is
malfunctioning.

Replace the bulb as soon as possible.
HIGH BEAM, R
CHECK LIGHT!
The right high beam lamp is
malfunctioning.

Replace the bulb as soon as possible.
LIGHT SENSOR
VISIT WORKSHOP!
The lamp sensor is malfunctioning. The
headlamps switch on automatically.

In the control system, set lamp
operation to manual (
page 125).

Switch on headlamps using the
exterior lamp switch.

Visit an authorized Mercedes-Benz
Center as soon as possible.
LICENSE PLATE LIGHT, L
CHECK LIGHT!
The left license plate lamp is
malfunctioning.

Replace the bulb as soon as possible.
LICENSE PLATE LIGHT, R
CHECK LIGHT!

The right license plate lamp is
malfunctioning.

Replace the bulb as soon as possible.

293
Practical hints
Replacing bulbs
 Replacing bulbs
Safe vehicle operation depends on proper
exterior lighting and signaling. It is there-
fore essential that all bulbs and lamp as-
semblies are in good working order at all
times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. See your autho-
rized Mercedes-Benz Center for headlamp
adjustment.
Bulbs Front lamps
iBackup bulbs will be brought into use
when the following lamps malfunction:

Rear fog lamp


Tail lamps


Standing lamps
Lamp
Type
1
Additional turn sig-
nal lamps
LED
2
Turn signal lamp
Halogen headlamp
Turn signal lamp
Bi-Xenon* headlamp
1156A
2357A
3
Halogen headlamps:
Low beam
Bi-Xenon* head-
lamps:
Low and high beam
H7 (55W)
D2S-35W
4
Halogen headlamps:
High beam
Bi-Xenon* head-
lamps:
High beam flasher
H7 (55 W)
H7 (55 W)
Parking and stand-
ing lamp
W 5 W
5
Fog lamp
HB4/9006
(55 W)

295
Practical hints
Replacing bulbs
Replacing bulbs for front lamps
Halogen headlamps
1 Bulb socket for turn signal lamp
2 Headlamp cover for high beam head-
lamp and for parking and standing
lamp
3 Headlamp cover for low beam head-
lamp 4
Low beam bulb
5 High beam bulb
6 Parking and standing lamp
Low and high beam bulb

Switch off the lights.

Open the hood (
page 236).

Turn headlamp cover 2 or 3 to the
left and remove.

Turn bulb holder with bulb to the left
and pull out.

Pull out the bulb from the base (do not
pull on glass tube).

Insert new bulb so that the base fits in
the bulb holder recess and is level.

Place the bulb holder with bulb on the
headlamp mounting and turn the bulb
holder to the right until it engages.

Replace headlamp cover 2 or 3 and
turn to the right until it engages.
Front turn signal lamp bulb

Switch off the lights.

Open the hood (
page 236).

Turn bulb socket 1 to the left and pull
out.

Push bulb into socket, turn to the left
and remove.

Insert new bulb in socket, push in and
turn to the right.

Reinsert bulb socket in lamp and turn
to the right.

296 Practical hintsReplacing bulbsParking and standing lamp bulb
Switch off the lights.

Open the hood (
page 236).

Turn headlamp cover2 to the left and
remove.

Pull out the bulb socket with the bulb.

Pull the bulb out of the bulb socket.

Insert a new bulb in the socket.

Reinstall the bulb socket.

Replace headlamp cover 2 and turn to
the right until it engages. Bi-Xenon* headlamps
1 Bulb socket for turn signal lamp
2 Cover for high beam flasher, parking
and standing lamp 3
Headlamp cover for Bi-Xenon head-
lamp
4 High beam bulb for high beam flasher
5 Bulb holder
6 Parking and standing lamp
High beam bulb for high beam flasher

Switch off the lights.

Open the hood (
page 236).

Turn headlamp cover 2 to the left and
remove.
iIf the inside of the headlamps is fogged
up, switch the lights on for a sufficient
amount of time.
Warning!
G
Do not remove the cover
3
for the
Bi-Xenon headlamp. Because of high voltage
in Bi-Xenon lamps, it is dangerous to replace
the bulb or repair the lamp and its compo-
nents. We recommend that you have such
work done by a qualified technician.

297
Practical hints
Replacing bulbs

Turn bulb holder
5 with bulb to the left
and pull out.

Pull out bulb from the base (do not pull
on glass tube).

Insert new bulb so that the base fits in
the bulb holder recess and is level.

Place the bulb holder with bulb on the
lamp mounting and turn bulb holder to
the right until it engages.

Install cover 2 and turn to the right
until it engages. Front turn signal lamp bulb

Switch off the lights.

Open the hood (
page 236).

Turn bulb socket
1 to the left and pull
out.

Push bulb into socket, turn to the left
and remove.

Insert new bulb in socket, push in and
turn to the right.

Reinsert bulb socket in lamp and turn
to the right. Parking and standing lamp bulb

Switch off the lights.

Open the hood (
page 236).

Turn headlamp cover
2 to the left and
remove.

Pull out the bulb socket 6 with the
bulb.

Pull the bulb out of the bulb socket.

Insert a new bulb in the socket.

Reinstall the bulb socket.

Install cover 2 and turn to the right
until it engages.
