2004 MERCEDES-BENZ C CLASS COUPE Owners Manual

97
Controls in detail
Memory function*
Storing exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gear
R.
For information on activating the parking
position, see see “Activating exterior rear
view mirror parking position”
(page 147). 1
Adjustment button
2 Passenger side exterior rear view mir-
ror
3 Memory button

Stop the vehicle.

Switch ignition on (if not already on).

Press button 2.
The passenger side exterior rear view
mirror is selected.

Adjust the exterior rear view mirror
with button 1 so that you see the rear
wheel and the curb.

Press memory button “M” 3 on the
door.

Within three seconds press bottom of
adjustment button 1 above the exteri-
or lamp switch.
The parking position is stored if the
mirror does not move.
iYou can store a parking position for the
passenger side exterior rear view mir-
ror for each SmartKey using the memo-
ry switch.
iIf the mirror does move, repeat the
above steps. After the setting is stored
you can move the mirror again.

98 Controls in detailLighting
LightingFor information on how to switch on the
headlamps and use the turn signals, see
the “Getting started” section (
page 48).
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel M
Off
U Automatic headlamp mode
C Parking lamps (also side marker
lamps, tail lamps, license plate
lamps, instrument panel lamps)
Canada only: When engine is run-
ning, the low beam is also switched
on.
B Low beam plus parking lamps or
high beam headlamps (combination
switch pushed forward).
ˆ Standing lamps, right (turn left one
stop)
‚ Standing lamps, left (turn left two
stops)
iIf you drive in countries where vehicles
drive on the other side of the road than
the country where the vehicle is regis-
tered, you must have the headlamps
modified for symmetrical low beams.
Relevant information can be obtained
at your authorized Mercedes-Benz Cen-
ter.

99
Controls in detail
Lighting
Manual headlamp mode
The low beam headlamps and parking
lamps can be switched on and off with the
exterior lamp switch.
Automatic headlamp mode
The parking lamps, low beam headlamps
and license plate lamps switch on and off
automatically depending on the brightness
of the ambient light.
Turn the exterior lamp switch to
U.
iIf you remove the SmartKey and open
the driver’s door while the parking
lamps or low beam headlamps are
switched on,

a warning sounds


$ appears in the multifunction
display


the message
TURN OFF LIGHTS!

appears in the multifunction display
iWith the daytime running lamp mode
activated and the engine running, the
low beam headlamps cannot be
switched off manually.
Warning!
G
If the exterior lamp switch is set to U,

the headlamps may switch off unexpect-
edly when the system senses bright am-
bient light, for example light from
oncoming traffic.


the headlamps will not be automatically
switched on under foggy conditions.
To minimize risk to you and to others, acti-
vate headlamps by turning exterior lamp
switch to
B
when driving or when traffic
and / or ambient lighting conditions require
you to do so.
In low ambient lighting conditions, only
switch from position
U
to
B
with the
vehicle at a standstill. Switching from U

to
B
will briefly switch off the head-
lamps. Doing so while driving in low ambient
lighting conditions may result in an acci-
dent.
The automatic headlamp feature is only an
aid to the driver. The driver is responsible for
the operation of the vehicle's lights at all
times.

100 Controls in detailLighting
Daytime running lamp mode
Turn exterior lamp switch to
positionM orU .
When the engine is running, the low beam
headlamps are automatically switched on.
In low ambient light conditions, the parking
lamps will also switch on.
Canada only
When you shift from a driving position to
position N or P, the low beam switches off
(with a three-minute delay).
For nighttime driving you should turn the
exterior lamp switch to position B to
permit activation of the high beam head-
lamps. USA only
The high beam headlamps can also be ac-
tivated when driving with the daytime run-
ning lamp mode activated and exterior
lamp switch in position
M.
To activate the daytime running lamp
mode, see “Setting daytime running lamp
mode (USA only)” (
page 125).
Locator lighting and night security illu-
mination
Locator lighting and night security illumi-
nation are described in the control system
section under “Setting locator lighting”
(
page 126) and “Exterior lamps delayed
shut off” (
page 127).
iWith the daytime running lamp mode
activated, the low beam headlamps will
not be switched off automatically.iThe front fog lamps and rear fog lamp
cannot be switched on manually with
exterior lamp switch in position U.
To activate the fog lamps, turn exterior
lamp switch to position B and pull
the exterior lamp switch to first or sec-
ond stop.
iFor exterior lamp switch, see
(page 98).

101
Controls in detail
Lighting
Switching on fog lamps
Switching on front fog lamps

Make sure the low beam headlamps
are switched on.

Pull out exterior lamp switch to first
stop.
The green indicator lamp‡ in the
lamp switch comes on. Switching on rear fog lamps

Make sure the low beam headlamps
are switched on.

Pull out exterior lamp switch to second
stop.
The yellow indicator lamp
† in the
lamp switch comes on.
iFog lamps will operate with the parking
lamps and/or the low beam headlamps
on. Fog lamps should only be used in
conjunction with low beam headlamps.
Consult your State or Province Motor
Vehicle Regulations regarding allow-
able lamp operation.
Warning!
G
In low ambient lighting or foggy conditions,
only switch from position
U
to
B

with the vehicle at a standstill. Switching
from
U
to
B
will briefly switch off
the headlamps. Doing so while driving in low
ambient lighting conditions may result in an
accident.

102 Controls in detailLightingCombination switch
The combination switch is located on the
left side of the steering column.1 High beam
2 High beam flasher
Switching on high beams
Turn exterior lamp switch to
position B or to U (
page 98).

Push the combination switch in
direction 1.
The high beam indicator B on the
instrument cluster is illuminated
(page 22). High beam flasher

Pull the combination switch briefly in
direction
2.
Hazard warning flasher
The hazard warning flasher can be activat-
ed with the ignition switched on or off. It is
activated automatically when an airbag is
deployed.
The switch is located on the center con-
sole.
1 Hazard warning flasher switch Switching on the hazard warning
flasher

Press the hazard warning flasher
switch.
All turn signals will flash.
Switching off the hazard warning
flasher

Press hazard warning flasher switch
again.iWith the hazard warning flasher acti-
vated and the combination switch set
for either left or right turn, only the re-
spective left or right turn signals will
operate when the SmartKey in the
starter switch is in position 1 or 2.iIf the hazard warning flasher was acti-
vated automatically press switch 1
twice.

103
Controls in detail
Lighting
Interior lighting
The controls are located in the overhead
control panel.
1 Rear interior lights
2 Right front reading lamp
3 Rocker switch for automatic control
system
4 Left front reading lamp Activating automatic control

Press the rocker switch
3 to center
position.
Interior lamps are switched on in dark-
ness, when you

unlock the vehicle


open a door


remove the SmartKey from starter
switch
The interior lamps are switched off follow-
ing a preset time (
page 128). Deactivating automatic control

Press the
=symbol on rocker
switch 3.
The interior lighting remains switched
off, even when you

unlock the vehicle


open a door


remove the SmartKey from the
starter switch
Manual control
Switching all front interior lights on and
off

Press the Wsymbol on rocker
switch 3.
The front interior lights come on.

Press rocker switch 3 to center
postion to activate the automatic
control.
iIf the door remains open, the interior
lamps switch off automatically after ap-
proximately five minutes, when the
SmartKey is removed or in the starter
switch position 0.
An interior lamp switched on manually
does not go out automatically.

104 Controls in detailLightingSwitching rear interior lights on and off
Press buttonV.
The lights in the rear passenger
compartment come on.

Press button Vagain.
The lights in the rear passenger
compartment go out. Switching right front reading lamp on
and off

Press right button
X.
The right reading lamp comes on.
Press right button X again.

The right reading lamp goes out.
Switching left front reading lamp on and
off

Press left button X.
The left reading lamp comes on.
Press left button X again.

The left reading lamp goes out.
iThe setting selected for the interior
lighting is used for the trunk lighting as
well.
If you leave the trunk lid open for an ex-
tended period of time, the trunk light-
ing will switch off automatically after
approximately ten minutes.
