2004 MAZDA MODEL MPV Quick Tips (in English)

82
3
1
5
4
\bEAT\b
Always check the Owner’s Manual for more operating information and safety features
\beats
\beats
Quick Tips 2004 Mazda MPV page 16 page 17
Manual seat controls1. Fore-aft adjustment Lift lever, slide seat
2. Head restraint To raise/lower: Pull up/push
stop-catch ( 8) and push down
3. Seatback angle To adjust: Lift and hold lever, lean
forward or backward, release lever
4. Seat tilt (Driver’s only)* Rotate front/rear dial to change
angle of seat front/rear
5. Lumbar adjustment
Power driver’s seat controls 6. Fore/aft adjustment Slide switch horizontally
Raise/lower seat cushion
Pull/push center vertically
Raise/lower front of seat
Pull/push front vertically
Raise/lower rear of seat
Pull/push rear vertically
7. Seatback angle Press front/rear of switch
WARNINGS: Do not adjust
seats while driving
Safety belts must always be
worn when vehicle is in motion
All air bags are supplemental and
do not replace safety belt usage
Always wear your safety belt
and properly secure children
12 and under in a rear seat
Use age appropriate child
restraints and safety seats, see
Owner’s Manual and state or
province laws
Never place rear-facing infant-
safety seat in front of any air
bag, an infant is in serious
danger of being injured or killed
If you must install a
forward-facing child-safety
seat in the front seating
position, move vehicle seat
as far back as possible Front passenger seat
side table
Pull up to locked position; push
down to verify table is secure
Expand table rearward
by pulling out the rear
Lowering side
table: Pull lever
(
2 ) under table
frontal section
and fold down
completely
WARNING: Do not use front
passenger seat side table
while vehicle is in motion
Shoulder belt
height
adjustment
To raise/lower
belt: Push button
( 1 ) and move belt
to desired position
WARNINGS: Make sure adjuster
locks in one of its positions
Removing and reinstalling
front seats for modification
purposes is dangerous and
may compromise the air
bag system
1
2
*Denotes optional equipment
82
5
67

\bEAT\b
Always check the Owner’s Manual for more operating information and safety features
\beats
Child-safety \beats
Quick Tips 2004 Mazda MPV page 18
page 19
*Denotes optional equipment
Child-safety seat
To install in rear outboard seats:
Use dual locking mode retractor
seat belts; see Owner’s Manual
for proper installation and child
seat tether and LATCH system
instructionsWARNING: Read all
information
and warnings
in Owner ’s Manual and
attached to seat before
using child-safety seat
Dual locking mode lap/
shoulder belt retractor
(Front passenger and rear
retractable safety belts only)
Emergency locking mode: Belt
locks only on hard braking/
cornering or impacts of about
5 mph or more Automatic locking mode:
Must be used when installing
child-safety seat
To activate: Pull webbing fully out
of retractor until click is heard;
belt will only tighten
To disengage: Unbuckle belt and
allow webbing to retract fullyWARNING: Make sure all
adjustable seats are properly
latched, because during a
sudden stop or collision the
seat or seatback could move,
causing injury
Third-row seat
Insert seat belts in retainers;
remove head restraints; pull strap
(
1 ), push seatback toward front of
vehicle until it locks with a click
Pull strap ( 2); lift seatback and
seat bottom up to vertical; gently
lower the seat into seat well
12

CLIMATE CONTROL\b
Always check the Owner’s Manual for more operating information and safety features
Climate
Controls
Climate
Controls
Quick Tips 2004 Mazda MPV page 20
page 21
Rear climate controls
Rear heater type*
Supplies only hot air via floor outlets
Rear cooler type*
Supplies only cold air via roof outlets
Front climate controls
1. Temperature controlRotate knob to blue for
cool, red for warm
Control positions for
maximum defrost
Fan to maximum, temperature
to maximum hot, air flow
selector knob to
2. Air Conditioning Press on/off
3. Fan control Rotate knob
4. Rear window defrost Press ON/OFF
Turns ON for approximately
15 minutes, after 15 minutes,
cycles ON or OFF unless
ignition is turned off
Tip: Indicator light stays
on during defroster
ON/OFF cycling
7. Rear air conditioningswitch*
0= fan off
REAR = enables fan speed
control from the rear
1 = low
2 = medium
3 = high
Tips: To help prevent windshield
fogging in humid weather,
select before starting engine
To prevent moisture buildup,
never drive with system off
Objects placed under the front
seats may interfere with air
flow to the rear5. Air flow selections = air to dash
= air to dash and floor
= air to floor
= air to floor and windshield
= air to windshield
6. Air intake selection switch
Press for cooling
with inside/outside air
When or is selected,
is automatically set so
that windshield fogging is
prevented, can not
be selected
/
0
0123 REAR
1 2
3
4A/C
15342
6
7
132
Rear heater/cooler type*1. Cool air from roof vent
2. Warm air from floor vent
3. Fan control Rotate knob
*Denotes optional equipment

RADIO/CA\b\bETTE/COMPACT DI\bC/MD
Always check the Owner’s Manual for more operating information and safety features
Audio
\bystems
Audio
\bystems
Quick Tips 2004 Mazda MPV page 22
page 23
3. SEEK/TRACK/APCRadio: Press to
automatically seek higher/
lower frequency
CD: Press to select
next/previous track
Tape: Press to
automatically advance tape to
beginning of next selection/
replay selection; to stop this
operation, press button again
4. FM1/2/AM Press to select between FM1/FM2/
AM station preset buttons ( 2)
5. SAT* If equipped with a separately sold
Sirius digital satellite radio, refer to
Sirius digital satellite radio manual
6. CD Press to play CD
7. MD*/Tape* Press to play Mini-disc Player/
cassette tape
Steering-wheel audio
controls, see Getting Started
Audio Systems
1. Power/Volume Press to turn on/off; rotate
to increase/decrease volume
2. Memory preset buttons To set: Tune to station, press and
hold until beep sound is heard
Press H (10) to set hour; then
press (CLOCK) button; Min
ADJ will be displayed next
with minutes flashing; press
M ( 10) to set minutes; then
press (CLOCK) to complete
9. CD eject button
10. Scan/Auto-Memory Press to briefly sample next
listenable selections
Radio: Press and hold until a
beep sound is heard; system auto-
matically scans and temporarily
stores six strong stations in each
band; pr ess again to cancel
11. Tuning/Audio Control Tune: Rotate counterclock-
wise/clockwise for lower
frequency/higher frequency
Audio control: Press to select
BASS/MID/TREBLE/FADE/
BALANCE/BEEP; rotate right/left
to adjust selected feature
8. Clock
To set: With ignition in ACC
or ON position, press (CLOCK)
and hold until beep sounds,
12 Hr/24 Hr will be displayed;
rotate Audio Control dial ( 11)to
switch between 12 Hr/24 Hr,
selection will flash; press (CLOCK)
again; Hr ADJ will be displayed
next with hour flashing
19. LOAD*To load multiple discs:
Press and hold LOAD ( 19)
until beep sound is heard; insert
CD when “In” is displayed
To eject disc: Press Eject ( 9)
To eject specific disc: Press and
hold Eject ( 9) until beep sound is
heard; within five seconds press
the desired tray number 1-6 ( 2)
20. Mini Disc slot*
21. DISP* Press: Changes display during
MD play
22. Mini Disc display*
23. Dolby
®Noise Reduction*
Reduces tape noise and hiss,
press to activate/deactivate
24. Cassette door*
25. Eject button*
26. Display Text dial: Use for MP3 CD
Player* or Sirius Radio*
Tips: Rotate (11) to display
complete song titles
Some song titles will not
display, see Owner
’s Manual
12. Fast forward Press to fast forward through a track
13. Reverse Press to reverse through a track
14. Program Random
†Press to enable/cancel random play
15. Repeat Press to replay current CD/
tape selection
16. Disc up
†
Press to skip forward to
beginning of next CD
17. Disc down
†
Press to skip back to
beginning of previous CD
18. CD slot*
SEEK
TRACK
APC
1 DISC 2 DISC 3 RPT 4 PROG RDM56
FM/AM SAT CD MD/TAPE
TEXT
CLOCKH SCAN
M AUTO-MDISP/ESN
DSP
. . . . . . . . . . . . .
14151713161211120222125
232425
4567891019
3
2
DISC INLOAD
TUNE PUSH AUDIO CONT
VOL PUSH POWER
18
26
*Denotes optional equipment†For use with cassette tape player,
MD player, or CD changer*

UNDER HOOD
Always check the Owner’s Manual for more operating information and safety features
Under Hood
Quick Tips 2004 Mazda MPV page 24page 25
1. Power steering fluidreservoir
Check with engine off; fill to
MAX mark
2. Engine coolant reservoir Level should be between F
and L lines when cold
WARNING: Never remove
coolant reservoir tank cap
while engine is running or
hot; you could get burned 3. Automatic transaxle
fluid dipstick
Check with engine running at
operating temperature;
fluid level should be within
v-notches on dipstick
4. Brake fluid reservoir Level should be kept at the
MAX mark on reservoir;
fill with DOT 3 brake fluid
5. Air filter
6. Fuse box (fuses and relays)
7. Battery
8. Hood support rod 9. Hood latch
Pull hood latch up,
open hood
10. Engine oil filler cap SAE 5W-20 recommended
for all temperatures
11. Engine oil dipstick Check with engine cold or
5 minutes after shutting
engine off; do not fill above
MAX line
12. Windshield washer reservoir
Fill with windshield
washer fluid
6
5
1298711
2
1
10
43
3.0-liter 24V V6
Under Hood

DRIVING TIP\b
Always check the Owner’s Manual for more operating information and safety features
DrivingTips
Quick Tips 2004 Mazda MPV page 26
page 27
Break-in period
First 600 miles: Avoid heavy
braking and acceleration; drive at
varying road and engine speeds
Anti-lock Brake System (ABS)*
When brake pedal is pressed, ABS
automatically reduces hydraulic
pressure to any wheel on the
verge of locking up
You may feel a slight pulsing of the
brake pedal and hear a clicking noise;
this tells you the ABS is functioning
properly; increase pressure on pedal
for maximum braking
Tips: Maintain constant
pressure on the brake pedal
Do not pump the brakes
Unique driving conditions
†Every 5,000 miles change oil/
filter, inspect coolant level,
lights, brake/clutch fluid, tire
pressure/wear, power steering
fluid, locks/hinges, washer fluid
and rotate tires
Maintenance notes:
Rotate tires every 7,500 miles
or sooner if needed
Replace cabin air filter once
every 2 years or 25,000 miles
†
Replace spark plugs every
100,000 miles (or 60,000 miles
if following the Unique driving
conditions
†)Traction Control System*
Automatically applies and releases
brakes to prevent excessive wheel
spin at all speeds, especially
when accelerating on
slippery surfaces
Tire economy and tips
Check pressure at least monthly
when tires are cold
Maintain correct front-end
alignment and tire balance; rotate
tires at 7,500-mile
intervals; see
Owner’s Manual for rotation chart
Tire pressure
Decal on the edge of the
driver’s door provides tire
pressure information
A.Change: Engine oil/
replace filter
Lubricate: All locks and hinges
B. Inspect: Disc brakes
C. Inspect: Drive belts, fuel lines
and hoses, cooling system,
brake lines, hoses and
connections, drum brakes,
steering operation and
linkages, front suspension
ball joints, driveshaft
dust boots
D. Replace: Air filter
E. Inspect: Exhaust system and
heat shields
F. Inspect: PCV valve
Change: Engine coolant
Tire chains*
†Tire chains can damage aluminum
wheels; use on steel wheels only
Tips: Use only SAE class
“S ”
chains, install only on front
tires; install as tightly as
possible and retighten
after driving 1/4 -1/2 miles;
chains may affect handling
Never exceed 30 mph with
tire chains
*Denotes optional equipment†See Owner’s Manual
NORMAL \bERVICE INTERVAL\b\0
7,500 miles
15,000 miles
22,500 miles 30,000 miles
37,500 miles
45,000 miles
52,500 miles 60,000 miles
67,500 miles
75,000 miles 82,500 miles
90,000 miles
A B C E
A
A B D
A
A B C F
A
A B E
A D
A B C
A

A B
A
